(Note1) Minimum supply pressure: At a downstream side flow rate of zero. Be sure to keep the
minimum supply pressure. (setting pressure+0.05MPa)
(Note2) Setting pressure: At a downstream side flow rate of zero.
(Note3) Setting sensitivity: This is the minimum pressure range that the downstream pressure is
adjustable by conducting fine adjustment of the setting knob on the downstream side of the
precision regulator.
(Note 4)The F.S. means the condition at the maximum setting pressure of the product. (F.S.
IR2000)
(Note 5) Repeatability: This is the reproducibility of the downstream pressure at every operation
(ON/OFF) on the downstream side. The repeatability does not consider the influence of
pressure variation due to aging deterioration, temperature change or oscillation of the
regulator. The aging deterioration means that the downstream pressure varies gradually
affected by change or distortion due to aging of the internal components of the precision
regulator.
(Note 6) Air consumption: This is the combined flow to atmosphere of the bleed and exhaust ports;
when the supply pressure is 1.0 MPa and the downstream setting pressure is 0.8MPa
(maximum setting pressure). It does not include any flow for the relief of downstream
pressure increases due to back pressure or downstream pressure decreases due to the
adjustment of the setting knob.
