TRUCK MOUNTED CRANE USER MANUAL
Model:GZB80263-1100-12V
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands
.

Advertisement

loading
Need help?

Need help?

Do you have a question about the GZB80263-1100-12V and is the answer not in the manual?

Questions and answers

Related Manuals for VEVOR GZB80263-1100-12V

Summary of Contents for VEVOR GZB80263-1100-12V

  • Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support TRUCK MOUNTED CRANE USER MANUAL Model:GZB80263-1100-12V We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
  • Page 3 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.

  • Page 4: General Safety Rules

    1. Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. 2. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. GENERAL SAFETY RULES 1. Never overload. 2. The load is maximum when the arm of the product is adjusted to the shortest.The load of the product decreases as the arm increases.
  • Page 5 area under and around the lifted cargo. When operating the Crane, stay clear of the area between the Crane and the load. 12. Before each use, inspect the Crane, the Long Ram Jack and the Chain and Hook for damage, corrosion and any other condition that might affect the safe performance of this product.

  • Page 6: Structure Diagram

    MODEL AND PARAMETERS GZB80263-1100-12V Model Bracket Capacity Max. 1100lbs Hoisting Height 107~245cm Electric Winch Max. 4500lbs， DC12V 1.1KW Rotation Angle 360 degree Material Powder-coated Steel STRUCTURE DIAGRAM 1. Electric Winch 2. Telescopic Boom 3. Hook 4. Movable Boom 5. Rotating head 6.
  • Page 7 COMPONENTS Q’ty of Name Picture GZB80263-1100- Electric winch M8*60 M8*16 - 5 -...
  • Page 8 Φ20*85 Φ16*65 Φ8 Remote Control Control Box Wired Controller - 6 -...
  • Page 9 ASSEMBLY Step 1: Install the upright rod(A) on the strong truck floor and lock it with bolts and nuts(G). Step 2: Slowly slip the rotating head(B) onto the upright rod; Locking the long screw can make the rotating head(B) not rotate. - 7 -...
  • Page 10 Step 3: Install the movable boom(C).Connect B and C with two pins(I), and the pin end is stuck into the cotter pin. Note:The rotating head(B) has three holes(X1, X2, X3) for adjusting angles. The movable boom(C) can rotate around O to adjust the angle. Step 4: Insert the telescopic boom(D) into the movable boom(C) ,then connect with a pin(J).
  • Page 11 Step 5: Install the electric winch,and lock it with bolts and nuts(H+K). Remove the limit pin at P,open the electric winch clutch, pull out the hook, place the steel wire into the pulley groove, reinstall the limit pin(E), as shown below. Electric Winch operation: WARNING: The electric winch is a very powerful machine.
  • Page 12 2. Inspect wire rope and equipment frequently. A frayed wire rope with broken strands should be replaced immediately. 3. Use heavy leather gloves when handling wire rope. Do not let wire rope slide through your hands. 4. Never winch with less than 5 turns of wire rope around the winch drum since the wire rope end fastener may NOT withstand the full load.

  • Page 13: Maintenance

    MAINTENANCE 1. Fr equently check the condition of the truck mounted crane. 2. Do not use the damaged crane. 3. Make sure all components are in good condition. If the crane or receiver hitch becomes damaged by an accident or any other type of damage is noted, it should be replaced.

  • Page 14: Troubleshooting

    TROUBLE SHOOTING Symptoms Possible Causes Corrective Action 1.Switch inoperative 1.Replace switch The motor does not turn 2.Broken wires or bad 2.Check for poor connections connection 3.Replace or repair the motor 3.Damaged motor 1.Let the winch cool down 1.Long period of operation The motor runs periodically.
  • Page 16 TechnicalSupport and E-Warranty Certificate www.vevor.com/support...
