Summary of Contents for ICT Distribution 3 Series
- Page 1 Distribution Series 3 Dual Bus (Breaker) Instruction Manual 855-314-002...
- Page 2 • Carefully observe wiring polarity when making input and WARNING output connections. • Securely tighten all connections. • Do not attempt to service any internal parts. Refer all product service to an authorized ICT Ltd. service facility. 855-314-002_Rev2.0_Instruction Manual...
- Page 3 • Consult with manufacturers of surge suppression devices to select appropriately rated protection device(s) and proper installation methods. • ICT’s product warranty does not cover damage caused by power surges and electrostatic discharge events including lightning. 855-314-002_Rev2.0_Instruction Manual...
- Page 4 Distribution Series 3 Dual Bus NOTE: Due to the breaker-detection circuitry internal to the unit, it may be possible to measure a voltage on the terminal(s) with no load connected, even if that terminal’s breaker is open circuit. This is normal operation.
- Page 5 Innovative Circuit Technology Ltd. Disclaimer ICT shall not be held liable for any damage or injury involving this product if it has been subjected to misuse and exposure to environmental conditions not conforming to the product’s limits of operation, improper installation, or maintenance.
- Page 6 Distribution Series 3 Dual Bus ICT LIMITED WARRANTY The warranty period on ICT products is two (2) years from date of purchase from an authorized ICT reseller or OEM with valid proof of purchase, or from date of shipment from the ICT manufacturing facility. The warranty period for a repaired product or part is ninety (90) days or the remainder of the unexpired term of the new product warranty period, whichever is greater.
- Page 7 Distribution Series 3 Dual Bus In no event shall ICT be liable for any special, indirect, or consequential damages such as, but not limited to, loss of use, business or goodwill, loss of revenue, or loss of profits, which may result, either directly or indirectly, from defects in products provided by ICT.
-
Page 8: Table Of Contents
Distribution Series 3 Dual Bus TABLE OF CONTENTS 1.0 INTRODUCTION ................... 1 1.1 Common Features ................2 1.2 Intelligent Models ................2 2.0 INSTALLATION ..................2 2.1 Quick Install Guide ................3 2.2 Unpacking and Inspection ..............3 2.3 Package Contents ................4 2.3.1 Tools and Parts Needed ............. - Page 9 Distribution Series 3 Dual Bus 6.0 FAQs ....................41 6.1 How do I access the web-based configuration utility? ....41 6.2 How do I reset the password? ............42 6.3 How do I receive e-mails from the unit? .......... 42 6.4 How do I configure a router? ............
-
Page 10: Introduction
Distribution Series 3 Dual Bus 1.0 INTRODUCTION The ICT Distribution Series 3 dual-bus DC distribution panel provides two 100 amps (peak) bus inputs; with six independently controlled and monitored output channels per bus in a compact 1RU chassis for 19-inch rack mounting. -
Page 11: Common Features
Distribution Series 3 Dual Bus 1.1 Common Features • 200 amps peak system current rating / 100 amps per bus • Six independently controlled and monitored output channels per • Independent form-C alarm contacts for each bus • High-quality, reliable hydraulic/magnetic breakers support 12-, 24- and 48-volt DC applications •... -
Page 12: Quick Install Guide
Distribution Series 3 Dual Bus • Channel output breakers must not exceed 30 amps max rating for 12- and 24-volt DC systems, 20 amps max rating for 48-volt DC systems. • Install unit in a restricted access location (such as an equipment rack) to limit unintentional contact with terminals and wiring. -
Page 13: Package Contents
2.3.2 Other Requirements To complete the installation, appropriate circuit breakers (available from ICT) are needed for each output channel that the user plans to use. Circuit breakers must be ordered separately from the following list for use on the ICT200DB-12IRC unit. -
Page 14: Ground Connection
Distribution Series 3 Dual Bus 2.5 Ground Connection All DC inputs and outputs of ICT’s DC distribution panels are isolated from chassis ground (floating). DC input and output returns can remain isolated from ground (DC-I) or can be grounded (DC-C), as per site grounding requirements and/or NOTICE local or national electrical codes. -
Page 15: Load Connections
Always observe the following: • DC-AC Inverters should not be connected to the outputs of any ICT Distribution Series panel. DC-AC Inverters create significant inrush current and may damage the circuitry or interfere with the operation of power distribution panels that they are connected to. -
Page 16: Installation Of Breakers
Distribution Series 3 Dual Bus Each bus provides six remotely controlled and monitored outputs, with front panel overcurrent protection provided by hydraulic-magnetic circuit breakers (see Section 2.8 for the installation instructions for the breakers). The maximum current rating for each bus is 100 amps. Each output can accept maximum current based on the bus voltage (see Table 4). -
Page 17: System Wiring Final Verification
Distribution Series 3 Dual Bus If the breakers are not fully installed or are not installed "square" they may cause intermittent power loss or unexpected behavior for the load devices. CAUTION When installing load breakers, apply even pressure to the top and bottom of the breaker to ensure proper engagement of the breaker with the rear contacts (see Figure 3). -
Page 18: Input Connections
Distribution Series 3 Dual Bus 2. Check that all connections to the power distribution panel are correct and properly tightened. 2.10 Input Connections 1. De-energize the DC source. 2. Connect the main Bus A RTN line to the power supply return using wire and ring connectors rated for up to 100 amps continuous current. -
Page 19: Operation: Front Display Panel
Distribution Series 3 Dual Bus 3.0 OPERATION: FRONT DISPLAY PANEL Energize each bus by closing the main external breaker or disconnect device on the bus input lines. Check that the distribution panel front graphic display powers up. The Distribution Series 3 will start up and operate at the factory default settings when DC power is connected, generally requiring no further set up or adjustment for basic operation. -
Page 20: Main Screen
Distribution Series 3 Dual Bus MAIN SCREEN ICT Dual Bus Panel PRESS "A" ICT Dual Bus Panel BUS : " A" BUS : " B" VOLTAGE: 13.7V VOLTAGE: −13.7V CURRENT: 0.0A PRESS "B" CURRENT: 0.0A PRESS "A" PRESS "B" Network Connected Network Connected HOLD "A"... -
Page 21: Network Screen
Distribution Series 3 Dual Bus 3.2.2 Network Screen The Network screen will show the network status, connection type, IP address assigned to the unit, and the MAC address of the unit. Other information will be shown depending on the operating state of the unit: •... -
Page 22: Site Alarm Input Screen (1 To 5)
Distribution Series 3 Dual Bus 3.2.4 Site Alarm Input Screen (1 to 5) The Site Alarm Input screen will show the status of the external site monitoring sensors. The screen will show the alarm input number (1 to 5), name of the alarm (if configured, default is blank), and the alarm status. The alarm screens are displayed only if the alarm input has been enabled using the Alarm Setup section of the GUI (see Section 4.9). -
Page 23: Operation: Graphical User Interface
Distribution Series 3 Dual Bus Table 5. Distribution Unit Alarms Channel Send Alarm Trigger Condition Alarm Alarm Output E-mail Contact Breaker opens or is Breaker Off removed Bus voltage drops below undervoltage No change Undervoltage threshold Bus voltage rises above the overvoltage No change Overvoltage... -
Page 24: Status & Control
The default username is "admin", and no password is required as the factory default. To log out of the ICT Distribution Series 3 GUI, click on the Logout link on the top right of the browser window. The system will also automatically log off the user after 20 minutes of inactivity. - Page 25 Distribution Series 3 Dual Bus This tab provides the operating status of the unit. Alarm Inputs Shows the status of any of the five Input Alarms that have been enabled (see Section 4.9). Will show grey if inactive or red if an alarm is active. An alarm input indicator box will not be displayed if the alarm is not enabled.
-
Page 26: Alarm Status
Distribution Series 3 Dual Bus a timed sequence if the "power-on sequencing" has been enabled on the Device Setup page (see Section 4.4). Disable Bus Buttons: Use these to open the six channel relays on that bus, disabling power to external loads on the bus. Output Status Each output on the unit will be displayed with name and status. -
Page 27: Device Setup
Distribution Series 3 Dual Bus 4.4 Device Setup Use this tab to configure the unit’s name, set the date and time and enable the watchdog timer and data logging features. Device Info Site Name: Enter a descriptive name for the system. This name will be used in all e-mail messages. - Page 28 Distribution Series 3 Dual Bus Power-On Sequencing/Cycling Sequence/Cycle Delay: Set the time in seconds (0–60 seconds) that will be used as the delay between energizing outputs. Will affect all outputs. Set to 0 to disable. Use this feature to allow a delay between energizing loads to reduce inrush current.
- Page 29 Distribution Series 3 Dual Bus Network Watchdog Watchdog Timeout: Set a time in minutes (1–80 minutes) for the unit to wait with no ping response from IP address before initiating a reset. Ensure this time is greater than the normal start-up time for the network hardware to prevent nuisance power cycle events at system start up.
-
Page 30: Bus Setup
Distribution Series 3 Dual Bus breaker status, and alarm inputs, recorded once per minute for the last 30 days. The default is Disabled. Updating the firmware will delete the current log file. Download the log before updating the firmware. NOTICE NOTE: Save Settings to enable any changes made. - Page 31 Distribution Series 3 Dual Bus Under-Voltage Recovery: Set the voltage that will clear the alarm on this bus. Bus voltage rising above this level will clear the alarm. The default setting is 12 VDC. Activate Alarm Form C Contact: Set the check box for the Alarm relay to trigger for an undervoltage condition.
-
Page 32: Output Setup
Distribution Series 3 Dual Bus Send E-mail: Set the check box to have a Bus Over-Current alarm e- mail sent to the e-mail addresses set up on the "E-mail Setup" page (see Section 4.8). The default setting is Disabled. NOTE: Save Settings to enable any changes made. 4.6 Output Setup Use this tab to configure the settings for each output channel on Bus A and Bus B. - Page 33 Distribution Series 3 Dual Bus Ignore Circuit Breaker Status: Select to disable alarms from this output. Will prevent false alarms on an unused channel. The default setting is Disabled. Enable Power Cycling: Select this box to enable output power cycling for the selected output.
- Page 34 Distribution Series 3 Dual Bus be at least 0.5 V above the Load-Shedding Threshold voltage. The default setting is 12.00 VDC. NOTE: Outputs that have been disabled on the Status & Control page will reconnect automatically if "Load-Shedding Auto Recovery" is enabled for that output.
-
Page 35: Network Setup
Distribution Series 3 Dual Bus Activate Alarm Form C Contact: Set the check box for the Alarm relay to trigger for an undercurrent condition. The default setting is Disabled. Send E-mail: Set the check box to have a Bus Under-Current alarm e- mail sent to the e-mail addresses set up on the "E-mail Setup"... - Page 36 Distribution Series 3 Dual Bus To manually assign a static IP address to the unit uncheck this box, then set the following parameters. IP Address: Set a unique IP address for the unit. Subnet Mask: Set the mask for the subnet the unit is located on. Gateway: Set the IP address of the default router (Gateway) used for connecting attached devices to different networks.
- Page 37 The information available from the SNMP agent is described in a MIB (Management Information Base) file, which can be downloaded from the ICT website: https://ict-power.com/resources/tools-utilities/. The MIB file can also be downloaded from within the GUI. There are links in the SNMP 855-314-002_Rev2.0_Instruction Manual...
- Page 38 • Full Device Control: Allows SNMP client to set all unit settings through SNMP. This setting requires a different MIB file which can be downloaded from the ICT Website: https://www.ict- power.com/resources/tools-utilities/. SNMP Contact Information: Set contact information, such as an operator name and phone number for the unit, which can be read via SNMP queries (this information is optional).
-
Page 39: E-Mail Setup
Distribution Series 3 Dual Bus Authentication Password: If an authentication protocol is selected, set the authentication password. Privacy Protocol: Set the SNMPv3 privacy protocol (None, or AES). Privacy Password: If a privacy protocol is selected, set the privacy password. SNMP Traps: Trap Version: Set the SNMP version (v1 or v3) for SNMP traps sent from the system. - Page 40 Distribution Series 3 Dual Bus E-mail SMTP Server: Set the name or the IP address of the SMTP server used for sending outgoing e-mail (e.g., “smtp.gmail.com”). SMTP Port: Set the port used by the SMTP server. The default setting is 25. SMTP Server requires SSL: Select this check box if the SMTP server requires an encrypted SSL connection.
-
Page 41: Alarm Setup
Distribution Series 3 Dual Bus Minimum E-mail Interval: Set a minimum interval in minutes (0–60 minutes) between e-mail notifications. This time interval is used to prevent an un-intended flood of e-mail alarm notifications that could occur when an alarm limit is incorrectly configured, for example. The default setting is 0. -
Page 42: User Setup
Distribution Series 3 Dual Bus Send E-mail: Select the check box to have an e-mail sent to the e-mail addresses set up on the E-mail Setup page when a breaker opens on any of the output channels (see Section 4.8). The default is Disabled. Alarm Input # Alarm Name: Set a meaningful name to suit the installation (these will be used in e-mail and front panel alarm messages). - Page 43 Distribution Series 3 Dual Bus Record the new password(s) for future access. If the Administrator password is lost the unit must be reset to return the password to the blank default setting, causing loss of all other NOTICE user settings (see Section 3.3). User Accounts Shows the User Name and Access Level.
- Page 44 Distribution Series 3 Dual Bus • Control: User has read-only access to the unit, but can enable or disable the outputs, and change some of the basic settings. • View-Only: User can only view status, cannot change any settings. Password: Enter the password for the chosen user. Password (confirm): Re-enter the new password to confirm the entry.
-
Page 45: Maintenance
Distribution Series 3 Dual Bus Confirm Changes User Name: Enter admin username to confirm these changes are valid. Password: Enter the password for the admin name to confirm the changes are valid. 4.11 Maintenance Use this tab to reset the unit (soft reset), restore the factory default settings, or send a test e-mail to verify e-mail functionality. - Page 46 Distribution Series 3 Dual Bus • Restoring the unit to Factory Default settings may cause loss of network communications due to loss of custom changes to any network settings. • Restoring the unit to Factory Default settings will not affect the NOTICE power output.
- Page 47 Distribution Series 3 Dual Bus Firmware Update Download the latest Distribution Series 3 firmware file from the ICT website (ict-power.com/resources/product-firmware/) to a local computer. Select the "Update Firmware" button to access the Firmware Update page shown below. Use this page to update the firmware on the unit by clicking the "Choose File"...
-
Page 48: Help
4.12 Help This tab has helpful links to ICT’s website. Instruction Manual Click the "HERE" button to download the ICT Distribution Series 3 Dual Bus Instruction Manual from ICT website. SNMP Click the "HERE" button to download the SNMP MIB file. -
Page 49: Status & Control
Distribution Series 3 Dual Bus the mobile web version or use a Virtual Private Network (VPN) connection. 2. Log into the unit’s built-in server when prompted with the username and password. The default username is "admin", and no password is required as the factory default. 5.2 Status &... -
Page 50: Faqs
Distribution Series 3 Dual Bus alarm is active. An alarm input indicator box will not be displayed if the alarm is not enabled. Bus Status Shows the voltage and total amps being used by each bus. Output Status Output #x cells: Use these to toggle the internal relay for each channel, enabling or disabling the power to the load on that output. -
Page 51: How Do I Reset The Password
User Name" and "SMTP Password" fields are correctly entered. 6.4 How do I configure a router? To set up the ICT Dual Bus Distribution Panel Series 3 with remote internet access when it is located behind a router, Port Forwarding will need to be enabled on the router to forward incoming HTTP or HTTPS traffic to the local IP address of the unit. -
Page 52: How Do I Upgrade The Firmware
NOTICE 6.7 How can I access the MIB file? The MIB file can be downloaded from the ICT website: https://ict- power.com/resources/tools-utilities/. It can also be downloaded from within the GUI. There are links in the SNMP section of the Network Setup tab (see Section 4.7 and on the Help tab (see Section 4.12). -
Page 53: How Do I Log Out Of The Gui
Distribution Series 3 Dual Bus 6.11 How do I log out of the GUI? To log out of the ICT Distribution Series 3 GUI, click on the Logout link on the top right of the browser window. The system will also automatically log off the user after 20 minutes of inactivity. -
Page 54: Regulatory Specification
Distribution Series 3 Dual Bus 7.3 Regulatory Specification Table 8. Regulatory Compliance Category Certification Safety, EMC-Emissions, ICES-003, FCC CFR47 Part 15/B , EMC-Immunity, RoHS EN61000-6-3:2007/A1:2011/AC and EN 61000-6-1:2007 7.4 Mechanical Specifications Table 9. Dimension and Weight Physical Property Value Dimension - L x W x H 9.0 x 19.0 x 1.7 in. -
Page 55: Glossary
Distribution Series 3 Dual Bus 8.0 GLOSSARY • One Rack Unit; 1.75-inch (44.45 mm) of rack height • A, amps Amperes • Advanced Encryption Standard • ANSI American National Standards Institute • American Wire Gauge • Comma-Separated Values • DHCP Dynamic Host Configuration Protocol •... - Page 56 Find the latest version of this manual here: https://ict-power.com/product/distribution-series-3-dual-bus/ INNOVATIVE CIRCUIT TECHNOLOGY LTD. 26921 Gloucester Way Langley, British Columbia, Canada V4W 3Y3 T +1 604.856.6303 (International) T +1 877.930.0717 (North America Toll-free) www.ict-power.com...
