CPW65 Quick Start

Package Contents

The following items are included in your package. If you find anything missing, contact your system administrator.

LED indicator on the Charger Cradle:

LED Status

Solid white

Off

Mute LED indicator on the CPW65:

LED Status

Solid green

Fast flashing red

Solid red

Fast flashing yellow

The CPW65 is being charged.

The CPW65 is not being charged.

The phone enters the pre-dialing screen. The phone is in a call and unmuted.

The phone is receiving an incoming call.

The phone is muted.

The CPW65 is in the registration mode.

Description

CPW65 Quick Start

Table of Contents

Do you have a question about the CPW65 and is the answer not in the manual?

Page 1 The phone enters the pre-dialing screen. The phone is in a call and unmuted. Fast flashing red The phone is receiving an incoming call. Solid red The phone is muted. Fast flashing yellow The CPW65 is in the registration mode.
Page 2 When charging, the battery LED indicator on the CPW65 glows red. When it is fully charged, the battery LED indicator on the CPW65 will glow green. The CPW65 starts up automatically when charging. Or you can long tap the Mute button on the CPW65 for 3 seconds to turn it on.
Page 3 Place CPW65 in a Conference Room The CPW65 is a wireless expansion mic that can work as the audio input device of the CP965 conference phone. It supports 360-degree audio pickup at a radius of up to 3 meters. You can place the CPW65 on a conference table.
Page 4 CPW65 Quick Start 1. How to turn off the CPW65? Long tap the Mute button on the CPW65 until the battery LED indicator the CPW65 glows red for 3 seconds and then goes out. 2. How to find the CPW65 which has registered with the CP965 conference phone? 1.
Page 5 CPW65 Quick Start 4. How to deregister the CPW65? 1. On the CP965, tap More More > Mic Mic. 2. Select the desired mic, and then tap Detail Detail. 3. Tap Unbind Unbind to deregister the CPW65.
