AFi HBFB-CYN Assembly Instructions

instructions carefully and familiarize yourself with the different parts.
please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726
PARTS LIST
1 HEADBOARD PANEL 1 PC
2 LEFT LEG
3 RIGHT LEG
4 PILLOW STOP
FOOTBOARD
5
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
Step 1
Attach the legs (2) and (3) to pillow stop (4), using JCB (C) and barrel nut (D). Do not tighten at this
step. Attach leg assembly to headboard panel (1), using wood dowels (A) and JCB (B).
Tighten all with the Allen wrench (E).
D
C
C
PO:
CODE ITEM
HBFB-CYN R-29574X
To ensure lasting safety, we recommend that you periodically check
BED WITH MATCHING FOOTBOARD
ASSEMBLY INSTRUCTIONS
Before assembling your bed, please read through these
ATTENTION! If you receive a damaged or defective item,
Instructions apply for bed sizes
A
Wooden dowel - 4 pcs
1 PC
B
JCB M6 X 40mm (1 1/2") - 6 pcs
1 PC
1 PC
C
JCB M6 X 110mm (4 3/8") - 2 pcs
1 PC
D
4
B
3
A
D
ITEM
R-29575X Congratulations!
Your headboard is now assembled.
that all screws are tight and all parts are secure.
QUEEN > KING
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
C
2
1
A
B
B
A
HARDWARE
D
Barrel Nut - 2pcs
E
Allen wrench - 1pc
Spare - 1pc
B
B
B
A
A
A
Adult assembly Adult assembly
READY
TO
ASSEMBLE
B
Page 1 of 3
