PQPro™ User Manual
Copyright © 2012 ELCOMPONENT Ltd.
All Rights Reserved.
The information in this document is subject to change without notice.
Elcomponent has made every effort to ensure the accuracy of this manual. However, Elcomponent makes no
warranties with respect to this documentation and disclaims any implied warranties of merchantability and fitness
for a particular purpose. Elcomponent assumes no responsibility for any errors that may appear in this document.
Trademarks
PQPro and PV II are registered trademarks of Candura Instruments.
All other product names are copyright and may be trademarks and/or registered trademarks of their respective
companies.
Manufactured by:
Elcomponent Ltd
Unit 5 Southmill Trading Centre
Southmill Road
Bishop's Stortford
Herts CM23 3DY
Document number: CID1008.01
Date: 2 November, 2012
Printed in the UK
Advertisement
Table of Contents
Related Manuals for Elcomponent PQPro
Summary of Contents for Elcomponent PQPro
- Page 1 Elcomponent has made every effort to ensure the accuracy of this manual. However, Elcomponent makes no warranties with respect to this documentation and disclaims any implied warranties of merchantability and fitness for a particular purpose. Elcomponent assumes no responsibility for any errors that may appear in this document. Trademarks PQPro and PV II are registered trademarks of Candura Instruments.
-
Page 2: Table Of Contents
Under/Over Voltage Events ....................9 High Speed Voltage Transients ..................... 9 Current Inrush ........................9 Voltage and Current Unbalance ..................... 9 PQPro™ Back Panel ........................10 PQPro™ Front Panel ........................11 PQPro™ Operation ........................12 Turning On and Off ....................... 12 Memory Card ........................ - Page 3 PQPro™ User Manual PQPro™ Operation – Setup (continued) ..................17 AEM35 Energy Meter Ext PT/CT ..........................17 System Freq ......................... 17 Clock ............................. 17 Bluetooth ..........................17 Calibrate ..........................18 Language..........................18 Display ..........................18 Record ..........................19 Specifications ..........................20...
-
Page 4: Introduction
Power Quality (IEC 61000-4-30 Class A) The PQPro™ is an 8 channel power quality analyzer / data recorder. It monitors three phases of voltage and current as well as a fourth channel of voltage and current. Measured parameters are updated every ½... -
Page 5: Safety
Please read and UNDERSTAND the following information before operating this instrument ▪ The PQPro™ uses a membrane keypad that could be damaged if a sharp object is brought into contact with it. ▪ Frequently inspect the test leads and the instrument for damage. If the instrument shows any signs of physical damage or functions improperly, it should not be used. -
Page 6: Quick Start
PQPro™ User Manual Quick Start Connecting the PQPro™ to the circuit to be measured is a straightforward process. 1. Connect the voltage leads for each phase to be measured. For proper operation V1 must always be used. Three phase circuits can be connected in either a ‘wye’ or 'delta’ configuration. Refer to the ‘Hookup Configurations’... -
Page 7: Hookup Configurations
PQPro™ User Manual Hookup Configurations The PQPro™ can be used to monitor any single phase or three phase power configuration. Following are descriptions of the five most common field setups: - 4 -... -
Page 8: Hookup Diagnostic Warnings
PQPro™ User Manual Hookup Diagnostic Warnings From the ‘RECORD’ screen the operator can select ‘SYSTEM CHECK’. The instrument does a number of checks on the connected signals, if it detects a potential problem a message will be displayed in the RECORD screen. - Page 9 PQPro™ User Manual ‘-VE POWER CHECK CT1’ ‘-VE POWER CHECK CT2’ ‘-VE POWER CHECK CT3’ ‘-VE POWER CHECK CT4’ This usually means that the relevant CT has been connected in reverse. To fix the problem remove the CT, rotate it 180 degrees, reconnect it and then press ‘SYSTEM CHECK’ again. In some cases this is not an error (i.e.
-
Page 10: Pqpro™ Firmware Features
RMS and Waveform Data Storage The PQPro™ stores RMS data at set intervals which can be adjusted from 0.2 (continuous) to 30 seconds or 1 to 30 minutes. The minimum, maximum and average values are stored at the end of each storage interval. -
Page 11: Interharmonics
PQPro™ User Manual Interharmonics Interharmonics are calculated by the software from the waveform snapshots that are stored every storage interval. The Interharmonic calculation requires multiple cycles of waveforms. If Interharmonics are turned off only one cycle of waveforms is captured and the software can only calculate the harmonics. -
Page 12: Under/Over Voltage Events
½ cycle resolution, for events less then 2 seconds and in seconds for longer events. The PQPro™ uses a hysteresis value of 0.1% of full scale to determine when the event has finished. For example if the under voltage trigger level is set at 228.0 volts the instrument will start recording an event when the voltage goes under 228.0 volts and will stop recording the event... -
Page 13: Pqpro™ Back Panel
PQPro™ User Manual PQPro™ Back Panel The voltage and current connections are colour coded according to phase and polarity (for voltage). Channel 1 or Phase A Channel 2 or Phase B Yellow Channel 3 or Phase C Blue Channel 4 Current... -
Page 14: Pqpro™ Front Panel
PQPro™ User Manual PQPro™ Front Panel The front panel of the PQPro™ has a colour graphics display, a 10 button keypad and a memory card interface. The colour graphics display is 270x480 pixels. The keypad has two types of buttons. The bottom row of 4 keys are fixed function buttons and the top row of 6 keys are function keys that change function depending on the active screen on the display. -
Page 15: Pqpro™ Operation
When it detects a card being inserted (or a card in the socket immediately after power up) the instrument checks the card size and the number of files on the card. The PQPro™ supports from 2GB to 64GB SD memory cards. Each file is allocated approximately 0.5GB on the card so that a 2GB card can hold up to 4 data files and a 64GB card can hold up to 128 data files. -
Page 16: Pqpro™ Setup
PQPro™ User Manual PQPro™ Setup Pressing the ‘SETUP’ button calls up the main setup screen. From the main setup screen you can select: PHASE CT RANGE CH 4 CT RANGE CONNECTION DATA STORAGE TRIGGER LEVELS ... -
Page 17: Pqpro™ Data Storage
PQPro™ User Manual PQPro™ Data Storage User can configure various data store parameters: ▪ STORAGE RATE ▪ RECORDING MODE ▪ INTERHARMONICS ▪ VOLT SPIKE WVFRM (Voltage Spike Waveforms) ▪ VOLT U/O WVFRM (Under/Over Voltage Waveforms) ▪ CURR INRSH WVFRM (Current Inrush Waveforms) ▪... -
Page 18: Interharmonics
PQPro™ User Manual Restart when full When the data file is full the file is closed and a new file is automatically started. For storage rates 1 second or longer the new file will start on an even minute boundary so there could be a gap of up to a minute between the end of one data file and the start of the next one. -
Page 19: Pqpro™ Trigger Levels
PQPro™ User Manual PQPro™ Trigger Levels The event trigger levels are set here. The options are: ▪ EVENT ENABLE Note: This menu is not accessible if the ▪ PHASE CURRENT INRUSH storage rate is set to continuous. ▪ CH4 CURRENT INRUSH ▪... -
Page 20: Phase Voltage Under
PQPro™ stores RMS data every 100 milliseconds and waveforms, with 64 samples/cycle, continuously Clock This enables the user to set the PQPro™ internal clock from the front panel. The internal clock can also be set from a computer using PV II™ software and a Bluetooth interface. Bluetooth User can turn off the internal Bluetooth radio transmitter. -
Page 21: Calibrate
Qualified personnel can modify the calibration factors by first entering a six digit password. Please consult sales@elcomponent.co.uk to receive the password. Language User can change the language used by the PQPro™ display. Presently only English and Spanish are supported Display Pressing the ‘DISPLAY’... -
Page 22: Record
PQPro™ User Manual Record Pressing the ‘RECORD’ button calls up the recording screen. From this screen user can: (F3) Run a system check that checks over range voltage and current, reverse CT connections, reverse phase sequence and voltage and current outside trigger levels. -
Page 23: Specifications
PQPro™ User Manual Specifications Specifications Comment Measurement V1, V2, V3 0.1% of full scale + - 600 VAC 0.1% of reading 0 - 80VAC / 110VDC 0.1% of full scale + 0.1% of reading 0 – 600VAC / 850VDC I1, I2, I3 0.1% of full scale +...
