Vulcan-Hart MG12 Specifications

SPECIFICATIONS:
12" modular gas restaurant range Vulcan-Hart Model No.
MG12. Two 26,000 BTU/hr. cast burners with lift-off heads.
52,000 BTU/hr. total input. Two 12" x 12" heavy cast top grates
with aeration bowls. Full width crumb drawer. Stainless steel
front, front top, sides and flue riser. 4" adjustable legs. Gas
pressure regulator. Gas supply to be (natural) (propane).
Exterior dimensions: 12"w x 29
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS WHEN ORDERING.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32197 (10-03)
3 / "d x 11 1 / "h.
4 2
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
MG12 SERIES
MODULAR GAS RESTAURANT RANGE
STANDARD FEATURES
Stainless steel front, front top, sides and riser.
Two 26,000 BTU/hr. open burners. Pilot for every burner.
Lift-off anti clog open burner heads.
Open top removable grate section is cast in one piece with
the burner spillover bowl. Grate size 12" x 12".
Full width pull out crumb tray under the burners.
Full width stainless steel panel behind controls.
4" adjustable nickel plated legs, shipped attached.
Cool to the touch control knobs.
Pressure regulator.
One year limited parts and labor warranty.
OPTIONS
Second year extended limited parts and labor warranty.
TOP OPTIONS
Even Heat Hot Top Sections
• 20,000 BTU/hr. input per section.
• 12" x 24" cast iron top sections.
• Substitute for open top burners.
• Corrugated heat absorbing ribs on under side of casting.
• Use for larger stock pots.
Step-Up Burners
• Rear burners elevated 4".
ACCESSORIES
3 / " x 4 ft. flexible gas hose with quick disconnect and
4
restraining device.
C.S.I. Section 11420
