Vulcan-Hart MG24 Specifications

optional step-up rear burners
SPECIFICATIONS:
Modular gas restaurant range with four 26,000 BTU/hr. open
burners, Vulcan-Hart Model No. MG24. Four removable level
top cast iron grates. Total top BTU/hr. input 104,000. Stainless
steel front, front top, sides and riser. 4" adjustable nickel plated
legs. Lift-off anti-clog open burner heads and full width pull out
crumb drawer. Pressure regulator. Gas supply to be (natural)
(propane).
Exterior dimensions: 24"w x 29
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS WHEN ORDERING.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32094 (10-03)
MG24 Shown with
3 / "d x 12 1 / "h.
4 2
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
MG24 SERIES
MODULAR GAS RESTAURANT RANGE
STANDARD FEATURES
Stainless steel front, front top, sides and riser.
Four 26,000 BTU/hr. open burners. Pilot for every burner.
Level cast iron burner grates for easy sliding of pots and pans
across the open top sections.
Each open top removable grate section is cast in one piece
with the burner spillover bowl. Grate size 12" x 12".
Full width pull out crumb tray under the burners.
Lift-off anti clog open burner heads.
Cool to the touch control knobs.
Full width stainless steel panel behind controls.
4" adjustable nickel plated legs, shipped attached.
Pressure regulator.
Ideal for 9, 12, or 16 quart stock pots.
One year limited parts and labor warranty.
OPTIONS
Second year extended limited parts and labor warranty.
TOP OPTIONS
Even Heat Hot Top Sections
• 20,000 BTU/hr. input per section.
• 12" x 24" cast iron top sections.
• Substitute for open top burner 12" sections, specify
location(s).
• Corrugated heat absorbing ribs on under side of casting.
• Use for larger stock pots.
Step-Up Burners
• Rear burners elevated 4".
ACCESSORIES
3
/ " x 4 ft. flexible gas hose with quick disconnect and
4
restraining device.
C.S.I. Section 11420
