NOTE: Do not use power tools for assembly. Power tools increase the risk of over tightening which leads to splitting or cracking
the wood.
COMPONENT LIST (CHAIR)
NO.
A
HARDWARE LIST
NO.
1
2
3
4
5
6
7
8
9
Assembly Instruction
RSF 2-SEATER WITH ONE POWER RECLINER,
USB PORT AND ADJUSTABLE HEADRESTS
ITEM NO.: 8256 / 8256GY / 8256SW / 8256FBR-RPW
DRAWING
DRAWING
QTY
DESCRIPTION
1 PC
RSF 2-SEATER
QTY
DESCRIPTION
2 PCS
METAL LEG
8 PCS
8 PCS
LOCK WASHER
1 PC
ALLEN KEY
2 PCS
PLASTIC LEG
2 PCS
ADJUSTABLE LEG
2 PCS
PLASTIC GASKET
1 PC
ADAPTOR
1 PC
PLUG WITH WIRE
QP-AI-P022-152-1
BOLT
1/3
Advertisement
Table of Contents
Related Manuals for Homelegance Cinque 8256
Summary of Contents for Homelegance Cinque 8256
- Page 1 QP-AI-P022-152-1 Assembly Instruction RSF 2-SEATER WITH ONE POWER RECLINER, USB PORT AND ADJUSTABLE HEADRESTS ITEM NO.: 8256 / 8256GY / 8256SW / 8256FBR-RPW NOTE: Do not use power tools for assembly. Power tools increase the risk of over tightening which leads to splitting or cracking the wood.
- Page 2 QP-AI-P022-152-1 STEP#1 Align and attach legs to chair, insert bolts and washers and tighten with Allen key. STEP#2 Place the cap screw from the end through the plastic leg, insert the gasket onto the leg. Rotate clockwise to tighten the leg. After that rotate clockwise to tighten the adjustable leg. Turn the leveler at the bottom of support leg to adjust the height to be level with floor.
- Page 3 QP-AI-P022-152-1 STEP#5 Completed. USB Port 5V/1A Press (Recline) Control Switch CARE INSTRUCTION FOR GENUINE ALL LEATHER: In order to maintain the original appearance of your leather furniture, please follow below simple care procedure : Avoid exposing furniture directly to sunlight or heating and air conditioning outlets. Exposure to sunlight or heating and air conditioning outlets will fade/damage leather.
