- Page 1 Kuhl GALAXIS BLDC SAVES NOISE ELECTRICITY User Manual...
- Page 2 Dear Customer, Thank you for choosing Kühl Stylish Fans! It is indeed a wise decision as Kühl Stylish Fans are based on the new BLDC technology that offers energy efficiency, high air-flow & low noise operation even at a high speed. This feature not only helps to keep your home comfortable but also keeps the electricity bill in check.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction....................1 Features of Kühl Galaxis Stylish Fan............. 1 Items in the Box .................... 2 Know your Remote Control Device..............3 Power Saving & Energy Efficient Guide............4 Cost Saving Guide ..................4 Mounting Recommendations & Maintenance ..........5 Safety Guidelines .................. -
Page 4: Introduction
Introduction Add elegant, yet magnificent statement piece to your home with the stylish Kühl Galaxis Series fans. Featuring a stunning design, Kühl Galaxis offers extraordinary air in your home while illuminating it with its fabulous down-lighting. Its streamlined design is a perfect choice to give your home an aesthetically pleasing touch that’s sure to redefine the interiors of your home. -
Page 5: Items In The Box
5 Star Rated: All Kühl Stylish Fans are 5 Star Rated that helps bring down the power consumption, thus, saving a lot of energy and money. Kühl Kühl Kühl Kühl Kühl Kühl Kühl SPECIFICATION Galaxis G8 Galaxis G8 Galaxis G6 Galaxis G6 Galaxis G5 Galaxis G5 Galaxis G5 (1740 mm) (1500 mm) (1670 mm) -
Page 6: Know Your Remote Control Device
Blades 5/6/8 N Supply Wire Pencil Cell AAA Warranty Card Know your Control Device Remote 1. SPEED SETTINGS: Speed varies for five different levels, wherein S1 is the lowest fan speed and S5 is the highest. Press as per your requirement. 2. -
Page 7: Power Saving & Energy Efficient Guide
Power Saving & Energy Efficient Guide Kühl Stylish Fans come with revolutionary and super energy-efficient BLDC motor technology that consumes less energy. Our fans consume only 1/3rd of the power consumed by induction fans. Kühl Stylish Fans run on just 32/37/38 Watt at full speed whereas induction fans run on approx. -
Page 8: Mounting Recommendations & Maintenance
Mounting Recommendations & Maintenance A minimum height of 2.3 meters above the ground is required for the fan's mounting. Allow enough room from the ceiling for the high-level cabinet doors to open. At least 0.25 meters should separate the blade from the ceiling. The horizontal distance from the nearest wall to the blade tip should be around 0.5 times the fan sweep, for example, from 1500 mm, it should be 750 mm. -
Page 9: Assembly Instructions
Assembly Instructions Kühl Galaxis Series Fan Step 1. Place the Motor Assembly As shown in the figure, remove all 5 motor screws Step 2. Assemble the Blade Housing Assemble the Blade Housing with previously removed screws... - Page 10 Step 3. Install All Blades Turn the fan over and install blades with blade screws provided on Blade Housing Step 4A. Install the LED Light Remove 3 screws from LED Fixing Plate (1), Place the Light Housing on it, and tighten with the same 3 screws (2)
- Page 11 Step 4B. Install the LED Light Fasten the LED (1), make wire connections (2) , and close with diffuser (3)
- Page 12 Step 5. Assemble Down Rod and Canopies • Insert Bottom Canopy (2) from Top end of Downrod (3) (no-slit end) • Insert Top Canopy also from the same end • Insert Supply Wire provided through the lower one of the Top side holes in Downrod Step 6.
- Page 13 Caution : Don’t move canopy while screw is tightened Detail X With screws X tightened, there can be scratches incurred on Down Rod on movement of canopy. Always loosen the screw before moving the canopy up / down, and re-tighten the screw after desired placement.
- Page 14 Step 8. Make Input Electrical Connection Make Input Electric connection into the Connector coming out of Fan...
- Page 15 Step 9. Insert The Down Rod Bolt Collared Clamp Bolt Clamp Washer Nut Cotter Pin Insert The Down Rod Bolt with Collared Take the Down Rod Bolt (A) from Clamp through Down Rod and Shaft Shackle kit Shackle Holes. Assemble other bolt parts. Step 10.
- Page 16 Step 11. Open Lower Bolt (A) from Shackle Step 12. Install Shackle and hang the Fan Re-insert Lower Bolt (A) Insert Shackle into Ceiling Hook Raise Fan to Shackle Tighten with Washer, Nut, Lock Nut and Cotter Pin in sequence as written...
- Page 17 Step 13. Connect to Electric supply • Connect the wires from Main Supply (A) into Fan connector (B) • Raise the Canopy and tighten the Canopy screw Step 14. Kühl Galaxis G5 Fan Assembly and Installation Complete...
-
Page 18: How To Operate Kühl Galaxis Bldc Fan
How to operate Kühl Galaxis BLDC Fan Important Instructions regarding Regulator: Fan regulator is not required for this BLDC fan because it is operated by remote. You should ask your electrician to bypass the Regulator in Switch Board wiring. Otherwise fan may not operate properly. If Fan wiring is already through a Regulator in switch board, then make sure that Regulator is always set at max speed, and any change in speed should be done by Remote. - Page 19 Power ON/OFF Button Press POWER button on Remote to start BLDC Fan Power Beep sound will indicate that it is switched ON. Press power button again to switch off / on the BLDC Fan. BLDC fan always re-starts at last Switch OFF speed. In case there is a power failure, the fan will automatically restart at previous speed If you want to switch off the fan during power failure, you have to switch...
- Page 20 KUHL Galaxis-G8-1500/2024 KUHL Galaxis-G8-1740/2024 1670 mm 1500 mm 1740 mm 38 watts 37 watts 37 watts 282 cu m/min 280 cu m/min 285 cu m/min Kühl GALAXIS G6 Kühl GALAXIS G8 Kühl GALAXIS G8 (1670 mm) (1500 mm) (1740 mm)
- Page 21 CONTACT US AT: E-6,7 & 8, Sector-59, Noida, U.P.-201 309, India. Call: 92-789-12345 E-mail: service@kuhl.in or visit us at www.kuhl.in...
