INSTALLATION GUIDE
PXIe-1090 Rack Mount Kit
This guide explains how to install the PXIe-1090 chassis Rack Mount Kit.
The kit allows easy installation of the PXIe-1090 in EIA 310-compliant racks of 480 mm (19 in.)
standard width.
Caution
surrounding equipment or blockages to ensure proper cooling for the chassis power
supply and modules plugged into the chassis. Refer to the chassis user manual for
cooling clearance requirements. Failure to provide these clearances may result in
thermal-related failures in the chassis or modules.
Specifications
Max loading
Supported rack screws
Form factor
Installation Instructions
To mount the chassis in an instrument rack, complete the following steps.
1.
Remove the bottom feet from the PXIe-1090 chassis by unscrewing them with a #2 Phillips
driver. Retain the feet and screws for future use, if needed. Reinstallation torque is
0.76 N m (6.7 lb in.).
2.
Install the PXIe-1090 chassis on the shelf as shown in Figure 1, using four #6-32 x 0.500 in.
flathead screws provided. Tighten the screws to 0.76 N m (6.7 lb in.) of torque with a
#2 Phillips driver.
Caution
PXIe-1090 without the shelf present. Damage to the chassis may occur.
You must maintain adequate clearance between the chassis and
Do not use longer screws or install the provided screws into the
15 kg
10-32, 12-24, and M6
EIA 310, 480 mm (19 in.) width, 2U height
Advertisement
Related Manuals for National Instruments PXIe-1090
Summary of Contents for National Instruments PXIe-1090
- Page 1 0.76 N m (6.7 lb in.). Install the PXIe-1090 chassis on the shelf as shown in Figure 1, using four #6-32 x 0.500 in. flathead screws provided. Tighten the screws to 0.76 N m (6.7 lb in.) of torque with a #2 Phillips driver.
- Page 2 You can choose between four sets of chassis mounting holes, depending on Note desired chassis recess. The default mounting holes place the chassis flush with the front panel, and each additional hole pattern adds a 25.4 mm (1 in.) chassis recess. 2 | ni.com | PXIe-1090 Rack Mount Kit Installation Guide...
- Page 3 Populating the front panel when installing the rack mount kit on the Note external/front rails of a rack allows for a nearly flush fit of the PXIe-1090 to the front of the rack with minimal gaps. Depopulating the front panel when installing the rack mount kit on internal/middle rails of a rack may be beneficial for system level airflow and cable routing.
-
Page 4: Chassis Orientation
Chassis Orientation You can rotate the PXIe-1090 chassis 180º when installing it on the rack mount kit to accommodate system airflow or cable routing needs. Figure 3. PXIe-1090 Chassis Rotated on Rack Mount Shelf PXIe-1090 Chassis Rack Mount Shelf #6-32 x 0.500 in. Flathead Screws (x4) - Page 5 Airflow, Baffle, and Thermal Considerations Consider the location of the PXIe-1090 chassis inlets and exhausts inside the completed system when determining where to install the rack mount kit. Neighboring equipment and recirculation can affect the ambient temperature at the PXIe-1090 chassis inlets.
-
Page 6: Grounding Considerations
Do not exceed the rack mount shelf maximum loading. Caution Figure 6. PXIe-1090 Rack Mount Shelf Side Holes and Slots M4 x 7 Tapped Holes for Customer-Provided Slots for Cable Strain Relief Accessories 6 | ni.com | PXIe-1090 Rack Mount Kit Installation Guide... - Page 7 NI products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your media, or the National Instruments Patent Notice at ni.com/patents. You can find information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer to the Export Compliance Information at ni.com/legal/ export-compliance for the NI global trade compliance policy and how to obtain relevant HTS codes, ECCNs, and other import/export data.
