Keysight PXIe Chassis Family
M9010A, M9019A, M9046A
M9010A
M9046A
M9019A
STARTUP GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M9010A and is the answer not in the manual?

Questions and answers

Related Manuals for Keysight M9010A

Summary of Contents for Keysight M9010A

  • Page 1 Keysight PXIe Chassis Family M9010A, M9019A, M9046A M9010A M9046A M9019A STARTUP GUIDE...
  • Page 3 Warranty © Keysight Technologies, Inc. 2018-2023 No part of this manual may be repro- To contact Keysight for sales and techni- THE MATERIAL CONTAINED IN THIS duced in any form or by any means cal support, refer to the support links on DOCUMENT IS PROVIDED “AS IS,”...
  • Page 4 Do not use this prod- Cleaning uct in any manner not specified by the Clean the outside of the Keysight mod- manufacturer. The protective features ule/chassis with a soft, lint-free, of this product must not be impaired if slightly dampened cloth.
  • Page 5 Industry Canadian Interference-Causing Equipment Standard (ICES/NMB-001). Frame or chassis Terminal The Keysight email address is This is also a symbol of an Industrial required by EU directives applicable Scientific and Medical Group 1 Class A to our product.
  • Page 6 August 13, 2005. All electric and electronic equipment are required to be separated from normal waste for disposal. To return unwanted products, contact your local Keysight office, or for more information see http:// about.keysight.com/en/companyinfo/ environment/takeback.shtml. Universal recycling symbol. This Universal recycling symbol.

  • Page 7: Table Of Contents

    Chassis Front Panel LEDs ......... 35 Using Keysight Connection Expert ........37 PC Startup Requirements for Keysight IO Libraries Suite .
  • Page 8 Verifying your Module ..........46 Related Documentation Chassis Related Products and Accessories viii Keysight PXIe Chassis Startup Guide...

  • Page 9: Introduction

    Keysight provides the below PXIe chassis in the PXIe Chassis Family: - M9010A – a 10-Slot PXI 24 GB/s, Gen 3 chassis - M9019A – a 18-Slot PXI 24 GB/s, Gen 3 chassis - M9046A - a 18-Slot PXI 24 GB/s, Gen 3, high power, exceptional cooling...

  • Page 10: About This Guide

    – How to use Keysight Connection Expert and the chassis Soft Front Panel (SFP) to verify operation of the chassis. – Overview of installing and verifying Keysight modules in the chassis.

  • Page 11: About The Chassis

    The Keysight Chassis Family is designed to deliver the highest power and cooling capability. The Keysight PXIe chassis have these key features: – The M9019A have up to 16 PXIe hybrid slots (the M9010A has 8 hybrid slots). – The M9046A has 3 PXIe hybrid slots and 13 PXIe slots.
  • Page 12 About the Chassis Introduction Figure 1 shows the front view of the M9019A chassis. The M9010A chassis is similar but has ten slots. Figure 1 Keysight M9019A PXI Chassis (the other chassis are similar) Figure 2 shows the front view of the M9046A PXIe chassis.

  • Page 13: M9010A And M9019A Front Panel Trigger

    Two front panel SMB trigger connectors connect to the PXI [0:7] backplane trigger bus in Trigger Bus Segment 1 in the M9010A chassis and Trigger Bus Segment 2 in the M9019A chassis. See the Keysight PXIe Chassis User Guide for detailed information.

  • Page 14: M9046A Advanced Rear Trigger Access (Option 001)

    M9046A Advanced Rear Trigger Access (Option 001) Eight rear panel SMB trigger ports connect to all 3 Trigger Bus Segments in the M9046A chassis. See the Keysight M9046A PXIe Chassis User Guide for detailed information. This option requires drivers version 1.7.913.1 or later and firmware version 2023A or later.

  • Page 15: M9046A Push-Pull Cooling (Option 003)

    The M9046A chassis has three fans that push air from the rear of the chassis and an optional top fan tray with four fans pulls air out from above the module slots. Figure 7 Keysight M9046A PXIe Chassis Top View with Option 003 Keysight PXIe Chassis Family Startup Guide...

  • Page 16: M9046A Additional Chassis Options (Options Qs1, Qs2, And Qs3)

    These options require drivers version 1.7.913.1 or later and firmware version 2023A or later. Refer to www.keysight.com/find/M9046A to install the latest drivers and firmware. M9046A-QS2 M9046A-QS1/ M9046A-QS3 Figure 4 Front Panels of M9046A-QS1, M9046A-QS2 and M9046A-QS3 Keysight PXIe Chassis Family Startup Guide...

  • Page 17: Interactive Block Diagram

    An interactive Block Diagram exists for all four chassis. This Block Diagram is usable for training and understanding how the chassis works. You can download the block diagram from: www.keysight.com/find/pxi-blockdiagram The Block Diagram and other information is available on the web: www.keysight.com/find/M9010A www.keysight.com/find/M9019A www.keysight.com/find/M9046A Keysight PXIe Chassis Family Startup Guide...
  • Page 18 Figure 9 Chassis Block Diagram Keysight M9046A 18-Slot PXIe Startup Guide...

  • Page 19: Terminology

    PC or laptop with Thunderbolt 3 technology, the M9025A PXIe System Module can be used to connect the PXIe chassis to PC or laptop. An embedded controller, such as the Keysight M9038A Embedded Controller, is a small form-factor, Windows-based PC that is designed for installation in the system controller slot of the chassis (slot 1).

  • Page 20: Static-Safe Handling Procedures

    DO NOT use these techniques for a static-safe work station when working on circuitry with a voltage potential greater than 500 volts. All front and rear panel I/O port cables are not recommended to be longer than 3 meters. Keysight PXIe Chassis Family Startup Guide...

  • Page 21: Step1: Verify Shipment Contents

    When shipping the M9046A chassis, use original packaging or comparable to avoid damage to the product. Keysight suggests that you save the chassis shipping container in case it ever becomes necessary to return the chassis to Keysight for service. Return the Chassis to Keysight for service. Chassis Shipment Verification Verify that your chassis shipment contains the following items: –...

  • Page 22: Step 2: Prepare The Hardware

    Use only the power cord supplied with the chassis. Keysight power cords ensure continuity between the chassis grounding-type power plug and the safety ground terminal at the power outlet.

  • Page 23: M9046A

    When operating the instrument at 100/120 VAC 50/60/400 Hz or 220/240 VAC 50/60 Hz, a ground cable (not provided by Keysight) must be connected to the rear panel of the instrument to a proper ground socket of the building. Install a...
  • Page 24 Remove screw from ground point Step 2. Attach the ground wire with the ring terminal into screw thread and tighten back to a original ground point in the following figure: Figure 12 Attach ground wire with ring terminal Keysight PXIe Chassis Family Startup Guide...

  • Page 25: Host Controller Hardware And Software Requirements

    1. 32-bit operating systems do not support large, multi-chassis systems. For details, refer to Keysight's Multi-Chassis Designer tool. This tool is available on-line at: www.keysight.com/find/pxie-multichassis 2. Because of the installation procedure, less memory may be required for operation than is required for installation.

  • Page 26: Setting Up The Chassis On A Bench

    Removing and Installing Filler Panels The chassis is shipped from the factory with all filler panels installed. If additional filler panels are needed, a set of five may be ordered using the Keysight part number: Y1213A. For more information, see: www.keysight.com/find/Y1213A.

  • Page 27: Connecting A Remote Host Pc To The Chassis

    “Static-safe Handling Procedures” page 20 of this guide. 1 Install a PCIe Host Adapter in the Host PC. Keysight offers the M9048B (x8) and M9049A (x16) PCIe host adapters for desktop and rack-mounted PCs. To install an adapter in your remote controller PC, follow the instructions provided with your adapter.
  • Page 28 With the injector/ejector handle in the down position, carefully slide the module to the rear of the chassis. When you begin to feel resistance from the backplane connectors, lift up on the injector/ejector handle to complete insertion of the module. Keysight PXIe Chassis Family Startup Guide...
  • Page 29 250 cycles. 4 Install the driver software for the PXIe System Module (required for the Keysight M9022A, M9023A, M9024A, or M9025A PXIe System Modules). 5 Install the PXIe Chassis Family Driver software. See “Install the PXIe Chassis Family Driver”...

  • Page 30: Installing An Embedded Controller In The Chassis

    The IO Libraries Suite is used with all Keysight instruments, and is not specific to the PXIe chassis. Download the latest version from: www.keysight.com/find/iosuite.

  • Page 31: Install The Pxie Chassis Family Driver

    Install the PXIe Chassis Family Driver Step 2: Prepare the Hardware Only one installation of the Keysight IO Libraries Suite is required on the host controller PC. This installation is used by both the PXIe Chassis drivers that are installed in the next section and the drivers associated with each module that you install in the chassis.
  • Page 32 7 Choose Run. Do not uninstall the KtMPxiChassis IVI.NET Driver 1.x.xxx, KtMPxiChassis IVI-C Driver 1.x.xxx, KtMTrig IVI.NET Driver 1.x.xxx, or KtMTrig IVI-C Driver 1.x.xxx files without also uninstalling the Keysight PXIe Chassis Family Driver. Keysight PXIe Chassis Family Startup Guide...

  • Page 33: Step 3: Turn On Chassis And Verify Operation

    100/120 VAC or 50/60/400 Hz, or 220/240 VAC, and 50/60 Hz frequency. Since 400 Hz frequency is not supported for M9019A/M9010A, ensure that AC supply line voltage is within the range of 100/120 VAC, or 220/240 VAC, and 50/60 Hz frequency for M9019A/M9010A.

  • Page 34: Chassis Power Sequencing

    The method of powering up the chassis depends on the position of the INHIBIT rear panel switch, which can be set to the DEF (default) position or to the MAN (manual) position. These two methods are shown on the interactive block diagram and work as follows: Keysight PXIe Chassis Family Startup Guide...

  • Page 35: Chassis Front Panel Leds

    For information on using the Inhibit signal on the rear panel DB-9 connector to power the chassis up and down, see the Keysight PXIe Chassis User Guide. Chassis Front Panel LEDs The chassis contains three LEDs on its front panel to the left of the ON/Standby (power) push button, as shown in the following figure.
  • Page 36 M9019A chassis See the Keysight the M9010A is 900 RPM limit. in a system with an SFP PXIe Chassis Family and for the M9019A is...

  • Page 37: Using Keysight Connection Expert

    Using Keysight Connection Expert Step 3: Turn On Chassis and Verify Operation The M9010A has a protective algorithm to monitor the AC input current and if the AC input current goes above 8.5A, it will automatically power-off. When automatically powered-off, the chassis will continually blink the blue power LED 3 times.

  • Page 38: Pc Startup Requirements For Keysight Io Libraries Suite

    PC Startup Requirements for Keysight IO Libraries Suite This section describes the PC startup events for Keysight Connection Expert (one of the utilities in the Keysight IO Libraries Suite). Keysight recommends using the latest version Keysight IO Libraries Suit. Two situations exist where Connection Expert, which is part of Keysight IO Libraries Suite, will not display a PCIe device, either the chassis or a module in the chassis.

  • Page 39: Using The Soft Front Panel (Sfp) To Monitor The Chassis

    Independent of whether you plan to run the SFP in Hardware Mode or Simulation Mode, the SFP is started from the Start menu as follows: Start > All Programs > Keysight > PXIe Chassis Family > PXIe Chassis SFP Simulation Mode If no chassis has been detected by Connection Expert, the SFP startup dialog appears as shown in the following image.

  • Page 40: Using The Sfp To Monitor The Chassis

    SFP includes an Allow Control check box that is unchecked by default. The unchecked box prevents any configuration change from being made. In the Keysight PXIe Chassis User Guide, which describes how to use the SFP to configure the chassis, this check box will be checked.
  • Page 41 This screen also displays the source of the 10 MHz reference clock and the current PCIe link configuration. For more information, see the Keysight PXIe Chassis User Guide. Figure 20...
  • Page 42 Keysight PXIe Chassis User Guide or the PXIe Chassis Soft Front Panel Help file. On the M9010A, if you use a Reference Clock signal with an amplitude of < 500mVpp, the Reference Clock alarm may repeatedly trigger even after clearing it.
  • Page 43 Allows you to configure the two front panel trigger post (TRIG 1 and TRIG 2) as either Input (default) or Output ports and connect it to one PXI backplane trigger Line (PXI_TRIG[0:7]) PCIe Link tab none The PCIe link configuration information can be viewed from the Monitor tab of the SFP. Keysight PXIe Chassis Family Startup Guide...

  • Page 44: Step 4: Overview Of Installing And Verifying Pxi/Pxie Modules

    Before installing modules in the chassis, power down the chassis but leave the power cord connected to the AC mains because it serves as a ground and helps protect the chassis and modules from electrostatic damage. Keysight PXIe Chassis Family Startup Guide...
  • Page 45 Ensure that all empty chassis slots are covered by filler panels or air inlet modules. f Power up the chassis. Verify that the chassis fans are operating and free of obstructions that may restrict airflow. Keysight PXIe Chassis Family Startup Guide...

  • Page 46: Installing The Module Software

    Verifying your Module Follow the instructions provided with your module to verify its operation. Module verification typically includes the following steps: - Verify that your module is displayed within the chassis in Keysight Connection Expert as described in “Using Keysight Connection Expert”...
  • Page 47 The following documents are also available on the product website: – Keysight M9022A, M9023A, M9024A, M9025A PXIe System Module Data Sheet – Tested PC and PXI/AXIe Chassis Configurations— This document lists the PCs that have been verified to work with the chassis. See http://www.keysight.com/find/PXIAXIeTestedPC...
  • Page 48 PXIe high performance System Module: dual port (x16) Gen 3 PXIe high performance System Module with connectivity M9024A expansion: two gigabit LAN, two USB 3.0, four USB 2.0, GPIB M9025A Dual Port Thunderbolt PXIe System Module: up to 40Gbps Keysight PXIe Chassis Family Startup Guide...
  • Page 49 Accessories Y1213A PXI EMI Filler Panel Kit: 5 single-slot panels Y1214B Air Inlet Module Kit (not for use with M9010A 10-Slot chassis and M9046A 18-Slot chassis) Y1215C Flush mount rack kit (M9018B, M9019A) Y1216B Recess mount rack kit (M9018B, M9019A)
