Mains electricity
230 V/50 Hz
Standby power
0.3 W
External operating temperature
-20 to +35 °C
Dimensions
46x46x18 mm
Load type
Trailing edge
Leading edge
Protection
Overtemperature software
Overtemperature hardware
Overload software
Radio
2.4 GHz mesh
Bluetooth
®
<10 dBm
Radio range
Approx. 10 m indoors
The Plejd mesh technology extends the range by
allowing the units to communicate with each other.
RISK OF INJURY TO PERSON OR PROPERTY
All work on the appliance must be carried out by
an authorized electrician. National laws and
regulations must be followed.
Compliant to standards
Hereby, Plejd AB declares that the radio
equipment type DIM-02 is in compliance
with Directive 2014/53/EU.
The full text of the EU declaration of
conformity is available at the following
internet address: plejd.com/compliance
Plejd AB, Krokslätts Fabriker 27A
431 37 Mölndal, Sweden
Important information
Do not use the product if it has visible signs
of damage.
Disposal and recycling
This electrical product should not be disposed
of together with other household waste. Contact
your local recycling center for guidance on
electrical and electronic equipment disposal.
EN
D I M - 0 2
INSTALLATION MANUAL
Further information can be found
in the Plejd app or at plejd.com
