N323TR
TEMPERATURE CONTROLLER – USER GUIDE – V1.8x K
1.
SAFETY ALERTS
The symbols below are used in the device and throughout this
manual to draw the user's attention to valuable information related to
device safety and use.
CAUTION:
Read the manual fully before
installing and operating the
device.
All safety recommendations appearing in this manual must be
followed to ensure personal safety and prevent damage to the
instrument or system. If the instrument is used in a manner other
than that specified in this manual, the device's safety protections may
not be effective.
2.
SUMMARY
1. SAFETY ALERTS ........................................................................ 1
2. SUMMARY .................................................................................. 1
3. PRESENTATION ......................................................................... 1
4. SPECIFICATIONS ....................................................................... 1
5. ELECTRICAL CONNECTIONS ................................................... 2
5.1 INSTALLATION RECOMMENDATIONS .............................. 2
6. OPERATION................................................................................ 2
6.1 LEVEL 1 – SETPOINT ADJUSTMENT LEVEL .................... 2
6.2 LEVEL 2 – OPERATION MODE LEVEL .............................. 2
6.3 LEVEL 3 – DEFROST SCHEDULING LEVEL ..................... 4
6.4 LEVEL 4 – CALIBRATION LEVEL ....................................... 4
7. WORKING WITH THE CONTROLLER ....................................... 5
7.1 DEFROST PROCESS .......................................................... 5
8. CONFIGURATION PROTECTION .............................................. 5
8.1 CONFIGURATION PROTECTION OPERATION................. 5
9. MASTER PASSWORD ................................................................ 5
9.1 HOW TO USE YOUR MASTER PASSWORD ..................... 5
10. ERROR INDICATION .................................................................. 5
11. WARRANTY ................................................................................ 5
NOVUS AUTOMATION
CAUTION OR HAZARD:
Risk of electric shock.
3.
PRESENTATION
N323TR is a temperature controller suitable for refrigeration, with
functions designed for temperature control applications and
optimization of the defrosting process.
Its internal clock allows you to program defrost times and days.
It has 2 input channels for temperature sensors (NTC thermistors)
that measure the temperature of the monitored environment and the
evaporator module.
It has 3 independent outputs to control the compressor (refrigeration
output), the defrost module, and the fan.
The details of the controller are in accordance with the purchase
order and are shown on the label attached to the controller.
4.
SPECIFICATIONS
SENSOR INPUT:
2 NTC Thermistors: Type 10 kΩ @ 25 °C | Measurement range:
-50 to 120 °C (-58 to 248 °F) | Accuracy: 0.6 °C (1.1 °F).
Note: The sensors are supplied with the equipment.
Its operating range is -30 to 105 °C (-22 to 221 °F). It has a 3 m
long cable (2 x 0.5 mm²), which can be extended up to 200
meters.
Maximum error when interchanging original NTC sensors: 0.75 °C
(33.35 °F). This error can be removed by using the Offset
parameter of the controller.
Measurement resolution: ........ 0.1 °C in the range -19.9 to 199.9 °C
........................................................................... (-3.8 to 391.8 °F).
............................................................................ 1 °C: Elsewhere.
Note: The equipment maintains accuracy over the entire range,
although the low resolution of the display in a portion of the range
does not allow it to be visualized.
OUTPUT1: .............................................. SPDT Relay; 1 HP 250 Vac /
.................................................... 1/3 HP 125 Vac (16 A Resistive)
Optionally: ..................................... Pulse, 5 Vdc, 25 mA maximum
OUTPUT 2: ........................................... SPST-NO relay, 3 A / 250 Vac
OUTPUT 3: ........................................... SPST-NO relay, 3 A / 250 Vac
POWER SUPPLY:
Voltage:................................................. 100~240 Vac/dc (± 10 %)
Optionally: ..................................................... 24 V (12~30 Vdc) (*)
Frequency: ...................................................................... 50~60 Hz
Consumption:.......................................................................... 5 VA
(*) Note: Models with a 24 V power supply do not have electrical
isolation between the power supply, input, and RS485
communication circuits.
In direct current (Vdc) supply networks, you must observe the
polarity of the connection.
Dimensions:
Width x Height x Depth: ....................................... 75 x 33 x 75 mm
Panel cutout: ................................................................ 70 x 29 mm
Weight:.................................................................................. 100 g
1/5
