Vulcan-Hart GL40 Specifications

GL40 40 gallons
GS60 60 gallons
GL80 80 gallons
GT100 100 gallons
GT125 125 gallons
GT150 150 gallons
SPECIFICATIONS:
Gas fully jacketed stationary kettle, Vulcan Model No. ________.
Kettle is mounted on 2" diameter legs with adjustable flanged
feet. Cover to be stainless steel dome shaped with drop type
handle and insulated knob. The dish shaped interior bottom is
sloped to the front for a smooth product flow through a mounted,
tapered, 2" plug type food product draw-off valve. Draw-off
includes opening strainer. Graduated measuring rod. Furnished
standard with a 15 PSI relief valve, vacuum relief valve, thermo-
stat with a combination gas control valve and electronic ignition,
low water cut-off control and a pressure limit switch and pressure
gauge.
CSA design certified. Classified by U L to NSF Std. #4. Meets
ASME code.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-31643 (07-07)
151 liters
227 liters
303 liters
379 liters
473 liters
568 liters
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
GS, GL, GT SERIES
GAS FULLY JACKETED KETTLE
STANDARD FEATURES
Kettle fully steam jacketed.
Mounted on stainless steel 2" diameter legs with adjustable
flange feet.
Stainless steel dome shaped spring assist cover with drop type
handle.
Kettle interior bottom sloped to front for smooth product flow
through a mounted, tapered, plug type food product draw-off
valve of standard 2" diameter.
Draw-off opening strainer.
Graduated measuring rod.
15 PSI relief valve.
Vacuum pressure relief valve.
Thermostat with a combination gas control valve and elec-
tronic ignition.
Low water cut-off control.
Pressure limit switch and pressure gauge.
Faucet bracket.
One year limited parts and labor warranty.
OPTIONS
3" compression type draw-off valve in place of 2".
Change in leg height to increase clearance under draw-off
valve.
Condensate ring on cover hinges.
Swing drain collector.
316 stainless steel jacket liner
Second year extended limited parts and labor warranty.
ACCESSORIES
Stainless steel draw-off extension tube.
(12") (18" double jointed) single pantry faucet.
(12") (18" double jointed) double pantry faucet.
Double pantry washdown hose with 16" add-on faucet with
backflow preventer.
Double pantry washdown hose with backflow preventer.
Double pantry pot filler and backflow preventer.
Rotating tri-basket assembly.
Clean-up kit to include draw-off brush, clean-up brush with
36" handle and paddle scraper with 40" handle.
48" stainless steel whip.
C.S.I. Section 11420
