Before attaching the door panel to the door,
remove the outer screws from each of the
three mounting positions along the hinge side
of the door. Unscrew the three remaining
screws in the center of each mounting position
P A N E L
just enough that the slotted holes on the hinge
R E Q U I R E M E N T S
side door panel bracket will slide under the
heads. These positioning screws will support
the door panel during installation and adjust-
Door and drawer
ment. Refer to illustration 14 below.
panels must be a
5
minimum of / "
8
Install the door panel by engaging the tabbed
(16) thick.
bracket to the handle side of the door first and
The door panel
then sliding the hinge side mounting bracket
cannot exceed 40
onto the positioning screws on the hinge side
lbs (18 kg) and each
of the door. The panel can be adjusted
drawer panel must
up and down and side to side.
not exceed 12 lbs
(5 kg) for 27" (686)
Once the door panel is in place and adjusted
wide units. For 36"
correctly, attach the six remaining #10 x
(914) wide units,
screws to the hinge side mounting bracket and
the door panel
install the magnetic decorative caps as shown
weight limit is
in illustration 14.
53 lbs (24 kg) and
16 lbs (7 kg) for each
drawer panel.
16
I N S TA L L A T I O N I N S T R U C T I O N S
I N S TA L L A T I O N
As the reveal between cabinets and the
unit decreases, the potential exists for
severe finger pinching if fingers are placed
in the opening when the door is closing.
Illus. 14
D R A W E R P A N E L I N S TA L L AT I O N
Remove the mounting hardware provided and
set aside. As with the door panel, you should
work on the back side of each drawer panel
and protect the fronts of these panels.
Position the top edge of the template flush
with the top edge of each drawer. For the top
drawer, there is only one location for the lower
mounting bracket to be placed. However, the
bottom drawer allows a second option, invert-
ing the lower mounting bracket, depending on
the height and thickness or detail of the panel.
Refer to illustration 15 below.
1
/ " (6)
Secure the template in place with tape or a
4
small clamp and mark positions for the pilot
holes. Remove the template and drill the pilot
holes. Place the mounting brackets in the
1
/ "
2
proper location with the tabbed bracket on top
and 'L' bracket on the bottom of the panel.
Fasten brackets securely with the #8 x
screws provided. Refer to illustration 16 below.
Illustration 13 on page 15 also shows the
mounting hardware location for drawer panels.
Top Of Template
Flush With Top Of
Drawer Panel
Gap On Side
Edges Will Vary
According To
Design
Back Of
Drawer Panel
Illus. 15
1
/ "
2
Illus. 16
