Part No.505071100002
Rev: C
Nov. 2022
Operation
Manual
产品说明书
PRODU
C T MAN U AL
TB32JN Plus/TB1060JN Plus
0608E (2132E)
G T JZ
0808E (2732E)
G T JZ
0808E (2732E)
G T JZ
G T JZ
0808E (2732E)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TB32JN Plus and is the answer not in the manual?

Questions and answers

Related Manuals for Sinoboom TB32JN Plus

Summary of Contents for Sinoboom TB32JN Plus

  • Page 1 Operation Part No.505071100002 Rev: C Manual Nov. 2022 产品说明书 PRODU C T MAN U AL TB32JN Plus/TB1060JN Plus 0608E (2132E) G T JZ 0808E (2732E) G T JZ 0808E (2732E) G T JZ G T JZ 0808E (2732E)
  • Page 3 Operating, servicing and maintaining this vehicle or equipment can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle or equipment in a well-ventilated area and wear gloves or wash your...
  • Page 4 : No.128, East Jinzhou Avenue, Ningxiang High-tech Industrial Park, Changsha, Hunan, China Zip Code : 410600 Copyright © Hunan Sinoboom Intelligent Equipment Co., Ltd. All Rights Reserved The final interpretation right of this manual belongs to Hunan Sinoboom Intelligent Equipment Co., Ltd.
  • Page 5 (See Decals/Nameplate Inspection of the Operation Manual for details.) Trade Identification Model Serial No. Imperial Metric From 0507100166 to present TB32JN Plus TB32JN Plus TB1060JN Plus NOTE: • Product model is applied in product nameplate for distinction of products of different main parameters.
  • Page 6 This Page Intentionally Left Blank...
  • Page 7 This manual covers the basic parts information of one or more products. Therefore, please use this manual according to your needs. If you find problems in the manual or have suggestions for improve- ment, feel free to share your feedback with Sinoboom, and we will address these issues as soon as possible.
  • Page 8 This Page Intentionally Left Blank...

  • Page 9: Table Of Contents

    Decals/Nameplates (GB) ..10-2 Inspecting the Battery ....5-6 TB32JN Plus Operation Manual © Nov. 2022...
  • Page 10 Appendix 1: Symbols and Description....... A-1 Appendix 2: Prepare the Work Record Before Delivery ..A-3 Appendix 3: Repair & Inspection Report ......A-5 Appendix 4: Major Modification and Repair Record ..... A-9 © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 11: Introduction

    The owner or administrator of the machine shall also provide the manufacturer’s maintenance information to the person responsible for maintaining the machine. If you have any questions, contact Hunan Sinoboom In- telligent Equipment Co., Ltd.. TB32JN Plus Operation Manual © Nov. 2022...
  • Page 12 This Page Intentionally Left Blank © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 13: Machine Specifications

    MACHINE SPECIFICATIONS Table 1-1 TB32JN Plus specifications TB32JN Plus (METRIC) TB1060JN Plus (IMPERIAL) MEASURE DIMENSION Max platform height 32.3m 105ft 12in Max working height 34.3m 112ft 6in Max horizontal reach (restricted/ 17.9m/20.0m 58ft 8in/65ft 7in unrestricted) Max horizontal working envelope 18.5m/20.6m...
  • Page 14 MACHINE SPECIFICATIONS Table 1-1 TB32JN Plus specifications (continued) TB32JN Plus (METRIC) TB1060JN Plus (IMPERIAL) MEASURE Max allowable inclination 5° Turning radius (inside) 3.65m 12ft Turning radius (outside) 6.91m 22ft 8in Max allowable side force 400N 90 lbf Max operating noise level...
  • Page 15 MACHINE SPECIFICATIONS Table 1-1 TB32JN Plus specifications (continued) TB32JN Plus (METRIC) TB1060JN Plus (IMPERIAL) MEASURE Gross weight (unladen) 17460 kg 38493 lb Note: a) The platform height plus operator height (taken as 2m/6ft 7in) is the working height. b) The ground bearing data is approximate value, not factoring different options, thus it serves only in adequately safe conditions.
  • Page 16 MACHINE SPECIFICATIONS Range of motion (5°) 300 kg (661 lb) 454 kg (1001 lb) © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 17: Machine Components

    MACHINE COMPONENTS 20 21 29 30 Figure 2-1 TB32JN Plus Operation Manual © Nov. 2022...
  • Page 18 Boom rises to be no more than 15°above the horizontal plane, and extends not exceeding 1.2m (3.9 ft). Operating/raised position: Boom rises to be more than 15°above the horizontal plane, or extends beyond 1.2m (3.9 ft). © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 19: Safety

    In case of any accident involving the machinery of Also, people who have alcohol or drugs in their Hunan Sinoboom Intelligent Equipment Co., Ltd., notify system, or experience excessive fatigue or Hunan Sinoboom Intelligent Equipment Co., Ltd.

  • Page 20: Electrocution Hazards

    Table 3-1 Minimum Safe Distance Voltage Minimum Safe Distance (Phase to Phase, kV) (m/ft) 0-50 3.05 (10) 50-200 4.60 (15) 200-350 6.10 (20) 350 -500 7.62 (25) 500 -750 10.67 (35) 750 -1000 13.725 (45) © Nov. 2022 TB32JN Plus Operation Manual...
  • Page 21 Do not use the platform or boom uneven surfaces, or near holes assembly to push other machines and steep slopes, maintain a or objects. minimum distance of 0.6m (2ft) and reduce the speed. TB32JN Plus Operation Manual © Nov. 2022...

  • Page 22: Jobsite Hazards

    Do not lift the platform when the wind speed exceeds 12.5 m/s (28 mph). If the wind speed exceeds 12.5 m/s (28 mph) after the platform is lifted, © Nov. 2022 TB32JN Plus Operation Manual...
  • Page 23 If the machine is to be used in any other applications, or by any other means, other than fold the platform and do not those specified by Sinoboom, it must be approved or continue to operate the machine. guided by the manufacturer.

  • Page 24: Unsafe Operation Hazards

    The battery not only provides power, but also serves as a counterweight. The battery is vital to maintaining the stability of the machine. © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 25: Fall Hazards

    At a minimum, operators must operate and maintain the machine as stated in the operation manual and in the maintenance manual in addition to following more stringent industry regulations and workplace rules. TB32JN Plus Operation Manual © Nov. 2022...

  • Page 26: Crush Hazards

    Set up roadblocks if necessary. • Limit the speed of travel according to ground conditions, crowding, gradients, the presence and location of personnel and any © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 27: Explosion And Fire Hazards

    During operation, keep the left and right doors of the chassis closed and locked. Only trained service personnel can open the left and right doors to repair the machine. TB32JN Plus Operation Manual © Nov. 2022...

  • Page 28: Battery Hazards

    ELECTROCUTION HAZARD • Contact with hot circuit may cause serious injury or death. Be sure to wear goggles, gloves and protective clothing. • Remove all rings, watches and other accessories. © Nov. 2022 3-10 TB32JN Plus Operation Manual...
  • Page 29 • Do not tamper with battery system to avoid serious accident. • Cut off the battery main switch if the battery is not to be used for an extended period. TB32JN Plus Operation Manual 3-11 © Nov. 2022...

  • Page 30: Hydraulic Hazards

    OFF position. 7. Turn the key switch at the ground controls to OFF position and remove the key to avoid unauthorized operation of the machine. 8. Turn off the main power switch. © Nov. 2022 3-12 TB32JN Plus Operation Manual...
  • Page 31 SAFETY NOTICE After using the machine, the main power switch must be disconnected. TB32JN Plus Operation Manual 3-13 © Nov. 2022...
  • Page 32 SAFETY This Page Intentionally Left Blank © Nov. 2022 3-14 TB32JN Plus Operation Manual...

  • Page 33: Jobsite Inspection

    Operators must identify and avoid workplace hazards when mov- ing, installing and operating the machine. Unless approved by Sinoboom, never operate the ma- chine in a hazardous site. The following items present danger on the jobsite: •...
  • Page 34 JOBSITE INSPECTION This Page Intentionally Left Blank © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 35: Pre-Operation Inspection

    Never use a machine that has damaged or modified be certified as a qualified operator in operation of parts. Mark the machine and stop using the this machine. machine if you discover damage or modifications. TB32JN Plus Operation Manual © Nov. 2022...

  • Page 36: Conducting A Pre-Operation

    If too high, the oil will spill out manifolds from the oil tank during machine operation, if too low, • Fuel tank and hydraulic tank the oil pump will suction air and damage hydraulic components. Performing daily inspection of the © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 37: Inspecting Fuel Level

    Figure 5-3 cannot be mixed. 3. When the fuel level is less than or equal to 10%, the alarm will sound, make sure to add fuel to continue work. TB32JN Plus Operation Manual © Nov. 2022...

  • Page 38: Inspecting Engine Oil Level

    4. Move the engine start switch and idle it for 2 minutes. 5. Switch off the engine, and 5 minutes later open the turntable cover on the right side. 6. Remove the engine dipstick to inspect the engine oil level. © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 39: Inspecting Coolant Level （Water

    The appropriate coolant level is vital to maintaining the below. engine performance and extending its service life, otherwise it will damage the engine parts. Through the daily check the inspector can know about the changes TB32JN Plus Operation Manual © Nov. 2022...

  • Page 40: Inspecting The Battery

    • Contact with live circuit may corrosion. cause serious injury or death. Be sure to wear goggles, gloves and protective clothing. • Remove all rings, watches and other jewelry. © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 41: Pre-Operation Function Test

    All the function tests of the ground controller must be completed within one cycle. Do not use a machine with problems or malfunctions. Mark the machine and do not use it if you discover any TB32JN Plus Operation Manual © Nov. 2022...
  • Page 42 22. Ground control position 6. Enable switch 14. Platform rotate switch 7. Emergency power switch 15. Platform level switch 8. After-treatment regeneration 16. After-treatment regeneration disable switch (if equipped) request switch (if equipped) © Nov. 2022 TB32JN Plus Operation Manual...
  • Page 43 21. Heavy load indicator 9. Platform info 33. Overload limit 10. Alarm message 34. Drive limit (operating position) 22. Overload alarm 35. Drive and boom functions 11. Fault alarm 23. Not used allowed TB32JN Plus Operation Manual © Nov. 2022...
  • Page 44 Emergency stop button 3. Turn the key switch on the ground controller to ON position. 4. Ensure the relevant indicator light on the display is on and no error is present. Horn button © Nov. 2022 TB32JN Plus Operation Manual...
  • Page 45 FALL HAZARD normally. The platform leveling function is only Main boom up/down switch used for slight adjustment of the platform. Improper operation may result in unintended movement or fall of the load/occupants. TB32JN Plus Operation Manual © Nov. 2022...
  • Page 46 2. Move the enable switch and meanwhile move downwards the jib rotate switch, the jib boom shall rotate clockwise. Emergency power switch © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 47: Testing The Platform Controller

    30. Horn button 9. Not used 20. Drive direction 31. Buzzer button 21. Drive high/low speed select 10. Jib up/down switch switch 11. Main boom telescope/jib rotate 22. Engine high/low speed select control handle switch TB32JN Plus Operation Manual © Nov. 2022...
  • Page 48 Light ON indicates the platform controller is normally powered. Horn button Move the glow plug switch and hold it for 6-10s, the engine should take in air for preheating. © Nov. 2022 TB32JN Plus Operation Manual...
  • Page 49 When driving the machine down a Drive high/low speed select switch slope, control the handle within small travel distance. TIPPING HAZARD The machine must drive at low speed when not on a level surface. TB32JN Plus Operation Manual © Nov. 2022...
  • Page 50 Main boom up/down main boom telescope/jib rotate proportional control handle, the jib should rotate counterclockwise. Note: The jib rotate speed is in direct proportion to the stroke of control handle. Platform level switch © Nov. 2022 6-10 TB32JN Plus Operation Manual...
  • Page 51 2. Depress the footswitch and move downwards the jib up/down switch, the jib boom shall go down, CAUTION and the buzzer should sound. Emergency power switch TB32JN Plus Operation Manual 6-11 © Nov. 2022...
  • Page 52 NOTICE At this time, the machine will drive and steer in opposite direction as indicated. Hydraulic generator switch (if equipped) © Nov. 2022 6-12 TB32JN Plus Operation Manual...
  • Page 53 High engine water temperature • CAN bus error • Other faults When the angle sensor malfunctions, the angle Chassis tilt indicator light sensor malfunction indicator light should be on. CAUTION Range limit indicator light TB32JN Plus Operation Manual 6-13 © Nov. 2022...

  • Page 54: Testing The Drive Speed

    3. Turn the key switch on the ground controller to the ON position. 3. Slowly push forward the drive/steer control handle to full drive speed. 4. Move and the hold the emergency power switch on the ground controller. © Nov. 2022 6-14 TB32JN Plus Operation Manual...

  • Page 55: Testing The Tilt Protection System

    With the machine in operating position, drive it onto the two wooden blocks. 10. The tilt alarm should sound with the chassis tilt indicator light flashing, some functions are restricted, but the boom retracting, turntable TB32JN Plus Operation Manual 6-15 © Nov. 2022...

  • Page 56: Testing The Weighing System

    TESTING THE WEIGHING SYSTEM Before the test, fully raise and lower the boom and fully extend and retract the boom at least twice to ensure the pulley and track are adequately lubricated. © Nov. 2022 6-16 TB32JN Plus Operation Manual...
  • Page 57 Before conducting any override operation, please make sure the surrounding area and the whole machine are in a safe state, try to avoid operation in a dangerous direction and ensure personal safety. TB32JN Plus Operation Manual 6-17 © Nov. 2022...
  • Page 58 PRE-OPERATION FUNCTION TEST This Page Intentionally Left Blank © Nov. 2022 6-18 TB32JN Plus Operation Manual...

  • Page 59: Operating The Machine

    • Check the work site. tipping. • Check the safety decals/ nameplate on the machine. • Only use the machine according to the instructions in this manual and for its intended purpose. TB32JN Plus Operation Manual © Nov. 2022...
  • Page 60 Boom fully extended; Boom kept horizontal; Turntable rotated 90°; The machine will tip over in the direction as indicated by the arrow if overloaded or operated beyond the limits of the maximum operating slope. © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 61: Emergency Stop

    • Push the power disconnect switch on the left side of chassis to OFF, the system power will be disconnected and all functions will get inoperative. TB32JN Plus Operation Manual © Nov. 2022...

  • Page 62: Emergency Lowering

    When the platform or boom is caught overhead: If the platform or boom becomes jammed or snagged in overhead structures or equipment, rescue all people in the platform before freeing the machine. © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 63: Operation From Ground

    Before applying any load, warm up the engine by running it at low speed for 3–5min. To position platform: 1. Move the enable switch and meanwhile move upwards/downwards the boom up/down switch to raise or lower the main boom. TB32JN Plus Operation Manual © Nov. 2022...

  • Page 64: Operation From Platform

    4. Depress the footswitch and meanwhile move upwards/downwards the platform level switch to level up/down the platform. © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 65: Driving On A Slope

    3. Ensure the slope grade is within the limits of the machine gradeability. TIPPING HAZARD The machine must be driven at low speed when tilted. When in operating position, the machine can only drive at operating speed; moving upward the drive high/low TB32JN Plus Operation Manual © Nov. 2022...
  • Page 66 2. Measure the height H and length/distance L of the slope. Figure 7-5 3. Slope grade= H/L x 100%. NOTICE The machine must not drive for over 2min on the maximum permissible slope grade to prevent the tires running suspended. © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 67: Transporting And Lifting The Machine

    When using a forklift or crane to lift the machine, prevent the machine from colliding with nearby objects. • Lock the wheels of the machine after it has been loaded to prevent the machine from rolling. TB32JN Plus Operation Manual © Nov. 2022...

  • Page 68: Lifting The Machine With A Crane

    OFF, and remove the key. 2. Perform a thorough inspection of the machine to prevent loose or untightened components and ensure the locking pin of turntable is locked. © Nov. 2022 TB32JN Plus Operation Manual...
  • Page 69 5. Adjust the rigging to prevent damage to the rope/ the air. belt. Figure 8-3 TB32JN Plus Operation Manual © Nov. 2022...
  • Page 70 TRANSPORTING AND LIFTING THE MACHINE This Page Intentionally Left Blank © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 71: Maintenance

    & counterbalance valve on the cylinder. inspection report and must complete the repair & inspection report. • Immediately remove a damaged or malfunctioning machine from service, mark and stop using it. TB32JN Plus Operation Manual © Nov. 2022...

  • Page 72: Conducting A Pre-Delivery Inspection

    Every half a year or every 500 involved. Use the table to help you adhere to a routine A+B+C hours maintenance schedule. Every year or every 1000 hours A+B+C+D © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 73: Completing A Repair & Inspection

    A-9 Inspect Coolant Level (water-cooled engine) A-10 Inspect Engine Belt A-11 Inspect Fuel Strainer (fuel-water separator) A-12 Inspect Cooling Fan A-13 Inspect Engine Intake System A-14 Functional Tests A-15 Perform Maintenance after 30 Days TB32JN Plus Operation Manual © Nov. 2022...
  • Page 74 Reducer Oil Level B-13 Inspect Slewing Bearing Bolts B-14 Lubricate Slewing Bearing B-15 Inspect Platform Rotate Cylinder Fasteners B-16 Test Cylinder Drift B-17 Inspect Counterbalance Valve Locking B-18 Inspect Electrical Wiring B-19 Inspect the Battery © Nov. 2022 TB32JN Plus Operation Manual...
  • Page 75 Reducer Gear Oil D-3 Replace Hydraulic Oil D-4 Replace Hydraulic Tank Suction Filter D-5 Replace Coolant and Coolant Hoses (water-cooled engine) D-6 Replace Fuel Hoses D-7 Inspect Boom Wear Pads User Inspector Signature TB32JN Plus Operation Manual © Nov. 2022...

  • Page 76: Major Modification And Repair Record

    “Good” condition before company. continuing to use the machine. Table 9-4 Major Modification and Repair Record Model Serial No. Machine Repair- Repairman’s Status Problem Description Modification/Repair Item Date Company and Signature Position ter Change © Nov. 2022 TB32JN Plus Operation Manual...
  • Page 77 MAINTENANCE TB32JN Plus Operation Manual © Nov. 2022...
  • Page 78 MAINTENANCE This Page Intentionally Left Blank © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 79: Decals/Nameplates Inspection

    Do not operate the engine if there are missing or badly worn safety labels. TB32JN Plus Operation Manual 10-1 © Nov. 2022...

  • Page 80: Decals/Nameplates (Gb)

    DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES (GB) （ 43 ） 环保信息代码打刻在此位置 4 19 （ 32 ） (20) 15 14 27 28 33 34 (32) © Nov. 2022 10-2 TB32JN Plus Operation Manual...
  • Page 81 104011100019 Decal-Crush hazard 104011100009 Decal-Read manuals 104011100017 Decal-Footswitch 104011100021 Decal-Crush hazard Decal-Rated load 454kg 105046103004 Yellow-Black caution stripe 216060000002 Decal-Hydraulic oil level 104011100003 Decal-Hydraulic oil level 104011100010 Decal-Hydraulic oil temperature range 104010100021 TB32JN Plus Operation Manual 10-3 © Nov. 2022...
  • Page 82 DECALS/NAMEPLATES INSPECTION Description Qty. Part No. Remarks Decal-Hydraulic oil 104009100018 104009100019 Decal-Diesel fuel Decal-Fuel-water separator 104009100020 Decal-Direction marking 105001100051 Decal-Direction marking 105001100053 Decal-TB32JN Plus range of motion 105071103001 Decal-NEO (large) 105068103020 © Nov. 2022 10-4 TB32JN Plus Operation Manual...

  • Page 83: Decals/Nameplates (Ce-Metric)

    DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES (CE-METRIC) 4 18 （31） Tel:0086-731-87116222 www.sinoboom.com (19) 15 14 23 24 26 27 (31) TB32JN Plus Operation Manual 10-5 © Nov. 2022...
  • Page 84 104011100009 Decal-Read manuals 104011100017 Decal-Footswitch 104011100021 Decal-Crush hazard Decal-Rated load 454kg 105046103004 Yellow-Black caution stripe 216060000002 Decal-Hydraulic oil level 104011100003 Decal-Hydraulic oil level 104011100010 Decal-Hydraulic oil temperature range 104010100021 Decal-Hydraulic oil 104009100022 © Nov. 2022 10-6 TB32JN Plus Operation Manual...
  • Page 85 DECALS/NAMEPLATES INSPECTION Description Qty. Part No. Remarks 104009100021 Decal-Diesel fuels Decal-Fuel-water separator 104009100020 Decal-Direction marking 105001100051 Decal-Direction marking 105001100053 Decal-Range of motion 105071103001 TB32JN Plus Operation Manual 10-7 © Nov. 2022...

  • Page 86: Decals/Nameplates (Ce-Imperial)

    DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES (CE-IMPERIAL) 4 18 （31） Tel:0086-731-87116222 www.sinoboom.com (19) 15 14 23 24 26 27 (31) © Nov. 2022 10-8 TB32JN Plus Operation Manual...
  • Page 87 104011100009 Decal-Read manuals 104011100017 Decal-Footswitch 104011100021 Decal-Crush hazard Decal-Rated load 454kg 105046103004 Yellow-Black caution stripe 216060000002 Decal-Hydraulic oil level 104011100003 Decal-Hydraulic oil level 104011100010 Decal-Hydraulic oil temperature range 104010100021 Decal-Hydraulic oil 104009100022 TB32JN Plus Operation Manual 10-9 © Nov. 2022...
  • Page 88 DECALS/NAMEPLATES INSPECTION Description Qty. Part No. Remarks 104009100021 Decal-Diesel fuels Decal-Fuel-water separator 104009100020 Decal-Direction marking 105001100051 Decal-Direction marking 105001100053 Decal-Range of motion 105071103001 © Nov. 2022 10-10 TB32JN Plus Operation Manual...

  • Page 89: Decals/Nameplates (Ansi)

    DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES (ANSI) 4 18 （ 31 ） Tel:0086-731-87116222 www.sinoboom.com (19) 15 14 23 24 (31) TB32JN Plus Operation Manual 10-11 © Nov. 2022...
  • Page 90 104011100009 Decal-Read manuals 104011100017 Decal-Footswitch 104011100021 Decal-Crush hazard Decal-Rated load 454kg 105046103004 Yellow-Black caution stripe 216060000002 Decal-Hydraulic oil level 104011100003 Decal-Hydraulic oil level 104011100010 Decal-Hydraulic oil temperature range 104010100021 Decal-Hydraulic oil 104009100022 © Nov. 2022 10-12 TB32JN Plus Operation Manual...
  • Page 91 DECALS/NAMEPLATES INSPECTION Description Qty. Part No. Remarks 104009100021 Decal-Diesel fuels Decal-Fuel-water separator 104009100020 Decal-Direction marking 105001100051 Decal-Direction marking 105001100053 Decal-Range of motion 105071103001 Decal-Annual inspection 101040103015 103010103014 Decal-Non-insulated TB32JN Plus Operation Manual 10-13 © Nov. 2022...

  • Page 92: Decals/Nameplates (Csa)

    DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES (CSA) 4 18 （ 31 ） Tel:0086-731-87116222 www.sinoboom.com (19) 15 14 23 24 (31) © Nov. 2022 10-14 TB32JN Plus Operation Manual...
  • Page 93 104011100009 Decal-Read manuals 104011100017 Decal-Footswitch 104011100021 Decal-Crush hazard Decal-Rated load 454kg 105046103004 Yellow-Black caution stripe 216060000002 Decal-Hydraulic oil level 104011100003 Decal-Hydraulic oil level 104011100010 Decal-Hydraulic oil temperature range 104010100021 Decal-Hydraulic oil 104009100022 TB32JN Plus Operation Manual 10-15 © Nov. 2022...
  • Page 94 DECALS/NAMEPLATES INSPECTION Description Qty. Part No. Remarks 104009100021 Decal-Diesel fuels Decal-Fuel-water separator 104009100020 Decal-Direction marking 105001100051 Decal-Direction marking 105001100053 Decal-Operating instructions 105029103023 Decal-Range of motion 105071103001 Decal-Annual inspection 101040103015 103010103014 Decal-Non-insulated © Nov. 2022 10-16 TB32JN Plus Operation Manual...

  • Page 95: Appendix 1: Symbols And Description

    Never use machine Never use machine Never push or pull Never suspend objects Never place ladders during strong, gusty during strong, gusty objects outside from platform and scaffolding on the wind wind platform platform TB32JN Plus Operation Manual © Nov. 2022...
  • Page 96 No smoking Lifting point Lashing points Tire to ground load Hydraulic oil filler Platform carrying Do not use damaged Tool or weight Fast/high speed Slow/low speed capacity cords Horn © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 97: Appendix 2: Prepare The Work Record Before Delivery

    2. Use the table to record the results. After each section is complete, mark the appropriate box. 3. Record the inspection results. If any inspection result is “NO”, the machine must be stopped, and then re- inspected after repair is completed, and the box marked “REPAIRED” shall be checked. TB32JN Plus Operation Manual © Nov. 2022...
  • Page 98 DECALS/NAMEPLATES INSPECTION This Page Intentionally Left Blank © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 99: Appendix 3: Repair & Inspection Report

    A-14 Functional Tests A-15 Perform Maintenance after 30 Days A-16 Perform Oscillate Cylinder Exhausting Checklist B Procedures REPAIRED/ YES/Machine is NO/Machine Has Problem Machine Has Items in Good Damage or Description Been Repaired Condition Malfunction TB32JN Plus Operation Manual © Nov. 2022...
  • Page 100 B-17 Inspect Counterbalance Valve Locking B-18 Inspect Electrical Wiring B-19 Inspect the Battery B-20 Test Oscillate Outriggers B-21 Test Drive Speed B-22 Inspect Emergency Lowering B-23 Inspect Tilt Protection B-24 Test Braking Distance © Nov. 2022 TB32JN Plus Operation Manual...
  • Page 101 D-3 Replace Hydraulic Oil D-4 Replace Hydraulic Tank Suction Filter D-5 Replace Coolant and Coolant Hoses (water-cooled engine) D-6 Replace Fuel Hoses D-7 Inspect Boom Wear Pads User Inspector Signature Inspection Date Inspector Title TB32JN Plus Operation Manual © Nov. 2022...
  • Page 102 4. Record the inspection results. If any inspection item is marked as “NO”, the machine must be stopped and re- inspected after repair is completed and the box marked "REPAIRED” shall be checked. Select the appropriate inspection procedure based on the inspection type. © Nov. 2022 TB32JN Plus Operation Manual...

  • Page 103: Appendix 4: Major Modification And Repair Record

    Modification/Repair” in the form will be “Good” and the machine can be used. If either inspection result is “NO”, the machine must be re-inspected after the repair is completed until the machine is in “Good” condition before continuing to use the machine. TB32JN Plus Operation Manual © Nov. 2022...
  • Page 104 Solution s Alw ays For B et t er A ccess Solution s Always for Better Access Solutions AS/N ZS Hunan Sinoboom Intelligent Equipment Co., Ltd. 长沙市宁乡高新技术产业园区金洲大道东 128 号 No.128, East Jinzhou Avenue, Ningxiang High-tech Industrial Park, Changsha, Hunan, China 市宁乡高新技术产业园区金洲大道东...

This manual is also suitable for:
