Keysight AXIe 14-Slot
Chassis M9514A
Site Preparation and
Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M9514A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Keysight M9514A

Summary of Contents for Keysight M9514A

  • Page 1 Site Preparation and Installation Guide Keysight AXIe 14-Slot Chassis M9514A...
  • Page 3 Warranty © Keysight Technologies, Inc. 2014 No part of this manual may be repro- To contact Keysight for sales and techni- THE MATERIAL CONTAINED IN THIS duced in any form or by any means cal support, refer to the support links on DOCUMENT IS PROVIDED “AS IS,”...
  • Page 4 Cautions of the instrument. Keysight Technolo- Cleaning gies assumes no liability for the cus- Clean the outside of the Keysight mod- Do NOT block vents and fan exhaust: tomer's failure to comply with these ule/chassis with a soft, lint-free, To ensure adequate cooling and venti- requirements.
  • Page 5 Standby Power. Unit is not To return unwanted products, contact completely disconnected your local Keysight office, or see from AC mains when This symbol represents the time period www.keysight.com/environment/prod- during which no hazardous or toxic switch is in standby.

  • Page 7: Table Of Contents

    Safety-Related Specifications ........40 A Power Cords Y1235A: Single-phase, no Neutral, 250 VAC, NEMA L6-30P, 2.5M (8.2ft). 43 Y1236A: 3-phase Wye (with Neutral), 240/415 VAC, IEC 60309, 2.5M (8.2ft) Keysight M9514A Site Preparation and Installation Guide...
  • Page 8 (8.2ft) ............45 Y1238A: 3-phase Wye with Neutral, 240/415 VAC, Stripped End, 2.5M (8.2ft) viii Keysight M9514A Site Preparation and Installation Guide...

  • Page 9: Introduction

    Site Preparation and Installation Guide Introduction Thank you for purchasing Agilent's M9514A AXIe 14-slot Chassis. To get you started and to assure a successful and timely installation, we’ve developed this Site Preparation Guide. Please read it carefully and follow all guidelines.

  • Page 10: Plan The Chassis Installation

    Plan the Chassis Installation Plan the Chassis Installation The M9514A can be used as either as a bench top or rack mounted chassis. Consider your anticipated chassis weight (with modules installed), power, noise, ventilation requirements, and rack mounting options to ensure safety and optimize access to test and control instrumentation.

  • Page 11: Chassis Ventilation

    This may overheat and damage components. AC Line Voltage Requirements The M9514A comes prewired for a 3-phase Wye with Neutral configuration for use with 220/380V, 230/400V, and 240/415C AC lines. Please consult Agilent Support if you need otehr power entry configurations.

  • Page 12: Other Considerations

    Networking (LAN). All the necessary software and licensing comes with the chassis but you will need to purchase and install the cabling and associated hardware external to the chassis. Refer to the M9514A and M9521A User Guide for additional information.

  • Page 13: Electrostatic Discharge (Esd) Precautions

    ESD protection. Of the two, only the table-mat and wrist-strap combination provides adequate ESD protection when used alone. To ensure user safety, the static-safe accessories must provide at least 1 M of isolation from ground. Keysight M9514A Site Preparation and Installation Guide...
  • Page 14 Introduction Plan the Chassis Installation Keysight M9514A Site Preparation and Installation Guide...

  • Page 15: Receive And Uncrate The Chassis

    Before unpacking the chassis, carefully inspect the shipping container for any shipping damage. Report any damage to the shipping agent immediately, as such damage is not covered by the warranty. To find warranty information on your M9514A AXIe chassis, go to www.agilent.com/find/warranty and enter your model number (M9514A) in the...

  • Page 16: Uncrate The Chassis

    (this Site Preparation Guide and the M9514A Startup Guide). Lift off the shipping carton. Use a mechanical lift to lift the M9514A and packaging from the base of the shipping carton. While the chassis is still on the mechanical lift, remove the packaging foam and protective plastic from the chassis.
  • Page 17 Refer to the M9514A Startup Guide for information on setting up and using the M9514A chassis. Designed for large system testing, the M9514A provides 14 AXIe slots (1 slot for the AXIe System Module plus 13 instrument module slots). ESD Wrist Strap...
  • Page 18 (refer to “Connecting chassis power-up these handles! Power to the Chassis” synchronization. Do not on page 24 for connect LAN cables to * For detailed information, refer to M9514A and M9521A User Guide Keysight M9514A Site Preparation and Installation Guide...

  • Page 19: Connect The Chassis To The Ac Power Line

    1 These are the AC power cord ratings, not the AC power ratings for the M9514A chassis. The Agilent M9514A chassis AC input is rated to 240 VAC line-to-line. See Appendix A for cord information.

  • Page 20: Mains Disconnect

    200-240 volt circuit . Convenience outlets should be installed near the system for external equipment such as computers and monitors, etc. Locate the outlets within 1 meter (three feet) of the rear of the system. Keysight M9514A Site Preparation and Installation Guide...

  • Page 21: Safety Ground Connection

    Safety ground connection This chassis must be grounded properly for proper operation and safety. Because the M9514A is connected to the AC mains by a plug/socket connection, a permanent earth ground must be supplied to reduce the risk of electric shock.

  • Page 22: Connecting Power To The Chassis

    (E) as the larger diameter pin. Refer to the following diagram: 1 These are the AC power cord ratings, not the AC power ratings for the M9514A chassis. The Agilent M9514A chassis AC input is rated to 240 VAC line-to-line. See Appendix A for cord information.
  • Page 23 Earth Figure 2 IEC 60309 3P+N+E, 6H Red connector. Agilent power cords have female connector shown on left. Male connector on right is on M9514A rear panel The mains wiring and connectors shall be compatible with the connector used in the premise electrical system. Failure to ensure adequate earth ground ing by not using the correct components may cause product damage and serious injury.

  • Page 24: 120 Vac (Low Line)

    - The chassis does not power-up any other modules. - The chassis Soft Front Panel (SFP) will be able to connect to the chassis. - The M9514A ASM SFP or chassis web page will be able to connect to the ASM and show the low voltage level alarm(s) - The chassis web page displays the AC input voltages to the three PSUs.
  • Page 25 120 VAC (Low Line) Connect the Chassis to the AC Power Line PSU1 AC Input Voltage PSU2 AC Input Voltage Figure 3 Normal Line voltage shown on the M9514A Web Page (shows normal AC Line voltage) Keysight M9514A Site Preparation and Installation Guide...
  • Page 26 Connect the Chassis to the AC Power Line 120 VAC (Low Line) The following graphic shows the sensors reading 120VAC. Notice that the voltage lines are now red indicating Lower Non-Recoverable. Figure 4 Sensors reporting 120 VAC operation Keysight M9514A Site Preparation and Installation Guide...

  • Page 27: Rack Mount The Chassis

    Site Preparation and Installation Guide Rack Mount the Chassis Up to three M9514A chassis will fit in a standard (19”) 2 meter rack (such as the Agilent E3662B). Use one option Y1229A Rail Kit for each rack-mounted chassis. All of the major field replaceable units (fan trays, power supplies, etc.) can be replaced while the chassis is installed in a rack.
  • Page 28 (see “Installing Multiple Chassis in a Rack” on page 35) the mechanical lift must be able to raise the chassis to approximately 60” (1.5 meters). Keysight M9514A Site Preparation and Installation Guide...

  • Page 29: Procedure

    Rack Mount the Chassis Procedure The M9514A AXIe chassis has four rubber feet on the bottom of the chassis that must be removed prior to rack mounting. Never lay the chassis on its front or back. Remove all AXIe modules from the chassis before removing the rubber feet.
  • Page 30 Slide clip-on sheet metal nuts over the rack holes to be used by the rack mount flanges. For detailed chassis dimensions, refer to Appendix A in the M9514A Service Guide. Keysight M9514A Site Preparation and Installation Guide...
  • Page 31 Procedure Rack Mount the Chassis 4.125 7.50in. 5.25in. 3.25in. bottom of Clip-on sheet metal chassis to first nuts. Flange mounting holes 4 required for rack Figure 7 Rackmounting the Agilent M9514A AXIe Chassis Keysight M9514A Site Preparation and Installation Guide...

  • Page 32: Space And Airflow Requirements

    60” (1.5 meters). Do not install the chassis upside down in the rack. Slide the M9514A chassis into the rack on the rack rails until the rack mount front handle flanges are against the rack’s vertical columns. Secure the chassis to the rack using the adapter dress screws.

  • Page 33: Installing Multiple Chassis In A Rack

    Rack Mount the Chassis Installing Multiple Chassis in a Rack Up to three M9514A (13U) chassis may be installed in a standard 42U rack. All of the major field replaceable units (fan trays, power supplies, etc.) can be replaced while the chassis is installed in a rack.
  • Page 34 Ensure that the rails are securely installed on the rack. See Figure Support Figure 9 Support rails for three chassis in a rack (left side panel removed for visibility in photo) Keysight M9514A Site Preparation and Installation Guide...

  • Page 35: Additional Information

    PC Additionally, the Software and Product Information CD that ships with your chassis has a PDF file of the M9514A and M9521A User Guide. This guide provides more detailed information about: – Power up / power down modes –...

  • Page 36: Service And Support

    Service and Support Service and Support Do not return the M9514A AXIe chassis to Agilent for service. Any adjustment, maintenance, or repair of this product must be performed by qualified personnel. Contact your Agilent customer engineer through your local Agilent Technologies Service Center.
  • Page 37 Service and Support Additional Information Keysight M9514A Site Preparation and Installation Guide...

  • Page 38: Safety-Related Specifications

    Safety-Related Specifications Safety-Related Specifications This section (next page) provides a partial set of safety-related specifications for the Keysight M9514A AXIe chassis. Complete specifications are included in the Keysight M9514A Data Sheet. CHASSIS CHARACTERISTICS Size 482.6 mm W x 589.7 mm H x 579.1 mm D (19 in W x 23.2 in H x 22.8 in D)
  • Page 39 * Characteristics apply to both M9514A and M9521A unless otherwise noted. † Samples of this product have been type tested in accordance with the Keysight Environmental Test Manual and verified to be robust against the environmental stresses of storage, transportation and end-use; those stresses include but are not limited to temperature, humidity, shock, vibration, altitude, and power line conditions.
  • Page 40 Safety-Related Specifications Keysight M9514A AXIe 14-Slot Chassis...

  • Page 41: A Power Cords

    The Agilent Y1235A, Y1236A, or Y1238A power cords are specifically designed to be used with the M9514A chassis, you do not need to rewire the chassis power terminal block. However, if you are connecting to a 3-phase Delta or Wye without neutral using an Agilent Y1237A power cord, you will need to rewire the chassis power terminal block.

  • Page 42: Y1236A: 3-Phase Wye (With Neutral), 240/415 Vac, Iec 60309, 2.5M (8.2Ft)

    Y1236A: 3-phase Wye (with Neutral), 240/415 VAC, IEC 60309, 2.5M (8.2ft) Splash proof (IP44) IEC 60309 connector Wire Color Brown Black Grey Blue Green/Yellow Figure 11 Y1236A Splash proof (IP44) IEC 60309 connector Keysight M9514A Site Preparation and Installation Guide...
  • Page 43 Splash proof (IP44) IEC 60309 Connector Wire Color Brown Black Grey Green/Yellow Blue Connectio Figure 12 Y1237A Y1238A: 3-phase Wye with Neutral, 240/415 VAC, Stripped End, 2.5M (8.2ft) Wire Color Brown Black Grey Blue Green/Yellow Figure 13 Y1238A Keysight M9514A Site Preparation and Installation Guide...
  • Page 44 Power Cords Keysight M9514A Site Preparation and Installation Guide...
  • Page 45 LAN eXtensions for instruments puts the power of Ethernet and the Web inside your test systems. Keysight is a founding member of the LXI consortium. www.pxisa.org PCI eXtensions for Instrumentation (PXI) modular instrumentation delivers a rugged PC-based high-performance measurement and automation platform.
  • Page 46 This information is subject to change without notice © Keysight Technologies 2014 Edition 2 September 2014 *M9514-90007* M9514-90007 www.keysight.com...
