GTZZ14EJ&16EJ Operation Manual

Manual No: 503007100002

REV: D

May 2023

Translated version

Preface to GTZZ14EJ&16EJ Operation

Operation

Manual

产品说明书

PRODU

GTZZ14EJ/AB14EJ/AB460EJ

Manual

GTZZ16EJ/AB16EJ/AB520EJ

G T JZ

C T MAN U AL

0608E (2132E)

0808E (2732E)

Table of Contents

Need help?

Do you have a question about the GTZZ14EJ and is the answer not in the manual?

Questions and answers

Summary of Contents for Sinoboom GTZZ14EJ

Page 1 GTZZ14EJ&16EJ Operation Manual Operation Manual No: 503007100002 REV: D May 2023 Manual 产品说明书 Translated version Preface to GTZZ14EJ&16EJ Operation PRODU C T MAN U AL GTZZ14EJ/AB14EJ/AB460EJ Manual GTZZ16EJ/AB16EJ/AB520EJ 0608E (2132E) G T JZ 0808E (2732E) G T JZ 0808E (2732E)
Page 3 Operating, servicing and maintaining this vehicle or equipment can expose you to chemicals including engine exhaust, carbon monoxide, phthalates and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure and avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle or equipment in a well-ventilated area and wear gloves or wash your hands...
Page 4 Sales Tel:400-601-5828/0086-0731-87116222 Service Tel:400-608-1289/0086-0731-87116333 E-mail:info@sinoboom.com/sales@sinoboom.com Address: No.128, East Jinzhou Avenue, Ningxiang High-tech Industrial Park, Changsha, Hunan, China Postal code:410600 Copyright©Hunan Sinoboom Intelligent Equipment Co., Ltd. Hunan Sinoboom Intelligent Equipment Co., Ltd. retains the right of final interpretation of the manual.
Page 5 To Users Thank you for choosing and using the machine of Hunan Sinoboom In- telligent Equipment Co., Ltd. Use this machine only to transport tools to work locations and for performing tasks on the work platform. Only authorized personnel who have received appropriate training on MEWP can operate this machine.
Page 6 Manual Revision History: Description DATE Comment Original issue March 2020 December Updated manual 2021 Revised manual, implemented the BS EN 280- November 1:2022 standard requirements, revised the logic 2022 description of drive speed selector switch, etc. May 2023 Comprehensively revised manual...
Page 7 Applicable Models The manual is applicable to machines with the following models and serial numbers: Metric Trade Imperial Trade Model Serial No. 0300600596 to present GTZZ14EJ AB14EJ AB460EJ 0300701188 to present GTZZ16EJ AB16EJ AB520EJ Note: • Check the machine model and serial number on the machine nameplate, and whose position can be found in the Decals Diagram section of the Operation Manual.
Page 9: Table Of Contents
Preventive Maintenance ... . . 66 6.4 Platform Display....34 © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 11: Safety Warning Symbols And Signs
Indicates an imminently hazardous situation that, if not avoided, could result in death or serious injury. Indicates an imminently hazardous situation that, if not avoided, could result in minor or moderate injury. NOTICE Indicates information directly or indirectly related to personal safety, machine damage, or property loss. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 12 Tipping hazard-Never Tipping hazard-Never Tip-over hazard-Never use machine in strong, use machine in strong, push or pull objects suspend objects from place ladders and gusty wind gusty wind outside platform platform scaffolding on platform © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 13 No fire personnel can perform hazard maintenance No smoking Lifting point Lashing point Tire-to-ground load Hydraulic oil filler Platform carrying Do not use damaged Tool or weight Fast/high speed Slow/low speed capacity cords Horn © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 15: Important Safety Rules
Unless with the written permission of Hunan Sinoboom Intelli- Sinoboom could not have foreseen all the dangers that gent Equipment Co., Ltd., this machine shall not be may arise in relation to this machine, so all relevant par- ties should pay attention to safety seriously.
Page 16: Operation Safety
Functional check : Make sure that all functions of the machine are working properly. Without the written permission of Hunan Sinoboom Intelligent Equipment Co., Ltd., it is forbidden to alter or modify the machine. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 17 Never disable any safety devices of the machine. • Never place items on the platform guardrails. • Never push the control switch or joystick through the neutral posi- tion and directly to the opposite © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 18 50-200 4.60m (15ft) • Do not allow oil, sludge or other slippery substances to remain on 200-350 6.10m (20ft) work shoes and platform floor. 350 -500 7.62m (25ft) • Keep the platform floor unobstructed. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 19 • Do not replace critical parts that instructions and move the ma- affect the stability of the machine chine to firm and level ground. with parts of different weights or © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 20 If the wind speed increases to exceed 12.5m/s (28mph) after the platform is raised, the platform should be retracted immediately, and then all power supplies should be cut off, and the machine should be stopped. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 21 If the boom is not lifted by lifting equipment, do not work under the platform or boom. • Make sure that other nearby oper- ators working at height and on floors are aware that this MEWP is © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 22: Towing, Hauling And Lifting
• The machine can only be lifted from the specific position with a forklift or crane with sufficient lift- ing capacity. Care should be taken © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 23: Maintenance Safety
• After maintenance, clean the spilled hydraulic oil thoroughly and do not spill the hydraulic oil on the ground. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 24 • If you are injured by ignoring the dangers of high temperature and high pressure, seek immediate medical attention. If treatment is not carried out immediately, seri- ous complications can result. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 25 • Only approved non-flammable be reported to relevant mainte- cleaning solutions should be used nance personnel in time. on the machine. • Batteries contain sulfuric acid and can produce explosive © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 26 • Do not reverse the positive and negative poles of the battery for use. • Do not short-circuit the positive and negative poles of the battery system. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 27: Responsibilities Of Relevant Parties
3.3 TRAINER’S RESPONSIBILITIES • The trainer must be accredited by Sinoboom as who has received comprehensive knowledge training on the machine, and has the required competencies re- lated to machine repair and maintenance.
Page 28 RESPONSIBILITIES OF RELEVANT PARTIES This Page Intentionally Left Blank © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 29: Technical Parameters
TECHNICAL PARAMETERS 4.1 MACHINE SPECIFICATIONS Table 4-1 GTZZ14EJ specifications Metric Imperial ITEM Product Category Power type Battery Outrigger type Fixed outrigger DIMENSION Maximum platform height 45ft 11in Maximum working height 52ft 6in Maximum horizontal reach 7.6m 24ft 11in Maximum horizontal working 8.2m...
Page 30 TECHNICAL PARAMETERS Table 4-1 GTZZ14EJ specifications (Continued) Metric Imperial ITEM Turntable tail-swing Options 250–15 (solid) Tire size (spec/type) 240/55D17.5 (foam-filled) 27×10.5-15 (rough-terrain, foam-filled) 27×10-15 (rough-terrain, solid) Maximum operating noise level 72dB IP rating IP65 Highest total vibration value of the 2.5m/s²...
Page 31 160° Gradeability （2WD） 30%/17° Max allowable tilt angle 5° Turning radius (inside/outside) 2ft 4in/10ft 10in 0.7m/3.31m Turntable tail-swing 2.0in 50mm Options 250–15 (solid) Tire size (spec/type) 240/55D17.5 (foam-filled) 27×10.5-15 (rough-terrain, foam-filled) 27×10-15 (rough-terrain, solid) © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 32 Maximum allowable side force 400N 90lbf Maximum allowable wind speed 12.5m/s 28mph Maximum allowable altitude 1000m 3280ft Allowable ambient temperature -10℃～40℃ 14℉～104℉ (lead-acid battery) Allowable ambient temperature -20℃～40℃ -4℉～104℉ (lithium battery) Maximum allowable relative humidity © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 33: Movement Speed
Raise the jib boom 28～33s 28～33s Rotate the turntable : With the boom centered, rotate the turntable through two full cycles. Lower the jib boom 20～25s 20～25s Max travel speed 18～24s 18～24s -stowed © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 34 Brake distance at maximum speed in high gear : As indicated by the “travel-stowed position” test, once the machine reaches the maximum travel speed, immedi- ately release the joystick (starting timing) until the ma- chine stops. Test twice. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 35: Pre-Operation Inspection
13. Rear wheel (non-steering wheel) 2. Foot switch 8. Lower articulated boom 14. Power unit 3. Platform controls 9. Front wheel (steering wheel) 15. Hydraulic tank 10. Turntable controls 16. Anchorage point 4. Jib boom (if equipped) © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 36: Machine Positions
Manual are intact, easy to read, and stored in the that the surrounding area is free of obstacles. manuals storage box on the platform. The gate should remain closed at all times, © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 37: Functional Test
Before performing the functional test: started and all functions cannot work. • Choose a solid, flat and horizontal test area. 3) Make sure that the horn sounds properly when the horn button is pressed. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 38 Note: When the travel control handle is re- leased, the brake must be able to hold the ma- chine on any slope within the maximum climbing angle reliably without sliding. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 39: Controls And Indicator Lights
Provide machine working states, fuel/battery level, fault codes Turntable display & query, and other information. Platform control position OFF position (neutral) Ground control position Turn the switch to OFF position (neutral), the machine will be Key switch turned off; © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 40 Emergency stop button push the button to OFF position, the controls will be powered off, the machine cannot start and all functions will be inoperative. Main boom luffing switch Control main boom luffing. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 41: Turntable Display
This icon lights up to indicate that the machine is in the operat- Operating position ing position. This icon lights up to indicate that the machine is in the non- Non-operating position operating position. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 42: Platform Controls
Main boom telescoping switch Control main boom telescoping. Provide emergency power in case of main power source Emergency power switch(if equipped) failure. Not used HV mode enable switch (if equipped) Turn on/off the HV mode. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 43 This indicator lights up to indicate that the platform controls Power indicator have normal power supply. Press the button, and the horn will sound. Horn Under different circumstances, the buzzer issues sound and Buzzer light alarms with different frequencies. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 44: Platform Display
High travel speed indicator at high speed. Angle sensor fault indicator This icon lights up to indicate: angle sensor faults. This icon flashes to indicate that the outrigger is retracting/ Outrigger telescoping indicator extending. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 45 This icon lights up to indicate: that the machine enters crab Crab walk indicator walk mode. This icon lights up to indicate: that the machine enters four- Four-wheel steering indicator wheel steering mode. Fuel/battery level indicator To display the current fuel level/battery level. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 47: Operation Instructions
If any switch/handle returns to the neutral po- sition but the corresponding movement does not stop, remove the foot from the foot switch or push in the emergency stop button to stop the machine. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 48: Working Envelope Diagram
OPERATION INSTRUCTIONS 7.2 WORKING ENVELOPE DIAGRAM Fig 1 Working envelope diagram of GTZZ14EJ (5°) © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 49 OPERATION INSTRUCTIONS Fig 2 Working envelope diagram of GTZZ16EJ (5°) © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 50: Stability
2. Main boom horizontal and fully extended; tilted surface exceeding the maximum allowable tilt angle. 3. Jib raised to be horizontal; 4. Turntable rotated 90°; © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 51: Gradeability
Do not drive the machine on the slope exceeding the machine’s maximum allowable climbing angle. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 52: Charging The Battery
NOTICE Measure the temperature of the electrolyte. If it is higher than 45°C, wait for the battery to cool before proceeding to the following steps. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 53 110VAC (210VAC) ≥3kW 3. The slow charging mode will resume automatically 220VAC (380VAC) ≥6kW after power-off. • Please refer to the following table to reasonably se- lect the diameter and length of the charging cable; © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 54: Turntable Rotation
2. Rotate the turntable counterclockwise: Depress the foot switch, push the main boom luffing/turntable 3. When the boom is above the rear-wheel drive axle, © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 55 Fig 5 3. With the machine in operating position, the machine can only travel at low speed. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 56: Boom Movements
Perform operation from the ground: Retract the main boom: Depress the foot switch, push the main boom telescope switch upwards, and the main boom will be retracted. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 57: Transportation And Lifting
5. To protect the boom, platform components and elec- trical and hydraulic components, do not apply ex- cessive downward pulling force to the ropes or belts © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 58: Storage
5. Chock the wheels. ing the machine: 6. Wipe off all dust and oil from the machine to keep it 1. Retract and lower the boom to the stowed position. clean. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 59 9. For a machine stored for more than three months, replaced as appropriate for the actual situation. idle the machine every three months for not less © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 61: Emergency Procedures
In case of any accident involving the machinery of Hunan Sinoboom Intelligent Equipment Co., Ltd., notify Sinoboom immediately, even if there is no personal in- When the main power source fails, the platform can be jury or property damage in the accident. Notify Sino- lowered into place as follows.
Page 62: Emergency Towing
3. Loosen the bolts on each drive hub and mount the drive hub cap reversely. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 63: Decals Diagram
DECALS DIAGRAM (23) (23) (23) (11) (14) (34) (19) Fig 1 Decals Diagram-1 © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 67 DECALS DIAGRAM (23) (23) (23) (32) (11) (19) (18) Fig 2 Decals Diagram-2 © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 71: Maintenance
Every 1 year or 1000 Replace oil working hours Every 3 months or 250 Check oil level working hours Slewing drive Refer to the Gear Oil section device Every 1 year or 1000 Replace oil working hours © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 72: Oil Requirements
• If special oil is required by the environments or users, please contact Sinoboom. • Before filling oil, wait until the temperature of the machine drops to room temperature, other- wise it may cause splashes, burns or other personal injury.
Page 73: Tire Assembly
25mm (1in) in either direction. • The tire has a perforation with the diameter of over 25mm (1in). • The tire has a large bulge. • The wear extent of the tire’s off-ground support sur- face exceeds 25%. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 74: Replacement Requirements
(such as battery charger) connected to the machine. Hunan Sinoboom Intelligent Equipment Co., Ltd. recom- 3. Use a wrench to loosen but do not remove the tire mends the replacement tire be of the same size, ply rat- retaining nut.
Page 75: Inspection And Preventative
Sinoboom as one who, by possession of essary inspection and maintenance works have been a recognized degree, certificate and training, has suc- completed before placing the machine into service.
Page 76: Preventive Maintenance
Schedule for items requiring this inspection. Re- The preventive maintenance operation shall be per- fer to the corresponding section of this manual to formed by qualified Sinoboom equipment mechanics. perform the inspection and maintenance procedures. The frequency of the inspection and maintenance must...
Page 77 Hydraulic cylinder 1, 2, 5, 6 1, 2, 5, 6 1, 2, 5, 6 Oscillating cylinder exhausting(if NO.1 NO.1 NO.1 equipped) Hydraulic valve 1, 2, 5, 6 1, 2, 5, 6 1, 2, 5, 6 © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 78 Drive brake 1, 3, 10 1, 3, 10 1, 3, 10 Rotation brake Other inspection items Operation Manual in the manuals storage box All decals/labels complete, clear and secure Annual inspection date of the machine © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 79 All fasteners, pins, protective guards 1, 2 1, 2 1, 2 and covers Grease and lubricating to specifications Functional test of all systems Paint and appearance Inspection date stamped on the chassis Notify Sinoboom of machine ownership © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 80 6. Check for correct sealing, leaking and level 7. Labels complete, clear and secure 8. Check for appropriate tolerances 9. Fully charged 10. Validation/Execution 11. Replace the oil or filter element 12. Correctly lubricated © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 81: Options
Before using the Secondary Guarding device, the safety rules and all operating instructions should be read, understood and observed. This manual should al- ways be kept an integral part with the Secondary Guarding device. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 82 OPTIONS Fig 1 Table 11-1 Part Number Part Name Quantity Comment 203080000101 Waterproof cap 203080000109 Slotted nut 203060000021 Toggle switch 203060000150 Toggle switch guard If equipped © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 83: Parts List
Nut M10-8-ZnD GB/T 6183 215040000035 Washer 10-200HV-ZnD GB/T 97.1 203060003031 Travel switch (Schneider) 215020000113 Screw M5×25-A2-70 GB/T 818 105070043031 Bolt 215020000007 Screw M5×16-A2-70 GB/T 70.1 215030000091 Nut M5-8-A2-70 GB/T 6184 105070043032 Support 215030000003 Nut M5-A2-70 GB/T 6170 © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 84: Installation And Removal
5. Install the travel switch #9 on the left and right sup- ports in turn, and tighten it with screws and washers. 6. Install the strobe light #20 on the left and right © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 85: Wiring Harness And Schematic
OPTIONS Wiring Harness and Schematic Secondary Guarding Harness Diagram Fig 3 © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 86 Nylon hose (closed-end) 203080000424 Thin-walled automotive wires 203080000563 (black) Thin-walled automotive wires (red) 203080000562 203080000408 Sheath 203080000021 Lock Tail attachment (2-pin, male) 203080000462 203080000044 Sheath 203080000020 Lock Tail attachment (4-pin, female) 203080000445 Rubber connector (4-pin) 203080000446 © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 87 OPTIONS Electrical Schematic Diagram of Secondary Guarding Device Fig 4 © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 88 Secondary Guarding device, and the complete harness layout can be found in the complete platform harness diagram. Crush Protect Inspect Crush Protect Warni n g Li g ht 174-1 174-2 174-2 Sensor Fig 6 © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 89 The diagram below only shows the electrical schematic related to the Secondary Guarding device, and the com- plete electrical schematic can be found in the complete electrical schematic diagram of platform. Man Protect Detection Fig 7 © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 90: Pipe Cradle
Before using the pipe cradle, the safety rules and all operating in- structions should be read, under- stood and observed. This manual should always be kept as an inte- gral part with the pipe cradle. Fig 8 © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 91: Installation And Removal
U-bolt through the platform guardrails, align it with the mounting holes of the pipe cradle, and then secure it with hex nuts. Install the pipe cradle to the other side of the © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 92: Instructions For Use
2. Place the load upon the pipe cradle, and ensure that the load length remains parallel with the pipe cradle length. 3. Ensure the load is centered on the same vertical © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 93: Parts List
Part Name Quantity Comment 216030003000 Tube pad 215020000011 Screw M6×16-A2-70 GB/T 70.1 105064043024 Cushion block 215030000004 Nut M6-A2-70 GB/T 6170 105064043178 Cushion plate 105064043136 Vertical cushion block 105064043017 Mounting plate 105064043020 U-bolt Strap 3000mm*25mm © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 94: Installation And Removal
3. Install the tube pads to the platform guardrails. 4. Attach the straps to the guardrails to secure the mounting plate tightly on the platform. Removal instructions Disassemble the panel cradle in the reverse order of the installation instructions. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 95: Instructions For Use
1. Ensure that the panel cradle is installed correctly and secured to the platform. 2. Place the load upon the panel cradle, and ensure that the load length remains parallel with the panel cradle length. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 96: Parts List
Lower side mesh 105064043027 Mesh 1 105064043176 Mesh 5 105064043175 Mesh 6 105064043028 Mesh 2 105064043030 Mesh 3 105064043031 Mesh 4 105064043103 Lower gate frame weldment 215010000050 Bolt M6×16-A2-70 GB/T 5783 215040000033 Washer 6-A2 GB/T 97.1 © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 97 Nut M8-8-ZnD GB/T 6170 Nylon cable tie Parts list of full mesh Fig 13 Table 11-10 Part Number Part Name Quantity Comment 105064043106 Side mesh 105064043109 Front right mesh 105064043110 Front left mesh 105064043114 Upper side mesh © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 98: Installation And Removal
2. Half mesh: Install each mesh in sequence as shown in the figure below, secure the mesh bottom ① with bolts, and secure the mesh top ② and side mesh ③ with nylon cable ties or bolts. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 99 3. Full mesh: Install each mesh in sequence as shown bolts, and secure the mesh top ② and side mesh ③ in the figure below, secure the mesh bottom ① with with nylon cable ties or bolts. © May 2023 GTZZ14EJ&16EJ Operation Manual...
Page 100: Instructions For Use
After the platform mesh is installed, the operator can only enter or exit the platform via the swing gate. • Do not install other attachments, such as pipe/panel cradles, to the platform already fitted with platform mesh. © May 2023 GTZZ14EJ&16EJ Operation Manual...
