pulse
•
Alarm Output 2: SPST relay 3A/250Vca (optional)
2.4.
POWER
Mains power is connected to terminals 5 and 6. Check the upper
side of the housing for proper power indication.
Novus Produtos Eletrônicos Ltda. / Tel: +55-51-3323-3600 / www.novus.com.br
about three seconds. After this time the controller will show the first
parameter of the next level. By keeping the INDEX key pressed for
another 3 seconds the next level will be accessed.
Release the
key when the desired level is reached. Press once
the
to go to the next prompt in the same level.
When a parameter is shown the display will alternate its name and
value. The value can then be changed by pressing the
key.
or
1/3
