Mounting & Commissioning
1
Ø 8 mm
3
4
RESET CARD
Change current
5
1
10 LEDs = 10 A
2 sec.
Wattpilot Go 11 J 2.0: 6 - 16 A
Wattpilot Go 22 J 2.0 / AUS: 6 - 32 A
Technical Data WLAN
Frequency Band
Radio-frequency power
2
*
*
Setup your PV system in a few minutes.
1
START INSTALLATION
LOGIN
Log in with your Fronius credentials (email adress
& password) in order to get the most out of the
PV System. Installing a new product does not
require a Login.
Imprint & Contact
Data Privacy
Terms & Conditions
Change mode
6
2
< 0,5 sec.
32 LEDs = 32 A
Eco Mode
channel 1 - 11 (2412 - 2462 MHz)
< 100 mW (< 20 dBm)
Instructions for packaging disposal
Emballages à séparer
et à déposer dans le
bac de tri
Quick
Start Guide
*digital input
Fronius Wattpilot
Home 11 J 2.0
Home 22 J 2.0
2
manuals.fronius.com/
html/4204260435
OPERATING
INSTRUCTIONS
Next Trip Mode
22
20
42,0410,2751
PAP
PAP
011-19122023
