I N T E G R AT E D
K I C K P L AT E / G R I L L E
Once your Integrated unit is secured, the
kickplate / grille can be installed. There is some
adjustment to the mounting assembly so that
this decorative piece can fit flush with the
surrounding area. Refer to illustration 11
P A N E L
below.
R E Q U I R E M E N T S
Turn power back on to the electrical outlet.
IMPORTANT NOTE: The unit must be allowed
Door and drawer
to have ventilation through the fins of the kick-
panels must be a
plate / grille. You may cover the solid area, but
5
minimum of / "
8
do not block the fins. The lower drawer panel
(16) thick.
may hang in front of the fins, but your base-
The door panel
board molding must not cover them.
cannot exceed 40
lbs (18 kg) and each
IMPORTANT NOTE: The kickplate / grille must
drawer panel must
be removed for servicing. The floor cannot
not exceed 12 lbs
interfere with removal.
(5 kg) for 27" (686)
wide units. For 36"
NOTE: The kickplate / grille can be painted
(914) wide units,
another color, if you choose. Follow these
the door panel
easy steps:
weight limit is
53 lbs (24 kg) and
16 lbs (7 kg) for each
drawer panel.
14
I N S TA L L A T I O N I N S T R U C T I O N S
I N S T A L L A T I O N
Rough up the surface to be painted with
fine grit sandpaper.
Wipe with alcohol to ensure that the surface
is clean and dry.
Use an appliance or industrial grade, oil
base, high gloss enamel paint.
PA N E L I N S TA L L A T I O N
The integrated design uses custom wood or
other decorative panels and handles provided
by the customer. Stainless steel panels
are available as sales accessories. Contact
your Sub-Zero dealer or check the accessories
section of our website, subzero.com.
Before beginning installation, check the panels
for the proper fit and finish desired.
Door and drawer panels must be a minimum
5
of / " (16) thick. The door panel cannot exceed
8
40 lbs (18 kg) and each drawer panel must not
exceed 12 lbs (5 kg) for 27" (686) wide units.
For 36" (914) wide units, the door panel weight
limit is 53 lbs (24 kg) and 16 lbs (7 kg) for each
drawer panel.
D-style pulls are recommended for handle
hardware. Handles should be located on the
opposite side from the hinge, centered on the
cabinet door, and on the top center area of the
drawer panel. Screw heads may have to be
countersunk to ensure that the hardware does
not interfere with the panels fitting flush with
the unit's door or drawers.
It is recommended that the door panel of the
tall unit be installed first and then the upper
and lower drawer panels.
Illus. 11
Back Of Door Panel
Gap On Side
Edges Will Vary
According To
Design
Bottom Of Template
Flush With Bottom
Of Door Panel
Illus. 12
