Vulcan-Hart 1T4024D Specifications

SPECIFICATIONS:
2
/ jacketed direct steam tilting kettle, 40 quart capacity,
3
Vulcan-Hart Model No. 1T4024D. Steam jacketed kettle
mounted on (18") (28") high base cabinet with stainless steel
frame, front full height door, stainless steel side and alumi-
nized rear panel with 6" adjustable legs with flanged feet for
anchoring. Fully welded hemispheric bottom kettle with type
304 stainless steel jacket and type 316 stainless steel liner.
Jacket tested to 50 psi (3.4 kg/cm
steam flow at 15 psi at the kettle. 12" single temperature
deck mounted faucet. Includes safety pop-off valve, pressure
reducing valve and steam control valve on right trunnion leg.
Exterior dimensions: 24"w x 35.4"d x (18") (28")h on 6" adjust-
able legs.
Classified by U L to NSF Std. #4. Meets ASME code.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32385 (2-06)
2 ). Requires 22 lbs./hr. of
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
MODEL 1T4024D
40 QUART DIRECT STEAM TILTING
KETTLE ON CABINET BASE
STANDARD FEATURES
2
/ jacketed direct steam tilting kettle, 40 quart capacity.
3
Steam jacketed kettle mounted on (18") (28") high base
cabinet with stainless steel frame, front full height door,
stainless steel side and aluminized rear panel with 6"
adjustable legs with flanged feet for anchoring.
Fully welded hemispheric bottom kettle with type 304 stain-
less steel jacket and type 316 stainless steel liner. Jacket
tested to 50 psi (3.4 kg/cm
flow at 15 psi at the kettle.
12" single temperature deck mounted faucet.
Includes safety pop-off valve, pressure reducing valve and
steam control valve on right trunnion leg.
One year limited parts and labor warranty.
OPTIONS
Correction package.
- Cabinet door with hasp (lock by others).
- Security type tamper resistant fasteners.
Tilting kettle strainer.
Pressure reducing valve if steam supply exceeds 50 psi.
12" dual temperature faucet.
Mount and interconnect kettle with boiler base at factory.
Includes steam supply piping. Shipped on one skid.
Second year extended limited parts and labor warranty.
ACCESSORIES
Stainless steel back panel.
Lift-off cover.
Contour measuring strip.
Single perforated stainless steel basket.
Ball float trap.
Pressure reducing valve.
C.S.I. Section 11420
2 ). Requires 22 lbs./hr. steam
