- 1 Pay Attention to the Direction of the Plate
- 2 Place the Rubber Pads on the Base
- 3 Unscrew the M6X10 Screws from the Metal Structure
- 4 Loosen the Screws
- 5 Place the Metal Structure at the Indicated Quote
- 6 Place the Rubber Pads on the Edge of the Glass
- 7 Insert the Structure and the Top into the Marble
- 8 Tighten the M6X10 Screws to the Metal Structure
- Download this manual
PEO LOW
PIECE
Via dell'Elettronica 9 36016 Thiene (VI) ITALY | I+39 0445 827469 | info@eforma.it | www.eforma.it
1
POSIZIONARE LA BASE IN MARMO NEL POSTO PRESCELTO E AVVITARE LA STRUTTURA IN METALLO ALLA BASE IN MARMO
PLACE THE MARBLE BASE IN THE CHOSEN PLACE AND SCREW THE METAL STRUCTURE TO THE MARBLE BASE
2
INSTALLARE I GOMMINI IN PVC SULLA BASE
PLACE THE RUBBER PADS ON THE BASE
Design ollen Pal
Fare attenzione al senso della piastra
Pay attention to the direction of the plate
Istruzioni di montaggio
Assembly instruction
Montageanleitung
Manuel d'installation
Manual de installacion
Data
2x
07/04/2023
1x 5
2x M8x16mm
2x Washer M8 Ø16
6x Rubber Pad
Advertisement
Table of Contents
Related Manuals for diotti PIECE
Summary of Contents for diotti PIECE
- Page 1 Manuel d'installation Manual de installacion Data PEO LOW PIECE Design ollen Pal 07/04/2023 Via dell'Elettronica 9 36016 Thiene (VI) ITALY | I+39 0445 827469 | info@eforma.it | www.eforma.it POSIZIONARE LA BASE IN MARMO NEL POSTO PRESCELTO E AVVITARE LA STRUTTURA IN METALLO ALLA BASE IN MARMO...
- Page 2 SVITARE LE VITI M6X10 DALLA STRUTTURA IN METALLO UNSCREW THE M6X10 SCREWS FROM THE METAL STRUCTURE 1x 4 1. Allentare le viti 1. Loosen the screws 2. Posizionare la struttura di metallo alla quota indicata 2. Place the metal structure at the indicated quote POSARE IL PIANO SULLA STRUTTURA IN METALLO E CHIUDERE SPINGENDOLA VERSO LA BASE IN MARMa LAY THE TOP ON THE METAL STRUCTURE AND CLOSE BY PUSHING IT TOWARDS THE MARBLE BASE 1.
