Vulcan-Hart VSB34R Specifications

mODEL VSB34R
SpECIFICATIONS:
Heavy duty gas salamander broiler, Vulcan-Hart Model No.
VSB-34R. Stainless steel reinforced back riser for mounting over
GH Series heavy duty ranges. Stainless steel front, top and sides.
Six 11,000 BTU/hr bar-type burners with stainless steel radiants;
66,000 BTU/hr total input. Infinite heat control valve. Pilot ignition
system. Chrome plated trigger grip control handle provides posi-
tive positioning of the broiling carriage. Heavy duty chrome plated
broiling grid measures 27 / "w x 13"d. Removable full width spillage
1
2
pan. / " top gas connection and gas pressure regulator.
3
4
Exterior dimensions: 34"w x 19"d x 17
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
VULCAN-HART COmpANy, p.O. BOX 696, LOUISVILLE, Ky 40201, TEL. 1-800-814-2028
F-32550 (04-07)
/ "h.
5
8
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
mODEL VSB34R
34" HEAVy DUTy GAS SALAmANDER BROILER
VSB34R 34" wide, 66,000 BTU/hr.
■
STANDARD FEATURES
■ Stainless steel reinforced back riser for mounting over GH
Series heavy duty ranges.
■ Stainless steel front, top and sides.
■ Six 11,000 BTU/hr bar-type burners with stainless steel radiants;
66,000 BTU/hr total input.
■ Infinite heat control valves.
■ Standing pilot ignition system.
■ Chrome plated trigger grip control handle provides positive
positioning of the broiling carriage. Heavy duty chrome plated
broiling grid measures 27
■ Removable full width spillage pan.
/ " top gas connection and gas pressure regulator.
3
■
4
■ One year limited parts and labor warranty.
OpTIONS
Set of stainless steel wall mount brackets.
■
Set of 4" legs with adjustable feet.
■
C.S.I. Section 11420
/ "w x 13"d.
1
2
