Controls
Remote Control:
Please refer to the photo. The remote
control supplied with your Vizualogic video system will also
operate the Vizualogic DVD player. (Except DVD Power function).
This section will describe the video system control functions
of the remote control. Please see your DVD Player Owner's Manual
for a description of the DVD controls.
Note: Install (2) AAA batteries (included) into the remote control.
Monitor Power: Press the 'Power' button to illuminate the
LCD screen.
Screen Adjustments: Press the MENU button to select the
desired screen adjustment, then press the up arrow
arrow
to change the setting. Each press of the MENU button
will cycle to the next adjustment.
Screen: Gives you three different options for turning the
screen power on and off. "Screen Off" means you will
have to push the power button to turn on the screen.
"Screen Auto" means the screen will default to the same
power setting that it was left in. If the screen was left on,
then the screen will turn on. If the screen was turned off then
the screen will stay off. "Screen On" means the screen will always
turn on when it receives power.
Contrast: Adjusts the differentiation between light and dark.
Brightness: Adjusts the overall brightness of the LCD display.
Color: Adjusts the intensity of the display colors.
Tint: Adjusts the overall red/green color balance.
Sharpness: Adjusts display sharpness.
Zoom: Changes the aspect ratio of the display. 'Full' is 16:9, Normal is 4:3,
'Cinema' is a zoom-in view of 16:9, 'Wide' is a zoom-out view of 16:9.
Input Select: Press the 'SEL' button to select Input 1, 'AV1' or Input 2, 'AV2'.
Reset Default: Adjusts the screen settings to factory settings.
4
or down

Limited Warranty

ONE YEAR LIMITED WARRANTY
NONTRANSFERABLE
Terms of Warranty
TMI Products, Inc (the Company) warrants to the original retail purchaser, that the auto video product(s) purchased from
a Company authorized installer are free from defects in materials or workmanship under normal use and conditions for a
period of one (1) year from date of purchase, except, the remote control and headphones which are warranted for a
period of sixty (60) days from date of purchase. A sales receipt is required to provide proof of date of purchase.
Should the product(s) be determined defective during the applicable warranty period, the defect(s) will
be repaired or replaced with a new or reconditioned part(s), at the Company's option. To obtain warranty service, the
product(s) must be returned to a Company authorized installer along with proof of warranty coverage.
Exclusions:
This limited warranty excludes:
• Elimination of externally generated static or noise, or the correction of antenna problems or weak television reception.
• Costs incurred for installation, removal or reinstallation of the product(s).
• Damage to tapes, video games, software, camcorders, discs, speakers, accessories or vehicle electrical systems.
• Cosmetic damage or damage due to negligence, misuse, abuse, failure to follow operation instructions, accidental spills
or customer applied cleaners.
• Damage due to environmental causes such as floods, airborne fallout, chemicals, salt, hail, windstorms, lightning or
extreme temperatures.
• Damage due to accidents, road hazards, fire, theft or vandalism.
• Damage due to improper installation or connection, improper connection to equipment of another manufacturer, modi-
fications of existing equipment, use of a faulty tape cartridge or cleaning of the VCR head.
• Product(s) which have been opened or tampered with for any reason or which have been damaged due to alteration or
service performed by anyone other than the Company or a Company authorized installer.
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, THE COMPANY MAKES NO OTHER WARRANTIES, EXPRESSED
OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PUR-
POSE. THE COMPANY EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY IMPLIED
WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS EXPRESSED LIMITED WARRANTY.
Some states do not allow limitation on how long an implied warranty lasts. In such states, the limitations or exclusions of
this Limited Warranty may not apply.
Some states do not allow the exclusion or limitation of incidental or consequential damages. In such states, the exclusion
or limitation of this Limited Warranty may not apply to you. This Limited Warranty gives you specific legal rights and you
may have other rights, which vary from state to state.
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, THE COMPANY MAKES NO OTHER WARRANTIES, EXPRESSED
OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. THE COMPANY EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY
IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS EXPRESSED
LIMITED WARRANTY.
9
