PoE-Powered 6-Port Lite Smart Managed PoE+ Switch
with 4 GbE Ports / 2 GbE Uplinks and PoE Passthrough

EXTERNAL COMPONENT DESCRIPTION

FRONT PANEL

The front panel of the Switch consists of six Gigabit ports; four are PoE-enabled and two are Gigabit uplink
ports. Each of the four PSE ports (Ports 1-4) can provide up to 30 watts (with total capacity of up to 60W);
non-PoE devices only receive data.
Reset button (Reset):
To reset the Switch press the button.
LED indicators:
The LED indicators will allow you to monitor, diagnose and troubleshoot any potential problem with the
switch, its connection or attached devices.
The following chart shows the LED indicators of the switch along with explanation of each indicator.
LED COLOR
PWR Orange
LINK/ACT
Green
POE Orange

REAR PANEL

The rear panel of the Switch contains one grounding terminal and an AC power connector as shown.
AC Power Connector:
Power is supplied through an external AC power adapter. It supports 100 – 240 V AC, 50/60 Hz.
Grounding Terminal:
Wire the grounding terminal to an object that provides earth grounding (in rackmount installations,
grounding is typically provided by the metal frame of the mounting rack), which is located on the side of the
power supply connector.

PACKAGE CONTENTS

Before installing the Switch, make sure that the following packing list matches the items in the
packaging. If any part is lost and damaged, please contact your place of purchase as soon as
possible. In addition, make sure that you have the tools to install switches and cables on hand.
• PoE-Powered 6-Port Lite Smart Managed PoE+ Switch with 4 GbE Ports / 2 GbE Uplinks and PoE
Passthrough
• Quick Instruction Guide
• AC Power Cord
6
STATUS
On Power is supplied via the AC adapter or the PD port.
Off No power is supplied to the switch
On A network link has been established
A network link has been established and data packets are being sent and received
Flashing
Off No network link is established
On Port is supplying power to a connected PoE device.
Flashing Abnormal power supply
Off Port is not supplying power to a connected PoE device.
STATUS DESCRIPTION
