Summary of Contents for Nibe F110
- Page 1 User manual Hot water heat pump NIBE F110 UHB EN 2344-1 731477...
- Page 2 Quick guide Navigation Ok button (confirm/select) Up/down buttons (move/increase/reduce) Back button (back/undo/exit) A detailed explanation of the button functions can be found on page 9. How to scroll through menus and make different settings is described on page 10. Increase hot water volume true To temporarily increase the amount of hot water, first press the down button to mark menu 2 (water droplet) and then press the OK button twice.
-
Page 3: Table Of Contents
F110 – An excellent choice 2 The heat pump – the heart of the house Heat pump function Contact with F110 Maintenance of F110 3 F110 – at your service Set the ventilation Set the hot water capacity Get information Adjust the heat pump... -
Page 4: Important Information
Exhaust air installation (fan sp. exhaust air, normal) Serial number must always be given. Certification that the installation is carried out according to instructions in the accompanying installer manual and applicable regulations. Date __________________ Signed _________________________ Chapter 1 | Important information NIBE F110... -
Page 5: Safety Information
Rights to make any design or technical servicing and support. modifications are reserved. ©NIBE 2023. If the supply cable is damaged, only NIBE, its service representative or similar author- ised person may replace it to prevent any danger and damage. -
Page 6: F110 - An Excellent Choice
F110 – An excellent choice F110 is a heat pump that has been developed to supply your house with ventilation and hot water in a cost-effective and environmentally friendly manner. With integrated water heater, immersion heater and control system, reliable and economical hot water production is obtained. -
Page 7: The Heat Pump - The Heart Of The House
22 °C -3 °C 0 °C 0 °C 22 °C The temperatures are only examples and may vary between different installations and time of year. Värmekälla NIBE F110 Chapter 2 | The heat pump – the heart of the house... -
Page 8: Heat Pump Function
Domestic hot water The heat energy that the refrigerant produces in the condens- er is retrieved by the domestic hot water which is heated to the set temperature. Chapter 2 | The heat pump – the heart of the house NIBE F110... -
Page 9: Contact With F110
Hot water temp. B C D E The information menu shows: • on starting. There is a display unit on F110, which is used to communicate with F110. Here you: • when the back button in the main menu is pressed. •... - Page 10 One of the options is pre-selected (white). Press the OK button to confirm the selected option. The selected option has a green tick. Chapter 2 | The heat pump – the heart of the house NIBE F110...
-
Page 11: Maintenance Of F110
Cleaning the air filter The air filter in F110 has to be cleaned regularly; how often depends, for example, on the quantity of particles in the ventilation air. Test, to find out what is most appropriate for your installation. -
Page 12: F110 - At Your Service
If longer time changes are required use the holiday function. Caution The heat pump requires a minimum ventilation flow in order to work properly. An insufficient ventilation flow can result in an alarm and blocking of compressor operation. Chapter 3 | F110 – at your service NIBE F110... -
Page 13: Set The Hot Water Capacity
Status information for comfort mode economy When the time has run out F110 returns to the mode set in the relevant menu menu 2.2. scheduling active can be found on the advanced Select “off"... - Page 14 Scheduling always starts on the date that the start time is set for. If time periods overlap each other at midnight, the time period that starts after midnight is prioritised. Chapter 3 | F110 – at your service NIBE F110...
-
Page 15: Get Information
To view the run status in the event of an alarm, mark the alarm and press the OK button. Ventilation (only Periodic increase or shown with exhaust lux mode for hot wa- alarm log 3.4 air installation) alarm 158 Scheduling Holiday setting NIBE F110 Chapter 3 | F110 – at your service... - Page 16 Information about an alarm. Chapter 3 | F110 – at your service NIBE F110...
-
Page 17: Adjust The Heat Pump
Operating mode auto In this operating mode the heat pump automatically selects MENU 4.8 - ALARM what functions are permitted. NIBE F110 Chapter 3 | F110 – at your service... - Page 18 All settings that are factory setting 4.9.4 available to the user (including advanced menus) can be reset factory setting to default values here. After factory settings, user settings must be reset. Chapter 3 | F110 – at your service NIBE F110...
-
Page 19: Disturbances In Comfort
In the event of an alarm a malfunction has occurred that • Thermostat setting too low F110 cannot rectify itself. The display shows what type of – Contact your installer! alarm it is and lets you reset the alarm. You can also choose •... - Page 20 • Fan speed in forced mode. – Enter menu 1 and select "normal". GURGLING SOUND • Not enough water in the overflow cup. – Top up the water in the overflow cup. Chapter 4 | Disturbances in comfort NIBE F110...
-
Page 21: Technical Data
Technical data Detailed technical specifications for this product can be found in the installation manual (nibe.eu). NIBE F110 Chapter 5 | Technical data... -
Page 22: Glossary
Compresses the gas state refrigerant. When the refrigerant is compressed, the pressure and the temperature increase. CONDENSER Heat exchanger where the hot gas state refrigerant con- denses (cools and becomes a liquid) and heats the hot water. Chapter 6 | Glossary NIBE F110... - Page 23 SUPPLY TEMPERATURE The temperature of the heated water that the heat pump sends out to the heating system. The colder the outdoor temperature, the higher the supply line temperature be- comes. NIBE F110 Chapter 6 | Glossary...
-
Page 24: Item Register
Menu system, 9 Room unit, 9 Disturbances in comfort Manage alarm, 19 Troubleshooting, 19 F110 – An excellent choice, 6 F110 – at your service, 12 Adjust the heat pump, 17 Get information, 15 Set the hot water capacity, 13... -
Page 27: Contact Information
Tel: +48 (0)85 66 28 490 Hannabadsvägen 5, 285 21 Markaryd Tel. +41 (0)58 252 21 00 biawar.com.pl Tel: +46 (0)433-27 30 00 info@nibe.ch info@nibe.se nibe.ch nibe.se For countries not mentioned in this list, contact NIBE Sweden or check nibe.eu for more information. - Page 28 WS release date: 2023-10-31 18:02 Publish date: 2023-11-14 10:32 This is a publication from NIBE Energy Systems. All product illustrations, facts and data are based on the available information at the time of the publication’s approval. NIBE Energy Systems makes reservations for any factual or printing errors in this publication.
