EN Quick guide iROB
A
Ethernet connection
B
Power connection
C
Ground cable connection
D
Cable assembly connection
E
Wire feeder connection
F
Switch voltage
This Quick guide is part of the technical documentation and is only valid in connection with the
operating instructions for the system components. Read and observe all documentation for the
system components.
