Using the Charger
The 4-Station Charger can be used to charge from one to four Battery Packs simultaneously.
1. Plug the AC Adapter into the bottom of the charger, then plug the cable from the AC Adapter
into a power outlet that is appropriate to the charger's power rating (this will vary in different
countries).
2. Insert the Battery Pack(s) into the 'D'-shaped charging bays as shown below, making sure to
fully engage the contacts on each.
© 2006 - 2007 Datalogic Scanning, Inc.
Battery
Packs
AC Adapter
LEDs
R44-2669 (Rev. X1)
Instructions
4 Station Charger
PowerScan 7000BT
Charging
Bays
3/07
Advertisement
Table of Contents
Related Manuals for Datalogic PowerScan 7000BT
Summary of Contents for Datalogic PowerScan 7000BT
- Page 1 2. Insert the Battery Pack(s) into the ‘D’-shaped charging bays as shown below, making sure to fully engage the contacts on each. Battery Packs Charging AC Adapter Bays LEDs © 2006 - 2007 Datalogic Scanning, Inc. R44-2669 (Rev. X1) 3/07...
- Page 2 6. If there are no LED indications on the charger, check to see that the power supply is fully plugged in, and that the power outlet is working and provides adequate power. © 2006 - 2007 Datalogic Scanning, Inc. R44-2669 (Rev. X1)
