- Page 1 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual 0800 222 111 sales@elevatedaccess.co.nz 021 500 486 www.elevatedaccess.co.nz...
-
Page 2: Table Of Contents
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Test Horn ........18 Key Points Test Enabling Switch ....18 Test rising/lowering function ..19 Before operating the machine, you should read, Test the Steering ......19 understand and follow these safety rules and operating Test Drive and Brake Functions.. -
Page 3: Product Performance Parameters
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Product Performance Parameters Parameter Items Unit GTJZ0608 GTJZ0808 Outline dimension Length 2.39 2.39 Width 0.81 0.81 Height (Folded railings) 1.83 1.96 Height (Unfolded railings) 2.22 2.35 Ground clearance... - Page 4 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Off-running status km/h 0～3.2 0～3.2 Lifting status km/h 0～0.8 0～0.8 Gradeability Lifting/lowering time 27/33 (No load) 33/37 (No load) Maximum allowable wind speed 0 (indoor)/ 12.5 (Gale...
- Page 5 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Hydraulic oil tank Hydraulic system 20 (Oil tank) 21 (Oil tank) Pressure of hydraulic system System voltage (DC) Maximum noise normal working Traveling speed Off-running status km/h 0～3.2...
- Page 6 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Control voltage (DC) Platform dimensions Length 2.25 2.25 Width 1.15 1.15 Tire size Diameter Width Oil volume Hydraulic oil tank Hydraulic system 34 (Oil tank) 35 (Oil tank)
-
Page 7: Descriptions Of Whole Vehicle
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Descriptions of Whole Vehicle GTJZ0608 GTJZ0808 1 Entrance/Exit of platform 2 Platform guardrail 3 Mooring Point 4 Platform controller 5 File box 6 Extension platform 7 AC power socket... - Page 8 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual GTJZ0612 GTJZ0812 GTJZ1012 GTJZ1212 1 Entrance/Exit of platform 2 Platform guardrail 3 Mooring Point 4 File box 5 Platform controller 6 AC power socket 7 Extended platform...
-
Page 9: Safety Rules
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Safety Rules Safety warning mark- It is used to prompt potential personal injuries. Observe all safety prompts behind this mark for the purpose of avoiding personal injuries or death. -
Page 10: Hazard Of Electric Shock
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual on the ground or platform must not touch or operate the machine before the power is cut off. Do not use the machine as ground electrode during welding operation. - Page 11 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual GTJZ0612 GTJZ1012 Maximum bearing capacity of platform Maximum bearing capacity of platform 550kg 320kg Retraction of platform Retraction of platform Extension of platform - only Extension of platform - only...
- Page 12 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Do not operate the machine during strong winds or gusts. Do not increase the surface area of platform or load. Increasing the area exposed to Only when the machine is in a firm and flat wind will reduce the machine stability.
-
Page 13: Hazard Of Falling
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual the manufacturer. If an additional device is object. installed on the platform or guardrail for placing tools or other materials, this will increase the Do not bind the platform on the adjacent object. -
Page 14: Hazard Of Collision
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Do not operate the machine if the handrails have The platform can be lowered when there are no not been installed properly and the entrance door people or obstacles in the lower area. -
Page 15: Hazard Of Machine Breakdown
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual and descriptions along with the power plant. It is allowed to connect the welding lead or the Hazard of Machine Breakdown cable only after turning off the power plant. -
Page 16: Pre-Operational Inspection
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual explosive gas. GTJZ0812, GTJZ1012 The weight of each storage battery must reach 28kg. For GTJZ1212 The weight of each storage battery must reach 33kg. Hazard during Lifting... -
Page 17: Symbol Description
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual to determine whether routine maintenance leaks and liquid level is suitable. Please procedures are required. The operator can only add distilled water as needed. Please refer carry out the routine maintenance items to "Operation Instructions". -
Page 18: Inspection On Storage Battery
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual problems in the hydraulic system. Wear protective clothing and protective glasses. Perform the following procedures when the platform is retracted. Ensure the connection of storage battery cable is not corroded. -
Page 19: Function Test
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Function Test Do not operate, unless: You have mastered and practiced the safe machine operating rules stated in this Manual. 1 Avoid dangerous situations. 2 Always perform the pre-operational inspection. -
Page 20: Lifting Function Test
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Lifting function test Display Lifting function start up. screen Result: Platform lifts. Lift and go Lowering function start up down Travel and veer Result: The platform should be lowered ... -
Page 21: Test Rising/Lowering Function
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Result: All the functions cannot work. backward and then stop. Test rising/lowering function Attention: The brake must be able to climb at any gradient and the brake must be able to stop Press lifting button which shall flash. -
Page 22: Test Limited Drive Speed
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual lift to the highest position. For weight more than Test Level Sensor 540kg, the platform lifting height is more than 1 m or 10% of the lifting height (larger) , the... -
Page 23: Test Pit-Hole Protection Device
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Test Pit-hole Protection Device Inspection on Work Site Attention: When platform raised, protection mechanism of pot hole be automatically activated. Two normal limit switches are started to limit travelling of the machine. If protection... -
Page 24: Operating Instructions
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Operating Instructions The machine has a red “power off switch” button on the chassis, press the button to the OFF position, the system is powered off and all functions will stop. -
Page 25: Steering
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual low-speed travelling button light is on. The fast Steering mode of drive speed is active when the low-speed travelling button light is off. Press the travel and veer button which shall flash. -
Page 26: Operate With The Controller On The Ground
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Fold failings at both sides, and hands shall not be placed where might get hurt. 50% of the battery capacity Remove the two wire rope safety pins at the rear of the fixed platform. -
Page 27: Transportation And Hoisting Instructions
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual to the bottom of the filling tube. Do not support the machine weight (please refer overdo it. to the "Specifications"). machine must be on the horizontal ground fixated before releasing the brakes. - Page 28 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Transfer Machine with Forklift Determine center of gravity of the machine according to the chart and picture on the page. Make sure the extension platform, controller and chassis components be safe and reliable.
-
Page 29: Labeling Instructions
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Labeling Instructions Use proper inspection methods to check that all the labels are easy to identify and appropriately positioned. Replace any missed or damaged safety signs. Use neutral soap and clean water to clean the safety signs. - Page 30 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual Beware of electric shocks. Use a charging plug in good working condition Disconnect the switch indicator Platform plug Read Operation Manual Do not drive on uneven roads to prevent rollover...
- Page 31 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual...
- Page 32 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual...
- Page 33 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual...
- Page 34 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual GTJZ0612 GTJZ0812 GTJZ1012 GTJZ1212 Code Description Quantity Manufacturer mark Product model Manufacturer mark Tire under the maximum pressure Beware of cramming or breaking feet No touch with the moving scissors arm. Fix the safety rod before maintenance.
- Page 35 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual...
- Page 36 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual...
- Page 37 GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual...
