- Page 1 DC TO AC POWER INVERTER 600W User Manual RND 320-00133 www.rnd-electronics.com CAUTION: Read the instructions before using the machine...
- Page 2 DC12V OR 24V TO AC220V~240V INSTRUCTION MANUAL Please read the user manual before use. USEFUL APPLICATIONS RUN NOTEBOOK COMPUTERS, RADIOS, TVs, VCRs, LAMPS, FANS, FAX, DRILL, ..ETC. SPECIFICATION INPUT VOLTAGE RANGE : DC 10~15V (12V) // DC 20~30V (24V) INPUT FULL LOAD CURRENT : 60A (12V) // 30A (24V) NORMAL STANDBY INPUT CURRENT : <0.6A (12V) // <0.4A (24V) EuP MODE STANDBY INPUT CURRENT : 0.03A~0.15A...
- Page 3 TROUBLESHOOTING IF THE INVERTER DOES NOT APPEAR TO BE FUNCTIONING PROPERLY, THERE ARE SEVERAL REASONS WHY THE INVERTER MAY NOT BE RESPONDING. POOR CONTACT *CLEAN CONTACT PARTS THOROUGHLY RECEPTACLE HAS NO POWER *CHECK CAR FUSE, REPLACE DAMAGED FUSE *CHECK RECEPTACLE WIRING. REPAIR IF NECESSARY FUSE IS BLOWN *THE FUSE IS LOCATED INSIDE THE P.C.B.
- Page 4 WHEN CONNECTED TO ANY APPLIANCE, BE SURE TO TURN ON INVERTER FIRST. AND THEN TURN ON THE POWER SWITCH OF THE APPLIANCE. WHEN CONNECTED TO ANY APPLIANCE, BE SURE TO TURN ON INVERTER FIRST. AND THEN TURN ON THE POWER SWITCH OF THE APPLIANCE.
- Page 5 WHEN THE INVERTER OPERATES IN FULL OUTPUT CAPACI- TY FOR A LONG PERIOD, THE TEMPERATURE OF THE INVERT- ER WILL INCREASE AND POTENTIALLY SHUT DOWN BY THE OVER-TEMPERATURE PROTECTION. THEREFORE, IT IS REC- OMMENDED TO REDUCE THE AC OUTPUT CAPACITY IF A LONG CONTINUOUS OPERATING TIME IS REQUIRED.
- Page 6 www.rnd-electronics.com...
