DOUBLE GLIDER RECLINING LOVE SEAT WITH CONSOLE
NOTE: Do not use power tools for assembly. Power tools increase the
risk of over tightening which lead to splitting or cracking the wood.
COMPONENT LIST
NO.
A
B
C
D
E
F
ASSEMBLY INSTRUCTION
ITEM NO: 8230BLK/BRW-2
DRAWING
QTY
DESCRIPTION
1
1
LSF BACK REST
1
CONSOLE BACK REST
1
RSF BACK REST
1
1
LSF EAR
RSF EAR
SEAT
