- Page 1 UHD12-EXB400-K 18Gbps HDMI 1x2 Splitter Follow us on Youtube and Facebook Over CAT6 Up To 400ft U S E R M A N U A L www.orei.com...
-
Page 2: Table Of Contents
Table of Contents Introduction Features Package Contents Specifications Operation Controls and Functions EDID Mode ASCII Commands Application Example Thank you for purchasing this product Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. - Page 3 Registration Page Please Activate your warranty by registering our product through the link below - www.orei.com/register Technical Support Need Help? Our experienced Technical Support Team is here for you to answer your questions, give technical advice or help troubleshoot your project to get you installed on time and on budget.
-
Page 4: Introduction
Introduction The UHD12-EXB400-K can distribute 1 source signal to 2 displays up to 400ft, with video resolution up to 4K@60Hz 4:4:4. Features an HDMI loop output on the Transmitter to connect a display at the source. The HDMI signal can be extended up to 394ft/120m at the resolution of 4K@60Hz, or 492ft/150m at 1080P@60Hz via a single CAT6/6a/7 cable. -
Page 5: Features
Bi-directional IR, and RS-232 control 10. Advanced EDID management 11. One-way POE (Power Over Ethernet) function from Transmitter to Receiver. 12. Features HDBaseT Technology Package Contents 1× UHD12-EXB400-K 1× 5pin-3.81mm Phoenix Con- nector (male) (Transmitter) 2× HDBaseT Receiver 6× Mounting Ear 1×... -
Page 6: Specifications
Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2/1.x Video Bandwidth 594MHz/18Gbps Video Resolution 480i ~1080P@50/60Hz, 2K@24/30/60Hz, 4K@24/30/60Hz 8-bit, 10-bit, 12-bit (1080p@60Hz) Color Depth 8-bit (4K & 2K@60Hz YUV4:4:4) 8-bit, 10-bit, 12-bit (4K & 2K@60Hz YCbCr 4:2:2/4:2:0) Color Space RGB 4:4:4, YCbCr 4:4:4 / 4:2:2 / 4:2:0 HDR, HDR10+, HLG, Dolby vision (Note: For Dolby vision, the local HDMI loopout supports... - Page 7 Specifications Connection Input: 1× HDBT IN [RJ45, 8-pin female] 1 × IR IN [3.5mm Stereo Mini-jack] 1 × RS-232 [Phoenix jack] Receiver 1 × SERVICE [Mini-USB, Update port] Output: 1 × HDMI Type A [19-pin female] 1 × AUDIO OUT [3.5mm Stereo Mini-jack] 1 ×...
-
Page 8: Operation Controls And Functions
Operation Controls and Functions Transmitter: Front Panel LOOP Name Function Description When the device is powered on, the red power LED will Power LED turn on. When an active source device is connected to the HDMI IN IN LED port, the green LED will turn on. When an active display is connected to the HDMI LOOP LOOP LED OUT port, the green LED will turn on. - Page 9 Operation Controls and Functions Transmitter: Rear Panel AUDIO OUT RS-232 HDBT OUTPUT LOOP OUT EDID HDMI DC 24V Name Function Description Connect to a PC or control system via a 3-pin phoenix connector cable for three functions: 1, Firmware update; RS-232 2, Control the Splitter via RS-232 commands;...
- Page 10 Operation Controls and Functions Name Function Description Power switch Press this switch to power on/off the device. EDID DIAL Used to set EDID mode. Please refer to “EDID Mode (Page 13)” switch for details. IN: HDMI input port; connect an HDMI source device such as DVD Player or set-top box with an HDMI cable.
- Page 11 Operation Controls and Functions Receiver SERVICE IR IN IR OUT HDMI OUT AUDIO OUT Name Function Description When the Receiver is powered on, the red power LED will Power LED turn on. SERVICE port Used for firmware update. Plug DC 24V/1A power supply into the unit and connect the adapter to an AC outlet.
- Page 12 Operation Controls and Functions Name Function Description HDMI output port; connect an HDMI display such as TV or HDMI OUT Projector with an HDMI cable. AUDIO OUT Audio output port; connect to a speaker or soundbar. Connect the IR Receiver cable. The IR signal will be sent IR IN to the IR OUT port of the Transmitter.
-
Page 13: Edid Mode
EDID Mode The defined EDID setting list of the product is shown below. 1 means “UP” and 0 means “DOWN” EDID EDID EDID Description EDID Description Mode Mode 11111 1080P, Stereo 2.0 01111 4K/2K60Hz_444, Dolby/DTS 5.1 11110 1080P, Dolby/DTS 5.1 01110 4K/2K60Hz_444, HD Audio 7.1 4K/2K60Hz_444, Stereo 2.0 11101 1080P, HD Audio 7.1... -
Page 14: Ascii Commands
ASCII Commands The product also supports ASCII command control. Connect the RS- 232 port of the product to a PC with a 3-pin phoenix connector cable. Then, open a Serial Command tool on the PC to send ASCII com- mands to control the product. The ASCII commands list is as below. - Page 15 Default Code System Setting help! List all commands help! r type! Get device model r type! UHD12-EXB400-K Get the unit all status: Get device current r status! r status! power, in/out connec- status tion, edid mode r fw ver- r fw MCU BOOT: Vx.xx.xx...
- Page 16 ASCII Commands Command Function Descrip- Example Feedback Default Code tion Output Setting Set hdmi loop output Enable hdmi loop out s hdmi stream on/off s hdmi stream enable stream z! z=0~1 (0:disable,1:en- stream 1 ! Disable hdmi loop out able) stream Set hdmi loop output Enable hdmi loop out...
- Page 17 ASCII Commands Command Function Description Example Feedback Default Code Output Setting r hdbt y Get hdbt output y hdcp status, r hdbt 1 Enable hdbt hdcp! y=0~2 (0=all) hdcp! output 1 hdcp r hdbt Get hdbt output y stream status, r hdbt 1 Enable hdbt stream!
- Page 18 ASCII Commands Command Function Description Example Feedback Default Code EDID Setting s edid s edid user1 user1 00 user1 EDID data: 00 Set user1 EDID data FF FF FF FF FF …. ff ff ff ff …. ! FF …! r edid user1 EDID data : 00 Get user1 EDID data...
-
Page 19: Application Example
Application Example Amplifier IR Receiver IR Blaster 2.0 Speakers Transmitter AUDIO OUT RS-232 HDBT OUTPUT LOOP OUT EDID HDMI DC 24V Power Supply CAT6/6a/7 Receiver DVD or Blu-ray Player HDMI OUT AUDIO OUT IR IN IR OUT HDMI Matrix with RS-232 function 2.0 Speakers IR Receiver... - Page 20 18Gbps HDMI 1x2 Splitter Over CAT6 Up To 400ft UHD12-EXB400-K www.orei.com © 2023...
