Summary of Contents for KUHL PLATIN D8

  • Page 1 BLDC ENERGY EFFICIENT NOISE Comprehensive KÜHL PLATIN STYLISH FANS FOR MODERN HOMES...
  • Page 2 Welcome to Kühl Dear Customer, Thank you for choosing Kühl Stylish Fans! It is indeed a wise decision as Kühl Stylish Fans are based on the new BLDC technology that offers energy efficiency, high air-flow & low noise operation even at a high speed.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction....................4 Features of Kühl Platin Stylish Fan ............4-5 Items in the Box .................... 6 Know your Remote Control Device..............7 Power Saving & Energy Efficient Guide............8 Cost Saving Guide ..................8 Mounting Recommendations & Maintenance ..........9 Safety Guidelines ..................
  • Page 4: Introduction

    INTRODUCTION Add elegant, yet magnificent statement piece to your home with the stylish Kühl Platin Series fans. Featuring a stunning design, Kühl Platin offers extraordinary air in your home while illuminating it with its fabulous down-lighting. Its streamlined design is a perfect choice to give your home an aesthetically pleasing touch that’s sure to redefine the interiors of your home.
  • Page 5 All Kühl Stylish Fans are 5 Star Rated that helps bring down the power consumption, thus, saving a lot of energy and money Kühl Kühl Kühl Kühl Kühl Kühl Kühl SPECIFICATION Platin D8 Platin D8 Platin D6 Platin D6 Platin D5 Platin D5 Platin D4 (1500 mm) (1200 mm) (1500 mm)
  • Page 6: Items In The Box

    Items in the box Canopies Down Rod False cover Controller Box Motor Assembly LED Light Assembly Shackle Down Rod Bolt Remote Unit Blades 4/5/6/8 N Supply Wire Pencil Cell AAA Warranty Card...
  • Page 7: Know Your Remote Control Device

    Know your Control Device Remote • SPEED SETTINGS: Speed varies for five different levels, wherein S1 is the lowest fan speed and S5 is the highest. Press as per your requirement. • SLEEP MODE: Auto speed control for uninterrupted comfortable sleep. Select this setting before going to bed, and the speed will automatically drop to the minimum pace you specify.
  • Page 8: Power Saving & Energy Efficient Guide

    Power Saving & Energy Efficient Guide Kühl Stylish Fans come with revolutionary and super energy-efficient BLDC motor technology that consumes less energy. Our fans consume only 1/3rd of the power consumed by induction fans. Kühl Stylish Fans run on just 38/29 Watt at full speed whereas induction fans run on approx.
  • Page 9: Mounting Recommendations & Maintenance

    Mounting Recommendations & Maintenance • A minimum height of 2.3 meters above the ground is required for the fan's mounting. Allow enough room from the ceiling for the high-level cabinet doors to open. At least 0.25 meters should separate the blade from the ceiling. •...
  • Page 10: Assembly Instructions

    ASSEMBLY INSTRUCTIONS KÜHL PLATIN SERIES FAN STEP 1 : PLACE THE MOTOR ASSEMBLY OVER THERMOCOL MOTOR PACKING Motor Assembly Thermocol Packing Motor Box STEP 2 : REMOVE THE 16 SCREWS FROM THE TOP BLADE MOUNTING PLATE Do Not remove 5 inner screws Plate A From the Outer edge of Plate A, 16 Blade Screws Removed.
  • Page 11 STEP 3: REMOVE THE 8 SCREWS FROM THE BOTTOM BLADE MOUNTING PLATE Plate B Next, From the Outer edge of 8 Blade Screws Removed Plate B, remove all 8 screws STEP 4. INSERT SCREW INTO LOWER BLADE HOLE Insert one Screw (A) into bottom Blade Hole of 1st blade (10) to be installed, as shown...
  • Page 12 STEP 5A. INSTALL FIRST BLADE Bring the Blade (10) towards Place as shown, and Align Blade Motor Assembly (5), as shown holes with Plates holes STEP 5B. INSTALL FIRST BLADE Tighten the bottom Screw Insert Top screws and tighten...
  • Page 13 STEP 6A. INSTALL ALL BLADES Insert one screw (A) in bottom hole of Align and Fasten the 3 screws on 2nd blade also, and bring blade to 2nd blade also in the same way as Fan Motor Assembly. for 1st Blade. STEP 6B.
  • Page 14 STEP 7. OPEN LED UNIT Housing Diffuser Light Unit Flip Light Unit Upside Down The Light Unit will open Hold Bottom half (A), and turn in Two parts, Housing Upper half (B) (LED Diffuser) and Diffuser. Anti-clockwise STEP 8A. FIX LIGHT HOUSING ON FIXING PLATE Open 3 screws on Fixing Plate (A) Place the Housing (B) of opened LED on Fixing Plate (A) The Light wire ©...
  • Page 15 STEP 8B. FIX LED PANEL ON FIXING PLATE Fix LED Housing with Fixing plate with the 3 screws opened before. STEP 9. CONNECT WIRE CONNECTORS FROM FAN UNIT INTO LED DISK CONNECTORS Insert the 3-Pin and 2-pin Wire connectors (A) into corresponding connector sockets B) on LED Plate.
  • Page 16 STEP 10. PLACE THE FAN IN UPRIGHT POSITION Turn the Fan and Place in Upright Position on Thermocol Packing. STEP 11A. INSERT PCB BOX ONTO SHAFT Open the Nut - Screw (A) on Shaft Insert the PCB Box (B) sideways onto shaft above the Plastic spacer (C)
  • Page 17 STEP 11B. INSERT PCB BOX ONTO SHAFT Push the PCB Box (A) firmly onto Insert back the Screw and tighten shaft till it locks with a click sound with Nut PUSH FIT 3 WAY CONNECTOR YELLOW BLUE WIRE WIRE Wire Connec�on Method WIRE Press Insert Wire...
  • Page 18 PUSH FIT 2 WAY CONNECTOR Wire Connec�on Method Press Insert Wire Release There is no need of matching wire colours in 2-way Push Fit Connector STEP 12A. JOINING MOTOR WIRES Next, we shall connect 3 Motor Wires First connect RED wire from Motor from Shaft into 3-way push connector.
  • Page 19 STEP 12B. JOINING MOTOR WIRES Next connect Yellow wire from Motor Next connect Blue wire from Shaft against Yellow in the 3-way Motor Shaft against Blue in the connector. 3-way connector. STEP 12C. JOINING MOTOR WIRES All Motor Wires connected color matched...
  • Page 20 STEP 13. MAKE LED WIRE CONNECTION Connect the LED wire (A) from Motor into PCB Box Light connector (B) STEP 14. INSERT PCB BOX CLIP Insert Clip (A) over PCB Box slot Push till Clip locks with a click...
  • Page 21 STEP 15. CHECK LINK WIRE CONNECTION !"#"$ The Link Wire (B) should come Pre-inserted into Motor Assembly (5). If found disconnected, do the below: Take Supply Link Wire (11) and insert it through hole (A) in ALU sleeve STEP 16. LINK WIRE CONNECTION "...
  • Page 22 STEP 17A. FALSE COVER INSTALLATION Remove the 3 screws from Fixing Bracket Insert False Cover(3) STEP 17B. FALSE COVER TIGHTENING Fasten again with 3 screws...
  • Page 23 STEP 18. ASSEMBLE DOWN ROD AND CANOPIES Insert Bottom Canopy Insert Supply Wire provided Insert Top Canopy (2) from Top end of Down rod through the lower one of the also from same end (3) (no-slit end) Top side holes in Downrod STEP 19.
  • Page 24 STEP 20A. PREPARE FOR DOWNROD ASSEMBLY Insert Bottom Canopy Insert Supply Wire provided Insert Top Canopy (2) from Top end of Downrod through the lower one of the also from same end (3) (no-slit end) Top side holes in Downrod THE DOWN ROD BOLT Take the Down Rod Bolt (8) from Bolt Assembly Details...
  • Page 25 BOLT ASSEMBLY SEQUENCE Collared Clamp Bolt Clamp Washer Co�er Pin STEP 21A. INSERT THE DOWN ROD BOLT Tighten the Down Rod Bolt Insert The Down Rod Bolt (8) with Collared Clamp (A) through Down Rod and Shaft Holes...
  • Page 26 STEP 21B . DOWN ROD ASSEMBLY Reinsert the Safety screw Safety screw tightened STEP 21C. INSERT THE DOWN ROD BOLT Wire Connec�on Method Press Connector Insert Wire Release Connect the Supply wires (A) from Down Rod into Link Wire connector (B)
  • Page 27 STEP 22. BRING LOWER CANOPY DOWN Loosen The Screw and Bring the Canopy down. STEP 23. OPEN LOWER BOLT A FROM SHACKLE...
  • Page 28 STEP 24. INSTALL SHACKLE AND HANG THE FAN Insert Shackle (7) into Raise Fan to Shackle Re-insert Lower Bolt (A) Ceiling Hook Tighten with Washer, Nut, Lock Nut and Cotter Pin in sequence as written STEP 25. CONNECT TO ELECTRIC SUPPLY Connect the wires from Main Supply(A) Raise the Canopy and tighten into Fan connector(B)
  • Page 29 FAN HUNG ON CEILING HOOK STEP 26A. INSTALL LIGHT DIFFUSER Bring the Light Diffuser(A) to Fan Align the projections and insert Diffuser...
  • Page 30 STEP 26B. INSTALL LIGHT DIFFUSER Turn the Diffuser (A) Clockwise till it locks with a click sound. KÜHL PLATIN D8 FAN ASSEMBLY AND INSTALLATION COMPLETE...
  • Page 31: How To Operate Kühl Platin Bldc Fan

    How to operate Kühl Platin BLDC Fan Important Instructions regarding Regulator: Fan regulator is not required for this BLDC fan because it is operated by remote. You should ask your electrician to bypass the Regulator in Switch Board wiring. Otherwise fan may not operate properly. If Fan wiring is already through a Regulator in switch board, then make sure that Regulator is always set at max speed, and any change in speed should be done by Remote.
  • Page 32 Power ON/OFF Button Press POWER button on Remote to start BLDC Fan. Power Beep sound will indicate that it is switched ON. Press power button again to switch off / on the BLDC Fan. BLDC fan always re-starts at last Switch OFF speed. In case there is a power failure, the fan will automatically restart at previous speed.
  • Page 33 All Kühl PLATIN Fans are 5-Star Rated By BEE KUHL PLATIN-D4-1500/2024 KUHL PLATIN-D5-1500/2024 KUHL PLATIN-D6-1500/2024 KUHL PLATIN-D8-1500/2024 Year Year Year Year 1500 mm 1500 mm 1500 mm 1500 mm 38 watts 38 watts 38 watts 38 watts 280 cu m/min...
  • Page 34 CONTACT US AT: E-6,7 & 8, Sector-59, Noida, U.P.-201 309, India. Call: 92-789-12345 E-mail: service@kuhl.in or visit us at www.kuhl.in...
