Vulcan-Hart 1T2018D Specifications

SPECIFICATIONS:
One 24 quart 2 / jacketed tilting steam kettle mounted on a 18"
3
wide cabinet base, Vulcan-Hart Model No. 1T2018D. Steam
jacketed kettle mounted on 28" high base cabinet with stainless
steel frame, front full height door, stainless steel side rear panel
with 6" adjustable legs with flanged feet for anchoring. Fully
welded hemispheric bottom kettle with type 304 stainless steel
jacket and type 316 stainless steel liner. Jacket tested to 50 psi
(3.4 kg/cm 2 ). Requires 21 lbs./1 hr. of steam flow at the kettle.
Steam control valve on right trunnion leg. 12" single temperature
deck mounted faucet.
Exterior dimensions: 18"w x 35.4"d x 28"h on 6" adjustable legs.
Overall height to the lip of the kettle 47
1
56 / ".
4
Classified by UL to NSF Std. #4. Meets ASME code.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-31680 (2-06)
1
/ ", to the top of the handle
2
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
MODEL 1T2018D
24 QUART TILTING STEAM KETTLE ON CABINET BASE
1T2018D – 18" wide
STANDARD FEATURES
One 2 / jacketed tilting steam kettle, 24 quart capacity.
3
Steam jacketed kettle mounted on 28" high base cabinet with
stainless steel frame, front full height door, stainless steel
side rear panel with 6" adjustable legs with flanged feet for
anchoring.
Fully welded hemispheric bottom kettle with type 304 stainless
steel jacket and type 316 stainless steel liner. Jacket tested
to 50 psi (3.4 kg/cm 2 ). Requires 21 lbs./hr. of steam flow per
hour at the kettle.
Steam control valve on right trunnion leg.
12" single temperature deck mounted faucet.
One year limited parts and labor warranty.
OPTIONS
Correction package.
- Cabinet door with hasp (lock by others).
- Security type tamper resistant fasteners.
Tilting kettle strainer.
12" dual temperature faucet.
Mount and interconnect kettle with boiler base at factory.
Includes steam supply piping. Shipped on one skid.
Second year extended limited parts and labor warranty.
ACCESSORIES
Lift-off cover.
Contour measuring strip.
Single perforated stainless steel basket.
Ball float trap.
Pressure reducing valve.
C.S.I. Section 11420
