USER MANUAL
NI 9901
Desktop Mounting Kit
Use the NI 9901 desktop mounting kit to mount a CompactRIO or CompactDAQ chassis on a
desktop.
What You Need to Get Started
You will need the following tools to install the NI 9901.
•
#1 Phillips screwdriver
•
#2 Phillips screwdriver
•
T-10 Torx screwdriver (for use with cRIO-905x controllers)
Kit Contents
Verify that the following items are included in the NI 9901 kit.
1. NI 9901 end bracket (x2)
2. NI 9901 adapter bracket (x2)
3. M3 x 14 screw (x2)
Note
The kit contains two sizes of adapter brackets. Determine which adapter
bracket length is appropriate for your chassis before installation.
1
2
3
4. M3 x 20 screw (x2)
5. M3 x 35 screw (x2)
4
5
