Homelegance 8548-2ACL Assembly Instructions Manual

8548-2ACL PARTS LISTS
NO. SKETCH
A
B
C
D
8548-2A PARTS LISTS
SKETCH
NO.
E
F
B
C
D
8548-CR PARTS LISTS
SKETCH
NO.
G
H
I
C
D
MADE IN VIETNAM
ASSEMBLY INSTRUCTIONS
ITEM NO.:
8548-2ACL Armless Convertible 2-Seater with Pull-out Bed and Click Motion Back
8548-2A Armless 2-Seater
8548-CR Corner Seat
8548-AC Armless Chair
8548-VCCL Armless Convertible Storage Chaise with Click Motion Back
8548-A Two Arms
8548-OT Storage Ottoman with Casters
Thank you for purchasing this product. Please take time to read and follow the instructions below.
Check that you have all parts and hardware before assembly. Parts apparently missing are often
found in the packing materials. If you do not have all the parts listed, have your dealer contact us
and they be sent to you immediately.
It is recommended to install protective pads under all legs and support to avoid damage or scratches
when placing furniture on a wood floor or orther hard surface, and to limit Indentation and prevent
discoloration if placing on carpet.
DESCRIPTION QTY
Seat 1 PC
Back Cushion
2 PCS
Pillow
1 PC
20"x20"
Pillow
1 PC
18"x18''
DESCRIPTION QTY
Seat
1 PC
Backrest
1 PC
Back Cushion
2 PCS
Pillow
1 PC
20"x20"
Pillow
1 PC
18"x18"
DESCRIPTION QTY
Seat 1 PC
Small Back
1 PC
Cushion
Big Back Cushion 1 PC
Pillow
1 PC
20"x20"
Pillow
1 PC
18"x18"
8548-AC PARTS LISTS
DESCRIPTION
NO. SKETCH
J Seat
K Backrest
B
Back Cushion
8548-VCCL PARTS LISTS
DESCRIPTION
SKETCH
NO.
Seat
L
Back Cushion
B
Pillow
C
20"x20"
Pillow
D
18"x18"
8548-A PARTS LISTS
DESCRIPTION
SKETCH
NO.
M LSF Arm
N RSF Arm
8548-OT PARTS LISTS
DESCRIPTION
NO. SKETCH
O Ottoman
QTY
1 PC
1 PC
1 PC
QTY
1 PC
1 PC
1 PC
1 PC
QTY
1 PC
1 PC
QTY
1 PC
PAGE 1 OF 8
