Page 4: Introduction
The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it. For more information on Ford Motor Company and its products visit the following website: • In the United States: www.ford.com •...
Page 5 Introduction Protecting the environment We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.
Page 6 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may...
Page 7 EDR. Ford Motor Company and Ford of Canada do not access event data recorder...
Page 8 WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that you use extreme caution when using any device or feature that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 9 Introduction ENTERING, EXITING AND/OR CLIMBING ON THIS VEHICLE You must be careful and deliberate to minimize the possibility of personal injury from a slip and fall when entering, exiting and/or climbing on this vehicle. Always use the steps and assist handles before climbing. Do not skip any steps or assist handles.
Page 10 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Child Seat Lower Airbag - Side Anchor Child Seat Tether Brake System Anchor Anti-Lock Brake System Parking Brake System Brake Fluid -...
Page 11 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Child Safety Door Interior Luggage Lock/Unlock Compartment Release Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 12: Vehicle Inspection Guide
Vehicle Inspection Guide To be sure your vehicle is ready to operate, conduct a pre-trip inspection at the beginning of each work period. Follow the steps listed in this section to ensure a proper vehicle inspection procedure. The pages in this section may be produced locally and used on a regular basis.
Page 13 Vehicle Inspection Guide Engine compartment (with engine stopped) Any leaks: Check for signs of fluid puddles, dripping fluid on the ground under the engine or the underside of the engine. HVAC air inlet: Check for debris, leaves, etc. that may have collected on the HVAC air inlet grille or inside the exterior module as this may cause reduced system performance.
Page 14 Vehicle Inspection Guide Engine starting (parking brake applied) Safety/Emergency Prior to entering the cab, verify that the equipment: vehicle is equipped with spare electrical fuses (if used), three red reflective triangles, a properly charged and rated fire extinguisher and wheel chocks. Walk around the vehicle and check that all steps and grab handles, inside and out as well as behind, are tight and clean.
Page 15 Vehicle Inspection Guide Engine starting (parking brake applied) Accelerator: Press the accelerator and verify that it operates smoothly without any binding or irregular feel. Remove your foot from the pedal and make sure the engine returns to idle speed immediately. Ammeter/Voltmeter: Check the gauge to see if the alternator is charging.
Page 16 Vehicle Inspection Guide Engine starting (parking brake applied) Air brake check: Check the air brakes in the following manner (Chock the wheels, if necessary. Push in the parking brake and on tractors, also push in the tractor parking brake knob): 1.
Page 17 Vehicle Inspection Guide Front of vehicle Lights: Make sure all lights illuminate and are clean. Make sure headlights function on both high and low beam. Make sure reflectors are clean, unbroken and of proper color (red on rear, amber elsewhere). Make sure the running lights are also clean and unbroken.
Page 18 Vehicle Inspection Guide Front brakes Hoses: Check for cracked, worn or frayed hoses. Make sure all couplings are secured. Chambers: Make sure brake chambers are not cracked or dented and that they are securely mounted. Slack adjusters: Check for broken, loose or missing parts. The angle between the push rod and adjuster arm should be approximately 90°...
Page 19 Vehicle Inspection Guide WARNING: If a wheel must be changed, obtain expert tire service help. Mounting and un-mounting of tires should only be performed by a qualified technician using necessary safety procedures and equipment, otherwise the result could be property damage, personal injury or death.
Page 20 Vehicle Inspection Guide Rear of vehicle Air/Electric lines: Make sure that air hoses are not cut, cracked, chafed or worn. Listen for audible air leaks. Make sure air and electrical lines are not tangled, crimped or pinched or being dragged against any truck parts.
Page 21 Vehicle Inspection Guide Tractor - coupling system Kingpin/Apron: Make sure kingpin is not bent or worn. Also make sure that the apron lies flat on the fifth-wheel skid plate and that the visible part of the apron is not bent, worn, cracked or broken.
Page 22 Vehicle Inspection Guide Rear brakes Drum: Make sure there are no cracks, dents or holes and no loose or missing bolts. Make sure brake linings are not worn, dangerously thin or contaminated by lubricant. Rear wheels Spacers: Make sure dual wheels are evenly separated and that tires are not touching one another.
Page 23: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Base instrument cluster with standard measure shown; metric similar Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 24 Instrument Cluster Wait to start: Indicates the air intake heater is in operation and special starting procedures are required. Refer to Starting in the Driving chapter. WARNING: If equipped with an air intake heater, DO NOT use ether or any other starting fluids. The use of starting fluids (ether) in an engine equipped with an air intake heater could result in damage and/or personal injury.
Page 25 Instrument Cluster Stop engine: This light is used in conjunction with the electronic engine control. When illuminated, lamp indicates the need to stop the engine as soon as it can be safely done. If the lamp begins flashing, automatic engine shutdown may take place in as little as 20 seconds.
Page 26 Instrument Cluster Water in fuel: During refueling, it is possible for water-contaminated diesel fuel to be pumped into your tank. Your vehicle fuel system is equipped with a fuel filter/water separator to remove water from the fuel. The light will illuminate when the fuel filter/water separator has a significant quantity of water in it.
Page 27 Instrument Cluster Do not shift (Allison Automatic transmission only): The lamp will illuminate for several seconds after the ignition is turned to the on position. Illumination of this light while driving indicates that a problem has been detected and shifting may be restricted. Depending upon the severity of the problem, the read-out digit on the shifter display may be blank.
Page 28 Instrument Cluster Brake system warning light: To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the on position when the engine is not running, or in a position between on and start, or by applying the parking brake when the ignition is turned to the on position.
Page 29 Instrument Cluster Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately by your authorized dealer. Normal braking is still functional unless the brake warning light also is illuminated. Trailer anti-lock brake system (ABS): Illuminates briefly when the engine is powered-up and only when...
Page 30 Instrument Cluster Electronic locking differential (if equipped): Displays when using the electronic locking differential. Speed control (if equipped): Illuminates when the speed control system is engaged. Turns off when the speed control system is disengaged. Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on.
Page 31: Gauges
Instrument Cluster GAUGES Base cluster with automatic transmission shown. Metric similar. 1. Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine. 2. Engine oil pressure gauge: Indicates engine oil pressure. The needle should stay in the normal operating range (between L and H).
Page 32: Message Center
Instrument Cluster 5. Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the on position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade. Refer to Filling the tank in the Maintenance and Specifications chapter for more information.
Page 33 Instrument Cluster Remember to turn the ignition off when refueling to allow this feature to correctly detect the added fuel. The low fuel indicator will display when the fuel level is at approximately 1/16 of the tank. DTE is calculated using a running average fuel economy, which is based on your recent driving history of 500 miles (800 km).
Page 34 Instrument Cluster System check and vehicle feature customization Press the SETUP button repeatedly to cycle the message center through features. Note: When returning to the SETUP menu and a non-English language has been selected, HOLD RESET FOR ENGLISH will be displayed to change back to English.
Page 35 Instrument Cluster • Some messages can be acknowledged and reset by pressing RESET. This allows you to use the full message center functionality by clearing the message. PARK BRAKE ENGAGED — Displayed when the parking brake is set, the engine is running and the vehicle is driven more than 3 mph (5 km/h).
Page 36: Entertainment Systems
AM/FM stereo system (if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device or feature that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
Page 37 Entertainment Systems 2. AUDIO: Press AUDIO repeatedly to gain access to the following settings: TREB (Treble): Press AUDIO to reach the treble setting. SEEK BASS (Bass): Press AUDIO to reach the bass setting. Use SEEK BAL (Balance): Press AUDIO to reach the balance setting. SEEK to adjust between the left and right speakers.
Page 38: Am/Fm Stereo With Cd
(if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device or feature that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
Page 39 Entertainment Systems : Press manually go up or down the radio frequency. Press and hold for a fast advance through radio frequencies. In satellite radio mode (if equipped), press to tune to the next/previous channel. Satellite radio is available only with a valid SIRIUS radio subscription.
Page 40 Entertainment Systems can save up to 20 song titles. If you attempt to save a song when the system is full, the display will read REPLACE SONG? Press OK to access the saved songs and press to cycle through the saved songs.
Page 41 Entertainment Systems TREB (Treble): Press MENU to reach the treble setting. SEEK, SEEK to adjust. BAL (Balance): Press MENU to reach the balance setting. SEEK, SEEK to adjust the audio between the left (L) and right (R) speakers. FADE: Press MENU to reach the fade setting. Use SEEK, SEEK to adjust the audio between the back (B) and front (F) speakers.
Page 42 Entertainment Systems 4. AUX: Press repeatedly to cycle through LINE IN (auxiliary audio mode, if equipped) and SAT1, SAT2 and SAT3 modes (satellite radio, if equipped). For location and further information on auxiliary audio mode, refer to Auxiliary input jack later in this chapter. Satellite radio is available only with a valid SIRIUS radio subscription.
Page 43 Entertainment Systems 7. SHUFFLE: In CD/MP3 mode, press SHUFFLE to engage shuffle mode. SHUFFLE ON will appear in the display. If you wish to engage shuffle mode right away, press SEEK to begin random play. Otherwise, random play will begin when the current track is finished playing.
Page 44 Entertainment Systems 13. TEXT/SCAN: In radio and CD/MP3 mode, press and hold for a brief sampling of radio stations or CD tracks. Press again to stop. In CD/MP3 mode, press and release to display track title, artist name, and disc title. In satellite radio mode (if equipped), press and release to enter TEXT MODE and display the current song title.
Page 45: Auxiliary Input Jack
Auxiliary input jack (if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device or feature that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
Page 46 Entertainment Systems 5. Turn the portable music player on and adjust the volume to ⁄ level normally used for the portable player. 6. Press AUX on the vehicle radio repeatedly until LINE, LINE IN or SYNC LINE IN appears in the display. You should hear audio from your portable music player although it may be low.
Page 47 (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 48: Climate Controls
Climate Controls SINGLE ZONE CLIMATE CONTROL MAX A/C Defrost: Distributes outside air through the windshield defroster vents and de-mister vents. Can be used to clear the windshield of fog and thin ice. The system will automatically provide outside air to reduce window fogging.
Page 49 Climate Controls Recirculated air engages automatically when MAX A/C is selected or can be engaged manually in any airflow mode except (defrost). When the ignition switch is turned off and back on, the climate system will return to the recirculated air mode only if the A/C button LED is illuminated and the air distribution selection is either (panel) (panel/floor).
Page 50 Climate Controls For maximum cooling performance (MAX A/C): • Select MAX A/C. (Panel) and (panel/floor) modes: • Move the temperature control to the coolest setting. • Select A/C and (recirculated air). Use recirculated air with A/C to provide colder airflow. •...
Page 51: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control clockwise to the first position turn on the parking lamps. Rotate clockwise to the second position to also turn on the headlamps. High beams/Flash-to-pass High beams: Push the lever toward the instrument panel to activate. Pull the lever toward you to deactivate.
Page 52: Turn Signal Control
Lights WARNING: Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Lamp (DRL) system does not activate your tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.
Page 53: Interior Lamps
Lights INTERIOR LAMPS Map lamps (if equipped) To turn on the map lamps, press the control next to each lamp. The dome lamp turns on when: • any door is opened, • any of the remote entry controls are pressed and the ignition is off.
Page 54: Bulb Replacement
Lights Bulb replacement Replacing headlamp bulbs To remove the headlamp bulbs: 1. Make sure the headlamp control is in the position. 2. Remove the four screws and move the parking lamp assembly away from the headlamp bulb. 3. Remove the four screws and the retaining bracket from the headlamp bulb.
Page 55 Lights 2. Remove the four screws from the lamp assembly. 3. Carefully lower the lamp assembly and pull the bulb socket straight out of the lamp assembly. 4. Carefully pull the bulb straight out of the socket and push in the new bulb.
Page 56: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Windshield washer: Press the end of the stalk: •...
Page 57: Steering Wheel Adjustment
Driver Controls TILT STEERING To adjust the steering wheel: 1. Pull the lever down to unlock the steering column. 2. While the lever is in the down position, move the steering wheel up or down and in or out until you find the desired position.
Page 58: Power Windows
Driver Controls Auxiliary power points can be found in the following locations: • On the instrument panel (two locations) • Inside the center console storage compartment (if equipped) • On the rear of the center console (if equipped) • Inside the 20-percent front seat console (if equipped) •...
Page 59 Driver Controls Press and pull the window switches to open and close windows. • Press down (to the first detent) and hold the switch to open. • Pull up (to the first detent) and hold the switch to close. Rear Window Buffeting: When one or both of the rear windows are open, the vehicle may demonstrate a wind throb or buffeting noise.
Page 60: Mirrors
Driver Controls EXTERIOR MIRRORS With the doors closed and the seat adjusted for proper comfort, move the mirrors to maximize rear viewing area by adjusting the western mirrors left or right as required. Adjust the auxiliary convex mirrors. Convex mirrors are a ball-stud design for precise adjustment to maximize viewing area.
Page 61 Driver Controls Heated outside mirrors (if equipped) The main mirror glass and lower convex spotter mirror are heated to remove ice, mist and fog. To activate the heated mirrors, press the heated mirror control located on the climate control panel. Do not remove ice from the mirrors with a scraper or attempt to re-adjust the mirror...
Page 62 Driver Controls Powerfold mirror positions, from left to right: Position 1, Position 2, Position 3 The powerfold mirrors may be folded forward/rearward manually to any of the three positions shown and electrically to positions 1 and 2 only. If a mirror is folded manually forward to position 3, you must manually fold it back to position 1 or 2 in order for the powerfold function to continue functioning.
Page 63 Driver Controls Telescoping mirrors (if equipped) The telescoping feature allows the mirror to extend approximately 2.75 inches (70 mm). This feature is especially useful to the driver when towing a trailer. Mirrors can be manually pulled out or pushed in to the desired telescopic position.
Page 64: Speed Control
Driver Controls Clearance lamps (if equipped) Illuminates when the headlamps or parking lamps are switched on. This provides additional visibility of your vehicle to other drivers on the road. SPEED CONTROL With speed control set, you can maintain a set speed without keeping your foot on the accelerator pedal.
Page 65 Driver Controls Note: • Vehicle speed may vary momentarily when driving up and down a steep hill. • If the vehicle speed increases above the set speed on a downhill, you may want to apply the brakes to reduce the speed. •...
Page 66: Upfitter Controls
Switch access location is in a connector located in the engine compartment More detailed information can be found at https://www.fleet.ford.com/truck/bbas/. GAUGE PACKAGE (IF EQUIPPED) Your vehicle may be equipped with an optional gauge package. It will...
Page 67: Locks And Security
Locks and Security KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency. POWER DOOR LOCKS (IF EQUIPPED) Press control to unlock all doors.
Page 68 Locks and Security CHILDPROOF DOOR LOCKS (IF EQUIPPED) When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 69: Seating And Safety Restraints
Seating and Safety Restraints FRONT SEATING WARNING: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. WARNING: Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 70 Seating and Safety Restraints To adjust the head restraint, do the following: 1. Adjust the seatback to an upright driving/riding position. 2. Raise the head restraint by pulling up on the head restraint. 3. Lower the head restraint by pressing and holding the guide sleeve adjust/release button and pushing down on the head restraint.
Page 71 Seating and Safety Restraints To remove the adjustable head restraint, do the following: 1. Pull up the head restraint until it reaches the highest adjustment position. 2. Simultaneously press and hold both the adjust/release button and the unlock/remove button, then pull up on the head restraint.
Page 72 Seating and Safety Restraints WARNING: To minimize the risk of neck injury in the event of a crash, head restraints must be installed properly. Front row center non-adjustable head restraint (if equipped) Vehicles equipped with a front center seat will have a head restraint that is non-adjustable.
Page 73 Seating and Safety Restraints To reinstall the non-adjustable head restraint, do the following: 1. Insert the two stems into the guide sleeve collars. 2. Push the head restraint down until it locks. WARNING: The non-adjustable head restraint is a safety device. It should be installed whenever the seat is occupied.
Page 74 Seating and Safety Restraints • Pull the release lever handle located on the side of the seat up to move the seatback forward or backward. 20% front seat armrest and console (if equipped) To release the armrest and gain access to the cupholders and seatback storage bin, push the button on the right-hand side of the seat and pull the seatback down.
Page 75 Seating and Safety Restraints 70% two-person passenger bench seat (if equipped) Lift the handle on the seatback to tilt the seatback forward. Using the manual lumbar support (if equipped) The lumbar support control is located on the outboard side of the seat Turn the lumbar support forward toward the front of the vehicle for...
Page 76 Seating and Safety Restraints Adjusting the front power seat (if equipped) The control is located on the outboard side of the seat cushion. Press to raise or lower the front portion of the seat cushion. Press to raise or lower the rear portion of the seat cushion.
Page 77 Seating and Safety Restraints Air-Ride seat (if equipped) 1. Chugger option: Dampens road vibrations and allows the seat to move with the driver when unlocked. To unlock, sit in the seat and slide the tab away from the seat (to the right) To lock, sit in the seat and slide the tab toward the seat (to the left).
Page 78 Seating and Safety Restraints REAR SEATS Non-adjustable second-row head restraints Your vehicle is equipped with second row outboard head restraints that are non-adjustable. Outboard head restraints (Crew Cab) Center head restraint (Crew Cab) The non-adjustable second row head restraints consist of : •...
Page 79 Seating and Safety Restraints Note: The SuperCab has rear outboard head restraints that are not removable and are bolted to the back wall. Rear flip-up seat (if equipped) Folding up the rear seats (SuperCab) 1. Pull control to release seat cushion.
Page 80: Safety Restraints
Seating and Safety Restraints Rear center armrest (if equipped) To use the armrest simply rotate it forward from the seatback. SAFETY RESTRAINTS Safety restraints precautions WARNING: Always drive and ride with your seatback upright and the lap belt snug and low across the hips. WARNING: To reduce the risk of injury, make sure children sit where they can be properly restrained.
Page 81 Seating and Safety Restraints WARNING: In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a safety belt. WARNING: Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair.
Page 82 Seating and Safety Restraints Restraint of pregnant women WARNING: Always ride and drive with your seatback upright and the safety belt properly fastened. The lap portion of the safety belt should fit snug and be positioned low across the hips. The shoulder portion of the safety belt should be positioned across the chest.
Page 83 Seating and Safety Restraints Shorten and fasten the belt when not in use. Vehicle sensitive mode The vehicle sensitive retractor allows free shoulder belt length adjustment to your movements and locks in response to vehicle movement. For example, if the driver brakes suddenly or turns a corner sharply, or the vehicle receives an impact of approximately 5 mph (8 km/h) or more, the combination safety belts will lock to help reduce forward movement of the driver and passengers.
Page 84 Seating and Safety Restraints Safety belt extension assembly If the safety belt is too short when fully extended, there is an eight inch (20 cm) safety belt extension assembly that can be added (part number 611C22). This assembly can be obtained from your dealer at no cost. Use only extensions manufactured by the same supplier as the safety belt.
Page 85 Seating and Safety Restraints If... Then... The driver’s safety belt is not The Belt-Minder feature is activated buckled before the vehicle has - the safety belt warning light reached at least 3 mph illuminates and the warning chime (5 km/h) and 1-2 minutes have sounds for six seconds every elapsed since the ignition 30 seconds, repeating for...
Page 86 Seating and Safety Restraints Reasons given... Consider... “I was in a hurry” Prime time for an accident. Belt-Minder reminds us to take a few seconds to buckle up. “Seat belts don’t work” Safety belts, when used properly, reduce risk of death to front seat occupants by 45% in cars, and by 60% in light trucks.
Page 87 Seating and Safety Restraints One-time disable Any time the safety belt is buckled and then unbuckled during an ignition ON cycle, Belt-Minder will be disabled for that ignition cycle only. Deactivating/Activating the Belt-Minder feature Read Steps 1-9 thoroughly before proceeding with the deactivation/activation programming procedure.
Page 88: Child Restraints
Seating and Safety Restraints 5. Buckle then unbuckle the safety belt three times, ending with the safety belt unbuckled. • After Step 5 the safety belt warning light will be turned on for three seconds. 6. Within seven seconds of the safety belt warning light turning off, buckle then unbuckle the safety belt.
Page 89 Recommendations for Safety Restraints are based on probable child height, age and weight thresholds from NHTSA and other safety organizations or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and consult your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in the vehicle.
Page 90 Seating and Safety Restraints Recommendations for Safety Restraints for Children Recommended Child size, height, weight, or age restraint type Larger Children who have outgrown or no Use a vehicle children longer properly fit in a belt-positioning safety belt having booster seat (generally children who the lap belt snug are at least 4 feet 9 inches and low across...
Page 91 Seating and Safety Restraints WARNING: Always carefully follow the instructions and warnings provided by the manufacturer of any child restraint to determine if the restraint device is appropriate for your child’s size, height, weight, or age. Follow the child restraint manufacturer’s instructions and warnings provided for installation and use in conjunction with the instructions and warnings provided by the vehicle manufacturer.
Page 92 • Place seat back in upright position. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with a tether anchor. For more information on top tether straps and anchors, refer to Attaching child safety seats with tether straps.
Page 93 Seating and Safety Restraints Installing child safety seats with combination lap and shoulder belts 1. Position the child safety seat in a seat with a combination lap and shoulder belt. WARNING: Children under 12 are safer when properly restrained in the rear seat, to the extent this is possible. 2.
Page 94 7. Check to make sure the child seat is properly secured before each use. 8. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) to make certain the child restraint is properly installed.
Page 95 Ford Motor Company recommends the use of a child safety seat having a top tether strap. See Attaching child safety seats with tether straps and Recommendations for attaching safety restraints for children in this chapter for more information.
Page 96 Ford or Lincoln Mercury dealer. If you have a Crew Cab, Ford recommends you attach tether safety seats in the rear seating position (if possible) with the tether strap attached to the tether anchorage bracket as shown in the instructions provided with the tether anchor kit.
Page 97 Seating and Safety Restraints The tether strap anchors in your vehicle are in the following positions (shown from top view): • F-Series Regular Cab • F-Series Crew Cab Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor.
Page 98 Seating and Safety Restraints 3. You may need to pull the seatback forward to access the tether anchors. Make sure the seat is locked in the upright position before installing the child seat. Refer to the Folding the rear seat back (Crew Cab) section in this chapter for information on how to operate the rear seats.
Page 99 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that vehicle lap/shoulder safety belts fit better.
Page 100 Seating and Safety Restraints height of at least 4 feet 9 inches (1.45 meters) tall (around age eight to age twelve and between 40 lb (18 kg) and 80 lb (36 kg) or upward to 100 lb (45 kg) if recommended by your child restraint manufacturer). Many state and provincial laws require that children use approved booster seats until they reach age eight, a height of 4 feet 9 inches (1.45 meters) tall, or 80 lb (36 kg).
Page 101 Seating and Safety Restraints • High back booster seats If, with a backless booster seat, you cannot find a seating position that adequately supports your child’s head, a high back booster seat would be a better choice. Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 102 Refer to the child restraint manufacturer’s instructions for additional inspection and maintenance information specific to the child restraint. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 103 Seating and Safety Restraints WARNING: Ford Motor Company recommends that all safety belt assemblies used in vehicles involved in a collision be inspected for proper function and replaced, if necessary. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
Page 104: Driving
Driving STARTING Positions of the ignition 1. ACCESSORY – allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK – locks the automatic transmission gearshift lever if equipped with a P (Park) position and allows key removal.
Page 105 Driving Note: When starting the engine, do not press the accelerator as engine damage may result. 1. Ensure headlamps and all accessories are turned off, the parking brake is applied and the transmission is in the neutral position (or P [Park] for Allison 2200 transmissions).
Page 106 Driving • When starting a cold engine, increase the engine RPM slowly to make sure adequate lubrication is available to the bearings. Cold weather operation WARNING: Do not use volatile starting aids such as ether, propane or gasoline in the engine air intake system. Glow plugs may ignite vapors which can cause engine damage or personal injury.
Page 107 Driving Hot weather operation • Keep the engine cooling system filled with a clean, permanent coolant solution to protect against damage from overheating. • Fill the fuel tank at the end of daily operation to prevent condensation in the fuel system. •...
Page 108 Driving • Always shift to a lower gear at high altitudes to prevent engine smoking. • Operate in a gear that will permit an engine speed not in excess of the maximum governed speed or high-idle RPM (no load). • Normally, choose the same gear to descend the hill that you would use to ascend the hill.
Page 109 Driving WARNING: When parking your vehicle, do not leave the transmission in gear; if the key is in the on position and the vehicle rolls, the engine could start. Failure to follow these instructions could result in an unattended vehicle moving, possibly causing personal injury or property damage.
Page 110 Driving ENGINE AUTOMATIC SHUTDOWN WARNING LIGHT OR CHIME (IF EQUIPPED) Your vehicle may be equipped with an automatic shutdown feature that stops the engine in the event of high coolant temperature, low engine oil pressure, high diesel particulate filter soot loading or low engine coolant level.
Page 111: Brakes
Driving WARNING: Do not drive with your foot resting on the brake pedal. This will result in abnormally high brake temperatures, excessive lining wear and increased stopping distances. Before descending a long or steep hill, shift to a lower gear and avoid continuous application of the brakes.
Page 112 Driving WARNING: If the red BRAKE warning lamp in the instrument cluster remains illuminated after engine start up, this indicates a system failure in the Full Power Brake System. Stop the vehicle safely as soon as possible and seek service immediately. Note: During normal driving the pump/motors may be heard replenishing the accumulators.
Page 113 Driving The parking BRAKE warning lamp in the instrument cluster illuminates and will remain illuminated (when the ignition is turned on) until the parking brake is released. Push the palm release lever on the parking brake handle and push down as far as possible to release the brake.
Page 114 Driving neutral (central), and release (in). The switch is spring-loaded to return to the neutral (central) position after being pushed or pulled. There is no visual indication at the knob that the park brake is applied or released. Always observe the gauge cluster Park Brake indicator to determine if the park brake is applied or released.
Page 115 Driving WARNING: Hold the brake pedal down while moving the gearshift lever from position to position. If the brake pedal is not held down, the vehicle may move unexpectedly resulting in property damage, personal injury or death. Parking brake light illumination due to low air pressure If at any time during vehicle operation air pressure is too low, the parking brake may apply and the parking brake light will turn on.
Page 116 Driving WARNING: Block the wheels to help prevent the vehicle from moving. WARNING: Unexpected and possibly sudden vehicle movement may occur if these precautions are not taken. Loosen the jam nut (1) and un-thread the adjustment rod (2) from the chamber to reduce tension on the cable (3).
Page 117 Driving WARNING: Avoid repeated light application of the brake pedal. This will deplete air pressure faster and could result in loss of braking capability. Periodically check the air pressure gauge while driving. Pressure should range between approximately 100–125 psi (690–862 kPa). The air compressor governor cut-in and cut-out pressure settings are preset at the factory and are not...
Page 118 Driving Cam brakes - automatic slack adjusters Standard air brakes (cam) are equipped with automatic brake adjusters. Automatic adjustment occurs during brake applications. Inspect brakes for proper adjustment at the intervals listed in the Scheduled Maintenance Guide chapter. WARNING: Do not manually adjust the automatic slack adjusters to correct excessive push rod stroke...
Page 119 Driving Air brake reservoir draining WARNING: Failure to drain air brake reservoirs can result in a reduction or loss of braking ability due to fluid accumulation in the reservoir and/or possible freeze-up during cold weather. Drain all the air brake reservoirs daily, completely to 0 psi/kPa, by opening the draincock at the ends of the tanks (where accessible.
Page 120 Driving Parking brake control (knob) Pull the yellow parking brake knob out to apply the parking brake. Push the knob in to release the parking brake. WARNING: This control is used for parking only. Do not leave the vehicle unattended after setting the parking brake without placing the transmission in R (Reverse) for manual...
Page 121 Driving Releasing spring brake manually WARNING: Do not attempt to disassemble the parking brake chamber under any circumstances. The high spring load may cause serious injury if the chamber clamps are removed. If air pressure is released from the spring brake chamber the power spring applies the brake and, unless air pressure can be re-established, the spring brake must be released as follows in order to move the vehicle.
Page 122 Driving 4. Turn the release stud one-quarter turn to engage the stud tangs with the slot in the pressure plate. Keep the stud engaged and install the nut on the release stud. 5. Tighten the nut until the spring is fully caged and the brakes are released.
Page 123 Driving Operation Push the rocker switch up to turn the exhaust brake on. Push the switch down to turn the brake off. Starting engine Before starting the engine, make sure that the exhaust brake switch is in the OFF position. Do not turn the exhaust brake on until the engine has reached normal operating temperatures.
Page 124 Driving Note: Engine speed has a major influence of retarding performance. When engine speed is maintained at the maximum allowable level, the exhaust brake will operate at peak performance. WARNING: The exhaust brake is not recommended for use on slippery or low traction road surfaces. Under these conditions a loss of vehicle control could occur.
Page 125 Driving Note: Installing an exhaust or auxiliary brake does not necessarily protect the engine from exceeding maximum governed speed. The primary brakes should be used to make sure the engine never exceeds maximum governed speed under any conditions. TRAILER BRAKE HAND CONTROL (IF EQUIPPED) The hand control, located on the right-hand side of the instrument panel, is used to apply the trailer...
Page 126 Driving TRAILER AIR SUPPLY AND PARKING BRAKE MODULAR CONTROLS (IF EQUIPPED) TRAILER AIR SUPPLY NOT FOR PARKING The trailer air supply valve delivers air to the trailer supply and will automatically pop out, shutting off the trailer supply, if pressure is decreased to approximately 35 psi (249 kPa).
Page 127 Driving The parking brake (2–yellow knob) can now be pushed in and supply air to the tractor spring brakes, releasing them. Normal driving position With both knobs pushed in, air is then supplied to both trailer and tractor spring brakes, and all brakes are released. 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 128 Driving System park With both knobs pushed in (normal driving position), the parking brakes for both the tractor and trailer can be applied by pulling the parking brake knob (2) out, exhausting air from the tractor spring brakes, simultaneously causing the trailer air supply valve to pop out, applying the trailer brakes.
Page 129 Driving Automatic application If both knobs are pushed in and the brake system air pressure is reduced to approximately 35 psi (249 kPa), the trailer air supply (1) knob will automatically pop out applying the emergency or parking brakes on the trailer.
Page 130 Driving ANTI-LOCK BRAKE SYSTEM (ABS) A noise from the hydraulic pump motor and pulsation in the pedal may be observed during ABS braking events. Pedal pulsation coupled with noise while braking under panic conditions or on loose gravel, bumps, wet or snowy roads is normal and indicates proper functioning of the vehicle’s ABS.
Page 131 Driving • We recommend that you familiarize yourself with this braking technique. However, avoid taking any unnecessary risks. TRACTION CONTROL (IF EQUIPPED) Your vehicle may be equipped with a traction control system. This system helps you maintain the stability and steerability of your vehicle, especially on slippery road surfaces such as snow- or ice-covered roads and gravel roads, by reducing engine power and/or selectively applying the rear brakes.
Page 132: Air Suspension
Driving WARNING: Aggressive driving in any road conditions can cause you to lose control of your vehicle increasing the risk of severe personal injury or property damage. The occurrence of a traction control event is an indication that at least some of the tires have exceeded their ability to grip the road;...
Page 133 Driving Tractor-trailer connections WARNING: To reduce the risk of personal injury, use extreme caution when making brake and light connections. Inclement weather and accumulated road contamination deposits on handhold and stepping surfaces require extra care to avoid slip and falls. Provide adequate lighting of working areas.
Page 134: Transmission Operation
Driving AUTOMATIC TRANSMISSION OPERATION (IF EQUIPPED) Main transmission, auxiliary transmission, transfer case and power take-off (PTO) control shift patterns can be found on a placard or decal on the driver’s sun visor, on the instrument panel or on the shift control itself.
Page 135 Driving Allison 2500 This transmission is available with a column-mounted gearshift lever. The gear positions are displayed on the RNDL in the instrument cluster. WARNING: To avoid sudden, unexpected vehicle movement and possible personal injury or death: 1. Bring the vehicle to a complete stop. 2.
Page 136 Driving Allison 3000 series push-button shifter To shift the transmission into R (Reverse) or D (Drive), press the brake pedal, then press R or D, then release the brake pedal. To select a lower range when in D (Drive), press the down-arrow button. To select a higher range when in D (Drive), press the up-arrow button.
Page 137 Driving Eaton UltraShift push-button shifter For operation of the push-button shifter, refer to the Operation — Shift Console Positions section of the Eaton UltraShift Driver Instructions Manual. CLUTCH (IF EQUIPPED) Do not ride or slip the clutch as this will cause unnecessary heat and wear.
Page 138 Driving If your vehicle’s transmission is equipped with a ceramic clutch, you must start the vehicle moving in first gear and engage the clutch before pressing the accelerator at idle. Also, don’t try to slip the clutch by raising engine RPM and riding or feathering the clutch pedal since the vehicle will experience erratic engagement.
Page 139 Driving Note: To avoid premature clutch wear and failure, do not drive with your foot resting on the clutch pedal or use it to hold the vehicle at a standstill on an upgrade as when waiting for a traffic light. Manual transmission shift patterns are displayed on either the shift lever knob or the sun visor.
Page 140 Driving To go backward Reverse is obtained by putting the gearshift lever in R (Reverse) and engaging the clutch while pressing lightly on the accelerator. Shifting with a synchronized transmission With the clutch pedal pressed in, use 2 (Second) gear synchronizer to stop the clutch disc rotation;...
Page 141 Driving Operating the Spicer ES56-7B and ES066-7B 7-speed transmissions These 7-speed transmissions are equipped with seven forward gears and one reverse. Gears 2–7 are synchronized. The shift pattern is embossed on the gear shift knob. Do not shift the transmission into 1 (First) or R (Reverse) while the vehicle is moving as this could damage the transmission.
Page 142 Driving PTO operation while vehicle is moving After the PTO is engaged for driven vehicle operation, shift to the desired range and drive the vehicle. The speed of the PTO, during this period of operation, will always maintain direct relation to vehicle speed. PTO speed will decrease in relation to vehicle (transmission output) speed as shifts to a higher gear occur.
Page 143 Driving REAR AXLE INFORMATION Axle operating temperature normally will not exceed 100°F (38°C). If the operating temperature exceeds 230°F (110°C), the rate of axle lubrication oxidation will increase and shorten the life of the lubricant and seals, requiring axle lubrication changes to become more frequent to preserve the axle.
Page 144 Driving Care should be taken to avoid sudden accelerations when both drive wheels are on a slippery surface. WARNING: Sudden accelerations on slippery surfaces could cause the wheels to spin, the vehicle to turn sideways on a crowned road surface or in a turn, possibly resulting in loss of vehicle control and personal injury.
Page 145 Driving TWO-SPEED REAR AXLE (IF EQUIPPED) A two-speed rear axle allows the driver to select a LO range for greater pulling power and a HI range for greater road speed and 2SPD fuel economy. These ranges can also be used to provide additional steps between transmission shifts when HIGH driving on steep grades and/or fuel...
Page 146 Driving Note: You cannot split-shift with an automatic transmission. Also, downshifting above 40 mph (64 km/h) may result in transmission or axle damage. Shifting the axle from LO to HI range - vehicle stopped Place the transmission in N (Neutral), then press the lower part of the switch.
Page 147: Vehicle Loading
Low for gradeability Axle high MAXIMUM VEHICLE LOADING Every vehicle manufactured by Ford Motor Company is supplied with information on the Safety Compliance Certification Label, located on either the B-pillar or the driver’s door edge, listing the maximum loading for the vehicle (GVWR), and its axle systems (GAWR) at the tire to ground interface.
Page 148 Driving WARNING: Do not use replacement tires with lower load carrying capacities than the originals because they may lower the vehicle’s GVWR and GAWR limitations. Replacement tires with a higher limit than the originals do not increase the GVWR and GAWR limitations.
Page 149 Driving Model Maximum Maximum GVWR - lb (kg) GCWR F-650 Pro-Loader (Kick-Up 20500–26000 Frame) (9299–11792) F-650 Pro-Loader (Straight 20500–29000 Frame)/F-650 Straight Frame (9299–13154) F-750 25999–37000 (11793–16783) * Specific GCWR and maximum trailer weight applicable to a given F–650/750 model is dependent on many variables including transmission capability.
Page 150 Driving WARNING: Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system. Your vehicle may not have enough braking power and your chances of having a collision greatly increase. Trailer lamps Trailer lamps are required on most towed vehicles. Your vehicle may be equipped with one of two possible trailer wiring designs.
Page 151 Driving • If you will be towing a trailer frequently in hot weather, hilly conditions, at GCW, or any combination of these factors, consider refilling your rear axle with synthetic gear lube if not already so equipped. Refer to Lubricant specifications in the Maintenance and Specifications chapter for the lubricant specification.
Page 152 Driving Hook-up 1. Back the tractor squarely under the trailer, engaging the fifth-wheel jaws on the kingpin. Always back-up slowly, making sure the trailer is neither too high nor too low. Avoid backing under the trailer from an angle. 2. Connect the service and emergency brake hoses and trailer light connector.
Page 153: Roadside Emergencies
Roadside Emergencies GETTING ROADSIDE ASSISTANCE To fully assist you should you have a vehicle concern, Ford offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty and is not applicable to vehicles sold in Canada. The service is available: •...
Page 154: Hazard Flasher Switch
Roadside Emergencies HAZARD FLASHER The hazard flasher control is located on the steering column, just behind the steering wheel. The hazard flashers will operate when the ignition is off. Press the flasher control and all front and rear direction signals will flash.
Page 155 Roadside Emergencies Fuse/Relay Fuse amp Fuse description location rating Horn Flasher relay Power point Data Link Connector (DLC), Engine diagnostic connector, Parking brake warning Run relay — Not used — Not used Radio, GEM Power window relay Heated mirrors Wiper and washer systems Transmission shift selector Radio, Power mirrors Interior lamp relay...
Page 156 Roadside Emergencies Fuse/Relay Fuse amp Fuse description location rating Allison electronic transmission Mirror fold relay Relay 1 — Interior lamps Relay 2 — Not used Relay 3 — Horn Relay 4 — Not used Relay 5 — Not used Power distribution box WARNING: Always disconnect the battery before servicing high current fuses.
Page 157 Roadside Emergencies Fuse/Relay Fuse amp Fuse description location rating Upfitter switches (AUX 2 and AUX 4) Power seat (driver) Power seat (passenger) Windshield washer relay, Washer pump motor Brake warning switch (hydraulic brake only) Upfitter switches (AUX 1 and AUX 3) Brake pressure switches, ABS event relay DEF (Urea), Line heaters Ignition switch, Starter cutoff...
Page 158 Roadside Emergencies Fuse/Relay Fuse amp Fuse description location rating — Not used — Not used — Not used — Not used — Not used — Not used Bendix Air ABS relay (Air brake vehicles only) Hydraulic brakes module (Hydraulic brake vehicles only) Ignition switch Ignition switch, Passenger compartment fuse...
Page 159 Roadside Emergencies Fuse/Relay Fuse amp Fuse description location rating Air brake trailer tow fuse block Hydraulic brakes pump motor 2 — Windshield washer relay — Wiper high/low relay — Wiper run/park relay — Windshield wiper relay — Body builder relay, right turn —...
Page 160 Roadside Emergencies Relay center The relay center is located along the passenger side A-pillar on the right side of the footwell. Relay Relay description location Spring applied hydraulic release warning chime module A/C compressor clutch Power windows Flasher (standard/LED) Upfitter relay 1 Upfitter relay 2 Headlights Spare...
Page 161 Roadside Emergencies Relay Relay description location Door unlock ABS warning indicator DRL #2 Park lights Spare Trailer tow relays (if equipped) Fuse/Relay Fuse Amp Description Location Rating 30A* Trailer tow ABS feed (non electric trailer brake vehicles only) 30A* Trailer tow park/marker lamps 30A* Trailer tow stop lamps 30A*...
Page 162: Jump Starting
Roadside Emergencies Fuse/Relay Fuse Amp Description Location Rating — Trailer tow marker lamp relay — Trailer tow stop lamp relay — Trailer tow tail lamp relay — Not used — Not used — Trailer tow left turn lamp relay — Trailer tow right turn lamp relay *Maxi fuse Inline fuses...
Page 163 Roadside Emergencies Before connecting a fast-charger, booster battery or installing a new battery, make sure the ground polarities of the fast-charger, booster battery or alternator (when installing a battery) are matched to the ground polarity of the vehicle battery. Improper usage of the fast-charger, hook-up of booster battery or installation of a new battery can cause damage to the electrical system or to the alternator.
Page 164 Roadside Emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 165 Roadside Emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
Page 166: Wrecker Towing
Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 167 Roadside Emergencies WARNING: To reduce the risk of personal injury or property damage when manually releasing the spring brakes, be sure to block the wheels so the vehicle cannot move once the brakes are released. Towing the vehicle with the front wheels suspended When it is necessary to tow a vehicle with the front wheels suspended, extra precautions must be taken to avoid transmission or differential damage.
Page 168 Roadside Emergencies 1. Shift collar in the locked position 2. Actuator assembly and shift fork 3. Axle shaft 4. Interference between the shift collar and housing 5. Shift collar in the unlocked position 6. Outer splines - axle shaft to collar 7.
Page 169 Roadside Emergencies Installing the axle shafts 1. Remove the covers from the wheel ends. 2. Shift the differential lock to the unlocked (disengaged) position. 3. Install the axle shafts. • Place the gaskets on the wheel hub studs. • Push the right-hand axle shaft and gasket into the wheel end and housing until the shaft stops against the differential shift collar.
Page 170: Customer Assistance
• The name of the authorized dealer and city where located • The vehicle’s current odometer reading In some states, you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states.
Page 171 • U.S. dealer locator by Dealer Name, City/State, or Zip Code • Owner Guides • Maintenance Schedules • Recalls • Ford Extended Service Plans • Ford Genuine Accessories IN CALIFORNIA (U.S. ONLY) California Civil Code Section 1793.2(d) requires that, if a manufacturer or its representative is unable to repair a motor vehicle to conform to the vehicle’s applicable express warranty after a reasonable number of...
Page 172: Getting Assistance Outside The U.s And Canada
ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 173 Customer Assistance Ford dealerships outside of the US & Canada may be unable to support the F–650/750 due to the specialized training and servicing requirements of these vehicles. If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership.
Page 174: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...
Page 175: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3-A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 176 Cleaning • Do not allow paint sealant to come in contact with any non-body (low-gloss black) colored trim, such as grained door handles, roof racks, bumpers, side moldings, mirror housings or the windshield cowl area. The paint sealant will “gray” or stain the parts over time. PAINT CHIPS Your authorized dealer has touch-up paint to match your vehicle’s color.
Page 177 Cleaning • Do not spray a hot engine with cold water to avoid cracking the engine block or other engine components. • Spray Motorcraft Engine Shampoo and Degreaser (ZC-20) on all parts that require cleaning and pressure rinse clean. • Never wash or rinse the engine while it is hot or running; water in the running engine may cause internal damage.
Page 178 Cleaning If you cannot remove those streaks after cleaning with the glass cleaner or if the wipers chatter and move in a jerky motion, clean the outer surface of the windshield and the wiper blades using a sponge or soft cloth with a neutral detergent or mild-abrasive cleaning solution.
Page 179 Cleaning 4. Remove the soaked cloth, and if it is not soiled badly, use this cloth to clean the area by using a rubbing motion for 60 seconds. 5. Following this, wipe area dry with a clean, white, cotton cloth. INTERIOR For fabric, carpets, cloth seats and safety belts: •...
Page 180 Cleaning LEATHER SEATS FOR THE KING RANCH EDITION ONLY (IF EQUIPPED) Your vehicle is equipped with seating covered in premium, top-grain leather which is extremely durable, but still requires special care and maintenance in order to ensure longevity and comfort. Regular cleaning and conditioning will maintain the appearance of the leather.
Page 181: Underbody Preservation
Flush the complete underside of your vehicle frequently. Keep body and door drain holes free from packed dirt. FORD CAR CARE PRODUCTS Your vehicle’s authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
Page 182: Maintenance And Specifications
Maintenance and Specifications GENERAL SERVICING GUIDELINES AND PRECAUTIONS As with any machine, care should be taken to avoid being injured when performing maintenance, repairs or system checks. Improper or incomplete service could result in the vehicle not working properly which, in turn, may result in personal injury or damage to the vehicle or equipment.
Page 183 Maintenance and Specifications vehicle at least once a year. Remember that regular maintenance and replacement of worn components will usually prevent serious problems from developing later. WARNING: Making modifications to various parts, components and systems of the vehicle, such as brake and steering systems can adversely affect the quality, reliability and operation of your vehicle and could result in property damage, personal injury or death.
Page 184 Maintenance and Specifications Check to make sure that the axle mounting U-bolt nuts, attaching or mounting bolts and nuts are securely tightened. Regularly check front axle for damage, binding, worn parts and adequate lubrication. At regular intervals, or during other scheduled maintenance, (tire rotation/service, wheel bearing service, alignment, etc.) the kingpins should be checked for excessive wear.
Page 185 Maintenance and Specifications Brake system - general inspection Your vehicle is equipped with non-asbestos brake linings. However, exposure to excessive amounts of brake material (whether asbestos or non-asbestos, fiberglass, mineral wool, aramid or carbon) may be a potentially serious health hazard. Note: Persons handling brake linings should follow all precautions listed below: WARNING:...
Page 186 Maintenance and Specifications Air brakes Inspection and adjustment A regular schedule for periodic cleaning, lubrication and adjustment inspection should be established based on the type of vehicle operation. It is difficult to predetermine an exact maintenance interval (time or mileage), since vehicles will be used in a wide variety of applications and conditions.
Page 187 Maintenance and Specifications • Condition of brake drums, brake chambers and slack adjusters. • System for air leaks. • Hose or pipes for rust, damage and deterioration. • Operation of service and parking brakes. Some parts such as air brake chamber diaphragm, air compressor and air cleaner should be inspected periodically and replaced if considered unserviceable.
Page 188 Maintenance and Specifications This inspection should be performed by a qualified technician and must be in accordance with instructions provided by the service manual. Note: Hydraulic brake systems are power assisted. Braking capabilities will be greatly reduced without engine assist. Fluid level Fluid level should be at the bottom edge of the ring on each reservoir fill port.
Page 189 Maintenance and Specifications Diesel exhaust fluid (DEF), Diesel particulate filter (DPF) and Select catalyst reduction (SCR) system Refer to your engine operator’s manual for information regarding DEF, DPF and SCR system service. Air induction system Once each year, perform a complete inspection of the air induction system.
Page 190: Hood
Maintenance and Specifications • Regularly inspect steering column joint bolts and steering linkage, particularly for body-to-chassis clearance. Note: Have any steering problems corrected at once by a qualified service technician. WARNING: Failure to maintain the steering system in proper condition can cause reduced steering ability resulting in property damage, personal injury or death.
Page 191 Maintenance and Specifications To open the hood: 1. Set the parking brake, shift into N (Neutral) (automatic transmission) or 1 (First) (manual transmission) and turn the engine off. 2. Lift upward on the bottom of each latch. 3. Pull the bottom of each latch away from the fender.
Page 192 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specifications. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
Page 193: Engine Oil
Maintenance and Specifications CHANGING THE WIPER BLADES 1. Pull the wiper arm away from the vehicle. Pry open the lock cover with your thumb (1) to release the blade and pull the wiper blade down toward the windshield to remove it from the arm (2).
Page 194 Maintenance and Specifications • Covered battery tray shown. Battery tray with steps similar. The two rubber straps on top of the cover must be pulled up and moved to the side of the battery in order to remove the lid. •...
Page 195 Maintenance and Specifications WARNING: Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation.
Page 196: Engine Coolant
Maintenance and Specifications ENGINE COOLANT Refer to your engine operator’s manual for engine coolant checking and adding instructions as well as engine coolant specifications and capacities. Severe climates If you drive in extremely cold climates (less than –34°F [–36°C]): • It may be necessary to increase the coolant concentration above 50%.
Page 197: Fuel Information
Maintenance and Specifications • The fan clutch is controlled by bimetallic spring sensors. Do not tamper with these sensors as this may change their calibration or keep the fan clutch from operating at all. WARNING: Stay clear of the fan/fan area while the engine is running or possible personal injury may occur.
Page 198 If you must replace the fuel filler cap, replace it with a genuine Ford or Motorcraft part. The customer warranty may be void for any damage to the fuel tank or fuel system if a genuine Ford or Motorcraft fuel filler cap is not used.
Page 199 Maintenance and Specifications Number 1-D or winter blend number 2-D fuel is recommended at temperatures below 20°F (-7°C) (see Cold weather operation in the Driving chapter. Diesel fuel containing no more than 20% biodiesel may be used. Biodiesel fuel is a product that has been converted from renewable fuel sources, including vegetable oil, animal fat and cooking oil.
Page 200 Maintenance and Specifications WARNING: Do not use starting fluid such as ether or gasoline. Such fluids can cause immediate explosive damage to the engine and possible personal injury. Fuel quality It should not be necessary to add any aftermarket additives to your fuel tank if you use a properly formulated diesel fuel that meets ASTM D 975 specification.
Page 201: Diesel Exhaust Fluid (Def)
Maintenance and Specifications • The engine may run rough and produce white smoke while air is in the fuel system. This is normal and should stop after a short period of time. Selective Catalytic Reduction (SCR) System Your vehicle is equipped with a selective catalytic reduction (SCR) system to help reduce emission levels of oxides of nitrogen from the exhaust of the diesel engine.
Page 202 Maintenance and Specifications Continued driving without refilling will result in the following actions as required by the U.S. Environmental Protection Agency (EPA): DEF Low Level Warning and Vehicle Consequence Indicator DEF Level Consequence Remedy Lamps Above initial warning threshold None None None (Tank above 10%...
Page 203 The following web address can be used to find the nearest location to purchase DEF: http://www.afdc.energy.gov/afdc/locator/def. Use Motorcraft DEF or equivalent meeting Ford specification WSS-M2C130-A and/or ISO 22241. Use only DEF certified by the American Petroleum Institute. Look for this certification trademark.
Page 204 Maintenance and Specifications To fill the DEF tank, see your authorized dealer or do the following (before filling the DEF tank in cold climates, see Filling the DEF tank in cold climates later in this section): DEF bottle fill with spout The following procedure applies to Motorcraft DEF or similar DEF bottles;...
Page 205 Maintenance and Specifications 4. Lift and tip the container to let DEF flow into the tank. Pour DEF until the container is empty or DEF flow stops. DEF can be seen flowing through the spout, but will not completely fill the spout while flowing.
Page 206 Maintenance and Specifications Contaminated DEF SCR systems are sensitive to contamination of the DEF. USE ONLY CERTIFIED DIESEL EXHAUST FLUID. If the system becomes contaminated and the vehicle continues to be driven with contaminated DEF, the following warnings will result: Reducing Agent and Vehicle Consequence Condition Indicator Lamps...
Page 207 Maintenance and Specifications • Do not overfill the DEF tank. • Avoid spilling DEF on painted surfaces, carpeting or plastic components. Immediately wipe away any DEF that has spilled on painted surfaces with a damp cloth and water. If it has already crystallized, use warm water and a sponge.
Page 208 Maintenance and Specifications The advertised fuel capacity of the fuel tank(s) on your vehicle is equal to the rated refill capacity of the fuel tank(s) as listed in Refill capacities in this chapter. The advertised capacity is the amount of the indicated capacity and the empty reserve combined.
Page 209 Maintenance and Specifications 5. Follow one of the simple calculations in order to determine fuel economy: • Divide total miles traveled by total gallons used. • Multiply liters used by 100, then divide by total kilometers traveled. Keep a record for at least one month and record the type of driving (city or highway).
Page 210 Maintenance and Specifications DIESEL PARTICULATE FILTER (DPF) Your vehicle is equipped with a diesel particulate filter (DPF), as part of the after-treatment exhaust system, to trap soot and other large particles produced by the engine combustion process. The soot that accumulates in the filter must be periodically reduced to ash to prevent excessive exhaust restriction.
Page 211 Maintenance and Specifications Diesel Particulate Filter Four–Level Loading Chart Level/Lamp status Filter status Requested action Level 3 Full. Engine is Perform “parked DPF lamp flashing + increasingly limited. regeneration” to Service Engine Soon prevent loss of engine lamp solid performance. Level 4 Over full.
Page 212 1. Bring the vehicle to a complete stop on level ground and safely off the road with the exhaust system away from people, flammable materials, vapors or structures. Ford recommends that you perform a walk-around to check before commencing parked regeneration.
Page 213 Maintenance and Specifications specifications will maximize the miles and hours of operation before a DPF professional cleaning is required. Refer to your engine manufacturer’s owner’s manual for more details regarding recommended maintenance and service of your DPF. Exhaust outlet assembly WARNING: The normal operating temperature of the exhaust system is very high.
Page 214 Maintenance and Specifications Cooling System • Check the fan for damage to blades; replace, if damaged, with the recommended parts. Inspect for fan to shroud interference, and any damage to shroud such as cracks and holes. • The fan ratio should not be changed and the fan spacer dimensions and positions should not be altered.
Page 215 Maintenance and Specifications 4. Remove the dipstick from the reservoir and wipe the dipstick clean. 5. Reinstall the dipstick. Remove it again and check the fluid level. • If the fluid temperature is at approximately 68°-120°F (20°-49°C) (fluid cool or warm to the touch), check the COLD FULL MAX.
Page 216 Refer to Lubricant specifications in this chapter. WARNING: Carefully read cautionary information on product label. For MEDICAL EMERGENCY INFORMATION, contact a physician or Poison Control Center immediately; on Ford-Motorcraft products call: 1-800-959-3673 (FORD). Failure to follow these instructions may result in personal injury.
Page 217 Maintenance and Specifications 1. Set the parking brake, shift into 1 (First) and turn the engine off. 2. Open the hood. 3. Clean the reservoir cap before removal to prevent dirt and water from entering the reservoir. 4. Remove cap and rubber diaphragm from reservoir.
Page 218 Maintenance and Specifications TRANSMISSION FLUID Always dispose of used automotive fluids in a responsible manner. Follow your community’s standards for disposing of these types of fluids. Call your recycling center to find out about recycling automotive fluids. Automatic transmission fluid Refer to your Allison Automatic Transmission Operator’s Manual for scheduled intervals for transmission fluid checks and changes.
Page 219 Maintenance and Specifications Eaton UltraShift (if equipped) The Eaton UltraShift transmission is filled with synthetic fluid from the factory with no scheduled lube change intervals. This fluid is intended to last the life of the transmission. However, the system should be checked regularly to ensure that proper transmission fluid levels remain constant.
Page 220 Maintenance and Specifications 7. Clean and install the filler plug securely. CHASSIS-MOUNTED CHARGE AIR COOLER Inspect charge air cooler daily With the engine off, visually inspect the charge air cooler core assembly for debris and clogging of external fins. Prior to engine operation, remove any debris blocking the core.
Page 221 Maintenance and Specifications SUSPENSION INSPECTION Note: Do not adjust air suspension height to any setting other than the specified setting. Altering the height setting will change the driveline angle and may result in unwarrantable component damage, such as transmission component damage. Verify drive axle air suspension height and height control valve performance at engine lube oil change intervals.
Page 222 Maintenance and Specifications WARNING: Do not use a jack when working under a vehicle. It may give way, causing the vehicle to fall and result in property damage, personal injury or death. Always use floor stands to support the vehicle. FRAME AND TOW HOOKS Your vehicles chassis is manufactured with frame rails of either HSLA steel or heat-treated steel.
Page 223 Maintenance and Specifications Air suspension U-bolt and U-bolt nut installation 1. Inspect the threads of the U-bolt and nut for rust and debris. Clean the threads if contaminated. 2. Install the U-bolts and nuts and torque the nuts to seat the cap flat which is about 18 ft-lb (25 N•m) using a diagonal pattern.
Page 224 Maintenance and Specifications Draining and refilling the rear axle lubricant 1. Drain the rear axle while the lubricant is warm. 2. Park the vehicle on level ground. 3. Set the parking brake and shift into N (Neutral) (automatic transmission) or 1 (First) (manual transmission) and turn the engine off. 4.
Page 225 Maintenance and Specifications Normal maintenance Over a period of time, if not routinely cleaned, a slight film of oil can collect dirt around the rubber fill plug and face, which could appear to be a leak. Routine cleaning ensures that the lube level can be easily observed through the clear window as intended.
Page 226 Maintenance and Specifications Disc wheel with flange nuts (hub-piloted) Front wheel mounting of flange nut system 1. Flange nut 2. Wheel(s) 3. Brake drum 4. Wheel stud (22 mm) 5. Wheel hub 2. Position the outer rear tire and wheel in place over the studs and push it back as far as possible.
Page 227 Maintenance and Specifications Aluminum rear disc wheel with flange nuts (hub-piloted) 1. Flange nut 2. Wheel(s) 3. Brake drum 4. Wheel stud (22 mm) 5. Wheel hub 6. Wheel locator pad Note for aluminum wheels: Prior to re-installing rear aluminum hub-piloted wheels, clean each wheel locator pad on the hub from all dirt, rust and foreign material.
Page 228 Maintenance and Specifications Wheel tightening sequence: 8–lug wheel 10–lug wheel 5. Continue tightening the nuts to the torque specifications in the torque chart using the same crisscross sequence shown. 6. After operating the vehicle approximately 50 miles (80 km), check the nuts for tightness.
Page 229: Wheel Lug Nut Torque
Maintenance and Specifications WARNING: Use only the same type and style wheels and mounting hardware to replace original parts. Failure to do so may result in an assembly that looks fine, but does not fit together properly. This could possibly cause wheel or fastener failures which could result in property damage, personal injury or death.
Page 230 Maintenance and Specifications WARNING: To avoid personal injury or death, always follow these instructions when mounting radial tires on wheels: • Only personnel that have had proper training and experience should mount or remove tires from rims or wheels. • Use only heavy-duty rims or approved rims for radial tires. It may be necessary to contact your wheel and rim distributor to determine if your rims are approved for radial tires.
Page 231 Maintenance and Specifications WARNING: An inflated tire and rim can be very dangerous if improperly used, serviced or maintained. To avoid serious injury, never attempt to re-inflate a tire which has been run flat or seriously under-inflated without first removing the tire from the wheel assembly for inspection.
Page 232 Maintenance and Specifications Stay out of the trajectory (1) as indicated in the illustration. WARNING: Do not mount tube type tires on tubeless wheels or tubeless tires on tube type wheels. To do so could result in tire or wheel failure and cause property damage, personal injury or death. Preserving proper inflation pressure is a very important maintenance practice to insure safe vehicle operation and long life for the tires.
Page 233 Maintenance and Specifications Under-inflation is the primary cause of premature tire concerns including sudden loss of air. In addition, low inflation causes an increase in rolling resistance. This results in reduced fuel mileage, a loss in tread mileage, and uneven wear due to increased tread movement. To determine proper inflation refer to the tire manufacturer load/inflation guide which can be found on the tire manufacturer website or at your local truck tire dealer.
Page 234 Maintenance and Specifications Matching Dual Tires: Dual tires should be matched using tires of equivalent size. Tires which differ more than ⁄ inch (6 mm) in diameter or ⁄ inch (19 mm) in circumference should not be mounted on the same dual wheel assembly.
Page 235 Maintenance and Specifications Wear Radial tires can exhibit three types of normal wear patterns: 1. Even 2. Erosion 3. Chamfer Even wear is a sign that the tire is being properly used and maintained. Erosion wear has also been called rolling wear, channel or river wear. Erosion wear is found more often at free rolling tires.
Page 236 Maintenance and Specifications Irregular wear can be minimized by: • Using the right inflation pressure for the load being carried. • Maintaining proper front wheel alignment - especially toe-in - to specifications. • Maintaining proper tire and wheel balance. • Maintaining shock absorbers and suspension components. Use of tire chains Refer to chain manufacturer’s recommendation for correct tire chain usage, installation and removal.
Page 237: Lubricant Specifications
Maintenance and Specifications 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 238 Maintenance and Specifications 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 239 Maintenance and Specifications 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 240 Maintenance and Specifications 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 241 Maintenance and Specifications 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 242 Maintenance and Specifications 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 243 Maintenance and Specifications 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 244 Maintenance and Specifications 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 245 Maintenance and Specifications 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 246 Maintenance and Specifications 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 247 Maintenance and Specifications 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 248 Maintenance and Specifications 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 249 Maintenance and Specifications 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 250: Refill Capacities
Maintenance and Specifications REFILL CAPACITIES Rear axle - Eaton-Spicer models Weight capacity - lb Pints Axle code Description (kg) (Liters) S135–S 13500 (6123) Single reduction 24.5 (11.6) 4S150–S 15500 (7031) Single reduction 24.5 (11.6) 17060S 17500 (7938) Single reduction 28.0 (13.2) 19055T 17500 (7938) Two-speed...
Page 251 Maintenance and Specifications Axle model Pints (Liters)* RS-19–220 30.0 (14.0) RS-19–223 29.0 (13.0) RS-21–145 32.3 (15.3) RS-21–160 39.0 (18.0) RS-21–230 38.9 (18.4) RS-23–160 39.5 (18.7) RS-23–161 37.2 (17.6) RS-23–180 47.3 (22.4) RS-23–186 47.3 (22.4) RS-23–240 37.4 (17.7) RS-23–380 63.6 (30.1) *Oil capacities are for standard track axles that have been measured at various common drive pinion angles.
Page 252 Maintenance and Specifications Transmission Description Pints (Liters) Allison 2000 Series 30.0 (14.2)* Allison 3000 Series 37.6 (17.8)* 5–speed manual 12.5 (5.9) 6–speed manual 19.5 (9.2) 7–speed manual 22.0 (10.4) *Total fluid capacity (dry transmission and torque converter). Air conditioner refrigerant - r134a This system uses PAG-type refrigerant oil.
Page 253 The VIN is printed on the Vehicle Rating Decal attached to the vehicle on the edge of the driver’s door or B-Pillar. The VIN also serves as the warranty number. If you ever find it necessary to communicate with Ford Motor Company about your vehicle, always include the VIN in your communication.
Page 254 Your authorized dealer specializes in knowing all about Ford Motor Company vehicles rather than knowing a little about all makes. There are Ford and Ford of Canada dealer service shops ready to serve you wherever you drive in the U.S. or Canada. They stock Ford and Motorcraft parts, and Ford chemicals and lubricants.
Page 255 It is critical that systems are flushed only with new fluid that is the same as that required to fill and operate the system, or using a Ford-approved flushing chemical. OWNER MAINTENANCE You can do much of the maintenance your vehicle requires yourself, if you have the time and a reasonable amount of mechanical ability.
Page 256 Scheduled Maintenance Guide Daily owner checks U.S. Department Service brakes of Transportation, Parking brake Federal Highway Steering mechanism Administration Lighting devices and reflectors requirements Tires (ensure that the Horn entire system is Windshield wipers functioning Rear vision mirrors properly) Wheels and rims Emergency equipment Every oil change Engine...
Page 257 Scheduled Maintenance Guide Every oil change Brakes Lubricate the air brake foot control valve, hinge and roller. Inspect the drum brake linings through the inspection holes. Lubricate the rear caliper slide rails. Lubricate the brake camshafts (air brakes only). Lubricate the brake slack adjuster (air brakes only).
Page 258 Scheduled Maintenance Guide Maintenance operation Frequency/Observation Inspect the automatic slack Insufficient power shown in loaded adjuster function practice stop. Check the operation of the Vehicle handling qualities not up to brakes, the clutch, and the par. (1),(2) steering Inspect the vehicle for missing, Excessive noise emanates from under damaged, or mislocated noise the cab or engine compartment.
Page 259 Scheduled Maintenance Guide Maintenance operation Frequency/Observation Check the transmission and Hard shifting or excessive vibration. engine mountings Check and adjust transmission High effort to shift or noisy controls transmission. Check fuel pump pressure Insufficient full-throttle power or backfiring. Clean radiator cap seal. Clean When the cap does not hold pressure.
Page 260 Scheduled Maintenance Guide EMISSIONS CONTROL SYSTEM To ensure the emissions control systems operate effectively, you should have the services listed in the maintenance schedule performed at the specified time and mileage intervals. You should avoid running out of fuel or turning off the ignition while the vehicle is in motion, especially at high speeds.
Page 261 Scheduled Maintenance Guide Among those acts presumed to constitute tampering are the following acts listed: Vehicle System Acts Acoustical Removal of noise shields, hood blanket, tunnel liner Shielding or acoustical absorptive material. Engine Removal or rendering inoperative the engine speed governor so as to allow engine speed to exceed manufacturer specifications.
Page 262 100,000 miles (160,000 km). Maintenance intervals Ford Motor Company has recommended maintenance intervals for various parts and component systems based upon engineering testing. Ford Motor Company relies upon this testing to determine the most 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 263 The maintenance or replacement of the emission control devices (or systems) in your new Ford Motor Company vehicle (or engine) may be performed at your expense. These services may be performed by any automotive repair establishment or individual using automotive parts equivalent to those with which your vehicle or engine was originally equipped.
Page 264 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 265 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 266 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 267 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 268 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 269 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 270 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 271 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 272 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 273 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 274 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 275 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 276 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 277 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 278 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 279 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 280 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 281 Scheduled Maintenance Guide 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 282 Scheduled Maintenance Guide Maintenance record retention and service log 2011 F-650/750 (f67) Supplement, 2nd Printing USA (fus)
Page 283 Scheduled Maintenance Guide EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS...
Page 284 Scheduled Maintenance Guide EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS...
Page 285 Scheduled Maintenance Guide EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS...
Page 286 Index Air conditioning ......48 Cassette tape player ....36 manual heating and air Catalytic converter conditioning system ....48 (see Emission control) .....188 Air suspension ......132 Cell phone use ......8 Anti-lock brake system Child safety seats ......92 (see Brakes) ......130 attaching with tether straps ..96 Audio system (see Radio) ...36, 38 in front seat ......93 Automatic transmission ....134...
Page 287 Cruise control lubrication specifications ..237 (see Speed control) ....64 Engine fan .........196 Customer Assistance ..153, 170 Engine oil ........193 Ford accessories for your oil pressure gauge ....31 vehicle ........181 refill capacities ......251 Getting assistance outside the specifications ......237 U.S. and Canada .....171–172 Event data recording ....6...
Page 288 Index odometer ........31 speedometer ......31 Lamps tachometer ........31 bulb replacement trip odometer ......31 specifications chart ....53 cargo lamps .......52 daytime running light ....51 headlamps .........51 Hazard flashers ......154 high beams ........51 instrument panel, dimming ..52 Headlamps ........51 interior lamps ......53 aiming ........52 replacing bulbs ....53–55 daytime running lights .....51...
Page 289 Index Scheduled Maintenance Guide .........254 General Maintenance Parking brake ....112, 119 Information ......254 warning light ......23 Seat belts (see Safety Power door locks ......67 restraints) ........80 Power mirrors ......60 Seats ..........69 child safety seats ......92 Power point .........57 cleaning ........180 Power steering ......190 heated ........76 fluid, checking and adding ..214...
Page 290 Index fluid, checking and adding (automatic) ......218 fluid, checking and adding Warning chimes ......23 (manual) .........219 Warning lights (see Lights) ..23 fluid, refill capacities ....252 lubricant specifications ..237 Washer fluid ......192 manual operation ....138 Water, Driving through .....109 Turn signal ........52 Wheels ........224 Windows power .........58...

This manual is also suitable for:

F-750 2011

Ford F-650 2011 Supplement Manual

Quick Links

Table of Contents

Related Manuals for Ford F-650 2011

Summary of Contents for Ford F-650 2011

This manual is also suitable for:

Table of Contents
