Elcomponent AEM33 485 DIN Quick Start Manual

AEM33 485 DIN
INSTRUCTIONS
1 SAFETY
This instrument is manufactured in compliance with EN61010-1
Cat III for nominal operating voltages of 400V L-L and 230V L-N, to
ensure safe operation the user must comply with the following
instructions:
•
Ensure that the supply voltage is correct.
•
The auxiliary mains supply is internally fused at 250V, 100mA
Type 2. External fusing is required if the auxiliary supply
voltage exceeds 250V.
•
Maintenance and/or repairs must be carried out only by
qualified, authorised personnel.
•
If there is ever the suspicion that safe use is no longer
possible, the instrument must be disconnected and
precautions must be taken against accidental use.
•
Operation is no longer safe:
1) If there is clearly visible damage
2) If the instrument no longer functions
3) After prolonged storage in unsuitable conditions.
1.1 OPERATOR SAFETY
Read these instructions carefully before installing and utilising the
instrument.
The instrument described in this user manual is intended for use
by properly trained staff only. Maintenance and/or repairs must
be carried out by authorised personnel only. For proper, safe use
of the instrument and for maintenance and/or repair, it is
essential that the persons instructed to carry out these
procedures follow normal safety precautions.
2 SYMBOLS
CAUTION: Failure to follow the instructions may result in
personal injury or damage to equipment.
NOTE: Failure to follow the instructions may result in an
instrument malfunction.
3 CONNECTION DIAGRAMS
CAUTION: The instrument is internally fused at 250V 100mA.
External fusing is required if the supply voltage exceeds 250V.
(OPT)
(OPT)
(OPT)
