Vulcan-Hart GHX Specifications

Model GHX45 shown
with 17" Backguard
SPECIFICATIONS
17" wide heavy duty expando gas range, Vulcan-Hart Model No.
___________. Stainless steel body and 6" adjustable legs.
1 ⁄ " diameter front gas manifold.
1
4
GHX45
Two 30,000 BTU/hr. heavy cast two piece "Flame Retention"
burners with individual pilots. Total input 60,000 BTU/hr.
Heavy cast iron aeration plates with deep bowls and removable
cast top grates.
GHX60T
⁄ " polished steel griddle plate with front grease trough and
3
4
removable grease collector. 4" side splashers and 5
splasher. Two 20,000 BTU/hr. burners. Pilot ignition system.
Total input 40,000 BTU/hr. Heat absorbent re brick and
griddle leveling bolts.
GHX72
One polished cast iron hot top section measures 17" w x 23
Ceramic re brick under hot top. Two 20,000 BTU/hr. burners.
Total input 40,000 BTU/hr. Pilot ignition system.
Exterior dimensions: 17"w x 39
CSA design certi ed. NSF listed.
SPECIFY TYPE OF GAS AND FINISH WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32238 (05-06)
Model GHX60T shown
with 17" Backguard
⁄ " rear
5
8
⁄ "d.
13
16
⁄ "d x 36" working height.
1
8
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
GHX SERIES
HEAVY DUTY EXPANDO GAS RANGE
GHX45 Two 30,000 BTU/hr. open burners
GHX60T 17" wide griddle top
GHX72 17" wide even heat top
STANDARD FEATURES
Stainless steel body.
1 ⁄ " diameter front gas manifold.
1
4
17" wide cabinet storage base with door.
One year limited parts and labor warranty.
OPTIONS
Stainless steel back nishing panel.
Common front top ledge up to 68" wide. (Not for use on
griddle tops, spreader plates and deep fat fryers.)
Cap and cover manifold end(s). (No charge.)
Set of four 5" diameter casters, two locking.
Stainless steel dolly frame with casters, up to 102" wide.
Rear gas connection. (Reference spec sheet F-31525.)
Second year extended limited parts and labor warranty.
C.S.I. Section 11420
Model GHX72 shown
with 17" Backguard
