XGS12 Chassis Platform
Assembly Guide
Version 1.0
Release 8.40 EA,
November 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ixia XGS12 and is the answer not in the manual?

Questions and answers

Related Manuals for Keysight ixia XGS12

Summary of Contents for Keysight ixia XGS12

  • Page 1 XGS12 Chassis Platform Assembly Guide Version 1.0 Release 8.40 EA, November 2017...
  • Page 2 Copyright and Disclaimer Copyright © 2017 Ixia. All rights reserved. This publication may not be copied, in whole or in part, without Ixia's consent. Ixia, the Ixia logo, and all Ixia brand names and product names in this document are either trademarks or registered trademarks of Ixia in the United States and/or other coun- tries.

  • Page 3: Contacting Ixia

    Contacting Ixia Contacting Ixia Corporate Ixia Worldwide Headquarters Web site: www.ixiacom.com 26601 W. Agoura Rd. Headquarters General: info@ixiacom.com Calabasas, CA 91302 Investor Relations: ir@ixiacom.com +1 877 FOR IXIA (877 367 4942) Training: training@ixiacom.com +1 818 871 1800 (International) Support: support@ixiacom.com (FAX) +1 818 871 1805 +1 818 595 2599 sales@ixiacom.com...
  • Page 4 [This page intentionally left blank]...

  • Page 5: Table Of Contents

    Contents Contents Contacting Ixia Introduction XGS12 Chassis Modules Install XGS12 Chassis XGS12 Chassis Installation Precautions Un-pack and Mount the Chassis Remove and Insert Processor Module Remove and Insert Power Supply Module Remove and Insert Fan Module Log on to XGS12 Chassis XGS12 Chassis Platform Assembly Guide, Release 8.40 EA...
  • Page 6 [This page intentionally left blank]...

  • Page 7: Introduction

    Introduction This document describes how to install the XGS12 chassis and its various modules. The XGS12 Chassis is the next generation high performance platform capable of supporting all XM form factor load modules, including full chassis configurations of the Xcellon load modules.
  • Page 8 [This page intentionally left blank]...

  • Page 9: Xgs12 Chassis Modules

    XGS12 Chassis Modules XGS12 Chassis Modules The modules that make up the chassis are as follows: Chassis Frame Module Chassis Fan Module Chassis Power Supply Module Chassis Processor Module The Processor Module is plugged into the front of the chassis, in slot 0. The power supplies and fans are accessible from the rear of the chassis.
  • Page 10 [This page intentionally left blank]...

  • Page 11: Install Xgs12 Chassis

    Install XGS12 Chassis The following sections describe the installation procedure: Un-pack and Mount the Chassis Remove and Insert Processor Module Remove and Insert Power Supply Module Remove and Insert Fan Module XGS12 Chassis Installation Precautions The following precautions should be followed while installing the XGS12 chassis: A two person lift is recommended when installing the chassis into the rack.

  • Page 12: Un-Pack And Mount The Chassis

    Install XGS12 Chassis Figure : XGS12 Rack Screw Mount Locations Un-pack and Mount the Chassis 1. Cut tape and open the carton. 2. Remove accessories box, top foam inserts, and side packing inserts. 3. Lift chassis out of the carton. 4.

  • Page 13: Remove And Insert Processor Module

    Install XGS12 Chassis Figure: XGS12 Mounted on Rack The weight of the chassis components are as follows: Empty chassis with air baffles = 70 lbs Empty chassis without air baffles = 48 lbs 3 power cords = 6 lbs Power supply assembly = 29 lbs Fan Assembly = 10 lbs CPU card = 10 lbs Do not attempt to lift the fully assembled chassis.

  • Page 14: Remove And Insert Power Supply Module

    Install XGS12 Chassis Figure: XGS12 Chassis removing processor module To insert the processor module: 1. Slide the module into the slot. 2. Pinch on the clips and push them in. 3. Fasten the screws. Figure : XGS12 Chassis inserting processor module Remove and Insert Power Supply Module The power supply module is accessible after removing the rear cover.
  • Page 15 Install XGS12 Chassis 1. Loosen the thumbscrew in the upper left corner of the power supply module. 2. Pull the power clamp handles. 3. Hold the two handles provided on the power supply module and pull them. To remove the individual power supplies, 1.
  • Page 16 Install XGS12 Chassis Figure : Inserting Power Supply Module 3. Push the power clamp handles in to lock the busbars in place. Figure : Inserting Power Supply Module 4. Tighten the thumbscrew at the upper left corner of the power supply module. Figure : Inserting Power Supply Module 5.

  • Page 17: Remove And Insert Fan Module

    Install XGS12 Chassis Figure :Inserting Power Supply Module Remove and Insert Fan Module The fan module is located on the rear side of the chassis. For details see Figure : XGS12 Chassis Back View. To remove the fan module: 1. Unfasten the four screws that are present on the edges of the fan module. 2.
  • Page 18 [This page intentionally left blank]...

  • Page 19: Log On To Xgs12 Chassis

    Log on to XGS12 Chassis Log on to XGS12 Chassis The Username for an XGS12 (Windows 7) remote desktop session is ixia and the password is the CPU module serial number found on the sticker located in front of the CPU module. The chassis windows wallpaper is not displayed.
