Hydroflow C Series Installation Manual page 3

Input Voltage
Input Frequency 47-63 Hz (50-60 Hz Nominal)
Material Specifications
Main unit:
End plates:
Water and Dust Protection
IP Rating:
Built-in EMI Filter
Meets:
Safety
Europe and Worldwide:
USA
Canada:
Overvoltage Category II
Environmental Specifications
Installation category:
Cat II; Altitude: <2000 Mtrs (6562'); Operating Temperature: -20 to + 50º C (-4 to 122ºF);
Maximum relative humidity; Max 80% up to 31ºC (87º F) decreasing linearly to 50% RH at 40º C (104º F)
Overload Protection
Insulation
Servicing
No user repairable parts are fitted. Repair must be undertaken by an authorised repair centre.
Panel Indicators
The unit is fitted with LED indicator lights. The Green LED indicates that the power is on, and the Red
indicates that a signal is being transmitted.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children
unless they are older than 8 years and supervised.
NRTL Certification
and CB Test Certificate
In accordance with the
International (IEC) and
NRTL standards listed
above.
All goods are supplied subject to our standard Terms and Conditions, copies of which are available upon request.
87-240V AC (100 -230 VAC Nominal)
Anodised Aluminium
UL V-0 rated polycarbonate
IP68 IEC 60529 (Transducer unit)
FCC 20780 Class B
VDE 0871 Level A
IEC 60335-1/ EN 60335-1
UL60335-1
CSA-C22.2 No:60335-1
Continuous short or open circuit on all outputs.
Basic insulation with the metal enclosure bonded to earth.
Manufactured to BSEN9002
To be installed in accordance with the
latest IEE wiring instructions.
IP66 IEC 60529 (Junction box)
Fuse rating: 1A.
To be installed in accordance with the
latest IEE wiring instructions.
Fuse rating: 1A.
