Summary of Contents for Keysight M9018B

  • Page 3 Warranty © Keysight Technologies, Inc. 2018 No part of this manual may be repro- To contact Keysight for sales and techni- THE MATERIAL CONTAINED IN THIS duced in any form or by any means cal support, refer to the support links on DOCUMENT IS PROVIDED “AS IS,”...
  • Page 4 Cleaning In Case of Damage The following general safety precau- tions must be observed during all Clean the outside of the Keysight mod- Instruments that appear damaged or phases of operation of this instrument. ule/chassis with a soft, lint-free, defective should be made inoperative Failure to comply with these precau- slightly dampened cloth.
  • Page 7: Table Of Contents

    Chassis Front Panel LEDs ......... 30 Using Keysight Connection Expert ........32 PC Startup Requirements for Keysight IO Libraries Suite .
  • Page 8 Verifying your Module ..........41 Related Documentation Chassis Related Products and Accessories viii Keysight PXIe Chassis Family Startup Guide...
  • Page 9 Keysight provides three PXIe chassis in the PXIe Chassis Family: - M9010A – a 10-Slot PXI 24 GB/s, Gen 3 chassis - M9018B – a 18-Slot PXI 8 GB/s, Gen 2 chassis - M9019A – a 18-Slot PXI 24 GB/s, Gen 3 chassis Unless specified, everything in this PXIe Chassis Family Startup Guide pertains to all three PXI chassis.
  • Page 10: Introduction

    – How to use Keysight Connection Expert and the chassis Soft Front Panel (SFP) to verify operation of the chassis. – Overview of installing and verifying Keysight modules in the chassis.
  • Page 11: About The Chassis

    – One common driver supports IVI-C and IVI.NET for all three chassis (and the M9018A PXIe chassis). Figure 1 shows a front view of the M9019A chassis. The M9018B chassis is similar; the M9010A chassis is similar but has ten slots.
  • Page 12: Front Panel Trigger

    Two front panel SMB trigger connectors connect to the PXI [0:7] backplane trigger bus in Trigger Bus Segment 1 in the M9010A chassis and Trigger Bus Segment 2 in the M9018B and M9019A chassis. See the Chassis Family User Guide for detailed information.
  • Page 13: Interactive Block Diagram

    You can download the block diagram from: www.keysight.com/find/pxi-blockdiagram The Block Diagram and other information is available on the individual the web pages of the three PXIe chassis: www.keysight.com/find/M9010A www.keysight.com/find/M9018B www.keysight.com/find/M9019A Keysight PXIe Chassis Family Startup Guide...
  • Page 14 Introduction Interactive Block Diagram Keysight PXIe Chassis Family Startup Guide...
  • Page 15 Figure 1 Chassis Block Diagram Keysight PXIe Chassis Family Startup Guide...
  • Page 16 Keysight PXIe Chassis Family Startup Guide...
  • Page 17: Terminology

    1 of the chassis. The M9048A and M9021A can be used with the M9018A and M9018B chassis in Gen 2 mode. An embedded controller, such as the Keysight M9037A Embedded Controller, is a small form-factor, Windows-based PC that is designed for installation in the system controller slot of the chassis (slot 1).
  • Page 18: Static-Safe Handling Procedures

    To ensure user safety, the static-safe accessories must provide at least 1 MΩ of isolation from ground. DO NOT use these techniques for a static-safe work station when working on circuitry with a voltage potential greater than 500 volts. Keysight PXIe Chassis Family Startup Guide...
  • Page 19: Step1: Verify Shipment Contents

    – Appropriate power cord for your location. – Printed Keysight PXIe Chassis Family Startup Guide (this document). The weight of an empty M9018B or M9019A PXIe chassis (no modules installed in the chassis) is approximately 29.8 lbs (13.5 kg). Lift the chassis using a single side handle only when the total chassis weight (chassis plus installed modules) does not exceed 75 lbs (34.0 kg).
  • Page 20: Step 2: Prepare The Hardware

    Use only the power cord supplied with the chassis. Keysight power cords ensure continuity between the chassis grounding-type power plug and the safety ground terminal at the power outlet.
  • Page 21: Host Controller Hardware And Software Requirements

    1. 32-bit operating systems do not support large, multi-chassis systems. For details, refer to Keysight's Multi-Chassis Designer tool. This tool is available on-line at: www.keysight.com/find/pxie-multichassis 2. Because of the installation procedure, less memory may be required for operation than is required for installation.
  • Page 22: Setting Up The Chassis On A Bench

    Removing and Installing Filler Panels The chassis is shipped from the factory with all filler panels installed. If additional filler panels are needed, a set of five may be ordered using the Keysight part number: Y1213A. For more information, see: www.keysight.com/find/Y1213A.
  • Page 23: Connecting A Remote Host Pc To The Chassis

    “Static-safe Handling Procedures” page 18 of this guide. 1 Install a PCIe Host Adapter in the Host PC. Keysight offers the M9048B (x8) and M9049A (x16) PCIe host adapters for desktop and rack-mounted PCs. To install an adapter in your remote controller PC, follow the instructions provided with your adapter.
  • Page 24 Ensure that all empty chassis slots are covered by filler panels or air inlet modules. f Power up the chassis. Verify that the chassis fans are operating and free of obstructions that may restrict airflow. Keysight PXIe Chassis Family Startup Guide...
  • Page 25: Installing An Embedded Controller In The Chassis

    Installing an Embedded Controller in the Chassis An embedded controller, such as the Keysight M9037A Embedded Controller, is a small form factor, Windows-based PC that is designed to be installed in the system controller slot of the chassis (slot 1). An embedded controller also occupies the expansion slots to the left of slot 1;...
  • Page 26: Install Keysight Io Libraries Suite (Remote Host Pc)

    The IO Libraries Suite is used with all Keysight instruments, and is not specific to the PXIe chassis. Download the latest version from: www.keysight.com/find/iosuite.
  • Page 27 Do not uninstall the KtMPxiChassis IVI.NET Driver 1.x.xxx, KtMPxiChassis IVI-C Driver 1.x.xxx, KtMTrig IVI.NET Driver 1.x.xxx, or KtMTrig IVI-C Driver 1.x.xxx files without also uninstalling the Keysight PXIe Chassis Family driver. The original M9018A PXIe chassis was provided with its own driver.
  • Page 28: Step 3: Turn On Chassis And Verify Operation

    If you prefer to install the chassis in a rack first, see the Keysight PXIe Chassis Family User Guide rack mounting information. The Keysight Chassis Family has auto-ranging power supplies, meaning that the chassis does not have a voltage selector switch.
  • Page 29: Chassis Power Sequencing

    The method of powering up the chassis depends on the position of the INHIBIT rear panel switch, which can be set to the DEF (default) position or to the MAN (manual) position. These two methods are shown on the interactive block diagram and work as follows: Keysight PXIe Chassis Family Startup Guide...
  • Page 30: Chassis Front Panel Leds

    Use of the ON/Standby push button to power up the chassis is assumed unless otherwise noted. For information on using the Inhibit signal on the rear panel DB-9 connector to power the chassis up and down, see the Keysight PXIe Chassis Family User Guide. Chassis Front Panel LEDs The chassis contains three LEDs on its front panel to the left of the ON/Standby (power) push button, as shown in the following figure.
  • Page 31 See the Keysight the M9010A is 900 RPM limit. multiple M9019A chassis PXIe Chassis Family and for the M9018B and in a system with an SFP Service Guide for M9019A is 1200 RPM. If the fan speed condition causing application running for details.
  • Page 32: Using Keysight Connection Expert

    This, in turn, may cause a thermal shutdown of the power supply. Using Keysight Connection Expert Use Connection Expert (one of the utilities in the Keysight IO Libraries Suite) to confirm that the host controller can connect to the chassis. 1 Start Connection Expert on the host controller.
  • Page 33: Pc Startup Requirements For Keysight Io Libraries Suite

    PC Startup Requirements for Keysight IO Libraries Suite This section describes the PC startup events for Keysight Connection Expert (one of the utilities in the Keysight IO Libraries Suite). Keysight recommends using the latest version Keysight IO Libraries Suit. Two situations exist where Connection Expert, which is part of Keysight IO Libraries Suite, will not display a PCIe device, either the chassis or a module in the chassis.
  • Page 34: Using The Soft Front Panel (Sfp) To Monitor The Chassis

    Independent of whether you plan to run the SFP in Hardware Mode or Simulation Mode, the SFP is started from the Start menu as follows: Start > All Programs > Keysight > PXIe Chassis Family > PXIe Chassis SFP Simulation Mode If no chassis has been detected by Connection Expert, the SFP startup dialog appears as shown in the following image.
  • Page 35: Using The Sfp To Monitor The Chassis

    SFP includes an Allow Control check box that is unchecked by default. The unchecked box prevents any configuration change from being made. In the Keysight PXIe Chassis Family User Guide, which describes how to use the SFP to configure the chassis, this check box will be checked.
  • Page 36 This screen also displays the source of the 10 MHz reference clock and the current PCIe link configuration. For more information, see the Keysight PXIe Chassis Family User Guide.
  • Page 37 For information on configuring these alarms to other than their default thresholds, see the Keysight PXIe Chassis Family User Guide or the PXIe Chassis Family Soft Front Panel Help file.
  • Page 38 Ports tab (default) or Output ports and connect it to one PXI backplane trigger Line (PXI_TRIG[0:7]) PCIe Link none The PCIe link configuration information can be viewed from the Monitor tab of the SFP. Keysight PXIe Chassis Family Startup Guide...
  • Page 39 With the injector/ejector handle in the down position, carefully slide the module to the rear of the chassis. When you begin to feel resistance from the backplane connectors, lift up on the injector/ejector handle to complete insertion of the module. Keysight PXIe Chassis Family Startup Guide...
  • Page 40 The chassis drivers permit interfacing to chassis functionality such as temperature sensors and fan speeds, while your module driver software is required to interface to your particular module. Keysight PXIe Chassis Family Startup Guide...
  • Page 41 Verifying your Module Follow the instructions provided with your module to verify its operation. Module verification typically includes the following steps: - Verify that your module is displayed within the chassis in Keysight Connection Expert as described in “Using Keysight Connection Expert”...
  • Page 42 The following documents are also available on the product website: – Keysight M9022A, M9023A, M9024A PXIe system module Data Sheet – Tested PC and PXI/AXIe Chassis Configurations— This document lists the PCs that have been verified to work with the M9019A chassis. See literature.cdn.keysight.com/litweb/pdf/5990-7632EN.pdf...
  • Page 43 PCIe Host Adapter: dual port (x16), Gen 3 M9021A PCIe Cable Interface Module, single port (x8), Gen 2 (use with M9018A or M9018B only) M9022A PXIe System Interface Module: single port (x8), Gen 3 M9023A PXIe high performance System Interface Module: dual port...
  • Page 44 Keysight PXIe Chassis Family Startup Guide...
  • Page 46 This information is subject to change without notice. © Keysight Technologies, 2018 Printed in Malaysia Edition 3, May 2018 *M9019-90001* M9019-90001 www.keysight.com...
