  • Page 1 Installer manual NIBE™ F110 Heat pump IHB GB 1540-5 231974...
  • Page 2 Quick guide Navigation Ok button (confirm/select) Up/down buttons (move/increase/reduce) Back button (back/undo/exit) A detailed explanation of the button functions can be found on page 22. How to scroll through menus and make different settings is described on page 23. Increase hot water volume true To temporarily increase the amount of hot water, first press the down button to mark menu 2 (water droplet) and then press the OK button twice.

  • Page 3: Table Of Contents

    Adjusting ventilation (exhaust air) 12 Technical data 5 Electrical connections Dimensions and setting-out coordinates General Technical specifications Connections Energy labelling Optional connections Electrical circuit diagram 6 Commissioning and adjusting Index Preparations Filling and venting Start-up and inspection NIBE™ F110 Table of Contents |...

  • Page 4: Important Information

    Marking F110 is CE marked and fulfils IP21. The CE marking means that NIBE ensures that the product meets all regulations that are placed on it based on relevant EU directives. The CE mark is obligat- ory for most products sold in the EU, regardless where they are made.
  • Page 5 Exhaust air filter Ventilation, surrounding air or outdoor air (page 15) Pressure drop in the system Hot water System vented Electricity (page 18) Supply connected 230 V Circuit fuses Earth circuit-breaker Miscellaneous Type of installation NIBE™ F110 Chapter 1 | Important information...
  • Page 6 NIBE Energy Systems France Sarl, Zone industrielle RD 28, Rue du Pou du Ciel, 01600 Reyrieux Tel : 04 74 00 92 92 Fax : 04 74 00 42 00 E-mail: info@nibe.fr www.nibe.fr NIBE Energy Systems Ltd, 3C Broom Business Park, Bridge Way, Chesterfield S41 9QG Tel: 0845 095 1200 Fax: 0845 095 1201 E-mail: info@nibe.co.uk www.nibe.co.uk...

  • Page 7: Delivery And Handling

    The centre of gravity is in the upper part. 40 mm Assembly Position F110 on a firm base that can take the weight, ■ preferably on a concrete floor or foundation. Use the product's adjustable feet to obtain a horizontal and stable set-up.
  • Page 8 Ensure that there is sufficient space (300 mm) pump. Approx. 50 mm free space is required on each above F110 for installing ventilation hoses. side, to remove the side panels. The panels do not need to be removed during service, all service can be carried out from the front.

  • Page 9: Supplied Components

    Supplied components Location The kit of supplied items is placed in the lower section of the product. Filter cartridge Silencer Air connection NIBE™ F110 Chapter 2 | Delivery and handling...

  • Page 10: Removing The Covers

    A display cable is installed in the hatch, it can therefore only be lifted out 1.5 m. If the hatch needs to be removed completely, the cable must be detached. Chapter 2 | Delivery and handling NIBE™ F110...
  • Page 11 L E K Heater section 1. Undo the screws at the edge. 2. Twist the cover slightly outward. 3. Move the side cover outwards and backwards. 4. Assembly takes place in the reverse order. NIBE™ F110 Chapter 2 | Delivery and handling...

  • Page 12: The Heat Pump Design

    3 The Heat pump design BT77 XL43 QM25 BT16 BT12 XL44 GQ10 QN20 EB10 BT13 GP12 BT76 QM30 BT35 Chapter 3 | The Heat pump design NIBE™ F110...
  • Page 13 EB10 Compressor heater FD 1 Temperature limiter HVAC components Cooling components FL 1 Safety valve, water heater FL 6 Vacuum valve (only F110 Cu) Evaporator FQ 1 Mixer valve, hot water Condenser GP12 Circulation pump, charging GQ10 Compressor QM 5...

  • Page 14: Pipe And Air Connections

    4 Pipe and air connections System diagram General pipe connections F110 consists of heat pump module, water heater, im- Pipe installation must be carried out in accordance with mersion heater and control system. current norms and directives. When the air passes through the evaporator, the refri- F110 is only designed for be installed vertically.

  • Page 15: Dimensions And Pipe Connections

    XL3 Cold water (mm) XL4 Hot water (mm) WM1 Drip tray (mm) Pipe dimensions Connection XL3 Cold water ext Ø (mm) XL4 Hot water ext Ø (mm) WM2 Overflow water discharge (mm) NIBE™ F110 Chapter 4 | Pipe and air connections...

  • Page 16: Installation Alternative

    The heat pump operates at outdoor temperatures ■ Caution down to -10 °C. Attempt to find a location for F110 on the side of the Noise from the fan can be transferred via the ■ house that faces the least sound sensitive neighbour- ventilation ducts.
  • Page 17 Have sufficient ceiling height so that recirculation of the air is avoided. ■ If incoming air to F110 contains a lot of particles and there is a high hot water demand the heat pump must be equipped with an air filter (HQ12) (supplied), minim- um class G2.

  • Page 18: General Air Connections

    B. If there is a high hot water demand and incoming air to F110 contains a lot of particles the heat pump module must be equipped with an air filter (HQ12) (enclosed).

  • Page 19: Exhaust Air Duct /Kitchen Fan

    A duct in a masonry chimney stack must not be used for extract air. Ventilation flow (exhaust air) Connect F110 so that all exhaust air except exhaust air duct air (kitchen fan) passes the evaporator (EP1) in the heat pump. For optimum heat pump performance, the ventilation flow should not be less than 25 l/s (90 m³/h).

  • Page 20: Electrical Connections

    20 cm from high voltage cables. F110 is connected to an earthed socket with the factory installed power cord, which is supplied with connection plug. Chapter 5 | Electrical connections NIBE™...

  • Page 21: Optional Connections

    External blocking of addition and compressor can be combined. A closed contact results in the electrical output being disconnected. AA2-X13 External F110 AUX2 AUX1 AA2-X13 1 2 3 4 5 6 7 8 9 10 11 12 NIBE™ F110 Chapter 5 | Electrical connections...

  • Page 22: Commissioning And Adjusting

    See page 22 for a more in-depth introduction to the heat pump’s control system. Selecting control The factory setting for F110 is that it controls according to delta-T, for certain water heaters this must be changed to a constant flow. The change is made in menu 5.6 .
  • Page 23 Order a ventilation adjustment to complete the setting. Fan capacity Available Tillgängligt tryck (Pa) pressure (Pa) 100% Luftflöde Airflow (m /h (l/s) Power output Effekt Output, fan 100% Airflow Luftflöde (m /h) (l/s) NIBE™ F110 Chapter 6 | Commissioning and adjusting...

  • Page 24: Control - Introduction

    See page 28. Menu system Menu 4 - MY SYSTEM When F110 is started you come to the information Setting time, date, language, operating mode etc. See menu. Basic information about the heat pump status page 29.
  • Page 25 Mark the applicable option using the up or down button. One of the options is pre-selec- ted (white). Press the OK button to confirm the selected option. The selected option has a green tick. NIBE™ F110 Chapter 7 | Control - Introduction...
  • Page 26 1. Mark, using the up and down keys, one of the ar- rows in the top left corner (at the page number). 2. Press the OK button to scroll between the windows in the start guide. Chapter 7 | Control - Introduction NIBE™ F110...

  • Page 27: Control - Menus

    After 4 hours the ventilation speed returns to the normal setting. The fan speed is shown in brackets (in percent) after each speed alternative. If longer time changes are required use the holiday function. NIBE™ F110 Chapter 8 | Control - Menus...

  • Page 28: Menu 2 - Hot Water

    To remove the scheduling for a When the time has run out F110 returns to the mode particular day, the time for that day must be reset by set in menu 2.2.
  • Page 29 The length of time between increases can be selected here. The time can be set between 1 and 90 days. Factory setting is 14 days. Tick/untick "activated" to start/switch off the function. NIBE™ F110 Chapter 8 | Control - Menus...

  • Page 30: Menu 3 - Info

    You can see inform- ation for the 10 most recent alarms. To view the run status in the event of an alarm, mark the alarm and press the OK button. Chapter 8 | Control - Menus NIBE™ F110...

  • Page 31: Menu 4 - My System

    If you choose mode "add. heat only" the com- pressor is deselected and there is a higher op- All settings that are available to the user (including advanced menus) can be reset to default values here. erating cost. NIBE™ F110 Chapter 8 | Control - Menus...
  • Page 32 Caution After factory settings, user settings must be reset. Chapter 8 | Control - Menus NIBE™ F110...

  • Page 33: Menu 5 - Service

    Here you set the start and stop temperature of the hot water for the different comfort options in menu 2.2 as well as the stop temperature for periodic increase in menu 2.9.1. NIBE™ F110 Chapter 8 | Control - Menus...
  • Page 34 Menu 5.1.16 - installation installation Setting range: outdoor air, ambient air, exhaust air Factory setting: outdoor air Set how F110 is installed here. This menu is not reset by a return to factory settings in menu 4.9.4 or 5.5. Chapter 8 | Control - Menus NIBE™...

  • Page 35: Service

    To drain F110 Cu faster: Slacken off the vacuum valve (FL6) a few turns. Some water will run out at the valve. To drain F110 R faster: Slacken off the vent screw (QM5) a few turns. Some water will run out at the screw.

  • Page 36: Disturbances In Comfort

    10 Disturbances in comfort Alarm list If F110 is not installed together with the indoor module, go directly to section Troubleshooting. Sensor alarm for example BT6/BT13/BT77: In most cases, the heat pump notes operational inter- The sensor has lost contact with the accessory card or ference (operational interference can lead to disturb- is broken.

  • Page 37: Troubleshooting

    If the operational interference is not shown in the dis- play the following tips can be used. Basic actions Start by checking the following possible fault sources: ■ That the indoor module or supply cable to F110 is connected. Group and main fuses of the accommodation. ■ ■...

  • Page 38: Accessories

    Part no. 067 152 Separable valve connector For external installation, relocation or separation. F110 Copper Part no. 624 922 F110 Stainless steel Part no. 624 923 Top cabinet Top cabinet for concealing the ventilation ducts. 245 mm Part no. 089 756 345 mm Part no.

  • Page 39: Technical Data

    12 Technical data Dimensions and setting-out coordinates NIBE™ F110 Chapter 12 | Technical data...

  • Page 40: Technical Specifications

    /h and 20 °C air temperature at 250 m /h and 7 °C air temperature The value varies with the selected fan speed. Visit www.nibe.eu for more extensive sound data including sound to channels. The value can vary with the room's damping capacity. These values apply with a damping of 4 dB.
  • Page 41 -10 - +37 +10 - +37 (factory setting) Pipe connections Hot water ext Ø Cold water ext Ø Safety valve ext Ø Ventilation ext Ø Filter box ext Ø 160 / 125 180 m NIBE™ F110 Chapter 12 | Technical data...
  • Page 42 Tap volume 40 °C at Normal comfort (V litre Idle loss at Normal comfort (P Dimensions and weight Width Depth Height 2030 - 2060 Required headroom 2110 Weight Part No. 066 083 066 025 A20(12), airflow 180 m Chapter 12 | Technical data NIBE™ F110...

  • Page 43: Energy Labelling

    Annual energy consumption water heating, cold cli- 1,452 2,037 1,283 mate, AEC Annual energy consumption water heating, warm 1,452 1,589 1,283 climate, AEC Daily electrical consumption, Q 6.60 8.08 5.83 elec Applied standards EN 16147 NIBE™ F110 Chapter 12 | Technical data...

  • Page 44: Electrical Circuit Diagram

    Electrical circuit diagram Chapter 12 | Technical data NIBE™ F110...

  • Page 45: Index

    Marking, 2 Menu 1 - INDOOR CLIMATE, 25 Menu 2 - HOT WATER, 26 Menu 3 - INFO, 28 Menu 4 - HEAT PUMP, 29 Menu 5 - SERVICE, 31 Menu system, 22 NIBE™ F110 Chapter 13 | Item register...
  • Page 47 Återvinning Lämna avfallshanteringen av emballaget till den installatör som installerade produkten eller till särskilda avfallsstationer. När produkten är uttjänt får den inte slängas bland vanligt hushållsavfall. Den ska lämnas in till särskilda avfallsstationer eller till återförsäljare som tillhandahåller denna typ av service. Felaktig avfallshantering av produkten från användarens sida gör att administrativa påföljder tillämpas i enlighet med gällande lagstiftning.
  • Page 48 WS name: -Gemensamt WS version: a81 (working edition) Publish date: 2015-09-16 09:56 NIBE AB Sweden Hannabadsvägen 5 Box 14 SE-285 21 Markaryd info@nibe.se www.nibe.eu 231974...
