ICT Energy Manager Series Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Energy Manager Series
Instruction Manual
855-371-000
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Energy Manager Series and is the answer not in the manual?

Questions and answers

Related Manuals for ICT Energy Manager Series

Summary of Contents for ICT Energy Manager Series

  • Page 1 Energy Manager Series Instruction Manual 855-371-000...
  • Page 2 • Carefully observe wiring polarity when making input and WARNING output connections. • Securely tighten all connections. • Do not attempt to service any internal parts. Refer all product service to an authorized ICT Ltd. service facility. 855-371-000_Rev1.0_Instruction Manual...
  • Page 3 • Consult with manufacturers of surge suppression devices to select appropriately rated protection device(s) and proper installation methods. • ICT’s product warranty does not cover damage caused by power surges and electrostatic discharge events including lightning. 855-371-000_Rev1.0_Instruction Manual...
  • Page 4 Energy Manager Series NOTE: Due to the breaker-detection circuitry internal to the unit, it may be possible to measure a voltage on the terminal(s) with no load connected, even if that terminal’s breaker is open circuit. This is normal operation. The breaker-detection circuitry is a high- impedance circuit, and while a voltage may be present on the output terminal, it is a signal voltage and does not support loading.
  • Page 5 Innovative Circuit Technology Ltd. Disclaimer ICT shall not be held liable for any damage or injury involving this product if it has been subjected to misuse and exposure to environmental conditions not conforming to the product’s limits of operation, improper installation, or maintenance.
  • Page 6 Energy Manager Series ICT LIMITED WARRANTY The warranty period on ICT products is two (2) years from date of purchase from an authorized ICT reseller or OEM with valid proof of purchase, or from date of shipment from the ICT manufacturing facility. The warranty period for a repaired product or part is ninety (90) days or the remainder of the unexpired term of the new product warranty period, whichever is greater.
  • Page 7 Energy Manager Series In no event shall ICT be liable for any special, indirect, or consequential damages such as, but not limited to, loss of use, business or goodwill, loss of revenue, or loss of profits, which may result, either directly or indirectly, from defects in products provided by ICT.

  • Page 8: Table Of Contents

    Energy Manager Series TABLE OF CONTENTS 1.0 INTRODUCTION ................... 1 Common Features............... 2 Intelligent Model ................2 2.0 INSTALLATION ..................2 Unpacking and Inspection ............3 Package Contents ............... 3 2.2.1 Tools and Parts Needed ..........4 2.2.2 Other Requirements ............4 2.2.3 Optional Accessories .............
  • Page 9 Figure 6. Incorrect Breaker Orientation ............9 Figure 7. Removing Load Wire/Ferrule from Breaker ........ 11 Figure 8. Dimensions ................41 Figure 9. Dimensions of Unit with ICT-CMA installed ....... 42 LIST OF TABLES Table 1. Breakers ..................4 Table 2. Minimum Size Equipment Grounding Conductors for Grounding Raceway and Equipment ...............

  • Page 10: Introduction

    Energy Manager Series 1.0 INTRODUCTION The ICT300DB-12IRC is a dual-feed DC power distribution unit for negative 48-volt DC applications that provides two 150 amps (continuous) bus inputs; with six independently controlled and monitored output channels each rated at 50 amps (maximum) per bus in a 2RU chassis for 19-inch rack mounting.

  • Page 11: Common Features

    Energy Manager Series 1.1 Common Features • 300 amps continuous system current rating / 150 amps per bus • Six independently controlled and monitored output channels per bus rated at 50 amps maximum each • Independent form-C alarm contacts for each bus •...

  • Page 12: Unpacking And Inspection

    Energy Manager Series • Each output load must not exceed 50 amps maximum. • Install unit in a restricted access location (such as an equipment rack) to limit unintentional contact with terminals and wiring. • Keep sources of moisture away from unit.

  • Page 13: Tools And Parts Needed

    Ferrule Terminals The ICT Miniature Circuit Breakers can accommodate up to 6 AWG wires. It is recommended to terminate the output cables with ferrule terminals to ensure ease of cable insertion as well as proper electrical contact.

  • Page 14: Quick Install Guide

    Energize the loads. 2.4 Cable Management Assembly Installation (optional) The Cable Management Assembly (ICT-CMA) can be mounted in the front or rear of the unit. Refer to the ICT-CMA user manual for more information. ICT-CMA for Output Cables ICT-CMA for Input Cables Figure 2.

  • Page 15: Ground Connection

    All DC outputs of ICT’s DC distribution systems are isolated from chassis ground (floating). DC output returns can remain isolated from ground (DC-I) or can be grounded (DC-C), as per site grounding requirements and/or local or national electrical codes.

  • Page 16: Alarm Connections

    Energy Manager Series 2.7 Alarm Connections Connect the two form-C relay Bus Alarm outputs to an external monitoring system, if needed, by stripping and terminating 16–28 AWG alarm wiring in the alarm 7-pin connector plugs and installing the connector in the front panel.

  • Page 17: Software Configuration

    150 amps continuous current if Bus B outputs are to be used. 5. If using the ICT-CMA for the input cables, anchor the cables to the ICT-CMA in the desired positions using cable ties.

  • Page 18: Installation Of The Breakers

    Energy Manager Series 2.11 Installation of the Breakers Risk of personal injury or damage to equipment and property. Always observe the following: • Ensure that the breakers are in the correct orientation when inserting into the breaker openings — the breaker switch must be on the bottom side of the unit as shown in Figure 4.

  • Page 19: Load Connections

    Energy Manager Series 2.12 Load Connections Risk of personal injury or damage to equipment and property. Always observe the following: • DC-AC Inverters should not be connected to the outputs of the distribution unit. DC-AC inverters create significant inrush current and may damage the circuitry or interfere with the operation of load distribution panels that they are connected to.

  • Page 20: System Wiring Final Verification

    Figure 7. Removing Load Wire/Ferrule from Breaker 3. If using the ICT-CMA for the load output cables, anchor the cables to the ICT-CMA in the desired positions using cable ties.

  • Page 21: Operation: Graphical User Interface

    DHCP server will be assigned a different IP address automatically. The IP address of any ICT unit on a local network can be found by running the ICT "IP Address Discovery tool", after installing it on a Windows computer connected to the same network (tool available for download from ICT http://www.ict-power.com/resources/tools-...

  • Page 22: Status & Control

    Energy Manager Series 4.2 Status & Control Once successfully logged in, the Status & Control tab will be shown in the browser. Bus Status Bus x: Shows name of each bus if one was assigned. Voltage: Shows output DC voltage on this bus. This value does specify polarity.

  • Page 23: Alarm Status

    Energy Manager Series Output Status Each output on the unit will be displayed with name and status (Enabled, Disabled, BREAKER OFF). A status "Enabled (green)" indicates that the internal electronic relay on that output channel is closed or turned on. A status "Disabled (orange)"...

  • Page 24: Device Setup

    Energy Manager Series 4.4 Device Setup Use this tab to configure the unit’s name, set the date and time and enable the watchdog timer and data logging features. Device Info Site Name: Enter a descriptive name for the system. This name will be used in all e-mail messages.
  • Page 25 Energy Manager Series Sequence/Cycle Delay: Set the time in seconds (0–60 seconds) that will be used as the delay between energizing outputs. Will affect all outputs. Set to 0 to disable. Use this feature to allow a delay between energizing loads to reduce inrush current. The default setting is 0 (Disabled).
  • Page 26 Energy Manager Series Select a Watchdog to edit: Select one of the six independent watchdogs to configure. Each watchdog, if enabled, will cause the unit to periodically ping up to two remote IP addresses to verify network connection status. If there is no response from either address, the unit will cycle power on all outputs that are configured in the "Cycle Outputs"...

  • Page 27: Bus Setup

    Energy Manager Series 4.5 Bus Setup Use this tab to configure each bus. Select a Bus to edit Select "Bus A" or "Bus B" to call up the settings for that bus. Bus "A/B" Settings Bus Name: Set a descriptive name for the selected bus if desired.

  • Page 28: Output Setup

    Energy Manager Series Under-Voltage Recovery: Set the voltage that will clear the alarm on this bus. Bus voltage rising above this level will clear the alarm. The default setting is 32 VDC. Activate Alarm Form C Contact: Set the check box for the Alarm relay to trigger for an undervoltage condition.
  • Page 29 Energy Manager Series Select an Output to edit Select the output to be edited in this section. Make any required changes, and then click on the "Save Settings" button at the bottom of the page to save any edits. Output Settings Output Label: Enter a descriptive label for the selected output channel.
  • Page 30 Energy Manager Series resetting power to a router or other hardware required for the network connectivity of the unit. The default setting is Disabled. NOTE: The "Sequence/Cycle Delay" time must be set on the "Device Setup" page with duration long enough for the connected network hardware to fully reset for this function to be effective.
  • Page 31 Energy Manager Series Output Over-Current Alarm Over-Current Threshold: Set the current (1.0–50.0 amps) that will trigger an overcurrent alarm on this output. Output current above this level for at least 5 seconds will trigger the Over-Current Alarm. Disable this alarm by setting the threshold to 0 amps. The default setting is 0 (Disabled).

  • Page 32: Network Setup

    Energy Manager Series Send E-mail: Set the check box to have a Bus Under-Current alarm e- mail sent to the e-mail addresses set up on the "E-mail Setup" page (see Section 4.8). The default setting is Disabled. NOTE: Save Settings for each channel and then repeat the setup process for all output channels to be used, or Copy Settings to All.
  • Page 33 The information available from the SNMP agent is described in a MIB (Management Information Base) file, which can be downloaded from the ICT website: https://ict-power.com/resources/tools-utilities/. The MIB file 855-371-000_Rev1.0_Instruction Manual Page 24 of 43...
  • Page 34 • Full Device Control: Allows SNMP client to set all unit settings through SNMP. This setting requires a different MIB file which can be downloaded from the ICT Website: https://www.ict- power.com/resources/tools-utilities/. SNMP Contact Information: Set contact information, such as an operator name and phone number for the unit, which can be read via SNMP queries (this information is optional).
  • Page 35 Energy Manager Series v1/v2c Settings Read Community: Enter the community string/password here for read- only SNMP access. The default read community string is "public". Write Community: Enter the community string/password here for read/write SNMP access. The default write community string is "write".

  • Page 36: E-Mail Setup

    Energy Manager Series Trap User Name: Set the username for SNMPv3 traps. This field is only used for v3 traps. Authentication Protocol: Set the authentication protocol for SNMPv3 traps (None, MD5, or SHA) Authentication Password: If an authentication protocol is selected, set the authentication password for SNMPv3 traps.
  • Page 37 Energy Manager Series E-mail SMTP Server: Set the name or the IP address of the SMTP server used for sending outgoing e-mail (e.g., "smtp.gmail.com"). SMTP Port: Set the port used by the SMTP server. The default setting is 25. SMTP Server requires SSL: Select this check box if the SMTP server requires an encrypted SSL connection.

  • Page 38: Alarm Setup

    Energy Manager Series Load-Shedding is activated: Select this check box to receive an e-mail notification when any of the outputs are disabled or enabled due the voltage crossing one of the load-shed settings configured on the Output Setup page. The Network Watchdog triggers: Select this check box to receive an e-mail notification when the Network Watchdog triggers due to a loss of the network connection.
  • Page 39 Energy Manager Series NOTE: The unit has no password assigned by default, so an Administrator password should be assigned to the unit for improved security. Record the new password(s) for future access. If the Administrator password is lost the unit must be reset to return the...
  • Page 40 Energy Manager Series Access Level: Set the access level: • Administrator: This level has full access to the unit settings and can set up users and change passwords ("admin" is the default user). • Control: User has read-only access to the unit, but can enable or disable the outputs, and change some of the basic settings.

  • Page 41: Maintenance

    Energy Manager Series Password: Enter the new password for the chosen user. Password (confirm): Re-enter the new password to confirm the entry. Confirm Changes User Name: Enter admin username to confirm these changes are valid. Password: Enter the password for the admin name to confirm the changes are valid.
  • Page 42 Energy Manager Series settings and passwords see the "Password Reset" section (this feature is only available to the system Administrator). • Restoring the unit to Factory Default settings may cause loss of network communications due to loss of custom changes to any network settings.
  • Page 43 Energy Manager Series Download the latest ICT300DB-12IRC firmware file from the ICT website (ict-power.com/resources/product-firmware/) to a local computer. Select the "Update Firmware" button to access the Firmware Update page shown below. Use this page to update the firmware on the unit by clicking the "Choose File"...

  • Page 44: Help

    5.1 Log In/Log Out 1. Connect to the ICT Dual Feed Intelligent Distribution Panel by entering the IP address of the unit in the address field of the mobile browser, followed by "/m" (e.g., https://192.168.0.180/m) shown below.

  • Page 45: Status & Control

    Energy Manager Series 5.2 Status & Control Once successfully logged in, the mobile version of the Status & Control page will be shown in the smartphone web browser. The mobile web version page provides information on the bus voltage, bus current, input alarm status, and the status and current level of each of the bus output channels.

  • Page 46: Faqs

    If required, resources are available from vendors who specialize in site protection to help you determine which devices are most suitable for your installation. 6.3 Why do I measure DC voltage on an output to ICT’s equipment even though the circuit breaker is open or not installed? This is normal operation;...
  • Page 47 The unit may also be restored to factory settings through the GUI (see Section 4.11). 6.7 How do I access the web-based configuration utility? • Check that you are using the correct IP address for the unit by downloading and running the ICT IP Address Discovery tool (tool available download from http://www.ict- power.com/resources/tools-utilities/)
  • Page 48 NOTICE 6.10 How do I update the firmware? On the ICT website, click on Resources > Product Firmware and select the product. Download the latest firmware. In the ZIP file will be a README document with step-by-step instructions or see "Firmware Update"...

  • Page 49: Product Specifications

    Energy Manager Series 6.11 How do I log out of the GUI? To log out of the ICT ICT300DB-12IRC GUI, click on the Logout link on the top right of the browser window. The system will also automatically log off the user after 20 minutes of inactivity.

  • Page 50: Regulatory Specification

    Energy Manager Series 7.3 Regulatory Specification Table 6. Regulatory Compliance Category Certification CSA C22.2 No. 62368-1:19, ANSI/UL 62368-1-2021, Safety, EMC-Emissions, EN 61000-3-2, EN 61000-3-3, EN 61000-6-3, EN 61000- EMC-Immunity, RoHS 6-4, ICES-003 Issue 7, CFR Title 47 FCC Part 15, EN 61000-6-1, EN 61000-6-2, CE, and RoHS 7.4 Mechanical Specifications...

  • Page 51: Figure 9. Dimensions Of Unit With Ict-Cma Installed

    Energy Manager Series Figure 9. Dimensions of Unit with ICT-CMA installed 855-371-000_Rev1.0_Instruction Manual Page 42 of 43...

  • Page 52: Glossary

    Energy Manager Series 8.0 GLOSSARY • Two Rack Unit; 3.5-inch (89 mm) of rack height • A, amps Amperes • Advanced Encryption Standard • ANSI American National Standards Institute • American Wire Gauge • Cable Management Assembly • DHCP Dynamic Host Configuration Protocol •...
  • Page 53 Find the latest version of this manual here: https://ict-power.com/product/ict300db-12irc/ INNOVATIVE CIRCUIT TECHNOLOGY LTD. 26921 Gloucester Way Langley, British Columbia, Canada V4W 3Y3 T +1 604.856.6303 (International) T +1 877.930.0717 (North America Toll-free) www.ict-power.com...
