INSTALLATION INSTRUCTIONS
Rack Mounting Kit with DIN Rail
for CompactRIO and CompactDAQ
Français
The National Instruments CompactRIO rack mounting kit with DIN rail is an accessory you can use to
mount a CompactRIO chassis and other DIN rail-mountable equipment on a standard 19-inch rack.
Note
You need a #2 Phillips screwdriver to install the rack mounting kit.
The NI CompactRIO rack mounting kit with DIN rail contains the following components:
1
Bracket with DIN Rail
Figure 1. Components of the NI CompactRIO Rack Mounting Kit with DIN Rail
Deutsch
ni.com/manuals
2
Top and Bottom Covers (2)
1
2
3
Front Cover
3
Advertisement
Related Manuals for National Instruments CompactRIO
Summary of Contents for National Instruments CompactRIO
- Page 1 Français Deutsch ni.com/manuals The National Instruments CompactRIO rack mounting kit with DIN rail is an accessory you can use to mount a CompactRIO chassis and other DIN rail-mountable equipment on a standard 19-inch rack. Note You need a #2 Phillips screwdriver to install the rack mounting kit.
-
Page 2: Installing The Rack Mounting Kit
DIN rail clip. The following figure shows how to install the DIN rail clip that fits the NI cRIO-908x chassis. Figure 2. Installing a DIN Rail Clip on the NI cRIO-908x Rack Mounting Kit with DIN Rail for CompactRIO and CompactDAQ ni.com... - Page 3 Connect the chassis ground wire to the bracket grounding screw. Refer to Figure 5 for the location of the bracket grounding screw. Install the top and bottom covers as shown in Figure 4. Figure 4. Installing the Top and Bottom Covers © National Instruments Corporation Rack Mounting Kit with DIN Rail for CompactRIO and CompactDAQ...
- Page 4 Rack Mounting Bracket Handles (2) Cable Entry/Exit Openings Bottom Cover Grounding Screw Mounts for Cable Ties (20) Figure 5. NI cRIO-908x Mounted in Bracket, Front View Rack Mounting Kit with DIN Rail for CompactRIO and CompactDAQ ni.com...
- Page 5 Figure 7. Installing the Front Cover ⋅ ⋅ Tighten the four captive screws on the front cover. Do not tighten past 0.5 N m (4.9 lb in.) of torque. © National Instruments Corporation Rack Mounting Kit with DIN Rail for CompactRIO and CompactDAQ...
- Page 6 For patents covering National Instruments products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your media, or the National Instruments Patents Notice at ni.com/ patents. You can find information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product.
