INSTALLATION GUIDE
VXI-1501 R
Installing the Flanges and Filler Panels
1 Recess Flange
2 Screw, M3x8L (Two Places Top and Bottom
on Each Side)
3 Rack Mount Flange (Purchased Separately)
™
™
National Instruments
, NI
, and ni.com
trademarks or trade names of their respective companies.
322832B-01
R
ECESS
ACK
This kit includes recess flanges and top and bottom filler panels for
mounting the VXI-1501 in a rack, with the front of the VXI-1501 recessed
from the front of the rack. The rack mount flanges are included with the
National Instruments Basic Rack Mount Kit or can be purchased separately
as the Flange-Only Kit.
1
™
are trademarks of National Instruments Corporation. Product and company names mentioned herein are
Copyright © 2001 National Instruments Corp. All rights reserved.
M
K
OUNT
IT
6
2
4 Screw (Supplied with Rack Mount Flanges,
Three Places Each Side)
5 Screw, M4x10L (Three Places Each Side)
6 Filler Panel
5
4
3
July 2001
Advertisement
Table of Contents
Related Manuals for National Instruments VXI-1501
Summary of Contents for National Instruments VXI-1501
- Page 1 OUNT This kit includes recess flanges and top and bottom filler panels for mounting the VXI-1501 in a rack, with the front of the VXI-1501 recessed from the front of the rack. The rack mount flanges are included with the National Instruments Basic Rack Mount Kit or can be purchased separately as the Flange-Only Kit.
- Page 2 Do not rack mount the mainframe using only the rack mount flanges. The Caution mainframe should be supported by either rack support rails (such as those included with the National Instruments Basic Rack Mount Kit) or a cabinet shelf.
