Elcomponent SPCPro Quick Start Manual

SPCPro
QUICK START GUIDE
Logging
Indicator
SETTING THE UNIT UP
Note: For the detailed PC Specification and Full User
Note: For detailed PC Specification and Full User Manual
ease see PowerPackPro Disk or
please see PowerPackPro Disk or www.spcloggers.com
cloggers.com download
download.
Install the PowerPackPro software onto your PC.
Plug the unit into a mains supply using the cable provided.
Switch the SPC Pro on by briefly pressing the 'Reset/Start' button. The
display will illuminate to indicate that the unit is powered up. The unit is
switched off by pressing the 'sleep' button.
Connect the SPC Pro (powered up) to an unused USB port on your PC.
Windows will then configure the USB interface for first time use. A 'found
new hardware' dialogue box will confirm your new hardware is now
ready for use. If the hardware interface is not successfully loaded,
windows may ask for a disk, or for permission to carry out a web search
or the relevant driver. The driver is present on CD supplied with the
product under the 'Drivers' Folder.
In rare cases, particularly on Windows 7 machines, the PC may not
recognise that the SPC Pro has been connected. See Additional Notes.
With the logger connected to the USB port of your PC, open
PowerPackPro. If a 'Bluetooth Scan' window appears, this should be
cancelled. Within a few seconds the logger will be found by the PC.
Press OK and the logger will be added to the tree on the upper left
hand side of the desktop as shown below.
SPCPRO – 'At a Glance'
Sleep Button
Power
Indicator
Reset/Start USB Connection
Button Socket
Highlight the Logger and right click to select 'Set Up Survey'
The set-up window will then appear
Click the 'Set Time' button to synchronise the logger clock with your
PC. Then select the desired storage interval, and click 'Set Logger'.
www.spcloggers.com
Multi-function
Display
Example of typical tree diagram
