Summary of Contents for Ford F-650 2025

Page 1 2025 FORD F-650 / 750 Owner's Manual...
Page 3 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2023 All rights reserved. Part Number: -202310-20231031170230...
Page 5: Table Of Contents
Table of Contents Introduction Seatbelts About This Manual ..........7 Principle of Operation .........38 Perchlorate ............11 Fastening the Seatbelts ......39 Ford Credit ............11 Seatbelt Height Adjustment .....42 Replacement Parts Recommendation Seatbelt Warning Lamp and Indicator ................11 Chime ............43 Special Notices ..........12 Seatbelt Reminder ........43...
Page 6 Table of Contents Instrument Lighting Dimmer ....56 Auxiliary Power Points Headlamp Exit Delay ........56 Auxiliary Power Points ........95 Daytime Running Lamps - Vehicles With: Daytime Running Lamps (DRL) ..57 USB Ports Daytime Running Lamps - Vehicles With: Locating the USB Ports .......97 Configurable Daytime Running Lamps Playing Media Using the USB Port ..97 ................57...
Page 7 Table of Contents Principle of Operation - Vehicles With: Transmission Air Brakes ............153 Automatic Transmission ......129 Using Stability Control ......154 Power Take-Off ..........134 Parking Aids Rear Axle Rear View Camera ........156 General Information ........135 Cruise Control Pneumatic Locking Differ- What Is Cruise Control .......157 ential Switching Cruise Control On and Off What Is the Pneumatic Locking...
Page 8 Table of Contents Cold Weather Precautions - 7.3L ...187 Engine Oil Dipstick - 6.7L Diesel ....226 Breaking-In .............187 Engine Oil Dipstick - 7.3L ......226 Driving Through Water ......188 Engine Oil Check .........226 Changing the Engine Oil and Oil Filter .................227 Roadside Emergencies Oil Change Indicator Reset .....228 Hazard Flashers ...........189...
Page 9 Table of Contents Air Conditioning System Capacity and Vehicle Care Specification - 7.3L ........305 General Information ........261 Washer Fluid Specification .....305 Cleaning Products ........261 Diesel Exhaust Fluid Capacity and Cleaning the Exterior ........261 Specification ..........306 Waxing ............263 Automatic Transmission Fluid Capacity Cleaning the Engine ........263 and Specification - Diesel ....306 Cleaning the Windows and Wiper Blades...
Page 10 Table of Contents Ford Protect Ford Protect ..........322 Scheduled Maintenance General Maintenance Information ..324 Normal Scheduled Maintenance ..329 Special Operating Conditions Scheduled Maintenance ..........334 Customer Information Rollover Warning ........344 Radio Frequency Certification Labels ................344 Warranty Information .......349 Appendices Electromagnetic Compatibility ....351...
Page 11: Introduction
Make sure you Note: Either Ford Motor Company or an are aware of all applicable local laws authorized Ford dealer may have originally that may affect the use of electronic sold this incomplete vehicle to a vehicle devices while driving.
Page 12 • An engine-mounted secondary fuel filter Engine Protection Mode • A fuel injector for each cylinder (8 Ford diesel engines are equipped with total) engine protection and emission control • A high-pressure fuel pump systems. These systems monitor critical temperatures and pressures, and modify •...
Page 13 Introduction If these modified engine performance Selective catalytic reduction system characteristics persist for an extended Your vehicle is equipped with a selective period and either the service engine soon catalytic reduction system designed to or powertrain malfunction, reduced power, reduce emission levels of nitrogen oxides electronic throttle control light is from the exhaust of your diesel engine.
Page 14 Introduction • The gearshift lever must be in P (Park) • Driving with frozen coolant or N (Neutral) in order for the starter • Sticking thermostat to operate. • Overloading or pulling heavy trailers • Try operating the starter switch several during hot weather times.
Page 15: Perchlorate
You can clearly For more information visit: identify genuine Ford and Motorcraft parts by looking for the Ford, FoMoCo or Web Address Motorcraft branding on the parts or their www.dtsc.ca.gov/hazard- packaging.
Page 16: Special Notices
Introduction On Board Diagnostics Data Link The Ford Warranty may not cover damage Connector caused to your vehicle as a result of failed non-Ford parts. For additional information, refer to the WARNING: Do not connect terms and conditions of the Ford Warranty.
Page 17: Mobile Communications Equipment
Ambulance caution when using any device that may take your focus off the road. Your If your light truck has the Ford Ambulance primary responsibility is the safe Preparation Package, it may be utilized as operation of your vehicle. We an ambulance.
Page 18: Export Unique Options
Introduction enhance personal safety and security when and regulations to your intended use for appropriately used, particularly in the vehicle, and to arrange for the emergency situations. Safety must be installation of required equipment. The paramount when using mobile dealer has information about the communications equipment to avoid availability of equipment which can be negating these benefits.
Page 19: Symbols Glossary
Symbols Glossary Child safety door lock or unlock SYMBOLS USED ON YOUR VEHICLE Child seat lower anchor These are some of the symbols you may E139211 see on your vehicle. Airbag Child seat tether anchor E141128 E67017 Air conditioning system Cruise control E162384 E332905...
Page 20 Symbols Glossary Fuel pump reset Malfunction Indicator Lamp E67028 (MIL) Note operating instructions Fuse compartment E72343 E139214 Panic alarm Hazard flashers E75790 Headlamp high beams Parking aid E67019 E139213 Headlamps on Parking lamps E71341 E270968 Heated rear window Passenger airbag activated E270849 Hill descent control Passenger airbag deactivated...
Page 21 Symbols Glossary Shield the eyes E167012 Stability control E138639 Stability control off E130458 Trail control E332910 Turn Signal E67018 Windshield defrosting system E73953 Windshield wiping system E270969 Windshield wash and wipe E270967 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 22: Data Privacy
If you use our services, we collect and use recommend that you visit the local Ford data, for example account information, website for the latest information. vehicle location and driving characteristics, that could identify you.
Page 23: Service Data
Data Privacy you, where permitted by law. For Canada SERVICE DATA only, for more information, please review the Ford of Canada privacy policy at Service data recorders in your vehicle are www.ford.ca, including our U.S. data capable of collecting and storing storage and use of service providers in diagnostic information about your vehicle.
Page 24: Settings Data
The data is refer to your local Ford website. stored locally in the vehicle or on devices Note: The modem continues to send this that you connect to it, for example, a USB information unless you disable the modem drive or digital music player.
Page 25: Emergency Call System Data
Data Privacy EMERGENCY CALL SYSTEM DATA (IF EQUIPPED) When the emergency call system is active, it may disclose to emergency services that your vehicle has been in a crash involving the deployment of an airbag or activation of the fuel pump shut-off. Certain versions or updates to the emergency call system may also be capable of electronically or verbally disclosing to emergency services...
Page 26: Environment
ENVIRONMENT • Inspect the fan for blade damage. If you find any damage, replace with the Sustainability is a priority at Ford. We are recommended parts. Inspect for constantly looking for ways to reduce our fan-to-shroud interference and any impact on the planet while providing...
Page 27 Environment • Do not change the tail pipe elbow or offset tail pipe orientation from the standard position as originally received. • To avoid abnormal changes in vehicle sound levels, it is necessary for the owner to perform inspections and necessary maintenance at specified intervals.
Page 28: At A Glance
At a Glance INSTRUMENT PANEL E 3 0 7 5 6 5 Direction indicators. See Direction Indicators (page 58). Wiper lever. See Windshield Wipers (page 54). Information display control. See Information Display Control (page 53). Instrument cluster. See General Information (page 71). Gearshift lever.
Page 29: Child Safety
Child Safety GENERAL INFORMATION (CPST) to make sure that you properly install the child restraint in your vehicle See the following sections for directions and that you consult your pediatrician to on how to properly use safety restraints make sure you have a child restraint for children.
Page 30 Child Safety Recommendations for Safety Restraints for Children Recommended Restraint Child Child Size, Height, Weight, or Age Type Use a child restraint Infants or Children weighing 40 lb (18 kg) or less (sometimes called an toddlers (generally age four or younger). infant carrier, convertible seat, or toddler seat).
Page 31: Installing Child Restraints
Child Safety INSTALLING CHILD RESTRAINTS WARNING: Depending on where you secure a child restraint, and depending on the child restraint design, Child Restraints you may block access to certain seatbelt buckle assemblies and LATCH lower anchors, rendering those features potentially unusable. To avoid risk of injury, make sure occupants only use seating positions where they are able to be properly restrained.
Page 32 Child Safety 3. While holding the shoulder and lap belt portions together, route the tongue through the child restraint according to the child restraint manufacturer's instructions. Make sure that you did not twist the belt webbing. E142528 Position the child restraint in a seat with a seatbelt.
Page 33 Child Safety Try to pull the belt out of the retractor to make sure the retractor is in the automatic locking mode. You should not be able to pull more belt out. If the retractor is not locked, unbuckle the belt and repeat Steps 5 and 6.
Page 34 Child Safety WARNING: Properly secure children 12 years old and under in a rear seating position whenever possible. If you are unable to properly secure all E 1 6 2 7 0 8 children in a rear seating position, properly secure the largest child on the front seat.
Page 35 Child Safety 4. Insert the belt tongue into the proper 8. Before placing the child in the seat, buckle, the buckle closest to the forcibly move the seat forward and direction the tongue is coming from, or back to make sure the seat is securely that seating position until the latch held in place.
Page 36 Child Safety Attaching the Tether Strap Contact the manufacturer of your child restraint for information about ordering a Route the child restraint tether strap tether strap, or to obtain a longer tether over the back of the seat. strap if the tether strap on your child restraint does not reach the appropriate Note: For vehicles with adjustable head top tether anchor in the vehicle.
Page 37: Booster Seats
Child Safety 5. Clip the tether strap to the anchor as shown. If the tether strap is clipped incorrectly, the child restraint may not be retained properly in the event of a crash. 6. Tighten the child restraint tether strap according to the manufacturer's instructions.
Page 38 Child Safety If your backless booster seat has a • High back booster seats removable shield, remove the shield. If a If, with a backless booster seat, you cannot vehicle seating position has a low seat find a seating position that adequately backrest or no head restraint, a backless supports your child's head, a high back booster seat may place your child's head...
Page 39: Child Restraint Positioning
Child Safety E142597 If the booster seat slides on the vehicle WARNING: Always carefully follow seat upon which it is being used, placing a the instructions and warnings provided rubberized mesh sold as shelf or carpet by the manufacturer of any child liner under the booster seat may improve restraint to determine if the restraint this condition.
Page 40: Child Safety Locks
Child Safety WARNING: Always restrain an WARNING: Never place, or allow unoccupied child seat or booster seat. a child to place, the shoulder belt under These objects may become projectiles a child's arm or behind the back because in a crash or sudden stop, which may it reduces the protection for the upper increase the risk of serious injury.
Page 41 Child Safety E162719 The child safety locks are on the rear edge of each rear door. You must set the lock separately for each door. Move the lock control up or down to engage or disengage the child safety lock. Note: To make sure the child safety lock is on, pull the inside door handle twice to verify the door does not open.
Page 42: Seatbelts
Seatbelts PRINCIPLE OF OPERATION WARNING: Each seating position in your vehicle has a specific safety belt assembly which is made up of one WARNING: Always drive and ride buckle and one tongue that are designed with the seat backrest upright and the to be used as a pair.
Page 43: Fastening The Seatbelts
Seatbelts • Height adjuster at the front outboard 2. To unfasten, press the release button seating positions. and remove the tongue from the buckle. • Safety belt pretensioner at the front outboard seating positions. Using the Seatbelt with Cinch Tongue (Front Center and Rear Center Seats Only) E71880 •...
Page 44 Seatbelts Fastening the Cinch Tongue WARNING: Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Pull the lap and shoulder belt from the retractor so that the shoulder belt portion of the seatbelt crosses your shoulder and chest.
Page 45 Seatbelts Using Seatbelts During Pregnancy The safety restraints in the vehicle are combination lap and shoulder belts. The driver seatbelt has the first type of locking mode. The front outboard passenger and WARNING: Always ride and drive rear outboard seat seatbelts have both with your seatback upright and properly types of locking modes described as fasten your seatbelt.
Page 46: Seatbelt Height Adjustment
Seatbelts When to Use the Automatic Locking Energy Management Feature Mode • This vehicle has a seatbelt system with Use this mode any time a child safety seat, an energy management feature at the except a booster, is installed in passenger front outboard seating positions to front or rear seating positions.
Page 47: Seatbelt Warning Lamp And Indicator Chime
Seatbelts 2. Release the button and pull down on SEATBELT WARNING LAMP the height adjuster to make sure it is AND INDICATOR CHIME locked in place. This lamp illuminates and an indicator chime will sound if the driver seatbelt has not been E71880 fastened when the vehicle's ignition is turned on.
Page 48 Seatbelts If... Then... You and the front seat passenger buckle The Belt-Minder feature will not activate. your safety belts before you switch the ignition on or less than 1-2 minutes elapse after you switch the ignition on... You or the front seat passenger do not The Belt-Minder feature activates, the buckle your safety belts before your vehicle safety belt warning light illuminates and a...
Page 49: Child Restraint And Seatbelt Maintenance
Seatbelts 4. While the safety belt warning light is SEATBELT EXTENSIONS on, buckle and then unbuckle the safety belt. After Step 4, the safety belt warning light flashes for confirmation. WARNING: Persons who fit into • This will switch the feature off for that the vehicle's seatbelt should not use an seating position if it is currently on.
Page 50: Keys And Remote Controls
Keys and Remote Controls Note: If you are in range, the remote control GENERAL INFORMATION ON will operate if you press any button RADIO FREQUENCIES unintentionally. Note: The remote control contains sensitive This device complies with Part 15 of the electrical components.
Page 51: Remote Control
Keys and Remote Controls REMOTE CONTROL WARNING: If the battery compartment does not securely close, stop using the remote control and replace it as soon as possible. In the meantime, keep the remote control away from children. Failure to follow this instruction could result in personal injury or death.
Page 52: Replacing A Lost Key Or Remote Control
Keys and Remote Controls Sounding the Panic Alarm Note: Do not wipe off any grease on the battery terminals or on the back surface of Press the button to sound the the circuit board. panic alarm. Press the button 2. Remove the old battery. again or switch the ignition on to E138624 turn it off.
Page 53: Doors And Locks
Doors and Locks Locking the Doors LOCKING AND UNLOCKING Press the button to lock all the You can use the power door lock control doors. The direction indicators or the remote control to lock and unlock flash. E138623 your vehicle. Press the button again within three Power Door Locks seconds to confirm that all the doors lock.
Page 54 Doors and Locks Autolock repeats when: Switch the ignition off. The horn sounds indicating programming is complete. • The vehicle is stopped. Note: You can also switch this feature on • Any door opens and closes while the or off using the instrument cluster display. ignition is on.
Page 55: Security
Your vehicle may have two integrated keyhead transmitters. Note: The system is not compatible with The integrated keyhead transmitter non-Ford aftermarket remote start systems. functions as a programmed ignition key Use of these systems could result in engine that starts your vehicle.
Page 56: Steering Wheel
Steering Wheel ADJUSTING THE STEERING CRUISE CONTROL - VEHICLES WHEEL WITH: ADAPTIVE CRUISE CONTROL WARNING: Do not adjust the steering wheel when your vehicle is moving. Note: Make sure that you are sitting in the correct position. See Sitting in the Correct Position (page 88).
Page 57: Information Display Control
Steering Wheel INFORMATION DISPLAY CONTROL E191336 See Information Displays (page 71). HORN You can activate the horn by pressing on the steering wheel E270945 near the horn icon. Some vehicles may also have a horn button on the instrument panel near the lighting control.
Page 58: Wipers And Washers
Wipers and Washers WINDSHIELD WIPERS WINDSHIELD WASHERS Note: Fully defrost the windshield before you switch the windshield wipers on. Note: Make sure you switch the windshield wipers off before entering a car wash. Note: If streaks or smears appear on the windshield, clean the windshield and the wiper blades.
Page 59: Lighting
Lighting GENERAL INFORMATION LIGHTING CONTROL Condensation in the Exterior Front Lamps and Rear Lamps Exterior front lamps and rear lamps have vents to accommodate normal changes in air pressure. Condensation can be a natural by-product of this design. When moist air enters the lamp assembly through the vents, there is a possibility that condensation can occur when the temperature is cold.
Page 60: Autolamps
Lighting Flashing the Headlamp High Beam Windshield Wiper Activated Headlamps When you switch the autolamps on, the headlamps turn on within 10 seconds of switching the wipers on. They turn off approximately 60 seconds after you switch the windshield wipers off. The headlamps do not turn on with the wipers: •...
Page 61: Daytime Running Lamps - Vehicles With: Daytime Running Lamps (Drl)
Lighting 3. The transmission is not in park (P) for DAYTIME RUNNING LAMPS - vehicles with automatic transmissions VEHICLES WITH: DAYTIME or you release the parking brake for RUNNING LAMPS (DRL) vehicles with manual transmissions. 4. The lighting control is in the autolamps position.
Page 62: Direction Indicators
Lighting Note: Using much larger tires or equipping Switch the lighting control to the vehicle accessories such as snowplows can autolamps position. See Autolamps modify your vehicle's ride height and (page 56). degrade automatic high beam control Overriding the System performance.
Page 63 Lighting Map Lamps E163273 Dome and Map Lamps E163274 Press the button to switch the lamps on or off. 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 64: Windows And Mirrors
Windows and Mirrors Note: Perform one-touch up recalibration POWER WINDOWS (IF EQUIPPED) with the door closed. Calibrating with the door open causes the window to bounce back continuously. WARNING: Do not leave children To reset the function after the battery unattended in your vehicle and do not recharges: let them play with the power windows.
Page 65: Exterior Mirrors
Windows and Mirrors EXTERIOR MIRRORS Auxiliary Convex Mirrors E163059 Left mirror. Off. Right mirror. To adjust a mirror: Rotate the control to select the mirror you want to adjust. 2. Adjust the position of the mirror. 3. Return the control to the center position to lock mirrors in place.
Page 66 Windows and Mirrors Telescoping Mirrors Note: If you repeatedly fold and unfold the (If Equipped) mirrors several times within one minute, the system may disable to protect the motors from overheating. It resets to normal function automatically within three to five minutes.
Page 67: Interior Mirror
Windows and Mirrors To adjust the mirrors: SUN VISORS • Press and hold the control. Slide-on-rod (If Equipped) • When you position the mirrors in or out, the motors run as long as you hold the control. The running motors allow you to make adjustments as needed.
Page 68: Instrument Cluster
Instrument Cluster GAUGES 2.3 Inch Display E219638 Engine oil pressure gauge. Engine coolant temperature gauge. Fuel gauge. Transmission fluid temperature gauge. Speedometer. Information display. See General Information (page 71). Tachometer. 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 69 Instrument Cluster 8 Inch Display E299699 Engine oil pressure gauge. Engine coolant temperature gauge. Fuel gauge. Configurable gauge. Speedometer. Information display. See General Information (page 71). Tachometer. 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 70 Instrument Cluster Engine Oil Pressure Gauge Low Fuel Reminder A low fuel level reminder displays and Indicates engine oil pressure. At normal sounds when the distance to empty operating temperature, the level indicator reaches 50 mi (80 km), 25 mi (40 km), is in the normal range.
Page 71: Warning Lamps And Indicators
Instrument Cluster Brake System Diesel Exhaust Fluid Gauge Indicates the fluid level in the diesel exhaust fluid (DEF) tank. WARNING: Driving your vehicle with the warning lamp on is dangerous. Voltmeter A significant decrease in braking Displays electrical system voltage. performance may occur.
Page 72 Instrument Cluster Door Ajar High Beam Displays when the ignition is on Illuminates when you switch on and any door is not completely the high beam headlamps. It E67019 closed. flashes when you use the headlamp flasher. Electronic Locking Differential Hydromax Equipped) If the light illuminates and...
Page 73 Instrument Cluster Powertrain Malfunction/Reduced Traction Control Indicator Power/Electronic Throttle Control Flashes during a traction control (If Equipped) event. E138639 Illuminates in the event of a powertrain fault. Have your If it does not illuminate when you switch the ignition on, or remains on when the vehicle checked as soon as engine is running, this indicates a possible.
Page 74: Audible Warnings And Indicators
Instrument Cluster Parking Brake On Warning Chime WARNING: Do not use starting Sounds when you have left the parking fluid, for example ether, in the air intake brake on and drive your vehicle. If the system. Such fluid could cause warning chime remains on after you have immediate explosive damage to the released the parking brake, have the...
Page 75: Information Displays
Information Displays Information Display Controls GENERAL INFORMATION WARNING: Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road.
Page 76 Information Displays Trip 1 or 2 • Instant fuel economy. • Average fuel economy. Displays the following of an individual journey. • Average speed. • Distance to empty. • Digital speed. • Distance. Note: Hold OK to reset fuel history and average fuel economy.
Page 77 Information Displays Main Menu MyView Trip/Fuel Truck Info Settings MyView MyView Trip 1 Fuel Economy Configure MyView For more options, press the OK button. Trip/Fuel Trip/Fuel Trip 1 Trip 2 Fuel Economy Fuel History Fuel Economy Trip 1 or 2 Displays your instant fuel usage as a bar Displays the following of an individual graph and average mpg.
Page 78 Information Displays Truck Info Truck Info Gauge View Digital Speedometer Engine Information Maintenance Monitor Transmission Temperature • Engine information shows engine hours, engine idle hours and engine oil temp and oil life. Settings Settings Driver Alert Turn On or Off Pre-Collision Select Your Setting Cruise...
Page 79: Information Messages
Information Displays Press the OK button to acknowledge and INFORMATION MESSAGES remove some messages from the information display. The information Note: Depending on your vehicle options display will automatically remove other and instrument cluster type, not all messages after a short period of time. messages display or are available.
Page 80 Information Displays Message Action Adaptive Cruise - Driver Resume Control The adaptive cruise has reinstated controls to the driver. Take control of your vehicle. Adaptive Cruise Speed Too Low to Activate Your vehicle speed is too low to activate the adaptive cruise. Increase your vehicle's speed to use the system.
Page 81 Information Displays Message Action Exhaust Filter Cleaning Your vehicle has entered the cleaning mode. Various engine actions raises the exhaust temperature in the diesel particu- late filter system to burn off the particles, exhaust soot. After the vehicle burns the particles off, the exhaust temperature returns to normal levels.
Page 82 Information Displays Message Action DEF Level Empty Speed Limited to avg The diesel exhaust fluid is nearing empty. speed imperial:#0 MPH in distance Your vehicle's top speed will become imperial:###0 mi limited in the displayed distance. You must replenish the diesel exhaust fluid to resume DEF Level Empty Speed Limited to avg normal operation of your vehicle.
Page 83 Information Displays Message Action DEF Fault Speed Limited to avg speed The selective catalytic reduction system imperial:#0 MPH Upon Restart requires service. Upon restart, your vehicle speed is now limited. Have the system DEF Fault Speed Limited to avg speed checked as soon as possible.
Page 84 Information Displays Driver Alert Message Action Driver Alert Warning Rest Now Stop and rest as soon as it is safe to do so. Driver Alert Warning Rest Suggested Take a rest soon. Drivetrain Message Action Check Locking Differential The electronic locking differential requires service.
Page 85 Information Displays Lane Departure Warning System Message Action Front Camera Temporarily Not Available The system has detected a condition that has caused the system to be temporarily unavailable. If the message continues to display, have the system checked as soon as possible.
Page 86 Information Displays Power Steering Message Action Steering Fault Service Now The power steering system requires service. Have the system checked as soon as possible. Steering Loss Stop Safely The power steering system is not working. Stop your vehicle in a safe place. Have the system checked as soon as possible.
Page 87 Information Displays Transmission Message Action Shift to Park You switched the engine off and the shift selector is in any position other than park (P). Press Brake Pedal Displays when the brake pedal needs to be pressed. Transmission Over Temperature Stop The transmission is overheating and needs Safely to cool.
Page 88 Information Displays Message Action Transmission IndicatMode Lockup On Displays when the transmission shift lever is locked and unable to select gears. Transmission IndicatMode Lockup Off Displays when the transmission shift lever is unlocked and free to select gears. Transmission Overheating Stop Safely The transmission is overheating and needs to cool.
Page 89: Climate Control
Climate Control (If Equipped) Setting the Temperature MANUAL CLIMATE CONTROL E305247 Note: Depending on your vehicle option package, the controls may look different from what you see here. Directing the Air E265862 Press and release the button to Turn the control to set the temperature. direct air between the E265283 instrument panel air vents,...
Page 90: Hints On Controlling The Interior Climate
Climate Control (If Equipped) Air directed to the instrument panel and Note: To reduce humidity build-up inside footwell air vents turns off. You can also your vehicle, do not drive with the system use this setting to defog and clear the switched off or with recirculated air always windshield of a thin covering of ice.
Page 91: Heated Exterior Mirrors
Climate Control (If Equipped) 3. Direct air to the instrument panel air vents. Vehicle Stationary for Extended Periods During Extreme High Ambient Temperatures Apply the parking brake. 2. Place your vehicle in park (P) or neutral (N). 3. Switch MAX A/C on. 4.
Page 92: Seats
Seats • Keep sufficient distance between SITTING IN THE CORRECT yourself and the steering wheel. We POSITION recommend a minimum of 10 in (25 cm) between your breastbone and the airbag cover. WARNING: Do not recline the • Hold the steering wheel with your arms seatback as this can cause the occupant slightly bent.
Page 93 Seats Note: Adjust the seat backrest to an upright Removing the Head Restraint driving position before adjusting the head Press and hold buttons C and D. restraint. Adjust the head restraint so that 2. Pull the head restraint up. the top of it is level with the top of your head and as far forward as possible.
Page 94: Manual Seats
Seats Installing the Head Restraint MANUAL SEATS Align the steel stems into the guide sleeves and push the head restraint down until it locks. WARNING: Do not adjust the driver seat or seat backrest when your vehicle Tilting Head Restraints (If Equipped) is moving.
Page 95: Power Seats
Seats Recline Adjustment Note: You may need to apply pressure on the back of the seat to get the release lever Type 1 to release. Lift the handle to unlock and release the seatback forward. Manual Lumbar (If Equipped) E162728 Type 2 E162729 The lumbar control is on the outboard side...
Page 96 Seats Air-Ride Seat Rotate the handle to adjust the angle of the seat backrest. Type 1 Pull the control up to raise the seat. Push the control down to lower the seat. Move the lever to the left to move the seat forward or backward.
Page 97: Rear Seats
Seats Folding the Rear Seat Back (Crew REAR SEATS (IF EQUIPPED) Cab) Folding Up the Rear Seats (SuperCab) E162738 E162737 Pull forward on the control to fold down the seatback. Pull the control to release the seat cushion. 2. Pull down on the handle and lift up on the seatback to return it to the original 2.
Page 98: Front Seat Armrest
Seats 20% Seat Cushion Storage 2. Push the seat cushion down until it locks into the horizontal position. Equipped) FRONT SEAT ARMREST E265303 Lift the latch to open the lid and gain access to the storage compartment under E162745 the center seat cushion. Press the button on the right-hand side of the seat, then pull the seat backrest down REAR SEAT ARMREST...
Page 99: Auxiliary Power Points
Auxiliary Power Points 12 Volt DC Power Point Locations Power points may be in the following locations: WARNING: Do not plug optional • On the instrument panel (two electrical accessories into the cigar locations). lighter socket. Incorrect use of the cigar lighter can cause damage not covered •...
Page 100 Auxiliary Power Points When the indicator light on the power point • On: The power point is working, the ignition is on and a device is plugged • Off: The power point is off, the ignition is off or no device is plugged in. •...
Page 101: Usb Ports
USB Ports LOCATING THE USB PORTS PLAYING MEDIA USING THE USB PORT Data Transfer USB Ports E250655 WARNING: Driving while distracted can result in loss of vehicle control, crash The USB ports could be in the following and injury. We strongly recommend that locations: you use extreme caution when using any device that may take your focus off the...
Page 102 USB Ports You can use the charger when the vehicle is in accessory mode, or when the vehicle is running. 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 103: Storage Compartments
Storage Compartments OVERHEAD CONSOLE EQUIPPED) E266392 Press near the rear edge of the door to open it. 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 104: Starting And Stopping The Engine
Starting and Stopping the Engine If you disconnect the battery, your vehicle GENERAL INFORMATION could exhibit some unusual driving characteristics for approximately 5 mi (8 km) after you reconnect it. This is WARNING: Extended idling at high because the engine management system engine speeds can produce very high must realign itself with the engine.
Page 105: Starting A Gasoline Engine
Starting and Stopping the Engine Note: When you switch the ignition off and Note: If you cannot start the engine on the leave your vehicle, do not leave your key in first try, wait for a short period and try again. the ignition.
Page 106: Starting A Diesel Engine
Starting and Stopping the Engine Diesel Engine Fast Start Glow Plug 2. Put the transmission into neutral (N) System and use the brakes to bring your vehicle to a safe stop. The diesel engine glow system consists of: 3. When your vehicle has stopped, shift •...
Page 107: Switching Off The Engine
Starting and Stopping the Engine Cold Weather Starting When starting the engine in extremely cold temperatures, for example -15°F (-26°C), we recommend you allow the engine to idle for several minutes before driving your WARNING: Do not use starting vehicle. fluid, for example ether, in the air intake system.
Page 108: Engine Idle Shutdown
Starting and Stopping the Engine The engine idle shutdown timer does not ENGINE IDLE SHUTDOWN start if: EQUIPPED) • The engine is operating in battery charge protect or power take-off mode. • The exhaust emission control device is WARNING: In the event of engine regenerating.
Page 109 Starting and Stopping the Engine We recommend that you do the following The heater uses 0.4 to 1.0 kilowatt-hours for a safe and correct operation: of energy per hour of use. The system does not have a thermostat. It achieves •...
Page 110: Fuel And Refueling
Fuel and Refueling Observe the following guidelines when SAFETY PRECAUTIONS handling automotive fuel: • Extinguish all smoking materials and any open flames before refueling your WARNING: Do not overfill the fuel vehicle. tank. The pressure in an overfilled tank • Automotive fuels can be harmful or may cause leakage and lead to fuel spray fatal if swallowed.
Page 111: Fuel Quality - Diesel
Note: The vehicle Warranty may be void if Virgin Islands And Other Locales) you use additives that do not meet or exceed Ford specifications. If the low fuel You should use Ultra-Low Sulfur Diesel pressure message persistently appears after fuel (also known as ULSD) designated as...
Page 112 Note: Do not use home heating oil, retrofitted for high-sulfur diesel fuel using agricultural fuel, raw fats and oils, waste Ford Motor Company dealer service parts. cooking greases, biodiesel fuels greater than Failure to use retrofit components other 20% or any diesel fuel not intended for than those available through your highway use.
Page 113 Fuel and Refueling Biodiesel fuel is a chemically converted Look for a label on the fuel pump to product from renewable fuel sources, such confirm the amount of biodiesel contained as vegetable oils, animal fats and waste in a diesel fuel. Biodiesel content is often cooking greases.
Page 114: Fuel Quality - Gasoline
We recommend Top Tier detergent using an aftermarket product that does gasolines, where available to help minimize not meet Ford specifications in your fuel. engine deposits and maintain optimal vehicle and engine performance. For additional information, refer to FUEL QUALITY - GASOLINE www.toptiergas.com.
Page 115: Running Out Of Fuel - Diesel
Fuel and Refueling If you run out of fuel: RUNNING OUT OF FUEL - • You may need to switch the ignition DIESEL from off to on several times after refueling to allow the fuel system to Avoid running out of fuel. This allows air to pump the fuel from the tank to the enter the fuel system and may make it engine.
Page 116 We recommend fuel tank or fuel system if the correct that you purchase diesel fuel from a genuine Ford, Motorcraft or other certified reputable fuel station. fuel filler cap is not used. Use only clean, approved containers that...
Page 117: Refueling - Gasoline
Ford, Motorcraft or other certified overflowing. fuel filler cap is not used. When refueling the vehicle fuel tank do the following.
Page 118: Fuel Consumption
Fuel and Refueling Filling the Fuel Tank When your vehicle has stopped, shift into neutral (N) or park (P). For consistent results when refueling: 2. Apply the parking brake and switch the • Turn the ignition off before fueling; an ignition off.
Page 119: Fuel Tank Selector Switch
Fuel and Refueling Keep a record for at least one month and FUEL TANK SELECTOR record the type of driving (city or highway). SWITCH (IF EQUIPPED) This provides an accurate estimate of your vehicle's fuel economy under current driving conditions. Keeping records during summer and winter will show how temperature impacts fuel economy.
Page 120: Engine Emission Control
Engine Emission Control Tampering With a Noise Control EMISSION LAW System Federal laws prohibit the following acts: WARNING: Do not remove or alter • Removal or rendering inoperative by the original equipment floor covering or any person other than for purposes of insulation between it and the metal floor maintenance.
Page 121: Catalytic Converter
Never work around or attempt your vehicle and to its emissions system. to repair any part of the exhaust system If you use anything other than Ford, until it has cooled. Use special care when Motorcraft or Ford-authorized parts for working around the catalytic converter.
Page 122 Engine Emission Control Illumination of the service engine soon Your vehicle has run out of fuel—the indicator, charging system warning light or engine may misfire or run poorly. the temperature warning light, fluid leaks, 2. Poor fuel quality or water in the strange odors, smoke or loss of engine fuel—the engine may misfire or run power could indicate that the emission...
Page 123: Selective Catalytic Reductant System - Diesel
Engine Emission Control Your vehicle may not pass the I/M test if SELECTIVE CATALYTIC the service engine soon indicator is on or REDUCTANT SYSTEM - DIESEL not working properly (bulb is burned out), or if the OBD-II system has determined Your vehicle may have a selective catalytic that some of the emission control systems reduction system.
Page 124 Engine Emission Control WARNING: Only refill the diesel exhaust fluid tank in a well ventilated area. When you remove the diesel exhaust fluid tank filler cap or a diesel exhaust fluid container cap, ammonia vapors may escape. Ammonia vapors can be irritating to skin, eyes and mucous membranes.
Page 125 Engine Emission Control Remove the diesel exhaust fluid Note: If the diesel exhaust fluid tank is container cap. Place the spout onto the frozen, it may not recognize when the tank container and tighten until you feel a is refilled. The diesel exhaust fluid level strong resistance.
Page 126 Engine Emission Control Diesel Exhaust Fluid Guidelines As the diesel exhaust fluid level and Information nears empty, the warning symbol displays and a series of E163176 • Use only diesel exhaust fluid that tones and messages starting at 500 mi carries the American Petroleum (800 km) remaining before diesel exhaust Institute (API) certified diesel exhaust...
Page 127: Diesel Particulate Filter
Engine Emission Control • Do not dilute diesel exhaust fluid with A warning lamp illuminates and water or any other liquid. a message appears in the information display if the system E163176 • An ammonia odor may be smelled becomes contaminated or inoperative. when the cap is removed or during refill.
Page 128 Engine Emission Control begins to restrict the filter. Periodically, you Failure to perform active or operator need to clean the soot that gathers inside commanded regeneration when instructed the filter. You can clean the soot in two could result in a clogged diesel particulate different ways, passive regeneration and filter.
Page 129 Engine Emission Control When to Carry Out Operator Commanded When the engine control module detects Regeneration that the diesel particulate filter is nearly full of particulates and you are not You can use the operator commanded operating your vehicle in a manner to allow regeneration feature when a message effective automatic regeneration, appears in the information display only.
Page 130 Engine Emission Control 4. After the DPF Service Regeneration Before you start operator commanded procedure completes: regeneration, do the following: • If the vehicle’s soot level is at an • Shift into park (P) or if you have an acceptable level, close the hood. RNDM selector shift into neutral (N) The vehicle is ready to be driven.
Page 131 Engine Emission Control Information Display Procedure complete. Do not reposition the vehicle over materials that could burn until the Start your vehicle engine and when it has exhaust system has had sufficient time to reached the normal operating temperature, cool. Depending on the amount of soot arrow through the display to get to the collected by the diesel particulate filter, Diesel Particulate Filter Status on the...
Page 132 Engine Emission Control How to Interrupt or Cancel Operator Resonator and Tailpipe Assembly Commanded Regeneration Maintenance If you need to cancel the operator Aftermarket devices or modifications to commanded regeneration, pressing the the exhaust system may reduce the brake, accelerator or switching the engine effectiveness of the exhaust system as off stops the procedure.
Page 133: Transmission
Transmission 2. Move the gearshift lever into the AUTOMATIC TRANSMISSION preferred gear. 3. When you finish driving, come to a complete stop. WARNING: Apply the parking brake, shift into park (P), switch the 4. Move the gearshift lever and securely ignition off and remove the key before latch it in park (P) or neutral (N).
Page 134 Transmission To return to normal drive (D) position, The tow/haul feature: move the shift lever back from manual (M) • Delays upshifts to reduce the frequency to drive (D). of transmission shifting. The transmission operates in gears one • Provides engine braking in all forward through six.
Page 135 Transmission Understanding Your SelectShift™ 10-Speed Transmissions Automatic Transmission Your vehicle has a SelectShift automatic transmission gearshift lever. SelectShift automatic transmission gives you the ability to change gears up or down, without a clutch. E308145 With the gearshift lever in drive (D), press the ( ) button to activate SelectShift.
Page 136 Transmission Recommended shift speeds Upshifts when accelerating (recommended for best fuel economy) 6-Speed Shift from: Gasoline engines 15 mph (24 km/h) 25 mph (40 km/h) 40 mph (64 km/h) 45 mph (72 km/h) 50 mph (80 km/h) SelectShift does not automatically upshift, Upshifts when Accelerating even if the engine is approaching the RPM (Recommended for Best Fuel...
Page 137 Transmission Automatic Transmission Adaptive If you do not have a blown fuse and the Learning brake lamps are working properly, the following procedure allows you to move This feature could increase durability and the gearshift lever from park (P): provide consistent shift feel over the life Apply the parking brake.
Page 138: Power Take-Off
Mobile Mode power source within the limits and operating guidelines detailed in the Perform Steps 4 through 8 in reverse order, Ford Truck Body Builders Layout Book, making sure to engage the hinge pivots found at https://fordbbas.com/home and between the upper and lower halves of the through the Ford Truck Body Builders shroud.
Page 139: Rear Axle
Rear Axle GENERAL INFORMATION WARNING: Exceeding these ratings by overloading can cause component failure resulting in property damage, personal injury or death. Fluid Temperature If the operating temperature exceeds 250°F (121°C), the rate of axle lubrication oxidation increases and shortens the life of the lubricant and seals, requiring axle lubrication changes to become more frequent to preserve the axle.
Page 140: Pneumatic Locking Differential
Pneumatic Locking Differential WHAT IS THE PNEUMATIC PNEUMATIC LOCKING LOCKING DIFFERENTIAL DIFFERENTIAL PRECAUTIONS The pneumatic locking differential can lock or unlock the differential when the vehicle WARNING: Exceeding any vehicle is moving or stopped. The differential lock weight rating can adversely affect the provides full power to both wheels when performance and handling of your extra traction is required.
Page 141: Pneumatic Locking Differential Indicators
Pneumatic Locking Differential PNEUMATIC LOCKING DIFFERENTIAL INDICATORS Illuminates when using the electronic locking differential. E163170 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 142: Brakes
Brakes Brake Over Accelerator GENERAL INFORMATION In the event the accelerator pedal Note: Occasional brake noise is normal. If becomes stuck or entrapped, apply steady a metal-to-metal, continuous grinding or and firm pressure to the brake pedal to continuous squeal sound is present, the slow the vehicle and reduce engine power.
Page 143: Hints On Driving With Anti-Lock Brakes
Brakes If the system is disabled, normal braking is still effective. If the WARNING: This control is for brake warning lamp illuminates E209041 parking only. Do not leave the vehicle with the parking brake released, have the unattended after setting the parking system checked immediately.
Page 144 Brakes WARNING: Unexpected and possibly sudden vehicle movement may occur if you do not take these precautions. If you release hydraulic pressure from the spring brake chamber, the power spring applies the brake. If the hydraulic pressure can be re-established, you must release the spring brake to move your vehicle.
Page 145 Brakes The parking brake warning lamp Releasing Spring Brake with Air illuminates and remains Pressure E208810 illuminated until you release the The air system in all vehicles with parking brake. spring-actuated rear wheel parking brakes has a valve on the governor for connection Releasing the Parking Brake to an outside air supply.
Page 146: Hill Start Assist - Vehicles With: Hydraulic Brakes
Brakes WARNING: The system will turn off if a malfunction is apparent or if you rev the engine excessively. Failure to take care may result in the loss of control of your vehicle, serious personal injury or death. The system makes it easier to pull away E210366 when your vehicle is on a slope without 4.
Page 147: Air Brakes
Brakes 4. Drive off in the normal manner. The system releases the brakes WARNING: Do not move the automatically. vehicle when the air pressure is Note: When you remove your foot from the insufficient because the brake system brake pedal and press the pedal again when may be inoperative.
Page 148: Exhaust Brake
Brakes Air Chamber Stroke Indication - Standard air brakes (cam) are equipped Drum Brakes with automatic brake adjusters. Automatic adjustment occurs during brake Air chamber push rods have orange stroke applications. Inspect brakes for proper indicator markers that warn when the adjustment at the specified intervals.
Page 149 Brakes WARNING: Do not use diesel engine exhaust braking when the road surface is slippery. Failure to follow this instruction could result in the loss of control of your vehicle. Note: Installing an exhaust or auxiliary brake does not necessarily protect the engine from exceeding the maximum governed speed.
Page 150: Trailer Brakes
Brakes While driving down a grade, use a low TRAILER BRAKES (IF EQUIPPED) enough gear to descend safely with a minimum application of the service brakes. Trailer Brake Hand Control (If Equipped) As a general guideline, use the same gear as you use to ascend the hill.
Page 151 Brakes Trailer Air Supply and Parking Brake Modular Controls (If Equipped) E210341 The parking brake controls the spring brakes on the tractor. When you pull the E210340 knob out, it causes the trailer supply valve The trailer air supply valve delivers air to to pop out, applying both the tractor and the trailer supply and automatically pops trailer parking brakes.
Page 152 Brakes Normal Driving Position Push in both knobs (A and B) to supply air to both trailer and tractor spring brakes, releasing all brakes. E210343 System Park E210344 With both knobs (A and B) pushed in (normal driving position), the parking brakes for both the tractor and trailer can be applied by pulling the parking brake knob (B) out, exhausting air from the...
Page 153 Brakes Trailer Charge E210342 piston within the valve moves, exhausting If both knobs (A and B) are out, and you the trailer air supply, applying the trailer want to recharge the trailer while leaving brakes. Further reduction of air pressure, the tractor spring brakes applied, the trailer while holding the trailer air supply knob in, air supply (A) can be pushed in to recharge...
Page 154: Traction Control
Traction Control During traction control operation, the PRINCIPLE OF OPERATION traction control light flashes rapidly and the engine does not rev-up when you press The traction control system helps avoid further on the accelerator. This is normal drive wheel spin and loss of traction. and is no reason for concern.
Page 155 Traction Control When the system turns the traction control off, the OFF light illuminates on the instrument cluster. If a traction event occurs in either mode, the stability and traction control light rapidly flashes. 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 156: Stability Control
Stability Control PRINCIPLE OF OPERATION - reduce the operator's ability to control VEHICLES WITH: HYDRAULIC the vehicle potentially resulting in a loss of vehicle control, vehicle rollover, BRAKES personal injury and death. If your electronic stability control system activates, SLOW DOWN. WARNING: Vehicle modifications involving braking system, aftermarket The system turns on each time you switch...
Page 157: Principle Of Operation - Vehicles With: Air Brakes
Stability Control Traction Control interfere with and adversely affect the electronic stability control system. Install The system helps maintain traction of the any aftermarket stereo loudspeaker as wheels by detecting and controlling wheel far as possible from the front center spin.
Page 158: Using Stability Control
Stability Control • The stability control and traction control systems do not enhance your vehicle's ability to maintain traction of the wheels. If a driving condition activates either the stability control or the traction control system you may experience the following conditions: •...
Page 159 • Your brakes are not properly adjusted a truck. Ford Motor Company is not or maintained. responsible for the performance of the • One side of your vehicle drops off the...
Page 160: Parking Aids
Parking Aids Example REAR VIEW CAMERA (IF EQUIPPED) WARNING: The rear view camera system is a reverse aid supplement device that still requires the driver to use it in conjunction with the interior and E142435 exterior mirrors for maximum coverage. WARNING: Objects that are close to either corner of the bumper or under the bumper, might not be seen on the...
Page 161: Cruise Control
Cruise Control WHAT IS CRUISE CONTROL SETTING THE CRUISE CONTROL SPEED Cruise control lets you maintain a set speed without keeping your foot on the accelerator pedal. WARNING: When you are going Requirements downhill, your vehicle speed could increase above the set speed. The Use cruise control when the vehicle speed system does not apply the brakes.
Page 162: Canceling The Set Speed
Cruise Control CANCELING THE SET SPEED WARNING: Pay close attention to Press the button, or tap the changing road conditions such as brake pedal to cancel the set entering or leaving a highway, on roads E265298 speed. with intersections or roundabouts, roads without visible lanes of travel, roads that Note: The system remembers the set are unpaved, or steep slopes, railroad...
Page 163 Cruise Control WARNING: Do not use the system with a snow plow blade installed. The system adjusts your vehicle speed to maintain the set gap between you and the vehicle in front of you in the same lane. You can select four gap settings. The system uses a radar sensor that projects a beam directly in front of your vehicle.
Page 164 Cruise Control Following a Vehicle The system applies the brakes to slow your vehicle to maintain a safe gap distance from the vehicle in front. The system only applies limited braking. You can override WARNING: When following a the system by applying the brakes. vehicle that is braking, your vehicle does not always decelerate quickly enough to If the system determines that its maximum...
Page 165 Cruise Control Press and release to decrease Adaptive Cruise Control Gap Settings the set speed in small E246885 increments. Graphic Distance Gap Dynamic Display, Behavior Press and hold either button to change the Bars Indic- set speed in large increments. Release the ated button when the indicated set speed Between...
Page 166 Cruise Control Hilly Condition and Trailer Tow The radar sensor has a limited field of Usage view. It may not detect vehicles at all or detect a vehicle later than expected in You should select a lower gear when the some situations.
Page 167 Cruise Control Blocked Sensor In these cases, the system may brake late or unexpectedly. You should stay alert and take action when necessary. If something hits the front end of your vehicle or damage occurs, the radar-sensing zone may change. This could cause missed or false vehicle detection.
Page 168 Cruise Control Possible causes and actions for a message displaying: Cause Details The surface of the radar is dirty or Clean the grille surface in front of the radar obstructed or remove the object causing the obstruc- tion. The surface of the radar is clean but the Wait a short time.
Page 169: Driving Aids
Driving Aids Note: If the camera is blocked or if the DRIVER ALERT (IF EQUIPPED) windshield is damaged, the system may not function. Note: The system remembers the last WARNING: You are responsible for setting when you start your vehicle, unless controlling your vehicle at all times.
Page 170: Lane Keeping System
Driving Aids The warning system uses two stages. At first the system issues a temporary warning WARNING: The sensor may that you need to take a rest. This message incorrectly track lane markings as other only appears for a short time. If the system structures or objects.
Page 171 Driving Aids System Display When you switch the lane keeping system on and the camera detects a drift out of the travel lane, the system alerts the driver by playing a chime. Switching the System On and Off Note: The system stores the on or off setting until you manually change it.
Page 172 Driving Aids See Troubleshooting for additional You can temporarily disable the system at information. any time by doing the following: • Quick braking. Green: Indicates that the system is available or ready to provide a warning on • Fast acceleration. the indicated side(s).
Page 173: Steering
Driving Aids Steering Tips STEERING If the steering wanders or pulls, check for: Hydraulic Power Steering • An improperly inflated tire. To help prevent damage to the power • Uneven tire wear. steering system: • Loose or worn suspension • Do not hold the steering wheel at its components.
Page 174 Driving Aids Using the Pre-Collision Assist System WARNING: The system is not designed to detect non-metallic objects If your vehicle is approaching a stationary and does not reliably detect some vehicle in your lane of travel, the system objects with limited metallic surfaces. provides an Alert.
Page 175 Driving Aids Pre-Collision Assist Settings The information display shows a blocked sensor message to indicate a sensor Active braking turns on every time you obstruction. The radar sensor is located switch the ignition on. You cannot adjust behind the bumper and mounted to the the Pre-Collision Assist settings.
Page 176: Pre-Collision Assist - Vehicles With: Hydraulic Brakes
Driving Aids Radar Troubleshooting Cause Action Clean the grille surface in front of the radar The surface of the radar in the grille is dirty or remove the object causing the obstruc- or obstructed in some way. tion. The surface of the radar in the grille is clean Wait a short time.
Page 177 Driving Aids WARNING: The system does not WARNING: Take additional care if detect vehicles that are driving in a your vehicle is heavily loaded or you are different direction, pedestrians, cyclists towing a trailer. These conditions could or animals. Apply the brakes when result in reduced performance of this necessary.
Page 178 Driving Aids Brake support: Helps reduce the impact speed by preparing the brakes for rapid braking. The system does not automatically apply the brakes. If you press the brake pedal, the system could apply additional braking up to maximum braking force, even if you lightly press the brake pedal.
Page 179 Driving Aids Note: Switch the system off if you install a If a message regarding a blocked sensor snowplow or similar object in such a way or camera appears in the instrument that it may block the radar sensor. Your cluster display, the radar signals or camera vehicle remembers the selected setting images are obstructed.
Page 180 Driving Aids Radar Troubleshooting Cause Action Clean the grille surface in front of the radar The surface of the radar in the grille is dirty or remove the object causing the obstruc- or obstructed in some way. tion. The surface of the radar in the grille is clean Wait a short time.
Page 181: Load Carrying
GVWR is exceeded. Every vehicle manufactured by Unloaded or Lightly Loaded Ford Motor Company is supplied Vehicles with information on the Safety Compliance Certification Label, located on either the B-pillar or WARNING: When the driver’s door edge, listing the...
Page 182: Air Suspension
Load Carrying System Indicator Light AIR SUSPENSION (IF EQUIPPED) The air suspension indicator light Note: Do not operate your vehicle without illuminates when using the button to air in the suspension springs. Operating your release air pressure in the rear air springs. vehicle without air in the suspension springs Never drive your vehicle when the warning damages the suspension, degrades ride...
Page 183 Load Carrying We do not recommend performing, or approve of, suspension conversions. However, we understand that, on occasion, others install aftermarket add-on suspensions on the truck chassis that allow operator control for weight transfer from other axles (such as air lift axles). 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 184: Towing
Inspect these dealer, or online. components periodically during, and after, any towing operation. RV & Trailer Towing Guide Online Website http://www.fleet.ford.com/towing-guides/ 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 185: Recommended Towing Weights
Towing RECOMMENDED TOWING WEIGHTS Market Website United States of America https://www.fordpro.com/en-us/ fleet-vehicles/manuals-and- guides/ Canada https://www.fordpro.com/en-us/ fleet-vehicles/manuals-and- guides/ 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 186: Essential Towing Checks
Towing The rating for the tow vehicle's braking ESSENTIAL TOWING CHECKS system operation is at the gross vehicle weight rating, not the gross combined See Load limits in the Load Carrying weight rating. chapter for load specification terms found on the tire label and Safety Compliance Trailer Lamps label and instructions on calculating your vehicle's load.
Page 187: Fifth Wheel Operation
Towing Hook-up • Shift to a lower gear when driving down a long or steep hill. Do not apply the Back the tractor squarely under the brakes continuously, as they may trailer, engaging the fifth-wheel jaws overheat and become less effective. on the kingpin.
Page 188 Towing Release the tractor parking brakes. 8. Pull out from the trailer slowly, allowing the landing gear to take the load gradually. 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 189: Driving Hints
Driving Hints Before backing up your vehicle, be sure you GENERAL DRIVING POINTS can do so safely. If anything behind the cab limits your view, do not rely on mirrors General Information alone to make sure that your intended path •...
Page 190: Economical Driving
Driving Hints Conditions ECONOMICAL DRIVING • Adding certain accessories to your Your fuel economy is affected by several vehicle may reduce fuel economy. For things, such as how you drive, the example bug deflectors, rollbars, light conditions you drive under, and how you bars, running boards, ski racks or maintain your vehicle.
Page 191: Cold Weather Precautions - 7.3L
Driving Hints Installation Instructions Installation and removal instructions are included in the winter grill cover package. Refer to the usage guidelines to understand when to use the cover. The cover will seem undersized during the first installation, which is normal. The cover stretches during installation to ensure a tight fit.
Page 192: Driving Through Water
Driving Hints Operation in Standing Water DRIVING THROUGH WATER Ingestion of water into the diesel engine can result in immediate and severe WARNING: Do not drive through damage to the engine. If driving through flowing or deep water as you may lose water, slow down to avoid splashing water control of your vehicle.
Page 193: Roadside Emergencies
Roadside Emergencies HAZARD FLASHERS WARNING: Keep batteries out of Note: If used when the vehicle is not reach of children. Batteries contain running, the battery loses charge. As a result, sulfuric acid. Avoid contact with skin, there may be insufficient power to restart eyes or clothing.
Page 194 Roadside Emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal WARNING: Do not attach the end of the booster vehicle battery. of the positive cable to the studs or 3. Connect the negative (-) cable to the L-shaped eyelet located above the negative (-) terminal of the booster positive (+) terminal of your vehicle’s...
Page 195: Transporting The Vehicle
We recommend the use of a wheel lift and dollies or flatbed equipment to tow your vehicle. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. Vehicle damage may occur if towed incorrectly, or by any other means.
Page 196 Roadside Emergencies • Always align the tow vehicle and stuck vehicle in a straight line (within 10 WARNING: Always slowly remove degrees). the slack from the recovery strap prior • Keep bystanders to the sides of the to pulling. Failure to do so can introduce vehicle, at a distance of at least twice significantly higher loads which can the length of the recovery strap.
Page 197: Crash And Breakdown Information
Getting Roadside Assistance within 50 mi (80 km) of the disablement location or to the nearest If you have a vehicle concern, Ford Motor authorized dealer. If a member Company offers a complimentary roadside requests a tow to an authorized dealer assistance program.
Page 198: Automatic Crash Shutoff
If you require more information, please call us in Canada at 1-800-665-2006, or visit our website at www.ford.ca. Ford Motor Company reserves the right to modify or discontinue Roadside Assistance at any time. Certain restrictions apply to Roadside Assistance benefits.
Page 199: Customer Assistance
In Canada: to the authorized dealer. Repairs will be Mailing address made using Ford or Motorcraft® parts, or remanufactured or other parts that are Customer Relationship Centre authorized by Ford. Ford Motor Company of Canada, Limited P.O.
Page 200: In California (U.s. Only)
In some states within the United States, conform the vehicle to its applicable you must directly notify Ford in writing express warranties if, within the first 18 before pursuing remedies under your months of ownership of a new vehicle or...
Page 201: The Better Business Bureau (Bbb) Auto Line Program (U.s. Only)
BBB AUTO LINE a Division of BBB During mediation, a representative of the National Programs, Inc. BBB will contact both you and Ford Motor 1676 International Drive, Suite 550 Company to explore options for settlement McLean, VA 22102 of the claim.
Page 202: Getting Assistance Outside The U.s. And Canada
If your vehicle must be serviced while you importing your vehicle back into the U.S. are traveling or living in the Middle East, Ford dealerships outside of the U.S. and contact the nearest authorized dealer. If Canada may be unable to support the...
Page 203: Ordering Additional Owner's Literature
French Owner’s Manual can be obtained identification number (VIN) and new from your authorized dealer or by address with Ford Motor Company Export contacting Helm, LLC using the contact Operations & Global Growth Initiatives by information listed previously in this section.
Page 204: Reporting Safety Defects (Canada Only)
(CANADA ONLY) safety from www.safercar.gov. If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform Transport Canada and Ford of Canada. Transport Canada Contact Information Website http://tc.canada.ca/recalls...
Page 205: Fuses
Fuses The engine compartment fuse box is in the FUSE SPECIFICATION CHART engine compartment. It has high-current fuses that protect your vehicle's main Engine Compartment Fuse Box electrical systems from overloads. If you disconnect and reconnect the WARNING: Always disconnect the battery, you need to reset some features.
Page 206 Fuses Item Rating Protected Component Blower motor control. 20 A Upfitter - frame. 30 A Starter motor. — Not used. 20 A Upfitter relay 4. — Not used. — Not used. — Not used. 10 A Run/start spare. Rear view camera. 10 A Adaptive cruise control.
Page 207 Fuses Item Rating Protected Component — Not used. 20 A Upfitter battery feed. — Not used. 10 A Glow plug relay coil. — Not used. 60 A Hydromax pump. 20 A Powertrain control module. 20 A Heater exhaust gas oxygen sensor 11 (gas).
Page 208 Fuses Item Rating Protected Component Nitrogen oxide sensor control module tailpipe (diesel). Particulate matter sensor (diesel). 10 A Fuel volume control value (diesel). Fuel pressure regulator (diesel). Transmission control module (diesel). — Not used. — Not used. — Not used. 30 A Trailer brake control module.
Page 209 Fuses Item Rating Protected Component USB power. 10 A U-Haul parking lamps. 10 A Dual fuel tank selector switch (diesel). — Not used. — Not used. 20 A Driver seat compressor. 20 A Passenger seat compressor. 10 A Upfitter - run activate feed. 10 A Four pack solenoid differen- tial lock.
Page 210 Fuses Item Rating Protected Component — Not used. Upfitter switch (factory location for ignition power). Upfitter switch (optional location for power at all times). — Not used. — Not used. — Not used. — Not used. 10 A Cargo lamps. 20 A Urea tank heater.
Page 211 Fuses Passenger Compartment Fuse Box Pull the fuse panel cover toward you to remove it. When the clips of the panel The fuse panel is in the passenger footwell. disengage, let the panel fall easily. Remove the panel cover to access the Use the provided fuse puller tool to remove fuses.
Page 212 Fuses Item Rating Protected Component — Not used. 10 A Smart data link connector power. Air brake diagnostic connector. — Not used. — Not used. — Not used. — Not used. 7.5 A Smart data link connector. 7.5 A Instrument Cluster. Steering column control module.
Page 213 Fuses Item Rating Protected Component 30 A Right-hand front window motor. — Not used. — Not used. 15 A Relay folding mirror. Brake signal for air brake. Customer access stoplamp signal. Brake on-off isolation relay. Trailer tow stoplamp relay. 10 A Upfitter interface module.
Page 214: Changing A Fuse
Fuses CHANGING A FUSE Fuses WARNING: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe E217331 wire damage and could start a fire. If electrical components in the vehicle are not working, a fuse may have blown.
Page 215 Fuses J Case Low Profile. Slotted M Case. 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 216: Vehicle Inspection Guide
Vehicle Inspection Guide VEHICLE INSPECTION INFORMATION WARNING: Do not operate the vehicle if any suspension conditions listed in the following charts are evident. To make sure your vehicle is ready to Loss of steering or suspension could operate, conduct a pre-trip inspection at result in property damage, personal injury the beginning of each work period.
Page 217 Vehicle Inspection Guide Engine compartment (with engine off) Belts (fan, alternator, Inspect for glazing, fraying or cracking. There should be no water pump and air more than 5-7 cracks per rib, per 1 in (2.5 cm) conditioning compressor) Fluid leaks Inspect for signs of fluid puddles or dripping fluid on the ground under the engine, or the underside of the engine.
Page 218 Vehicle Inspection Guide Engine starting (with parking brake applied) Voltmeter Check the gauge (diesel engine) or indicator light (gasoline engine) to verify the alternator is charging. Steering linkage free play Inspect for excessive free play in the steering linkages. The steering wheel should have less than 2 in (5 cm) of free play at its rim.
Page 219 Vehicle Inspection Guide Front of vehicle Verify running lights are clean and unbroken. Steering gear Inspect for any missing or loose fasteners, power steering fluid leaks and damage to power steering hoses. Steering linkage Verify connecting links, arms and rods are not worn or cracked. Verify joints, sockets and boot seals are not worn or loose.
Page 220 Vehicle Inspection Guide Front brakes Hoses Inspect for cracked, worn or frayed hoses, and that all coup- lings are secure. Brake chambers Verify that there are no cracks or dents, and that the cham- bers are securely mounted. Slack adjusters Inspect for broken, loose or missing parts.
Page 221 Vehicle Inspection Guide Diesel Exhaust Fluid (DEF) area DEF tanks Verify the tanks and caps are secure and that there are no leaks from the tanks. Leaks Inspect for leaks from the tanks. Underbody Driveshaft Verify that the driveshaft is not bent or cracked and that all driveshaft couplings are secure.
Page 222 Vehicle Inspection Guide Tractor-coupling system Mounting bolts Inspect for loose or missing mounting brackets, clamps, bolts or nuts. Verify solid attachment of both fifth wheel and the slide mounting. Platform Inspect for cracks or breaks in the platform structure. Safety latch Verify engagement of the safety latch.
Page 223 Vehicle Inspection Guide Rear brakes Hoses Inspect for cracked, worn or frayed hoses, and that all coup- lings are secure. Brake chambers Verify that there are no cracks or dents, and that the cham- bers are securely mounted. Slack adjusters Inspect for broken, loose or missing parts.
Page 224 Vehicle Inspection Guide Inspect the transmission fluid level and shift linkage for proper operation. 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 225: Maintenance
Maintenance If your vehicle requires professional service, GENERAL INFORMATION an authorized dealer can provide the necessary parts and service. Check your warranty information to find out which WARNING: Making modifications parts and services are covered. to various parts, components and Use only recommended fuels, lubricants, systems of the vehicle, such as brake and fluids and service parts conforming to...
Page 226: Opening And Closing The Hood
Maintenance Quality service parts are available through 4. Raise your vehicle with the jack applied an authorized dealer. If dealer parts are not to the axle(s). Do not use the bumper used, make sure the replacement parts are as a lifting point. of equivalent quality.
Page 227 Maintenance Opening the Hood 2. Fully disengage the hood latches on both sides of your vehicle. E209159 Lift and release the hood latches on both sides of your vehicle. E209161 3. Tilt the hood fully forward until held by the gas struts. Note: Open the hood from the front of the grille.
Page 228: Under Hood Overview - 6.7L Diesel
Maintenance UNDER HOOD OVERVIEW - 6.7L DIESEL E389955 Engine compartment fuse box. See Fuses (page 201). Windshield washer fluid reservoir. See Washer Fluid Check (page 248). Secondary Cooling System Reservoir. See Engine Coolant Check (page 234). Engine coolant reservoir. See Engine Coolant Check (page 234). Secondary fuel filter.
Page 229: Under Hood Overview - 7.3L
Maintenance UNDER HOOD OVERVIEW - 7.3L E330964 Engine compartment fuse box. See Fuses (page 201). Engine oil dipstick. See Engine Oil Dipstick (page 226). Windshield washer fluid reservoir. See Washer Fluid Check (page 248). Automatic transmission fluid dipstick. See Automatic Transmission Fluid Check (page 242).
Page 230: Engine Oil Dipstick - 6.7L Diesel
Maintenance 2. Check the oil level before starting the ENGINE OIL DIPSTICK - 6.7L engine, or switch the engine off after DIESEL warm up and wait 15 minutes for the oil to drain into the oil pan. Note: Checking the oil level too soon could result in an inaccurate reading.
Page 231: Changing The Engine Oil And Oil Filter
Maintenance CHANGING THE ENGINE OIL WARNING: Do not remove the filler AND OIL FILTER cap when the engine is running. Do not use supplemental engine oil WARNING: Do not add engine oil additives because they are unnecessary when the engine is hot. Failure to follow and could lead to engine damage that the this instruction could result in personal vehicle warranty may not cover.
Page 232: Oil Change Indicator Reset
Maintenance • Frequent low-speed operation, or Message Action and Description consistent heavy traffic less than 25 mph (40 km/h). Oil Life Press and hold the OK Hold OK button until the instrument • Operating in severe dust conditions. to Reset cluster displays the •...
Page 233: Changing The Engine Air Filter - 6.7L Diesel
Maintenance The restriction gauge, on the upper housing Message Action and Description of the air filter assembly, measures the vacuum inside the air filter. The more the Oil Life: 100% air filter is dirty or clogged, the higher the When the oil change indic- vacuum reading.
Page 234 Maintenance We recommend the following actions after Locate the mass airflow sensor operating the vehicle up to 200 mi electrical connector on the air inlet (320 km) in heavy snowfall or extreme tube. Disconnect the electrical rain: connector. Unlock the locking clip on the connector, then squeeze and pull •...
Page 235: Changing The Engine Air Filter - 7.3L
Maintenance 4. Remove and install a new foam filter, Note: Operating your vehicle in heavy if needed. See Scheduled snowfall or extreme rain conditions may Maintenance (page 324). If you do not allow excessive amounts of snow or water replace the foam filter, be sure the into the air intake system.
Page 236 Maintenance E317616 2. Reposition the locking clip on the connector, squeeze the connector and E317618 pull it off the air outlet tube. 5. Remove the clips that secure the air filter housing cover. Push the air filter cover toward the center of the vehicle and up slightly to release it.
Page 237: Draining The Fuel Filter Water Trap - 6.7L Diesel
Maintenance Draining the Diesel Fuel Conditioner Module (DFCM) WARNING: Do not drain the water-in-fuel separator while the engine is running. Failure to follow this warning may result in fire, serious injury, death or property damage. Note: If you drain the diesel fuel conditioner module while the system is running air will enter into the fuel system.
Page 238: Engine Coolant Check - 6.7L Diesel
Maintenance 3. Rotate the drain counterclockwise until Note: Make sure that the coolant level is the O-ring is visible. Allow the diesel between the MIN and the MAX marks on fuel conditioner module to drain for the coolant reservoir. approximately 25 seconds or until Note: Coolant expands when it is hot.
Page 239 50/50 with distilled water. See Note: Coolants marketed for all makes and Cooling System Capacity and models may not be approved to Ford Specification (page 300). Using water that specifications and may cause damage to has not been deionized may contribute to the cooling system.
Page 240 Maintenance 3. Refill with prediluted coolant as soon Start and run the engine at 2000 rpm as possible. for 2 minutes. 8. Switch the engine off and remove the Water alone, without prediluted coolant, pressure relief cap as previously can cause engine damage from corrosion, outlined.
Page 241: Engine Coolant Check - 7.3L
Maintenance Engine-driven Cooling Fan (Fan Follow your community’s regulations and Clutch) standards for recycling and disposing of automotive fluids. Your vehicle may have an engine driven Severe Climates cooling fan drive (also called a fan clutch). This fan drive changes the fan speed to If you drive in extremely cold climates: match the vehicle’s changing cooling air flow requirements.
Page 242 Maintenance WARNING: To reduce the risk of WARNING: Do not remove the personal injury, make sure the engine is coolant reservoir cap when the engine is cool before unscrewing the coolant on or the cooling system is hot. Wait 10 pressure relief cap.
Page 243 Maintenance For vehicles with overflow coolant systems If you have to add more than 1.1 qt (1 L) of with a non-pressurized cap on the coolant engine coolant per month, have your recovery system, add coolant to the vehicle checked as soon as possible. coolant recovery reservoir when the engine Operating an engine with a low level of is cool.
Page 244 Maintenance Engine-driven Cooling Fan (Fan Dispose of used engine coolant in an Clutch) appropriate manner. Follow your community’s regulations and standards Your vehicle comes with an engine driven for recycling and disposing of automotive cooling fan drive, also called a fan clutch. fluids.
Page 245 Maintenance If the engine reaches a preset Your vehicle has limited engine power over-temperature condition, the engine when in the fail-safe mode, drive your switches to alternating cylinder operation. vehicle with caution. Your vehicle does not Each disabled cylinder acts as an air pump maintain high-speed operation and the and cools the engine.
Page 246: Automatic Transmission Fluid Check - 10-Speed Automatic Transmission
Maintenance At this time, you may notice the coolant AUTOMATIC TRANSMISSION temperature gauge moves toward the red FLUID CHECK - 10-SPEED zone and a message may appear in the AUTOMATIC TRANSMISSION information display. You may notice a reduction in vehicle The transmission does not consume fluid.
Page 247 Maintenance 8. If the fluid level is correct, replace the High Fluid Level dipstick and make sure it is fully seated. Note: If the fluid level is between the maximum and minimum marks, the fluid level is acceptable. Do not add fluid. Transmission Fluid Level Low Fluid Level E163744...
Page 248: Brake Fluid Check
Maintenance BRAKE FLUID CHECK WARNING: Do not use any fluid other than the recommended brake fluid as this will reduce brake efficiency. Use of incorrect fluid could result in the loss of vehicle control, serious personal injury or death. WARNING: Only use brake fluid from a sealed container.
Page 249: Power Steering Fluid Check
Maintenance For detailed interval information, see CHANGING THE 12V BATTERY Scheduled Maintenance in your Owner's Manual or your local maintenance guide. WARNING: This vehicle may be POWER STEERING FLUID equipped with more than one battery, removal of cable from only one battery CHECK does not disconnect the vehicle electrical system.
Page 250 Maintenance Note: Battery posts, terminals and related 5. Turn the air conditioning (if equipped) accessories contain lead and lead on and allow the engine to idle for at compounds. Wash hands after handling. least one minute. 6. Release the parking brake. With your Note: Electrical or electronic accessories foot on the brake pedal and with the or components added to the vehicle by the...
Page 251: Adjusting The Headlamps
Park the vehicle directly in front of a the battery should only be replaced with wall or screen on a level surface, a Ford recommended replacement battery approximately 25 ft (7.6 m) away. which matches the electrical requirements 2. Measure the height of the headlamp of the vehicle.
Page 252: Washer Fluid Check
4. On the wall or screen you will observe low. Only use a washer fluid that meets a flat zone of high intensity light Ford specifications. See Capacities and located at the top of the right hand Specifications (page 290).
Page 253: Changing The Wiper Blades
Maintenance Run the tip of your fingers over the edge of Note: Make sure that the wiper blade locks the blade to check for roughness. into place. Lower the wiper arm and blade back on the windshield. The wiper arms will Clean the wiper blades with washer fluid automatically return to their normal position or water applied with a soft sponge or...
Page 254: Changing The Engine-Mounted And Diesel Fuel Conditioner Module Fuel Filters - 6.7L Diesel
Maintenance Brake Lamp, Rear Lamp, Rear Headlamp bulbs must be marked with an Direction Indicator, License Plate authorized D.O.T. marking for North America to make sure they have the proper Lamp and Reverse Lamp lamp performance, light brightness, light pattern and safe visibility. Install in the reverse order unless otherwise stated.
Page 255 Maintenance Regular fuel filter changes are an important part of engine maintenance; failing to keep with the scheduled maintenance could lead to engine performance issues and fuel injection system damage. See Scheduled Maintenance (page 324). Use only recommended service parts conforming to specifications.
Page 256 Maintenance 4. Disconnect the electrical connector. 2. Install the lower portion of the housing on the top portion. Tighten by hand 5. Fully loosen the lower portion of the until you feel a strong resistance. diesel fuel conditioner module housing Continue to tighten with a 32mm using the nut cast into the lower socket wrench until the mechanical...
Page 257: Electrical System Inspection
Maintenance Removal 2. Reconnect the fuel lines. 3. Switch the ignition on for 30 seconds and then switch the ignition off. Repeat this operation six times in a row to purge any trapped air from the fuel system. ELECTRICAL SYSTEM INSPECTION Periodically inspect electrical connectors on the outside of the cab and on the engine...
Page 258: Air Induction System Inspection
Maintenance Before engine operation, remove any debris AIR INDUCTION SYSTEM blocking the core. INSPECTION • Turbocharger-to-charge air cooler. • Charge air cooler-to-intake manifold pipe. WARNING: When performing • Mounting bracket. maintenance to any turbocharged engine with engine air inlet piping disconnected, •...
Page 259: Brake System Inspection
Maintenance Air Brakes BRAKE SYSTEM INSPECTION WARNING: Do not manually adjust WARNING: Always wear a the automatic slack adjusters to correct respirator approved by the National excessive push rod stroke as it may result Institute of Occupational Studies of in reduced brake effectiveness and a Health (NIOSH) or Mine Safety and vehicle crash.
Page 260 Maintenance as a stroke indicator to aid in Air Dryer adjustment checks. If the push rod is Climactic conditions affect performance clean and the brakes are out of of desiccant or after-cooler type air dryers. adjustment, you can see the orange You must establish a maintenance marker protruding from the chamber schedule for each specific operation.
Page 261 Maintenance any air tanks equipped with automatic inspection and keep to instructions moisture ejector valves, as required, to provided by the service manual. maintain a dry air system. Contact an Hydraulic brake systems are authorized dealer if you are unsure of the power-assisted.
Page 262: Axle Inspection
Maintenance Follow the tire manufacturer's AXLE INSPECTION recommended cold inflation pressure for the tire size, load range (ply rating) and Front Axle steer axle loading typical for their operation Maintaining the front axle alignment to (each steer axle tire equals ½ steer axle specifications is very important.
Page 263: Suspension System Inspection
Maintenance • Maintaining proper steering gear and • For proper suspension alignment. power steering pump lubricant levels. Maintain proper alignment at all times. • Checking steering column joint bolts • U-bolts. After the chassis has been and steering linkage, particularly for operating under load for 1,000 mi body-to-chassis clearance.
Page 264: Spring U-Bolt Check
Maintenance 2. Set the parking brake and shift into Inspect the U-bolt threads for rust and position neutral (N) or park (P). Turn debris. Clean the threads if contaminated. the engine off. U-bolt Nut Torque 3. Clean any dirt from around the axle filler plug.
Page 265: Vehicle Care
Vehicle Care GENERAL INFORMATION CLEANING PRODUCTS Materials Your dealer has many quality products available to clean your vehicle and protect For best results, use the following products its finishes. or products of equivalent quality: For additional information and assistance, we recommend that you contact an authorized dealer.
Page 266 Vehicle Care Exterior Chrome Parts • Dry your vehicle with a chamois or soft terry cloth towel to eliminate water • Apply a high quality-cleaning product spotting. to bumpers and other chrome parts. • Immediately remove fuel spillages, bird Follow the manufacturer’s instructions. droppings, insect deposits and road tar.
Page 267: Waxing
Vehicle Care Underbody • Do not apply wax to glass areas. • After waxing, your car's paint should Regularly clean the entire underside of your feel smooth, and be free of streaks and vehicle. This includes the chassis, body smudges. floor sheet metal and wheel wells using fresh water.
Page 268: Cleaning The Windows And Wiper Blades
Vehicle Care CLEANING THE WINDOWS AND WIPER BLADES WARNING: On vehicles equipped with seat-mounted airbags, do not use chemical solvents or strong detergents. Car wash chemicals and environmental Such products could contaminate the fallout can result in windshield and wiper side airbag system and affect blade contamination.
Page 269: Cleaning The Instrument Panel And Instrument Cluster Lens
Regularly clean them with a wheel If a staining liquid like coffee or juice has cleaner. We recommend that you use been spilled on the instrument panel or on Ford approved wheel cleaner if interior trim surfaces: available. Wipe up spilled liquid using a clean, 2.
Page 270: Vehicle Storage
3. Remove tar and grease with a bug and tar remover. We recommend that you • Wash your vehicle thoroughly to use Ford approved bug and tar remover remove dirt, grease, oil, tar or mud from if available. exterior surfaces, rear-wheel housing 4.
Page 271 Vehicle Care Cooling system Removing Vehicle From Storage • Protect against freezing temperatures. When your vehicle is ready to come out of storage, do the following: • When removing your vehicle from storage, check coolant fluid level. • Wash your vehicle to remove any dirt Confirm that there are no cooling or grease film build-up on window system leaks and that fluid is at the...
Page 272: Wheels And Tires
Wheels and Tires *Cold tire pressure: The tire TIRE CARE pressure when the vehicle has Glossary of Tire Terminology been stationary and out of direct sunlight for an hour or more and *Tire label: A label showing the prior to the vehicle being driven for original equipment tire sizes, 1 mi (1.6 km).
Page 273 Wheels and Tires Information on P Type Tires B. 215: Indicates the nominal width of the tire in millimeters from sidewall edge to sidewall edge. In general, the larger the number, the wider the tire. C. 65: Indicates the aspect ratio which gives the tire's ratio of height to width.
Page 274 Wheels and Tires the week and year the tire was built. For example, the numbers Letter Speed Rating 317 mean the 31st week of 1997. Rating After 2000 the numbers go to four 75 mph (120 km/h) digits. For example, 2501 means the 25th week of 2001.
Page 275 Wheels and Tires *Traction: The traction grades, Additional Information from highest to lowest are AA, A, Contained on the Tire Sidewall B, and C. The grades represent the for LT Type Tires tire's ability to stop on wet Note: Tire Quality Grades do not pavement as measured under apply to this type of tire.
Page 276 Wheels and Tires C. Maximum Load Dual lb (kg) at psi (kPa) cold: Indicates the maximum load and tire pressure when the tire is used as a dual; defined as four tires on the rear axle (a total of six or more tires on the vehicle).
Page 277 Inflate all tires to the information found on the tire. The inflation pressure recommended Ford recommended tire inflation by Ford Motor Company. pressure is found on the Safety Compliance Certification Label or You are strongly urged to buy a Tire Label.
Page 278 Wheels and Tires Maximum Inflation Pressure is Note: If you are checking tire the tire manufacturer's maximum pressure when the tire is hot, for permissible pressure and the example, driven more than 1 mi pressure at which the maximum (1.6 km), never bleed or reduce air load can be carried by the tire.
Page 279 Wheels and Tires Note: Some spare tires operate at After inflating the tires while hot, a higher inflation pressure than the make sure to recheck tire pressure other tires. For T type mini-spare later once the tires are cold. tires, see the Dissimilar spare wheel and tire assembly information for For Example Only a description.
Page 280 Wheels and Tires All tires with Steel Carcass Plies according to Federal Occupational (if equipped): Safety and Health Administration regulations. For example, during This type of tire utilizes steel cords any procedure involving tire in the sidewalls. As such, they inflation, the technician or cannot be treated like normal light individual must utilize a remote...
Page 281 Wheels and Tires E161438 Stay out of trajectory wear. If internal damage to the tire Inspecting Your Tires and is suspected, have the tire Wheel Valve Stems demounted and inspected in case it needs to be repaired or replaced. Periodically inspect the tire treads For your safety, tires that are for uneven or excessive wear and damaged or show signs of...
Page 282 Wheels and Tires Improper or inadequate vehicle Damage maintenance can cause tires to Periodically inspect the tire treads wear abnormally. Inspect all your and sidewalls for damage, such tires, including the spare, as bulges in the tread or sidewalls, frequently, and replace them if cracks in the tread groove and one or more of the following separation in the tread or sidewall.
Page 283 Wheels and Tires U.S. DOT Tire Identification Number WARNING: Only use replacement tires and wheels Both United States and Canada that are the same size, load Federal regulations require tire index, speed rating, and type as manufacturers to place those originally provided for your standardized information on the vehicle.
Page 284 20 psi spinning the tires can tear the (1.38 bar) greater than the tire and cause an explosion. A maximum pressure, a Ford tire can explode in as little as dealer or other tire service three to five seconds.
Page 285 Wheels and Tires a greater chance of causing tire allowable loads for the particular damage than at a lower speed. application will build up excessive Moreover, driving at high speed heat that may result in sudden tire reduces the reaction time destruction.
Page 286 Wheels and Tires following the US Tire When tires are stored, be sure they Manufacturers Association are placed away from sources of (USTMA) recommended repair heat and ozone such as direct procedures. Plug-only repairs sunlight, hot pipes and electric done on-the-wheel are considered generators.
Page 287 Wheels and Tires on the road. If a tire is mounted by REMEMBER... TO AVOID error on the wrong-sized rim, do DAMAGE TO YOUR TIRES AND not remount it on the proper rim - POSSIBLE ACCIDENT: scrap it. It may have been •...
Page 288 Wheels and Tires • Avoid potholes and objects on Tire and Wheel Alignment the road A bad jolt from hitting a curb or • Do not run over curbs or hit the pothole can cause the front end tire against a curb when of your vehicle to become parking misaligned or cause damage to...
Page 289 Wheels and Tires Note: Your vehicle may be equipped with a dissimilar spare wheel and tire assembly. A dissimilar spare wheel and tire assembly is defined as a spare wheel and tire assembly that is different in brand, size or appearance from the road tires and wheels.
Page 290: Using Snow Chains
Wheels and Tires Sometimes irregular tire wear can • Drive cautiously. If you hear the chains rub or bang against your vehicle, stop be corrected by rotating the tires. and retighten the chains. If this does not work, remove the chains to prevent USING SNOW CHAINS damage to your vehicle.
Page 291 Wheels and Tires 3. Replace the flat tire with the spare tire, making sure the valve stem is facing WARNING: Do not attempt to outward on all front and inboard rear change a tire on the side of the vehicle wheels.
Page 292: Technical Specifications
M22 x 1.5 450 500 lb.ft (610 678 Nm) Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. On vehicles equipped with single rear wheels, retighten the lug nuts to the specified torque at 100 mi (160 km) after any wheel disturbance (such as tire rotation, changing a flat tire, wheel removal).
Page 293 Wheels and Tires E145950 Hub pilot bore Inspect the wheel pilot hole and mounting surface prior to installation. Remove any visible corrosion or loose particles. 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 294: Capacities And Specifications
Capacities and Specifications ENGINE SPECIFICATIONS - 6.7L DIESEL Engine 6.7L V8 Diesel Engine Displacement. 406 in³ (6,651 cm³) Required fuel. Ultra Low Sulfur Diesel up to B20 Firing order. 1-3-7-2-6-5-4-8 Compression ratio. 15.2:1 Single Alternator With Air Brake Drivebelt Routing Compressor Single Alternator E224825...
Page 295: Engine Specifications - 7.3L
Capacities and Specifications Dual Alternator Dual Alternator With Air Brake Compressor E224826 Drivebelt closest to the engine. E224820 Drivebelt furthest from the engine. Note: The belt routings show vehicles with air conditioning. When vehicles do not have air conditioning, an idler pulley is in place of the A/C compressor.
Page 296: Motorcraft Parts - 6.7L Diesel
Capacities and Specifications Drivebelt Routing Dual Alternator Single Alternator E388772 E388771 Drivebelt closest to the engine. Drivebelt furthest from the Drivebelt closest to the engine. engine. Drivebelt furthest from the engine. MOTORCRAFT PARTS - 6.7L DIESEL Component Part Number FL-2124-S Engine oil filter.
Page 297 Capacities and Specifications Component Part Number Three batteries (optional)(2700 CCA). BH-31-XT Windshield wiper blade. WW-2208 If a Motorcraft oil filter is not available, use an oil filter that meets WSS-M99P55-D1 Performance Specification We recommend Motorcraft parts that are available at your authorized dealer or at www.fordparts.com.
Page 298: Motorcraft Parts - 7.3L
Capacities and Specifications MOTORCRAFT PARTS - 7.3L Component Motorcraft Part Number Air filter element. FA-2061 One battery (standard)(900 CCA). BH-31-XT Two batteries (optional)(except for Limited BH-31-XT Series)(1800 CCA total). Three batteries (optional)(2700 CCA). BH-31-XT FL-820-S Engine oil filter. Spark plug. SP-589 Transmission fluid filter.
Page 299: Bulb Specification Chart
Capacities and Specifications North America and an “E” for Europe to BULB SPECIFICATION CHART ensure lamp performance, light brightness and pattern and safe visibility. The correct Replacement bulbs are specified in the bulbs will not damage the lamp assembly chart below. Headlamp bulbs must be or void the lamp assembly warranty and marked with an authorized “D.O.T.”...
Page 300 Capacities and Specifications Engine Oil We recommend Motorcraft motor oil for your vehicle. If Motorcraft motor oil is not available, use motor oil of the recommended viscosity grade that meets our specification WSS-M2C171-F1. You can find the list of approved motor oils at www.motorcraft.com.
Page 301 Capacities and Specifications Capacities Variant Including the Oil Filter All. 17.0 qt (16.1 L) Materials Name Specification Motorcraft® SAE 10W-30 Super Duty Diesel Motor WSS-M2C171-F1 Oil(U.S.) Motorcraft® Super Duty Motor Oil SAE 10W-30 / Huile moteur Super Duty SAE 10W-30 Motor- craft®(Canada) XO-10W30-QSDF(U.S.) CXO-10W30-LSD12(Canada)
Page 302: Engine Oil Capacity And Specification - 7.3L
Capacities and Specifications Materials Name Specification Motorcraft® SAE 5W-40 Full Synthetic Diesel Motor WSS-M2C171-F1 Oil(U.S.) (Canada) XO-5W40-5Q3SD(U.S.) Motorcraft® SAE 15W-40 Super Duty Diesel Motor WSS-M2C171-F1 Oil(U.S.) Motorcraft® Super Duty Motor Oil SAE 15W-40 / Huile moteur Super Duty SAE 15W-40 Motor- craft®(Canada) XO-15W40-QSDF(U.S.) CXO-15W40-LSD12(Canada)
Page 303 Capacities and Specifications We recommend Motorcraft motor oil for engines. your vehicle. If Motorcraft oil is not Do not use supplemental engine oil available, use motor oils of the additives because they are unnecessary recommended viscosity grade that display and could lead to engine damage that your the API Certification Mark for gasoline vehicle warranty does not cover.
Page 304: Cooling System Capacity And Specification - 6.7L Diesel
Capacities and Specifications E240523 Note: If you use your vehicle regularly above If you do not use coolant that meets the the altitude of 5,000 ft (1,524 m) and under defined specification, it could result in: the temperature of -4.0°F (-20°C), it is •...
Page 305: Cooling System Capacity And Specification - 7.3L
Capacities and Specifications Materials Name Specification Motorcraft® Yellow Prediluted Antifreeze/ WSS-M97B57-A2 Coolant(U.S.) Motorcraft® Yellow Prediluted Antifreeze/Coolant / Antigel/liquide de refroidissement prédilué jaune Motorcraft®(Canada) VC-13DL-G(U.S.) CVC-13DL-G(Canada) If you do not use coolant that meets the defined specification, it could result in: COOLING SYSTEM CAPACITY •...
Page 306: Fuel Tank Capacity - Diesel
Capacities and Specifications FUEL TANK CAPACITY - DIESEL Capacities Variant Quantity Small. 50 gal (189.2 L) Medium. 55 gal (208.2 L) Large. 65 gal (246 L) With dual tanks - Driver side tank. 65 gal (246 L) With dual tanks - Passenger side tank. 50 gal (189.2 L) 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 307: Fuel Tank Capacity - Gasoline
Capacities and Specifications FUEL TANK CAPACITY - GASOLINE Capacities Variant Quantity Small. 50 gal (189.2 L) Large. 60 gal (227.1 L) 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 308: Air Conditioning System Capacity And Specification - 6.7L Diesel
Capacities and Specifications AIR CONDITIONING SYSTEM the air conditioning refrigerant system CAPACITY AND can cause personal injury. SPECIFICATION - 6.7L DIESEL Use refrigerant and oil that meets the defined specifications. If you do not use refrigerant and oil that WARNING: The air conditioning meets the defined specifications, it could refrigerant system contains refrigerant result in:...
Page 309: Air Conditioning System Capacity And Specification - 7.3L
Capacities and Specifications AIR CONDITIONING SYSTEM the air conditioning refrigerant system CAPACITY AND can cause personal injury. SPECIFICATION - 7.3L Use refrigerant and oil that meets the defined specifications. If you do not use refrigerant and oil that WARNING: The air conditioning meets the defined specifications, it could refrigerant system contains refrigerant result in:...
Page 310: Diesel Exhaust Fluid Capacity And Specification
Capacities and Specifications Materials Name Specification Motorcraft® Premium Windshield Wash Concen- WSS-M14P19-A trate with Bitterant(U.S.) Motorcraft® Premium Quality Windshield Washer Fluid -35 °C / Liquide lave-glace de haute qualité - 35 °C Motorcraft®(Canada) ZC-32-B2(U.S.) CXC-37-M(Canada) DIESEL EXHAUST FLUID CAPACITY AND SPECIFICATION Capacities Variant Quantity...
Page 311: Automatic Transmission Fluid Capacity And Specification - Gasoline
Capacities and Specifications Capacities Variant Quantity All. 18.2 qt (17.2 L) Approximate dry fill capacity. Actual amount could vary during fluid changes. Materials Name Specification Motorcraft® MERCON® ULV Automatic Transmis- WSS-M2C949-A, sion Fluid(U.S.) Motorcraft® MERCON® ULV Automatic Transmis- sion Fluid / MERCON® ULV huile pour boîtes auto- matique Motorcraft®(Canada) XT-12-QULV(U.S.
Page 312: Brake Fluid Specification
Capacities and Specifications Materials Name Specification Motorcraft® MERCON® LV Automatic Transmission WSS-M2C938-A Fluid(U.S.) Motorcraft® MERCON® LV Automatic Transmission Fluid / Huile pour boîte automatique MERCON® LV Motorcraft®(Canada) XT-10-QLVC(U.S.) CXT-10-LV6(Canada) If you do not use fluid that meets the defined specification and viscosity grade, BRAKE FLUID SPECIFICATION it could result in: •...
Page 313 Capacities and Specifications Capacities Variant Quantity S-140 (13.5K, 17.5K, 19K single-speed). 9.5 qt (9 L) 21060S (21K single-speed). 11.2 qt (10.6 L) 21065T/P (21K two-speed). 17.5 qt (16.6 L) S23-172 (23K single-speed). 14.3 qt (13.5 L) S26-190 (26K single-speed). 18.5 qt (17.5 L) Materials Name Specification...
Page 314: Rear Axle Fluid Capacity And Specification - Gasoline
Capacities and Specifications If you do not use fluid that meets the REAR AXLE FLUID CAPACITY defined specification and viscosity grade, AND SPECIFICATION - it could result in: GASOLINE • Component damage that your vehicle warranty does not cover. Use fluid that meets the defined •...
Page 315: Hydraulic Power Steering Fluid Capacity And Specification
Capacities and Specifications If you do not use oil and fluid that meets HYDRAULIC POWER the defined specification and viscosity STEERING FLUID CAPACITY grade, it could result in: AND SPECIFICATION • Component damage that your vehicle warranty does not cover. Use oil and fluid that meets the defined •...
Page 316: Vehicle Identification
Vehicle Identification VEHICLE IDENTIFICATION NUMBER LOCATING THE VEHICLE IDENTIFICATION NUMBER The vehicle identification number is on the left-hand side of the instrument panel. E142477 World manufacturer identifier. Brake system, gross vehicle weight rating, restraint devices and their locations. Make, vehicle line, series, body type.
Page 317: Connected Vehicle
Some remote features require additional 3. Add your vehicle or select your vehicle service activation. Log in to your Ford if already added. account for details. Some restrictions, third 4. Select the option to activate your party terms and message or data rates vehicle.
Page 318: Audio System
Audio System (If Equipped) GENERAL INFORMATION hand-held device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws WARNING: Driving while distracted that may affect the use of electronic can result in loss of vehicle control, crash devices while driving.
Page 319 Audio System (If Equipped) Accessing the Sound Settings Note: You can change between auto or manual tuning with the rotary control using Press the button to adjust the the system settings. sound settings. You can also Note: You can change radio stations using E280315 activate and set the sensitivity the seek buttons.
Page 320 Audio System (If Equipped) Selecting a Menu Option Switching the Audio Unit On and E260781 E260686 Selecting the Radio Press and release the button. Press the button to select radio Using a Cell Phone mode. Press the button to either Press the button again to display answer an incoming phone call the available radio sources.
Page 321: Connecting A Bluetooth® Device
Audio System (If Equipped) In satellite radio mode, press and release Press the button once to return to select the next or previous satellite radio to the beginning of the track. station. If you select a specific category, Repeatedly press the button to such as jazz, rock or news, press to find the return to previous tracks.
Page 322: Audio Input Jack
Audio System (If Equipped) Sorting by Categories The auxiliary input jack allows you to connect and play music from your portable You can also sort and play music by music player through your vehicle speakers. specific categories, for example artist or You can use any portable music player album.
Page 323: Usb Port
Audio System (If Equipped) Press and hold the voice control USB PORT button on the audio unit. E142599 Note: This only works when connected via WARNING: Driving while distracted Bluetooth. See Connecting a Bluetooth® can result in loss of vehicle control, crash Device (page 317).
Page 324: Auxiliary Switches
Each switch includes a power lead, a • If you or an authorized Ford dealer add blunt-cut and sealed wire below the any non-Ford electrical or electronic instrument panel and to the left of the accessories or components to your steering column in the driver footwell area.
Page 325 AUX 4 CAC08 Brown Learn more about auxiliary switches by visiting: Web Address www.fleet.ford.com/truckbbas/ Upfitter Interface Module (If Equipped) The Upfitter Interface Module (UIM) is an electronic control module that operates equipment, such as lift buckets, cranes, motors, salt spreaders and snow plows, with external relays.
Page 326: Ford Protect
If you bring your car into your dealer for Vehicle Limited Warranty coverage. When service, we’ll give you a loaner to use for you visit your Ford Dealer, Insist on Ford the day. Protect extended service plans! Extended Rental Benefits...
Page 327 To learn This information is subject to change. For more, call our Ford Protect extended more information; visit your local Ford of service plan specialists at 800-367-3377. Canada dealer or www.ford.ca to find the...
Page 328: Scheduled Maintenance
If you do not use Ford authorized parts they you sell or trade it. Keep all receipts for may not meet our specifications and completed maintenance with your vehicle.
Page 329 Additives and Chemicals A message appears in the instrument cluster display when it is time for an oil This owner's manual and the Ford change. Make sure you perform the oil Workshop Manual list the recommended change within two weeks or 500 mi additives and chemicals for your vehicle.
Page 330 Ford vehicle crash. Excessive push rod stroke recommends that you perform indicates that a problem exists with the...
Page 331 Scheduled Maintenance Check Every Month Air filter restriction gauge. Engine oil level. Fuel and water separator. Drain if necessary, or if indicated by the information display. Function of all interior and exterior lights. Holes and slots in the tail pipe to make sure they are functional and clear of debris. Tires (including spare) for wear and proper pressure.
Page 332 Scheduled Maintenance Tightening Lug Nuts Tighten the lug nuts to the specified torque at 500 mi Single rear wheels (800 km) after any wheel disturbance (such as tire rota- tion, changing a flat tire or wheel removal). Tighten the wheel lug nuts to the specified torque 100 mi (160 km), and again at 500 mi (800 km) of new Dual rear wheels vehicle operation and after any wheel disturbance (such...
Page 333: Normal Scheduled Maintenance
Scheduled Maintenance Multi-point Inspection For oil and fluid leaks Washer spray and wiper operation Hood rest for lubrication Hazard warning system operation Brake, coolant recovery reservoir, automatic transmission, power steering and window washer. If your vehicle is equipped with a temporary mobility kit, check the tire sealant expiration Use By date on the canister.
Page 334 Scheduled Maintenance When to Expect the OIL CHANGE REQUIRED Message Interval Vehicle Use and Example Mountainous or off-road conditions Extended idling Extended hot or cold operation Extreme 3,000 5,000 mi Maximum load or towing (4,800 8,000 km) Extreme hot or cold operation Use of high sulfur diesel fuel Note: Use the appropriate special operating Normal Maintenance Intervals...
Page 335 Scheduled Maintenance 15,000 mi (24,000 km) or 12 Months Whichever Comes First Inspect the automatic transmission fluid level. Consult an authorized dealer for requirements. Inspect the brake pads, shoes, rotors, drums, brake linings, hoses and the parking brake. Inspect the engine cooling system concentration, freeze-point protection, coolant level and hoses.
Page 336 Scheduled Maintenance Other Maintenance Items Replace the front wheel bearings and seals if you have non-sealed bearings. Every 200,000 mi Change the engine coolant. (320,000 km) If not replaced, inspect every 15,000 mi (24,000 km). Initial replacement at 10 years or 200,000 mi (320,000 km), then every five years or 100,000 mi (160,000 km).
Page 337 Scheduled Maintenance At Every Oil Change Interval as Indicated by the Information Display Inspect the steering linkage, ball joints, suspension, tie-rod ends, driveshaft and the U- joints. Lubricate any components that have grease fittings. Inspect front oil hubs for leaks and check fluid level through hub cap sight glass. Do not exceed one year/10,000 mi (16,000 km) or 350 engine hours between service intervals.
Page 338: Special Operating Conditions Scheduled Maintenance
Scheduled Maintenance Other Maintenance Items Change the rear axle fluid. See Special Operating At 100,000 mi (160,000 km) Conditions Scheduled Maintenance (page 334). Change the automatic transmission fluid and filter. Consult an authorized dealer for requirements. Every 150,000 mi Replace the accessory drive belt or belts if not replaced (240,000 km) within the last 100,000 mi (160,000 km).
Page 339 Scheduled Maintenance Towing a Trailer Inspect frequently, service Inspect and lubricate the U-joints. as required See axle maintenance items under Exceptions. Every 5,000 mi (8,000 km) Inspect the wheels and related components for abnormal noise, wear, looseness or drag. Every 5,000 mi (8,000 km) Change the engine oil and filter.
Page 340 Scheduled Maintenance Extensive Idling or Low-speed Driving for Long Distances, as in Heavy Commercial Use (Such as Delivery, Taxi, Patrol Car or Livery) Short Trips that do not allow the engine to get to operating temperature causing fuel dilution and an increase of the engine oil level Every 7,500 mi (12,000 km) Rotate the tires and inspect them for wear, and measure...
Page 341 Scheduled Maintenance Off-road Operation Inspect the wheels and related components for abnormal noise, wear, looseness or drag. Every 7,500 mi (12,000 km) Rotate the tires and inspect them for wear, and measure the tread depth. Rotate the front wheels on vehicles with dual rear wheels when specified. Only rotate the rear wheels if you notice unusual wear.
Page 342 Scheduled Maintenance Frequent or Extended Idling, Over 10 Minutes Per Hour of Normal Driving or Frequent Low-speed Operation if You Use Your Vehicle for Stationary Operation As required Change the engine oil and filter as indicated by the instru- ment cluster display, and perform the services listed in the scheduled maintenance chart.
Page 343 Scheduled Maintenance Frequent Low-speed Operation, Consistent Heavy Traffic Under 25 mph (40 km/h) or Long Rush-hour Traffic As required Change the engine oil and filter as indicated by the instru- ment cluster display, and perform the services listed in the scheduled maintenance chart.
Page 344 Scheduled Maintenance Sustained High-speed Driving at Gross Vehicle Weight Rating, Maximum Loaded Weight for Vehicle Operation As required Change the engine oil and filter as indicated by the instru- ment cluster display, and perform the services listed in the scheduled maintenance chart. Every 15,000 mi Replace the engine-mounted and frame-mounted fuel (24,000 km), six months or...
Page 345 Scheduled Maintenance Operating in Dusty or Sandy Conditions, Such as Unpaved or Dusty Roads Inspect the steering and suspension ball joints and tie rods. Lubricate any grease fittings. Every 7,500 mi (12,000 km), Change the engine oil and filter. six months or 300 engine hours Inspect and lubricate the U-joints.
Page 346 Scheduled Maintenance Off-road Operation Every 15,000 mi Replace the engine-mounted and frame-mounted fuel (24,000 km), six months or filters. 600 engine hours Every 30,000 mi Replace the air inlet foam filter. (48,000 km) Rotate the front wheels on vehicles with dual rear wheels when specified. Only rotate the rear wheels if you notice unusual wear.
Page 347 Scheduled Maintenance Rear Axle Maintenance Diesel Particulate Filter A rear axle fluid change or level check is Over time, a slight amount of ash builds not required unless you suspect a leak or up in the diesel particulate filter, which is the assembly has been submerged in not removed during the regeneration water.
Page 348: Customer Information
Customer Information ROLLOVER WARNING WARNING: Do not become overconfident in the ability of four-wheel drive vehicles. Although a four-wheel WARNING: Utility vehicles have a drive vehicle may accelerate better than significantly higher rollover rate than a two-wheel drive vehicle in low traction other types of vehicles.
Page 349 Customer Information Argentina European Union EU E310043 E308030 Brazil Ghana E340118 Djibouti E340191 Indonesia E342394 E342395 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 350 Customer Information Israel HIDF16000009 Mauritania E402791 Jamaica E340190 Moldova E340518 Malaysia E337971 Morocco E269697 E340192 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 351 Customer Information Pakistan Singapore E342396 E340193 Paraguay South Africa E308039 E340194 Serbia South Korea E308040 E339675 R-CMM-DLH-L2C0065TR 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 352 Customer Information Syria United Arab Emirates E342397 Taiwan, China E308044 United Kingdom E362840 E340195 Ukraine United States and Canada WARNING: Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment. The term "IC:" before the radio certification number only signifies that Industry Canada technical specifications were met.
Page 353: Warranty Information
New vehicle limited warranties. assemblies. Where a warrantable condition • Emissions warranties, if applicable. exists, Ford Motor Company will repair your (Note: Fully-electric vehicles are not vehicle at no cost to you including eligible for emissions warranties.) diagnosis, parts and labor.
Page 354 - You are responsible for presenting your vehicle to a Ford or Lincoln dealer as soon as a problem exists. The warranty repairs should be completed in a reasonable amount of time, not to exceed 30 days.
Page 355: Appendices
Appendices Note: We test and certify your vehicle to ELECTROMAGNETIC meet electromagnetic compatibility COMPATIBILITY legislation. It is your responsibility to make sure that any equipment an authorized dealer installs on your vehicle complies with applicable local legislation and other WARNING: Do not place objects requirements.
Page 356 Appendices E239122 Truck E239121 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 357 Appendices Frequency Band Maximum Output Power Watt Antenna Positions (Peak RMS) 1-30 50-54 2, 3 68-88 2, 3 142-176 2, 3 380-512 2, 3 806-870 2, 3 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 358 2025 F-650/750 (TBC) , enUSA, Edition date: 202310, First-Printing...
Page 359 Index Automatic Transmission Fluid Capacity and Specification - Diesel.....306 Automatic Transmission Fluid Capacity and Specification - Gasoline....307 See: Climate Control...........85 Automatic Transmission Fluid Check - About This Manual...........7 10-Speed Automatic Transmission..........242 See: Brakes............138 Auxiliary Power Points.........95 ABS driving hints Auxiliary Switches........320 See: Hints on Driving With Anti-Lock Axle Inspection..........258 Brakes..............139...
Page 360 Index Checking the Wiper Blades.....248 Cruise Control..........157 Child Restraint and Seatbelt Cruise Control Indicators......158 Maintenance..........45 Cruise Control - Vehicles With: Adaptive Child Restraint Positioning......35 Cruise Control..........52 Child Safety............25 Cruise Control - Vehicles With: Cruise Control.............52 General Information..........25 Child Safety Locks.........36 Customer Assistance........195 Cleaning Products........261 Customer Information.......344...
Page 361 Fifth Wheel Operation........183 See: Climate Control...........85 Flat Tire Hill Start Assist - Vehicles With: See: Changing a Road Wheel.......286 Hydraulic Brakes........142 Ford Credit............11 Hints on Controlling the Interior Ford Protect...........322 Climate............86 Frame and Tow Hook Inspection..259 Hints on Driving With Anti-Lock Front Seat Armrest........94...
Page 362 Index Icons Motorcraft Parts - 6.7L Diesel....292 Motorcraft Parts - 7.3L.......294 See: Symbols Glossary........15 Ignition Switch..........100 In California (U.S. Only)......196 Information Display Control.......53 Information Displays........71 Noise Pollution Control........22 Normal Scheduled Maintenance..329 General Information..........71 Information Messages........75 Installing Child Restraints......27 Instrument Cluster........64 Instrument Lighting Dimmer.....56 Oil Change Indicator Reset......228 Instrument Panel..........24...
Page 363 Index Seatbelts............38 Principle of Operation........38 Seatbelt Warning Lamp and Indicator Radio Frequency Certification Chime..............43 Labels............344 Seats..............88 Cruise Control Module........344 Security...............51 Rear Axle Fluid Capacity and Selective Catalytic Reductant System - Specification - Diesel......308 Diesel...............119 Rear Axle Fluid Capacity and Service Data............19 Specification - Gasoline......310 Settings Data...........20 Rear Axle Fluid Check........259...
Page 364 Index Ventilation See: Climate Control...........85 Technical Specifications See: Capacities and Specifications....290 The Better Business Bureau (BBB) Auto Warning Lamps and Indicators....67 Line Program (U.S. Only)......197 Warranty Information........349 Tire Care............268 Washer Fluid Check........248 Tires Washer Fluid Specification......305 See: Wheels and Tires........268 Washers Towing a Trailer..........180 See: Cleaning the Exterior.......261...

This manual is also suitable for:

F-750 2025

Ford F-650 2025 Owner's Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ford F-650 2025

Summary of Contents for Ford F-650 2025
